Panasonic SA-AK240PL Service Manual

Cd stereo system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Notes: This model's CD mechanism changer unit is CRS1. Please refer to the original Service Manual
(Order No. MD0509368C0) for this mechanism.

Specifications

n AMPLIFIER SECTION
FTC Output power
THD 10%, both channels driven
100 Hz to 10 kHz
Total FTC power
RMS Output Power
THD 10%, both channels driven
1 kHz
Total output power
PMPO
n FM/AM TUNER, TERMINALS SECTION
Preset station
Frequency Modulation (FM)
Frequency range
Sensitivity
S/N 26dB
Antenna terminals
Amplitude Modulation (AM)
Frequency range
Sensitivity
90 W per channel (3 Ω)
180 W
115 W per channel (3 Ω)
230 W
2500 W
FM 15 stations
AM 15 stations
87.9 to 107.9 MHz (200 kHz
steps)
87.5 to 108.0 MHz (100 kHz
steps)
4.0 µV (IHF)
2.2 µV
75 Ω (unbalanced)
520 to 1710 kHz (10 kHz step)
SA-AK240PL
Colour
(S)... Silver Type
S/N 20dB (at 1000 kHz)
Music Port input jack
Terminal
Sensitivity
Phone jack
Terminal
n CASSETTE DECK SECTION
Track system
Heads
Record/playback
Erasure
Motor
Recording system
Erasing system
Tape speed
Overall frequency response (+3, -6 dB) at DECK OUT
NORMAL
S/N Ratio
Wow and flutter
Fast forward and rewind time
n DISC SECTION
Disc played [8 cm or 12 cm]
© 2006 Matsushita Electric Industrial Co. Ltd.. All
rights
reserved.
distribution is a violation of law.
ORDER NO. MD0512481C3
CD Stereo System
Stereo, 3.5 mm jack
100 mV, 4.7 kΩ
Stereo, 3.5 mm jack
4 track, 2 channel
Solid permalloy head
Double gap ferrite head
DC servo motor
AC bias 100 kHz
AC erase 100 kHz
35 Hz to 14 kHz
50 dB (A weighted)
0.18 % (WRMS)
Approx. 120 seconds with
C-60 cassette tape
Unauthorized
copying
560 µV/m
4.8 cm/s
and
