Panasonic SA-AK640E Service Manual

Cd stereo system
Hide thumbs Also See for SA-AK640E:
Table of Contents

Advertisement

Quick Links

Notes: This model's CD mechanism changer unit is CRS1. Please refer to the original Service Manual
(Order No. MD0509368C0) for this mechanism.

Specifications

n AMPLIFIER SECTION
RMS output power
THD 10%,
1 kHz
(Low channel-both channels driven)
10 kHz
(High channel-both channels driven)
60 Hz
(Subwoofer channel)
Total output power
n FM/AM TUNER, TERMINALS SECTION
Preset station
Frequency Modulation (FM)
Frequency range
Sensitivity
S/N 26dB
Antenna terminal(s)
Amplitude Modulation (AM)
Frequency range
Sensitivity
S/N 20dB (at 999 kHz)
90 W per channel (3 Ω)
90 W per channel (3 Ω)
180 W (8 Ω)
FM 15 stations
AM 15 stations
87.50 to 108.00 MHz (50 kHz steps)
4.0 µV (IHF)
75 Ω (unbalanced)
522 to 1629 kHz (9 kHz step)
560 µV/m
SA-AK640E
SA-AK640EB
SA-AK640EG
Colour
(S)... Silver Type
Music Port input jack
Terminal
Sensitivity
Phone jack
Terminal
n CASSETTE DECK SECTION
Track system
Heads
Record/playback
Erasure
Motor
540 W
Recording system
Erasing system
Tape speed
Overall frequency response (+3, -6 dB) at DECK OUT
NORMAL
S/N ratio
Wow and flutter
Fast forward and rewind time
2.2 µV
n DISC SECTION
Disc played [8 cm or 12 cm]
(1) CD-Audio (CD-DA)
(2) CD-R/RW (CD-DA, MP3, WMA formatted disc)
(3) MP3/WMA
© 2006 Matsushita Electric Industrial Co. Ltd.. All
rights
distribution is a violation of law.
ORDER NO. MD0601012C2
CD Stereo System
Stereo, 3.5 mm jack
Stereo, 3.5 mm jack
4 track, 2 channel
Solid permalloy head
Double gap ferrite head
AC bias 100 kHz
AC erase 100 kHz
35 Hz to 14 kHz
50 dB (A weighted)
0.18 % (WRMS)
Approx. 120 seconds with
C-60 cassette tape
reserved.
Unauthorized
100 mV, 4.7 kΩ
DC servo motor
4.8 cm/s
copying
and
