ViewSonic G90fB-4 Service Manual page 7

19” digital controlled color monitor
Hide thumbs Also See for G90fB-4:
Table of Contents

Advertisement

10. Video Bandwidth: 240 MHz
11. Power Source:
Switching Mode Power Supply
AC 90 ~264V, 50/60Hz Universal Type
12. Operating Temperature: 0°C to 40°C Ambient
13. Humidity: 5% to 95% Relative, Non-Condensing
14. Weight: 18.0 kgs / 39.7 (lbs) (Net), 21.2 kgs / 46.7 (lbs) (Gross)
15. Dimensions
Width:
Height:
Depth:
16. External Connection:
15 Pin D-sub Connector
AC Power Cord
17. Power Consumption Modes :
ON Mode < 75Watts
Sleep < 4Watts
Off < 2W (Power switch off)
18. Regulatiory/Safety
North America
Regulatory Filing
WW
International
ViewSonic Corporation
Machine
445 mm
424 mm(378mm w/o Base)
465 mm
Regulatory filing should be made under the
"VS10794".
UL60950, cUL60950 or CSA 22.2; DHHS Part 21,
Subpart J X-Ray Protection; FCC, Part 15, Subpart
J, Subpart B;ICES-003, Class B; NOM; Argentina –
TUV/S
CB,
BSMI,CCC,PSB,CE,GOST-R;ISO9241-3
(covered in TUV-ergo)
Package
540 mm
530 mm
570 mm
TCO03
(Black);TUV/GS,
Confidential - Do Not Copy
4
TUV/Ergo,
7
8
G90fB-4
