RIM 802D Integrator Manual

Hide thumbs Also See for 802D:
Table of Contents

Advertisement

Quick Links

Download this manual
RIM 802D Radio Modem
Integrator Guide
Version 2.5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 802D and is the answer not in the manual?

Questions and answers

Related Manuals for RIM 802D

Summary of Contents for RIM 802D

  • Page 1 RIM 802D Radio Modem Integrator Guide Version 2.5...
  • Page 2 © 1999-2001 Research In Motion Limited. All rights reserved. Research In Motion, RIM, the RIM logo, RAP and RIM 802D are trademarks of Research In Motion Limited. RIM, Research In Motion - Registered in the U.S. Patent and Trademark Office and registered in other countries.
  • Page 3 Research In Motion (RIM). In the event that you enter into a binding legal agreement with RIM, all provisions contained in such binding legal agreement shall apply, regardless of whether such provisions conflict with information contained herein.

  • Page 5: Fcc Compliance Statement

    FCC compliance statement FCC Class B Part 15 This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation.
  • Page 6 FCC compliance statement The Integrator of the RIM 802D Radio Modem is solely responsible for obtaining all necessary government approvals, including but not limited to, Electromagnetic Compatibility (EMC) compliance and applicable radio frequency radiation exposure evaluations, such as Specific Absorption Rate (SAR), Environmental Assessment (EA), and...

  • Page 7: Industry Canada Certification

    This device complies with Industry Canada RSS 119, under certification number 2503195603A. IC Class B compliance This device complies with the Class B limits for radio noise emissions as set out in the interference-causing equipment standard entitled “Digital Apparatus,” ICES-003 of Industry Canada. RIM 802D Radio Modem Integrator Guide...

  • Page 9: Table Of Contents

    Contents FCC compliance statement ..........5 Industry Canada certification .........7 Chapter 1 Introduction...............11 Radio performance ................12 DataTAC network technology ...........14 Integration steps ................16 Chapter 2 Getting started ..............21 Test board overview ..............22 Connecting the test board ............23 Using the MENU tool ..............25 Chapter 3 Mechanical integration ...........31...
  • Page 10 Antenna selection.............67 Selecting an antenna ..............67 Introduction to antenna terminology ........69 Antenna design considerations ..........71 Shielding ....................73 FCC radio frequency exposure rules ........74 DataTAC Network Certification ..........79 Specifications ...................79 Chapter 7 Glossary of terms..............83 RIM 802D Radio Modem Integrator Guide...

  • Page 11: Introduction

    Introduction The RIM 802D Radio Modem set a new standard for radio modem performance in key areas, such as receiver sensitivity, output efficiency, noise immunity, and power consumption. Its small size and weight make it suitable for virtually any wireless data application, including handheld devices and mobile terminals.

  • Page 12: Radio Performance

    The RIM 802D Radio Modem offers high performance on DataTAC networks. Receiver sensitivity The RIM 802D Radio Modem has a receiver sensitivity of –118 decibel milliwatts (dBm) using the MDC over-the-air protocol, and –111 dBm using RD-LAP, at a 0.05 packet error rate (BER).
  • Page 13 Introduction Powerful and efficient transmitter The RIM 802D Radio Modem is designed to supply a full 2.0 watts to the antenna. RIM radio modems provide reliable, efficient transmission across the entire operating voltage range of 4.1 to 4.75 volts. Batteries can be used even when they are almost depleted, which maximizes the radio coverage area throughout the life of the battery.

  • Page 14: Datatac Network Technology

    Small size Using a single-board design, the RIM 802D Radio Modem is very thin, and smaller than a business card. It measures 1.65 by 2.66 inches (42.0 by 67.5 mm). This small size allows the radio modem to meet tight space requirements within most applications.
  • Page 15 Setup time is eliminated and network connection is instantaneous. Packet-switching uses channel capacity efficiently, typically allowing 10 to 50 times more users over a radio channel than a circuit-switched network. RIM 802D Radio Modem Integrator Guide...

  • Page 16: Integration Steps

    Introduction Integration steps The following flowchart illustrates the integration process. RIM 802D Radio Modem Integrator Guide...
  • Page 17 Introduction 1. Contact the RIM OEM team Email OEMinquiry@rim.net or call (519) 888-7465 x5200 to obtain more information about RIM Radio Modem products and whether they are suitable for your application. 2. Obtain Integrator's Kit You can request the Integrator’s Kit from Research In Motion.
  • Page 18 Radio Access Protocol (RAP). 8B. Develop an Antenna Several antennas have been certified for use with the RIM radio modem. Refer to the Integrator's Guide for details. If these antennas do not meet your needs, start developing an antenna for use with the final product.
  • Page 19 For more information, visit http://www.rim.net/oem/. 10B. Pilot/Beta Release Contact RIM prior to beta release of the product, especially if the product has not been certified yet. There are very specific guidelines that must be followed to ensure legality of the release prior to certification.

  • Page 21: Getting Started

    Working with RIM RIM has an experienced team to help you with design and implementation. If you need help getting started, or if you have any questions about the radio technology or its integration into...

  • Page 22: Test Board Overview

    The RIM test board provides a standard RS-232 serial interface between a computer and the radio modem. The test board helps you interface the RIM 802D Radio Modem to a standard computer using a COM port, or to a terminal device using a RS-232 serial port.

  • Page 23: Connecting The Test Board

    Connecting the test board You must connect the RIM 802D Radio Modem to an antenna and to a computer, or some other device with a RS-232 serial interface. Use the test board and cables supplied with your Integrator’s Kit.
  • Page 24 5. Turn on the system The power switch on the test board is connected to the TURNON line of the RIM 802D Radio Modem. To determine whether the radio is on, look at the LED marked ON. It is lit when the radio is on.

  • Page 25: Using The Menu Tool

    Getting started Using the MENU tool The RIM 802D Radio Modem contains a diagnostic utility called MENU. This utility enables you to set the current network, send test messages to the radio modem, and monitor radio and network status. The MENU utility is embedded in the radio modem firmware.
  • Page 26 If you continue to have problems, verify that the radio is turned on and connected to the computer, and that all cables are connected securely. Contact RIM for assistance if you are unable to continue at this point. The MENU screen displays the software version, the radio modem serial number, a list of available wireless networks, a list of setup commands, and status indicators.
  • Page 27 43 for more information. The Rx/Tx field indicates whether the radio’s receiver and Rx/Tx transmitter are enabled or disabled. The transmitter can be enabled or disabled by your application, and is normally enabled. RIM 802D Radio Modem Integrator Guide...
  • Page 28 Contact your network operation to obtain the locations of network base stations. Changing to a different network RIM radio modems can be used on different DataTAC networks operating on different channels. RIM can program up to 16 network channel lists into each radio. If the network shown is not the correct one, you can choose another from the list of networks available.
  • Page 29 Ensure that the antenna is connected properly and is positioned vertically. Signal quality can vary significantly in buildings. Try moving the antenna to a new location, perhaps near a window, to see if you can improve the signal. RIM 802D Radio Modem Integrator Guide...
  • Page 30 The screen clears and a message appears indicating that the radio is reset. You can safely disconnect the radio and close your terminal program after you receive this message. RIM 802D Radio Modem Integrator Guide...

  • Page 31: Mechanical Integration

    Each unit in the sample is also visually inspected after testing. This experience enables RIM to fine-tune its design and manufacturing process. Storage temperature The RIM 802D radio modem can be stored at a temperature from -40°C to 85°C (-40°F to 185°F).

  • Page 32: Physical Properties

    75°C (167°F). Physical properties Weight The RIM 802D Radio Modem weighs 35 g (1.2 oz), including the case. Dimensions RIM radio modems meet stringent space requirements. The maximum dimensions of the radio modem, not including cables, are: •...
  • Page 33 Mechanical integration Mounting methods RIM radio modems can be fastened securely using a variety of methods. You must consider the operating environment when choosing a mounting option. For example, extreme temperature, heavy vibration, or high electromagnetic interference areas can require a special mounting solution. You must ensure that the radio modem remains securely attached in the environment where it is used.
  • Page 34 62.5-by-36.5 mm rectangle, with each hole 2.5 mm in diameter. To allow room under the radio for components on your board, you can use standoffs instead of bolts, as illustrated in the following diagram. RIM 802D Radio Modem Integrator Guide...
  • Page 35 If you are using tie wraps, ensure that the surface beneath the RIM 802D Radio Modem is flat. Otherwise, the mounting surface can push up on the bottom surface of the radio case, and the tie wraps, when tightened, can push down on the edge of the radio case.

  • Page 36: Cables And Connectors

    The interface cable supplied with the Integrator’s Kit is a Type D 76.2 mm (3.0 inches) long FFC Jumper in 1-mm centerline spacing, Molex part number 210390382, as illustrated in the following mechanical drawing: RIM 802D Radio Modem Integrator Guide...
  • Page 37 AMP part number 2-487951-2. More information about each connector, including mechanical drawings, is available from the manufacturer’s web site (http://www.amp.com). Contact RIM (oemsupport@rim.net) for help selecting an appropriate connector for your application. RIM 802D Radio Modem Integrator Guide...
  • Page 38 MMCX connector because it is very small, and it has the mating force to withstand heavy vibration. Typically, an antenna does not plug directly into a RIM 802D Radio Modem. Instead, a cable is used between the radio’s antenna connector and a second connector at the outer casing of the device.
  • Page 39 Mechanical integration RIM 802D Radio Modem Integrator Guide...

  • Page 41: Power Requirements

    Power supply parameters The RIM 802D Radio Modem requires a clean, stable 4.1 V to 4.75 V source that is capable of delivering a 1-second burst of up to 1.7 A (at 4.5 V) when required by the transmitter.
  • Page 42 15 mV. Note that if there are several ripple components, or if ripple is measured with a larger (typically 20-MHz) bandwidth, the ripple seems worse. If the ripple is still below 15 mV under these conditions, it meets the ripple specification. RIM 802D Radio Modem Integrator Guide...

  • Page 43: Reducing Power Consumption

    Power requirements A passive LC (series L, shunt C) power filter can be put between your power supply and the RIM 802D Radio Modem to reduce ripple at the radio connector. The radio modem already has about 70 µF of on-board shunt capacitance. The inductor cannot exceed 100 µH (otherwise, transients could...
  • Page 44 802D’s overall power consumption, while providing the same receive latency as previous versions. An additional feature in the 802D allows applications to trade off some of the new power savings for improved receive latency. Four powersave modes are available: EPS1, EPS2, EPS3, and EXPRESS.

  • Page 45: Calculating Overall Power Consumption

    RD-LAP. The RIM 802D will automatically determine which protocol to use; your application does not need to indicate this. RIM 802D Radio Modem Integrator Guide...
  • Page 46 Power requirements The RIM 802D Radio Modem receiver draws 61 mA when it is turned on. However, in Powersave mode, the receiver is nearly always turned off, and is turned on only four times in every 510 second (8.5 minute) window. The base station waits until the radio’s receiver is turned on before attempting to send data to...

  • Page 47: Batteries

    8.45 12.40 mA (4.1 V) Batteries When integrated into a handheld device, the RIM 802D Radio Modem can be powered by batteries. This technology is easily available and eliminates the need for power supply components such as voltage regulators. RIM 802D Radio Modem Integrator Guide...
  • Page 48 Power requirements Rechargeable batteries RIM recommends using rechargeable nickel cadmium (NiCad) batteries to power the RIM 802D Radio Modem for battery-operated applications that require a wide operating temperature range. Nickel metal hydride (NiMH) and lithium ion (Li+) cells can also be used with good results, but many such cells do not work very well at temperatures below freezing.

  • Page 49: Plug-In Supplies

    These should have a value of 20 V and be placed on the supply side of the regulator circuit. RIM recommends a supply capable of providing 4.1 V and rated for 2.5 A peak current. RIM 802D Radio Modem Integrator Guide...

  • Page 50: Automotive Supplies

    Power requirements Automotive supplies If you plan to power the RIM 802D Radio Modem from an automotive supply, special steps must be taken to protect the radio modem from intense power fluctuations experienced when an automobile is started. A circuit comprising inductors, transorbs and voltage regulators should be used to ensure that the radio modem is protected from these power fluctuations.

  • Page 51: Interface Specification

    (RAP). If you are using a NCL application with another DataTAC radio and are now migrating to the RIM 802D, you do not need to rewrite the application in RAP. You can continue using the existing NCL application. If you are writing a new application for the RIM 802D Radio Modem, you must choose whether to use NCL or RAP as your link-layer protocol.
  • Page 52 NCL is designed to be robust and redundant, and should be used when the serial link is unreliable or when the serial cable to the RIM 802D radio modem is very long. However, advances in mobile computing technology have helped to ensure that serial links are short enough to make bit errors extremely unlikely.

  • Page 53: Software Developer's Kit

    The RIM 802D Radio Modem is based on a 32-bit Intel® 386 processor, which you can use to run third-party applications residing on the device. Memory available for your resident...

  • Page 54: Pin Descriptions

    NCL traffic. Flow control lines are provided for the primary serial port only. Pins 9 through 22 on the RIM 802D Radio Modem correspond to pins 14 through 1 on the RIM 801D Radio Modem. The numbering is reversed because the connector is reversed, but physically the leftmost pin on the RIM 802D connector is the same as the leftmost pin on the RIM 801D connector.
  • Page 55 Interface specification On the RIM 802D Radio Modem, pins labelled TX are input Note lines to the radio; pins labelled RX are output lines from the radio. PIN # Label Description 1,2,3,4 — Bidirectional I/O lines Message Waiting Coverage 7, 8...
  • Page 56 _inp() function provided by the Software Developer’s Kit (SDK). These lines are meaningful only to an application that resides on the RIM 802D and is developed using the SDK. These lines are never used in a RAP or NCL interface to an external computing device.
  • Page 57 ONI is low, then the radio modem is not ready to receive data because it is off. When ONI is low, all inputs to the radio modem should be held low or disconnected. Otherwise, power is consumed and wasted. RIM 802D Radio Modem Integrator Guide...
  • Page 58 Transmit Indicate The active (radio transmitting) state of this line is high. This output from the radio modem is asserted while the RIM radio is transmitting a packet to the network base station. TRI has a built-in current limiter that enables it to drive an LED directly, to provide real-time visual feedback that the radio is transmitting packets.
  • Page 59 Pin 15 ~CTS ~Clear To Send This line is an output from the RIM 802D Radio Modem to the computing device. The active (clear to send) state of this line is low. When asserted low by the RIM 802D Radio Modem, this line indicates that it is ready to receive data from the computing device.
  • Page 60 The active, or data terminal ready (DTR), state of this line is low, and indicates that the computing device is ready to receive data from the RIM 802D Radio Modem. De-asserting this line high turns communication off; the radio modem does not...
  • Page 61 8 bits, No parity, 1 stop bit. This line is meaningful only to an application that resides on the RIM 802D and developed using the SDK. It allows the application to receive data from a second serial device. No flow control lines are provided for this second device.

  • Page 62: How To Turn The Radio On And Off

    Turning on the radio To turn the RIM 802D radio modem on, the software should first check the ONI pin. If ONI is high, but TURNON is being held low, then your application has recently requested the radio modem to shut down, and the radio is performing shutdown operations and should not be disturbed.
  • Page 63 Note that if any line is left in the high state, as much as 5 mA may flow into the radio modem. Data that has been received by the RIM 802D radio modem from the DataTAC network, but has not been transferred to the computing device, will not be saved.

  • Page 64: Loading Firmware (Optional)

    Nevertheless, you may choose to design your application in such a way that allows the RIM firmware to be updated after your product is deployed in the field.
  • Page 65 Change the mode of operation flag to 0, so that upon reset, the radio will default back to its normal mode of operation. Alternatively, the product being used for testing can be programmed without an application. RIM 802D Radio Modem Integrator Guide...

  • Page 67: Antenna Selection

    The antenna is one of the most important components of a wireless communication system. The right antenna will maximize the coverage area of the RIM radio modem. The antenna that you choose should complement the needs of your specific project. There are many different antenna types and options that will meet your engineering and user requirements while remaining within budget constraints.
  • Page 68 Antenna selection Antenna requirements The following are the minimum requirements of the antenna system used with the RIM radio modem. 50 Ω Impedance: 833.5 MHz, ±5 MHz (λ=27.8 cm, ±0.2 cm) Center frequency: This is deliberately biased toward transmit because of the exceptionally sensitive receiver in the radio;...

  • Page 69: Introduction To Antenna Terminology

    VHF and UHF has led to the use of a half-wave dipole as the reference element. At the antenna port, the output power of the RIM 802D is 2.0 W The antenna gain (or loss) will result in an increase (or decrease) in the output power.
  • Page 70 The antenna, cables, and connectors in a radio frequency system must all possess the same impedance. The impedance required by the RIM 802D radio modems is 50 Ω, which is a widely-available industry standard. Any deviation from this value may result in impedance mismatch and signal loss.

  • Page 71: Antenna Design Considerations

    = 3 x 10 m/s by the center frequency f = 833.5 MHz. Because the RIM 802D radio modem’s receiver is so sensitive, this value includes a 5 MHz bias toward the transmit frequencies to help balance the uplink and downlink between the radio modem and the network base station.
  • Page 72 RF systems. It is important to make allowances early in the design process to optimize performance and provide flexibility in antenna choice. Generally, it is prudent to position the antenna “up and away” from the radio modem and printer motors to RIM 802D Radio Modem Integrator Guide...

  • Page 73: Shielding

    RF interference originating from the computing device to which it is attached, and to prevent the RIM radio modem from emitting RF energy into the computing device and disrupting the computing device’s operation.

  • Page 74: Fcc Radio Frequency Exposure Rules

    Human Exposure to Radio Frequency Electromagnetic Fields, OET Bulletin 65 and its Supplement C, all integrations of the RIM 802D OEM unit radio modems are subject to routine environmental evaluation for radio-frequency (RF) exposure prior to equipment authorization or use.
  • Page 75 Both of these ground plane mount antennas, with a 6 foot cable length, pass the MPE test when 20 cm from the user. If the RIM 802D radio modem is integrated in a vehicle, and if one of the above antennas is used, the MPE limits will not be exceeded, provided that the antennas are installed at least 20 cm from any edge of the vehicle rooftop.
  • Page 76 Antenna selection RIM strongly recommends the use of one of the following labs for SAR/MPE testing, because of their experience with this type of device testing using RIM radio modems. For information on labs for SAR/MPE testing, visit the web site http://www.rim.net/oem.
  • Page 77 If antennas other than those tested by RIM are used, a set of tests must be performed to determine the passing distance that meets the exposure limits with respect to SAR for handheld, body-worn, and portable devices, or MPE for vehicular and mobile devices.
  • Page 78 RF exposure limits, by contacting the RF Safety Group: Phone: (202) 418-2464 Email: rfsafety@fcc.gov http://www.fcc.gov/oet/rfsafety You can also contact the FCC Call Centre: Phone: 1-888-CALL-FCC (1-888-225-5322) You can contact the RIM engineering development team at: Tel: (519) 888-7465 Email: oemsupport@rim.net RIM 802D Radio Modem Integrator Guide...

  • Page 79: Datatac Network Certification

    A copy of the required tests should be obtained from Motient or Bell Mobility after joining their developer programs. Specifications The RIM 802D Radio Modem meets the following specifications. Power supply & typical current usage •...

  • Page 80: Other Features

    • Certified by Motient and Bell Mobility to meet DataTAC 4000 (ARDIS) Specifications Mechanical & environmental properties • Weight: 35 g (1.2 oz), including case • Footprint: 42.0 by 67.5 mm (1.65” x 2.66”) RIM 802D Radio Modem Integrator Guide...
  • Page 81 Antenna cable connector: MMCX • Tested to IEC 68-2-6 Part 2 for vibration • Metal case • Operating temperature tested to: -30°C to +70°C (at 5-95% relative humidity, non-condensing) • Storage temperature: -40°C to +85°C RIM 802D Radio Modem Integrator Guide...

  • Page 83: Glossary Of Terms

    32-bit LLI that identifies it to the DataTAC network. The protocol governing communication between the RIM 802D and the DataTAC base station outside urban areas. MMCX The connector on the RIM 802D to which an antenna cable is connected.
  • Page 84 Original Equipment Manufacturer. Usually implies that the “OEM product” is carried another manufacturer’s name. The RIM 802D is designed to be embedded in OEM terminals, PCs, and data gathering equipment. The Open Systems Interconnection model allows different systems, following the applicable standards, to communicate openly with each another.
  • Page 85 DataTAC network and the radio modem. An RF connector type. Transistor-Transistor Logic. Used in digital circuits. Low (0) is represented by 0 V and High (1) by 5 V. The RIM 802D uses 3.0 V for High. Type Approvals These approvals are required by most governments before radio transmitters and equipment containing radio transmitters can be used.
