User Manual

YOYORouter
Mobile Travel Router EE1
Versatile multi-function router with Wi-Fi, Ethernet
and USB Modem support
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YOYORouter EE1 and is the answer not in the manual?

Questions and answers

Related Manuals for YOYOMOTION YOYORouter EE1

Summary of Contents for YOYOMOTION YOYORouter EE1

  • Page 1: Copyright

    User Manual YOYORouter Mobile Travel Router EE1 Versatile multi-function router with Wi-Fi, Ethernet and USB Modem support...

  • Page 2: Fcc Interference Statement

    Copyright The contents of this publication may not be reproduced in any part or as a whole, stored, transcribed in an information retrieval system, translated into any language, or transmitted in any form or by any means, mechanical, magnetic, electronic, optical, photocopying, manual, or otherwise, without the prior written permission.

  • Page 3: Table Of Contents

    Setting up YOYORouter EE1 in Wireless WAN Mode ....11 2.6. Setting up YOYORouter EE1 in Ethernet WAN Mode....13 2.7. Setting up YOYORouter EE1 in Ethernet WAN Mode with Failover 2.8. Setting up YOYORouter EE1 in Share Mode....... 16 2.9.
  • Page 4 3.2.4.4. SNMP ..................55 3.2.4.5. Routing ..................56 3.2.4.6. System Time ................57 3.2.4.7. Scheduling .................. 58 3.2.5. Tool Box ..................59 3.2.5.1. System Info ................. 59 3.2.5.2. Firmware Upgrade..............60 3.2.5.3. Backup Setting................60 3.2.5.4. Reset to Default ................60 3.2.5.5.

  • Page 5: Chapter 1 Introduction

    Internet access beyond his home and office The Quick-Start Guide shows how to get up and running with the YOYORouter EE1. This User Guide provides in-depth instructions to use all of the features.

  • Page 6: Led Indicators

    1.3. LED indicators Battery and Power status Battery is fully charged (power on) Battery is powering the router Battery is on charge or no battery is installed Battery low Battery is fully charged (charger connected and power switch off) Wi-Fi Status Wi-Fi (WLAN) is on Data transfer over Wi-Fi Fast flash denotes WPS mode...

  • Page 7: Getting Started

    2. Getting Started 2.1. Operating Modes YOYORouter EE1 has four operating modes to keep you connected via cabled Ethernet WAN (Wide Area Network), Wireless WAN (Mobile Broadband) or Wi-Fi hotspot sharing: Wireless WAN (Mobile Broadband) Mode Make a Mobile Broadband connection using LTE/HSPA/HSDPA/UMTS/EDGE/GPRS via a USB modem (USB dongle) plugged in to YOYORouter EE1.

  • Page 8: Preparing Yoyorouter Ee1

    YOYORouter can be located in, for example, a window, providing better signal strength without moving your laptop or other devices. 2.2. Preparing YOYORouter EE1 1. Open the battery compartment Slide the cover in the direction shown until it clicks open.
  • Page 9 4. Connect the power cord and plug in the AC adaptor. 5. Turn on YOYORouter EE1.

  • Page 10: Connecting To Yoyorouter Ee1

    2.3. Connecting to YOYORouter EE1 Select YOYORouter’s Wi-Fi network which has a network name (SSID) like YOYORouter-07-76. The network name and network password are printed on a label in the battery compartment and on the box. For example, in Windows 7 Click the icon in the notification area.

  • Page 11: Setting Up Yoyorouter Ee1 In Wireless Wan Mode

    1. Make sure your SIM card is installed in the USB modem. Consult the USB Modem’s documentation for further information. 2. Plug in your USB Modem and turn on YOYORouter EE1. Allow at least 60 seconds for the USB modem to be detected and configured.
  • Page 12 6. At the end of the Wizard, check The Ethernet Port will be set as LAN Port and click Apply Settings. YOYORouter restarts. 7. If you are connecting using Wi-Fi, you may need to re-make the connection in line with your new settings.

  • Page 13: Setting Up Yoyorouter Ee1 In Ethernet Wan Mode

    2.6. Setting up YOYORouter EE1 in Ethernet WAN Mode 1. Plug in the Ethernet cable and switch on YOYORouter EE1. Typical WAN sources include ADSL modems, cable modems and hotel/office cabled Internet connections. 2. Connect to YOYORouter via Wi-Fi, access the status page at and log in.
  • Page 14 2.7. Setting up YOYORouter EE1 in Ethernet WAN Mode with Failover First configure YOYORouter EE1 in Wireless WAN Mode and test the connection. Next, configure YOYORouter EE1 in Cable and test the connection. To enable WAN Mode with Failover, ensure that the USB Modem and Ethernet WAN are both connected and follow these steps: 1.
  • Page 15 8. Unplug the cabled WAN plug and check that Failover occurs: 3G Failover indicated in System Status. Wireless Modem indicates Connected. 9. Re-connect the cabled WAN and check that service reverts to the WAN connection.

  • Page 16: Setting Up Yoyorouter Ee1 In Ethernet Wan Mode With Failover

    2.8. Setting up YOYORouter EE1 in Share Mode 1. Switch on YOYORouter EE1. 2. Connect to YOYORouter via Wi-Fi or Ethernet, access the status page at http://192.168.1.1 log in. 3. Select Wizard. Click through the Wizard making any changes to the default settings if necessary.

  • Page 17: Wi-Fi Configuration Tips

    2.9. Wi-Fi Configuration Tips YOYORouter is pre-configured with a default Wi-Fi network name (SSID) and password. The network name and password are printed on the label on the underside of the device and on the label affixed to the carton in which it was packaged. Security is set to WPA-PSK(TKIP) and WPA2-PSK(AES) –...

  • Page 18: Configuration Reference Guide

    3. Configuration Reference Guide 3.1. Using the Setup Wizard 3.1.1. Starting the Wizard Please type in the IP Address (http://192.168.1.1) Please type “admin” in the Password and click the Login button. Select your language. Press “Next” to start the Setup Wizard.

  • Page 19: Configure Settings Using The Wizard

    3.1.2. Configure Settings using the Wizard Step 1. Change System Password. Set up your system password. (Default admin) Step 2a. Select LAN IP Address and Wan Type. Step 2b. 3G WAN type Select “Auto Detection” Dial-up Profile, and the Utility will try to detect and configure the required Mobile Broadband service settings...
  • Page 20 Step 3a. Set up your Wireless Network. Set up your Wi-Fi network name (SSID). Channel Auto (default enables the router to identify the best channel. If you wish to manually select the channel, typically 1, 6 or 11, pick it in the drop-down menu.
  • Page 21 Step 5. Click Finish to close the Wizard. Note: The router has already restarted.

  • Page 22: Advanced Settings

    3.2.Advanced Settings Whenever you want to configure your network or this device, you can access the Configuration Menu by opening the web-browser and typing in the IP Address of the device. The default IP Address is: 192.168.1.1 Enter the default password “admin” in the System Password and then click ‘login’ button. Then, you can browse the “Advanced”...

  • Page 23: Network Setup

    3.2.1.1.Network Setup Ethernet port Configuration: Off: Disable the Ethernet port. LAN: The Ethernet port is as LAN port. WAN: The Ethernet port is as LAN port. Auto: It will be WAN Port if a DHCP server can be detected on the Ethernet port. Otherwise, it will be LAN port.
  • Page 24 A. 3G This device supports different WAN types of connection for users to connect to remote wireless ISP, such as 3G (WCDMA, HSxPA, HSPA+, CDMA2000, EV-DO, TD-SCDMA), iBurst, or Wi-Fi Hotspot. Note. Users need to insert USB modem card for 3G and iBurst WAN connections. 3G WAN Types: The WAN fields may not be necessary for your connection.
  • Page 25 Account: Enter the new User Name for your PC card here, you can contact to your ISP to get it. Password: Enter the new Password for your PC card here, you can contact to your ISP to get it. 10. Authentication: Choose your authentication. 11.
  • Page 26 B. Static IP Address: Activate WWAN for Auto-Failover: With this function enabled, when the Ethernet WAN connection is broken, the device will automatically activate the WWAN connection and keep you connected to internet with the alternative WWAN broadband service. Meanwhile, if the device detected that the Ethernet WAN connection is recovered, your broadband connection will be switched to use the Ethernet WAN service.
  • Page 27 C. Dynamic IP Address: : With this function enabled, when the Ethernet WAN Activate WWAN for Auto-Failover connection is broken, the device will automatically activate the WWAN connection and keep you connected to internet with the alternative WWAN broadband service. Meanwhile, if the device detected that the Ethernet WAN connection is recovered, your broadband connection will be switched to use the Ethernet WAN service : Optional, required by some ISPs, for example, @Home.
  • Page 28 D. PPP over Ethernet Activate WWAN for Auto-Failover: With this function enabled, when the Ethernet WAN connection is broken, the device will automatically activate the WWAN connection and keep you connected to internet with the alternative WWAN broadband service. Meanwhile, if the device detected that the Ethernet WAN connection is recovered, your broadband connection will be switched to use the Ethernet WAN service PPPoE Account and Password: The account and password your ISP assigned to you.
  • Page 29 E. PPTP : With this function enabled, when the Ethernet WAN Activate WWAN for Auto-Failover connection is broken, the device will automatically activate the WWAN connection and keep you connected to internet with the alternative WWAN broadband service. Meanwhile, if the device detected that the Ethernet WAN connection is recovered, your broadband connection will be switched to use the Ethernet WAN service : Please check the IP mode your ISP assigned, and select “Static IP Address”...
  • Page 30 Auto Reconnect (Always-on): The device will link with ISP until the connection is established. Manu ally: The device will not make the link until someone clicks the connect-button in the Status-page. 9. Maximum Transmission Unit (MTU): Most ISP offers MTU value to users. The default MTU value is 0 (auto).
  • Page 31 F. L2TP 1. Activate WWAN for Auto-Failover: With this function enabled, when the Ethernet WAN connection is broken, the device will automatically activate the WWAN connection and keep you connected to internet with the alternative WWAN broadband service. Meanwhile, if the device detected that the Ethernet WAN connection is recovered, your broadband connection will be switched to use the Ethernet WAN service 2.
  • Page 32 7. Maximum Idle Time: The time of no activity to disconnect your L2TP session. Set it to zero or enable “Auto-reconnect” to disable this feature. If Auto-reconnect is enabled, this device will connect with ISP automatically, after system is restarted or connection is dropped.
  • Page 33 G. iBurst iBurst Type: The WAN fields may not be necessary for your connection. The information on this page will only be used when your service provider requires you to enter a User Name and Password to connect with the iBurst network. Please refer to your documentation or service provider for additional information.
  • Page 34 Primary DNS/Secondary DNS: Optional, This feature allows you to assign a DNS Servers Connection Control: There are 3 modes to select: Connect-on-demand: The device will link up with ISP when the clients send outgoing packets. Auto Reconnect (Always-on): The device will link with ISP until the connection is established.
  • Page 35 H. Wi-Fi HotSpot Wi-Fi HotSpot Types: This WAN type allows you to share one Wi-Fi Hotspot account with your friends or colleagues. Local clients connect to this device via Wi-Fi connection, and surfing Internet by connecting to remote Wi-Fi Hotspot. Just follow a few steps below to connect to remote Wi-Fi HotSpot.
  • Page 36 Step 3: Click “Save” button to save settings after selecting. There will be a field here for you to input encryption key if remote Wi-Fi Hotspot or Wi-Fi AP requires. Step 4: Click “Reboot” button to restart device to take new settings effective.

  • Page 37: Dhcp Server

    3.2.1.2.DHCP Server 1. DHCP Server: Choose either Disable or Enable. If you enable the DHCP Server function, the following settings will be effective. 2. IP Pool Starting/Ending Address: Whenever there is a request, the DHCP server will automatically allocate an unused IP address from the IP address pool to the requesting computer.
  • Page 38 Press “Fixed Mapping” and the DHCP Server will reserve the special IP for designated MAC address.

  • Page 39: Wireless Settings

    3.2.1.3.Wireless Settings Wireless settings allow you to set the wireless configuration items. 1. Wireless Module: You can enable or disable wireless function. 2. Network ID (SSID): Network ID is used for identifying the Wireless LAN (WLAN). Client stations can roam freely over this device and other Access Points that have the same Network ID.
  • Page 40 Open Open system authentication simply consists of two communications. The first is an authentication request by the client that contains the station ID (typically the MAC address). This is followed by an authentication response from the AP/router containing a success or failure message. An example of when a failure may occur is if the client's MAC address is explicitly excluded in the AP/router configuration.
  • Page 41 WPA-PSK/WPA-PSK2 Another encryption options for WPA-PSK-TKIP and WPA-PSK2-AES, the others are same the WPA-PSK. WPA/WPA2 Another encryption options for WPA-TKIP and WPA2-AES, the others are same the WPA. By pressing “WPS Setup”, you can configure and enable the easy setup feature WPS (Wi-Fi Protection Setup) for your wireless network.

  • Page 42: Change Password

    3.2.1.4.Change Password You can change the System Password here. We strongly recommend you to change the system password for security reason. Click on “Save” to store your settings or click “Undo” to give up the changes.

  • Page 43: Forwarding Rules

    3.2.2. Forwarding Rules 3.2.2.1.Virtual Server This product’s NAT firewall filters out unrecognized packets to protect your Intranet, so all hosts behind this product are invisible to the outside world. If you wish, you can make some of them accessible by enabling the Virtual Server Mapping. A virtual server is defined as a Service Port , and all requests to this port will be redirected to the computer specified by the Server IP.

  • Page 44: Special Ap

    Service Port Server IP Enable 192.168.1.1 192.168.1.2 1723 192.168.1.6 Click on “Save” to store your settings or click “Undo” to give up the changes. 3.2.2.2.Special AP Some applications require multiple connections, like Internet games, Video conferencing, Internet telephony, etc. Because of the firewall function, these applications cannot work with a pure NAT router.

  • Page 45: Miscellaneous

    3.2.2.3. Miscellaneous 1. IP Address of DMZ Host DMZ (Demilitarized Zone) Host is a host without the protection of firewall. It allows a computer to be exposed to unrestricted 2-way communication for Internet games, Video conferencing, Internet telephony and other special applications. 2.

  • Page 46: Security Setting

    3.2.3. Security Setting 3.2.3.1.Packet Filters Packet Filter includes both outbound filter and inbound filter. And they have same way to setting. Packet Filter enables you to control what packets are allowed to pass the router. Outbound filter applies on all outbound packets. However, inbound filter applies on packets that destined to Virtual Servers or DMZ host only.
  • Page 47 You can specify 8 rules for each direction: inbound or outbound. For each rule, you can define the following: Source IP address Source port Destination IP address Destination port Protocol: TCP or UDP or both. Use Rule# For source or destination IP address, you can define a single IP address (4.3.2.1) or a range of IP addresses (4.3.2.1-4.3.2.254).

  • Page 48: Domain Filters

    3.2.3.2.Domain Filters Domain Filter prevents users under this device from accessing specific URLs. : Check if you want to enable Domain Filter. 1. Domain Filter : Check if you want to log the action when someone accesses the specific 2. Log DNS Query URLs.

  • Page 49: Url Blocking

    3.2.3.3.URL Blocking will block LAN computers to connect with pre-define Websites. The major URL Blocking difference between “Domain filter” and “URL Blocking” is Domain filter require user to input suffix (like .com or .org, etc), while URL Blocking require user to input a keyword only. In other words, Domain filter can block specific website, while URL Blocking can block hundreds of websites by simply a keyword .

  • Page 50: Mac Control

    3.2.3.4.MAC Control MAC Address Control allows you to assign different access right for different users and to assign a specific IP address to a certain MAC address. : Check “Enable” to enable the “MAC Address Control”. All of the MAC Address Control settings in this page will take effect only when “Enable”...

  • Page 51: Miscellaneous

    3.2.3.5. Miscellaneous 1. Administrator Time-out: The time of no activity to logout automatically, you may set it to zero to disable this feature. 2. Remote Administrator Host/Port In general, only Intranet user can browse the built-in web pages to perform administration task.

  • Page 52: Advanced Setting

    3.2.4. Advanced Setting 3.2.4.1.System Log This page support two methods to export system logs to specific destination by means of syslog (UDP) and SMTP(TCP). The items you have to setup including:...

  • Page 53: Dynamic Dns

    : Host IP of destination where sys log will be sent to. Check 1. IP Address for Sys log to enable this function. Enable : Check if you want to enable Email alert (send syslog via email). 2. E-mail Alert Enable : Input the SMTP server IP and port, which are connected with 3.

  • Page 54: Qos

    3.2.4.3.QOS Provide different priority to different users or data flows, or guarantee a certain level of performance. 1. QOS Control: Check Enable to enable this function. 2. Bandwidth of Upstream: Set the limitation of upstream bandwidth 3. Local IP : Ports: Define the Local IP address and ports of packets 4.

  • Page 55: Snmp

    3.2.4.4.SNMP In brief, SNMP, the Simple Network Management Protocol, is a protocol designed to give a user the capability to remotely manage a computer network by polling and setting terminal values and monitoring network events. : You must check “Local”, “Remote” or both to enable SNMP function. If 1.

  • Page 56: Routing

    3.2.4.5.Routing If you have more than one routers and subnets, you will need to enable routing table to allow packets to find proper routing path and allow different subnets to communicate with each other. The routing table allows you to determine which physical interface address to use for outgoing IP data grams.

  • Page 57: System Time

    3.2.4.6.System Time 1. Time Zone: Select a time zone where this device locates. 2. Auto-Synchronization: Check the “Enable” checkbox to enable this function. Besides, you can select a NTP time server to consult UTC time. 3. Sync with Time Server: Click on the button if you want to set Date and Time by NTP Protocol manually.

  • Page 58: Scheduling

    3.2.4.7.Scheduling You can set the schedule time to decide which service will be turned on or off. 1. Schedule: Check to enable the schedule rule settings. 2. Add New Rule: To create a schedule rule, click the “Add New Rule” button. You can edit the Name of Rule, Policy, and set the schedule time (Week day, Start Time, and End Time).

  • Page 59: Tool Box

    3.2.5. Tool Box 3.2.5.1.System Info You can view the System Information and System log, and download/clear the System log, in this page.

  • Page 60: Firmware Upgrade

    3.2.5.2.Firmware Upgrade You can upgrade firmware by clicking “Upgrade” button. 3.2.5.3.Backup Setting You can backup your settings by clicking the “Backup Setting” function item and save it as a bin file. Once you want to restore these settings, please click Firmware Upgrade button and use the bin file you saved.

  • Page 61: Reboot

    3.2.5.5.Reboot You can also reboot this device by clicking the Reboot function item. 3.2.5.6.Miscellaneous Domain Name or IP address for Ping Test Allow you to configure an IP, and ping the device. You can ping a specific IP to test whether it is alive.

  • Page 62: Troubleshooting

    4. Troubleshooting This Chapter provides solutions to problems for the installation and operation of the YOYORouter. You can refer to the following if you are having problems. 4.1. Basic Problems YOYORouter does not switch on – indicator lights all off The battery may be fully discharged –...
  • Page 63 The default network password is printed on the device label and on the label affixed to the carton in which the device was packaged. If these labels are missing or damaged: Contact YOYOMotion. If possible please supply the MAC address, serial number or IMEI of the device in question.

  • Page 64: Problems With The Mobile Broadband Connection

    pages By default the configuration pages are reached by opening the browser on a connected device and selecting 192.168.1.1 If you previously changed the IP address range, for example to 192.168.123.254, you must use this address to access the configuration pages If you changed the IP address and no longer know the new setting, you should perform a factory re-set and then reconfigure your YOYORouter.
  • Page 65 * indicates mandatory items. In most cases only APN is needed; DNS is rarely required. Note: the number to dial is *99# I have set up my PIN code but YOYORouter still cannot connect If your SIM has a PIN code, the configuration wizard may not have been able to detect the settings for the mobile operator.

  • Page 66: Other Problems

    My USB Modem has a microSD Card slot. Can I access the card via YOYORouter EE1? Sorry, YOYORouter does not support this feature.

  • Page 67: Appendix A Licensing Information

    Appendix A Licensing information This product includes copyrighted third-party software licensed under the terms of the GNU General Public License. Please refer to the GNU General Public License below to check the detailed terms of this license. The following parts of this product are subject to the GNU GPL, and those software packages are copyright by their respective authors.

  • Page 68: Gnu General Public License

    GNU GENERAL PUBLIC LICENSE Version 2, June 1991 Copyright (C) 1989, 1991 Free Software Foundation, Inc. 59 Temple Place, Suite 330, Boston, MA 02111-1307 USA Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed. Preamble The licenses for most software are designed to take away your freedom to share and change it.
  • Page 69 GNU GENERAL PUBLIC LICENSE TERMS AND CONDITIONS FOR COPYING, DISTRIBUTION AND MODIFICATION 0. This License applies to any program or other work which contains a notice placed by the copyright holder saying it may be distributed under the terms of this General Public License. The "Program", below, refers to any such program or work, and a "work based on the Program"...
  • Page 70 3. You may copy and distribute the Program (or a work based on it, under Section 2) in object code or executable form under the terms of Sections 1 and 2 above provided that you also do one of the following: a) Accompany it with the complete corresponding machine-readable source code, which must be distributed under the terms of Sections 1 and 2 above on a medium...
  • Page 71 It is not the purpose of this section to induce you to infringe any patents or other property right claims or to contest validity of any such claims; this section has the sole purpose of protecting the integrity of the free software distribution system, which is implemented by public license practices.
