PRODUCT DATA
MODEL
WEIGHT
NOMINAL HEAT OUTPUT
Firebelly Stoves Ltd, Unit 16, Upper Mills, Slaithwaite, Huddersfield, West Yorkshire, HD7 5HA, UK
FB2 DS
100KG
12KWs
CONTENTS
OPERATING INSTRUCTIONS
Lighting the fire
Firebox linings and baffle
Wood burning tips & theory
Running temperatures
Cleaning and Maintenance
INSTALLATION INSTRUCTIONS
Building regulations
Positioning and Clearances
Chimney
Flue connection

Problem solving

www.firebellystoves.com sales@firebellystoves.com
2
2
2
3
3
4
4
4
5
6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FB2 DS and is the answer not in the manual?

Questions and answers

Summary of Contents for Firebelly FB2 DS

  • Page 1: Problem Solving

    Firebox linings and baffle Wood burning tips & theory Running temperatures Cleaning and Maintenance INSTALLATION INSTRUCTIONS Building regulations Positioning and Clearances Chimney Flue connection Problem solving Firebelly Stoves Ltd, Unit 16, Upper Mills, Slaithwaite, Huddersfield, West Yorkshire, HD7 5HA, UK www.firebellystoves.com sales@firebellystoves.com...
  • Page 2: Operating Instructions

    Operating Instructions Building regulations Installation of the Firebelly woodburning stove must comply with all local building regulations, including those referring to national and European standards. It is a good idea to consult your local chimney sweep to check the suitability of the chinmney and ensure there is adequate updraft and suggest any remedies to potential chimney problems.
  • Page 3 Notes on woodburning Wood burns most efficiently when the air for combustion is supplied from above the fire bed rather than below. The air supplied above the fire bed provides the oxygen necessary for the volatile gases (smoke), given off by the wood as it heats, to combust. This ensures that the gases are burnt and used to heat the appliance instead of being wasted up the chimney or condensing and forming tarry deposits inside the stove, the flue pipe or on the door glass.
  • Page 4 The high temperature paint finish normally requires no treatment. Any damage or wear to small areas of the paint finish may be remedied using STOVEBRIGHT’s high temperature aerosol paint (colour ‘charcoal’, available from stove shops and from Firebelly). Make sure the stove is cold and read the instructions on the can carefully before applying the paint.
  • Page 5 Installation Building regulations Installation of the Firebelly woodburning stove must comply with all local building regulations, including those referring to national and European standards. It is a good idea to consult your local chimney sweep to check the suitability of the chinmney and ensure there is adequate updraft and suggest any remedies to potential chimney problems.
  • Page 6 Operational problems Blackened glass • The wood is too damp. Only use wood stored for at least 12 months under cover and with a moisture level not exceeding 20% RH. • Insufficient intake of air from the top air control. Open the top air control further. The air shield system is more efficient the more air is allowed to run over the glass panel.
  • Page 7 These include: Glass & Door rope seal & Fire Brick linings Firebelly Stoves Ltd, Unit 16, Upper Mills, Slaithwaite, Huddersfield, West Yorkshire, HD7 5HA, UK www.firebellystoves.com sales@firebellystoves.com...

This manual is also suitable for:

Fb1 ds
