Orban OPTIMOD-FM 5518 Operating Manual

Fm stereo encoder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operating Manual
OPTIMOD-FM
5518
FM Stereo Encoder
Version 1.2 Software

Advertisement

Table of Contents
loading

Related Manuals for Orban OPTIMOD-FM 5518

Summary of Contents for Orban OPTIMOD-FM 5518

  • Page 1 Operating Manual OPTIMOD-FM 5518 FM Stereo Encoder Version 1.2 Software...
  • Page 2 European Parliament, this product must not be discarded into the municipal waste stream in any of the Member States. This product may be sent back to your Orban dealer at end of life where it will be reused or recycled at no cost to you.

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS All the safety and operating instructions should be read before the appliance is operated. Retain Instructions: The safety and operation instructions should be retained for future reference. Heed Warnings: All warnings on the appliance and in the operating instructions should be adhered to. Follow Instructions: All operation and user instructions should be followed.
  • Page 4 Safety Instructions (German) Gerät nur an der am Leistungsschild vermerkten Spannung und Stromart betreiben. Sicherungen nur durch solche, gleicher Stromstärke und gleichen Abschaltverhaltens ersetzen. Sicherungen nie überbrücken. Jedwede Beschädigung des Netzkabels vermeiden. Netzkabel nicht knicken oder quetschen. Beim Abziehen des Netzkabels den Stecker und nicht das Kabel enfassen.
  • Page 5 (2) Check the other sections of the Manual (consult the Table of Contents and Index) to see if there might be some sug- gestions regarding your problem. (3) After reading the section on Factory Assistance, you may call Orban Customer Service for advice during normal Ari- zona business hours. The number is (1) (480) 403-8300.
  • Page 6 Orban and 5518 are registered trademarks. All trademarks are property of their respective companies. This manual was published in August 2014. © Copyright Orban 8350 East Evans Suite C4, Scottsdale, AZ 85260 USA Phone: +1 (480) 403-8300; Fax: +1 (480) 403-8302; E-Mail: custserv@orban.com; Site: www.orban.com...
  • Page 7 Operating Manual OPTIMOD-FM 5518 FM Stereo Encoder Version 1.2 Software...

  • Page 8: Table Of Contents

    Table of Contents Index.........................0-7 Section Introduction ............................1-1 .......................1-1 BOUT THIS ANUAL 5518 FM S ..................1-1 TEREO NCODER Flexible Configuration ....................1-1 Signal Processing Features ..................1-2 Controllable ......................1-3 5518......................1-4 RESETS IN THE ..................1-5 NPUT UTPUT ONFIGURATION Digital AES3 Left/Right Input/Output ..............1-5 Analog Left/Right Input/Output................1-6 Stereo Analog Baseband Composite Output ............1-6 Subcarriers........................1-6 Remote Control Interface ..................1-7...
  • Page 9 5518 PC R ............2-47 NSTALLING EMOTE ONTROL OFTWARE Installing the Necessary Windows Services............2-48 Check Hardware Requirements ................2-48 Running the Orban Installer Program..............2-49 Setting Up Ethernet, LAN, and VPN Connections ..........2-49 Conclusion......................2-50 .............2-51 PPENDIX ETTING ERIAL OMMUNICATIONS Preparing for Communication through Null Modem Cable ......2-51 Connecting Using Windows 2000 Direct Serial Connection:......2-51...
  • Page 10 Preparing for Communication through Modems ..........2-71 Connecting Using Windows 2000 Modem Connection ........2-71 Connecting using Windows XP Modem Connection ..........2-77 5518’ .................2-82 PDATING YOUR OFTWARE SNMP S ......................2-84 UPPORT SNMP Network Setup..................... 2-84 SNMP Mib file......................... 2-84 SNMP Default Settings ....................2-85 SNMP Features........................
  • Page 11 RFI, Hum, Clicks, or Buzzes ....................5-1 Unexpectedly Quiet On-Air Levels ................... 5-1 Poor Peak Modulation Control ..................5-2 Unexpected Delay Between the Program Feed and the On-Air Signal ......5-2 Audible Distortion On-Air ....................5-2 Whistle on Air, Perhaps Only in Stereo Reception............5-3 Interference from stereo into SCA ...................
  • Page 12 Function Description Drawing Page 6-27 Chassis Circuit Board Locator and Basic In- Top view terconnections (not to scale) 6-28 Control board Control microprocessor. Services Parts Locator front panel, serial port, Ethernet, Drawing and DSP+I/O board. Contains: 6-29 General Purpose bus, address de- Schematic 1 of 5 coder, I/O+DSP interface 6-30...

  • Page 13: Index

    Index automation 3- · 13 19 K Ref control 2- · 9 backing up presets 3- · 11 balance adjust 2- · 23 balanced inputs 2- · 6 5518 FM Stereo Encoder 1- · 1 output, simulates transformer 2- · 6 base board removing 4- ·...
  • Page 14 reset to hour 2- · 41 reset to midnight 2- · 42 resetting via remote control 2- · 42 D/A converter setting 2- · 27 circuit description 6- · 10 common-mode rejection 2- · 10 specification 6- · 2 components delay obtaining 6- ·...
  • Page 15 meters 3- · 2 SCA, specifications 6- · 4 subcarrier 2- · 7 factory service 5- · 11 input level Firewall 2- · 49, 9 line-up 1- · 14 Firmware input meters 1- · 15 updating 8500 2- · 82 input selector frequency response I/O setup 2- ·...
  • Page 16 NAB Broadcast and Audio System Test CD recovering from lost 2- · 16, 33 4- · 6 Netcat Orban installer program 2- · 49 automated control using 2- · 37 PC board locator diagram 6- · 27 automation using 2- · 36...
  • Page 17 Remote Software 2- · 34, 44, 47, 82 power supply resolution circuit description 6- · 13 specification 6- · 1 Orban part # 6- · 13 RFI 5- · 1 testing 4- · 7 right channel balance power supply board I/O setup 2- ·...
  • Page 18 Stereo encoder composite meter does not indicate 1- · 16 SSB/VSB Operation 3- · 6 stereo encoder mode input, specifications 6- · 4 inputs 1- · 6 audio processing for 2- · 17 interference from stereo 5- · 3 input/output 1- · 6 modulation reduction 2- ·...
  • Page 19 Windows installing services 2- · 48 Windows 2000 unlock front panel 2- · 33 adding direct serial connection 2- · 52, 56, 72 unpacking 2- · 1 Adding direct serial connection 2- · 78 Updating software 2- · 82 Direct Connect 5- · 6 user presets direct serial connection 2- ·...

  • Page 21: Section 1 Introduction

    Adobe Acrobat Reader’s text search function. The 5518 FM Stereo Encoder Orban’s all-digital 5518 FM Stereo Encoder is a high-quality stand-alone stereo en- coder that operates at 64 kHz to 512 kHz sample rates and offers lowpass filtering, overshoot limiting, composite limiting, diversity delay, and an ITU412 multiplex power controller.

  • Page 22: Signal Processing Features

    The sample rate is 64 kHz and multiples thereof, up to 512 kHz. The inter- nal audio bandwidth is high enough to prevent overshoot caused by spectral truncation of the left/right input signals that are band-limited to 18 kHz or lower. This makes the 5518 compatible with all Orban OPTIMOD-FM audio proc- essors. ...

  • Page 23: Controllable

    5518-FM DIGITAL INTRODUCTION  A dual-mode composite limiter is available. The composite limiter uses a unique, “you can only do this in DSP” process that beats composite clippers by preserving stereo imaging while fully protecting the stereo pilot tone, RDS/RBDS, and subcarriers. It can operate in either “Half-Cosine Interpola- tion”...

  • Page 24: Presets In The 5518

     The 5518’s software can be upgraded by running Orban-supplied download- able upgrade software on a PC. The upgrade can occur remotely through the 5518’s Ethernet port or serial port (connected to an external modem), or locally (by connecting a Windows®...

  • Page 25: Input/Output Configuration

    5518-FM DIGITAL INTRODUCTION User Presets are stored in non-volatile memory that does not require battery backup. To Create or Save a User Preset on page 3-3 has more about User Presets. To recall a preset: A) Turn the knob until your desired preset is visible in the lower line of the dis- play.

  • Page 26: Analog Left/Right Input/Output

    INTRODUCTION ORBAN MODEL 5518 The 5518 can apply J.17 deemphasis to signals applied to its digital input and J.17 preemphasis to the processed signal emitted from its digital output. J.17 is a 6 dB/octave shelving preemphasis/deemphasis standard with break points at 400 Hz and 4 kHz.

  • Page 27: Remote Control Interface

    5518-FM DIGITAL INTRODUCTION Subcarrier inputs sum into the composite baseband outputs. Rear-panel accessible PC-board-mounted trim pots allow the user to adjust the sensitivities of the two SCA inputs from <100 mV p-p to >10 V p-p to produce 10% injection with respect to 100% modulation = 4 V p-p at the 5518’s composite outputs (the factory setting is 4 V p-p to produce 10% injection).

  • Page 28: Computer Interface

    INTRODUCTION ORBAN MODEL 5518  Input: Analog: Indicates that the 5518 is using audio from its analog input.  Input: Digital: Indicates that the 5518 is using audio from its AES3 digital input.  Analog Input Silent: Indicates that the level at either or both analog input chan- nels is below the threshold set in step (A) on page 2-20.

  • Page 29: Location Of The 5518

    5518-FM DIGITAL INTRODUCTION configure the 5518 to lock its 19 kHz pilot tone and output sample frequency to this input. The sample frequency at the 5518’s digital output does not have to be the same as the reference frequency. If the output frequency is different, the output sample fre- quency will be the product of a quotient of integers times the reference frequency.

  • Page 30: Best Location For The 5518

    1-10 INTRODUCTION ORBAN MODEL 5518 3) Any preemphasis used in the audio transmission system prior to the stereo en- coder must be canceled by a precisely complementary deemphasis: Every pole and zero in the preemphasis filter must be complemented by a zero and pole of identical complex frequency in the deemphasis network.

  • Page 31: Studio-Transmitter Link

    1-11 5518-FM DIGITAL INTRODUCTION connection instructions, please refer to the Orban CIT25 Composite Isolation Trans- former schematic diagram, which is shown on page 12 of the CIT25 manual. This is available from: ftp.orban.com/CIT25/CIT25 Instructions.pdf (Please note that Orban no longer manufactures the CIT25, which used the Jensen transformer.) If you need to drive an auxiliary or standby transmitter, the best way to connect it to the 5518 is via the 5518’s second composite output.

  • Page 32: Composite Baseband Microwave Stls

    1-12 INTRODUCTION ORBAN MODEL 5518 verely. This will force you use the 5518’s left/right overshoot limiters to apply heavy limiting, which can reduce audio quality. For any lossy compression system the higher the data rate, the less the peak levels will be corrupted by added noise, so use the highest data rate practical in your system.

  • Page 33: Dual Microwave Stls

    1-13 5518-FM DIGITAL INTRODUCTION In general, a composite microwave STL provides good audio quality, as long as there is a line-of-sight transmission path from studio to transmitter of less than 10 miles (16 km). If not, RF signal-to-noise ratio, multipath distortion, and diffraction effects can cause serious quality problems.

  • Page 34: About Transmission Levels And Metering

    1-14 INTRODUCTION ORBAN MODEL 5518 About Transmission Levels and Metering Meters Studio engineers and transmission engineers consider audio levels and their meas- urements differently, so they typically use different methods of metering to monitor these levels. The VU meter is an average-responding meter (measuring the approxi- mate RMS level) with a 300ms rise time and decay time;...

  • Page 35: Transmission Levels

    1-15 5518-FM DIGITAL INTRODUCTION Transmission Levels The transmission engineer is primarily concerned with the peak level of a program to prevent overloading or over-modulation of the transmission system. This peak overload level is defined differently, system to system. In FM modulation (FM/VHF radio and television broadcast, microwave or analog sat- ellite links), it is the maximum-permitted RF carrier frequency deviation.

  • Page 36: Composite Output Level

    1-16 INTRODUCTION ORBAN MODEL 5518 put, the maximum digital word at the input corresponds to the 0 dB point on the 5518’s input meter. Composite Output Level When its left/right overshoot limiter and composite limiter are enabled, the 5518 controls instantaneous, absolute peak levels to a tolerance of approximately 0.1 dB.

  • Page 37: Built-In Calibrated Bypass Test Mode

    However, the limitation of any right or remedy shall not be effective where such is prohibited or restricted by law. Simply take or ship your Orban products prepaid to our service department. Be sure to include a copy of your sales slip as proof of purchase date. We will not repair...

  • Page 38: International Warranty

    Warranty (yielding a total Warranty period of five years) by remitting to Orban ten percent of the gross purchase price of your Orban product. This offer applies only to new Orban products purchased from an authorized Orban Dealer.

  • Page 39: Section 2 Installation

    C) Complete the Registration Card and return it to Orban. (please) The Registration Card enables us to inform you of new applications, per- formance improvements, software updates, and service aids that may be...
  • Page 40 INSTALLATION ORBAN MODEL 5518 TYPE 18/3 SVT COR, TYP (3 x .82 mm WIRE COLOR CONDUCTOR NORMAL LINE BROWN BLACK NEUTRAL BLUE WHITE EARTH GND GREEN-YELLOW GREEN PLUG FOR 115 VAC (USA) TYPE H05VV - F - 0.75 CONDUCTOR WIRE COLOR...
  • Page 41 5518-FM DIGITAL INSTALLATION TOPIC PAGE Audio Input and Audio Output Connections..........2-5 AES3 Digital Input and Output ..............2-7 Composite Output and Subcarrier Inputs ..........2-7 Wordclock/10 MHz Sync Reference Input ..........2-9 Grounding ....................2-10 5. Connect remote control interface. (optional) For a full listing of 5518’s extensive remote control provisions, refer to Remote Control Interface Programming on page 2-34.

  • Page 42: 5518 Rear Panel

    INSTALLATION ORBAN MODEL 5518 6. Connect tally outputs (optional) See the schematic on page 6-32. The 5518 supports two hardware tally outputs, which are NPN open-collector and operate with respect to pin 1 (common). Therefore, the voltage applied to the load (such as a relay or opto-isolator) must be positive. You can use the 12 VDC source on pin 25 to drive the high side of the load, taking into account the fact that the voltage on pin 25 is current limited by a 300 Ω...

  • Page 43: Input And Output Connections

    5518-FM DIGITAL INSTALLATION left, mono-right, mono-sum), selecting analog, digital or digital+J.17 input, over- shoot compensation, SCA modulation compensation, and clock synchronization. (See Remote Control Interface Programming on page 2-34.) The 5518 remote control ac- cepts a DB-25 connector. The Ethernet Port accepts a 10Mb/second or 100Mb/second Ethernet connection terminated with an RJ45 connector.

  • Page 44: Analog Audio Input

    INSTALLATION ORBAN MODEL 5518 any studio-wiring standard: If pin 2 or 3 is considered LOW, the other pin is automatically HIGH. Analog Audio Input  Nominal input level between –9 dBu and +8 dBu will result in normal operation of the 5518.

  • Page 45: Aes3 Digital Input And Output

    5518-FM DIGITAL INSTALLATION  Use two-conductor foil-shielded cable (Belden 8451, or equivalent).  At the 5518’s output (and at the output of other equipment in the system), do not connect the cable’s shield to the CHASSIS GROUND terminal (pin 1) on the XLR-type connector.
  • Page 46 INSTALLATION ORBAN MODEL 5518 Each output can drive up to 75 in parallel with 0.047F before perform- ance deteriorates significantly (see Figure 2-3 on page 2-8). Connect the 5518’s composite output to the exciter input with up to 100 feet (30.5m) of RG-58/U or RG-59/U coaxial cable terminated in BNC connectors.

  • Page 47: Wordclock/10 Mhz Sync Reference Input

    5518-FM DIGITAL INSTALLATION ways protect the stereo pilot tone by at least 60 dB (250Hz from 19 kHz) and will protect the region from 55 kHz to 100 kHz by at least 75 dB (re 100% modulation). See Figure 5-1 on page 5-3. The subcarrier (SCA) inputs are provided for convenience in summing subcarriers into the baseband prior to their presentation to the FM exciter.

  • Page 48: Grounding

    2-10 INSTALLATION ORBAN MODEL 5518 by using a BNC Tee connector and a 75 BNC terminator. This will prevent perform- ance-degrading reflections in the cable. This is required for both wordclock and AES11id operation. Grounding Very often, grounding is approached in a “hit or miss” manner. However, with care...

  • Page 49: Quick Setup

    When the 5518’s stereo encoder is driving an unbalanced exciter input, you may encounter a ground loop. (Some older exciters have unbalanced inputs.) Unlike some older Orban FM processors, the 5518 does not have a ground lift switch. If you cannot reconfigure your grounding scheme to eliminate such a loop, you can balance and float the exciter input with a Jensen JT-123-BLCF transformer (see page 2-10).
  • Page 50 2-12 INSTALLATION ORBAN MODEL 5518 with knob” appears. At this point, you will be at step 5.F) in this Quick Setup procedure. When you enter Quick Setup for the first time, the set time screen appears. A) Hold down the appropriate soft button while turning the knob to enter the hour, minute, and seconds.
  • Page 51 2-13 5518-FM DIGITAL INSTALLATION 8. Set analog output feed. The analog output emits the signal driving the 5518’s internal stereo encoder af- ter the overshoot limiter. In most installations, this output is not used. However, this overshoot-controlled output can be useful to drive other stereo encoders that have no overshoot limiters.
  • Page 52 2-14 INSTALLATION ORBAN MODEL 5518 The internal sample rate converter sets the rate at the 5518’s digital output. This ad- justment allows you to set the output sample rate to ensure compatibility with equipment requiring a fixed sample rate. In all cases, the 5518’s fundamental sample...
  • Page 53 (e.g., “Z-100”). The name can be up to eight characters long. It is used to identify your 5518 to Orban’s PC Remote application, and appears on the Main Screen when the 5518 is being controlled by the PC Remote application.
  • Page 54 2-16 INSTALLATION ORBAN MODEL 5518 To comply with FCC Rules, set the modulation reduction to one-half the injection of the associated subcarrier. For example, if your subcarrier in- jection totals 20% from two 10% subcarriers, set M ODULATION EDUCTION TO “5%” and M 2 to 5%.
  • Page 55 2-17 5518-FM DIGITAL INSTALLATION without additional 50 or 75 µs preemphasis. For example, see step (10.B) on page 2-13. A) Press the Modify button. B) If you do not see the A soft button, press the Next button until it PPLY appears.
  • Page 56 2-18 INSTALLATION ORBAN MODEL 5518 If you are using an OPTIMOD-FM 8000, 8100, 8500, or 8600 audio proces- sor to drive the STL, set the 5518’s L to O or 17 . If you OWPASS ILTER are using any other OPTIMOD-FM, set the filter to O...
  • Page 57 When operating in Half-Cosine mode, the composite limiter produces somewhat less brightness but does not compromise stereo imaging. Be- cause this mode produces lower subjective distortion, Orban’s factory programmers prefer the sound of the Half-Cosine mode. In either mode, the baseband output is overshoot compensated and bandlimited to 53 kHz, unlike conventional composite clippers.
  • Page 58 2-20 INSTALLATION ORBAN MODEL 5518 We recommend setting the control to “0.” This sets the limiter threshold to be the same as the analog and digital reference levels, which corre- spond to 100% baseband tone modulation. This setting only removes overshoots.
  • Page 59 2-21 5518-FM DIGITAL INSTALLATION 28. Program Tally Outputs. [Skip this step if you do not wish to use the tally outputs.] See step 6 on page 2-4 for wiring instructions. You can program the two tally outputs to indicate a number of different opera- tional and fault conditions.
  • Page 60 2-22 INSTALLATION ORBAN MODEL 5518 29. Activate the 5518’s ITU-R BS412-9 multiplex power controller (optional). [Skip this step if ITU-R BS412 is not enforced in your country. At the time of this writing, it is only enforced in certain European countries. If your country does not enforce ITU-R BS412, set the ITU412-9 control to OFF.]...

  • Page 61: Analog And Digital I/O Setup

    2-23 5518-FM DIGITAL INSTALLATION only for reference because QUICK SETUP has enabled them to set up the 5518 cor- rectly. Analog and Digital I/O Setup For the following adjustments, use the appropriately labeled soft button to choose the parameter to be adjusted. To change a parameter (like an output level), it is usu- ally necessary to hold down the soft button while turning the knob.
  • Page 62 2-24 INSTALLATION ORBAN MODEL 5518 B) Set PILOT LVL to 9%. 1 LV or If you have to reduce the setting of the composite level (C 2 LV) control to accommodate overshoots in the transmission path following the 5518 (including the transmitter), you may have to increase...
  • Page 63 2-25 5518-FM DIGITAL INSTALLATION 6. Set analog output and configuration level. (Usually, the analog output will not be used and you can skip this step. However, the analog output can be useful in some facilities. See the notes in step 8 on page 2-13.) A) Navigate to Setup >...
  • Page 64 2-26 INSTALLATION ORBAN MODEL 5518 put level for the equivalent of 90% modulation, not counting the subcar- riers. (90% + 20% = 110%.) The pilot injection will thus be about 8% Setup > S TEREO modulation instead of the desired 9%. Adjust the >...

  • Page 65: Automation Using The 5518'S Internal Clock

    2-27 5518-FM DIGITAL INSTALLATION The 5518 can also truncate its output word length to 20, 18, 16 or 14 bits. The 5518 can add dither for input material that is insufficiently dithered for these lower word lengths (see the next step). G) Adjust D to I or O...
  • Page 66 2-28 INSTALLATION ORBAN MODEL 5518 b) Enter seconds slightly ahead of the correct time. c) Wait until the entered time agrees with the correct time. Then press the NTER button to set the clock. B) Press the S button. a) Set today’s date, using the days, month, and year buttons.
  • Page 67 2-29 5518-FM DIGITAL INSTALLATION D) For events that occur on a daily or weekly schedule: a) Use the Prev and Next buttons to move the cursor the each day of the week in turn, and use the rotary encoder to turn the day on or off. You can program the event to occur on as many days of the week as you wish.

  • Page 68: Security And Passcode Programming

    2-30 INSTALLATION ORBAN MODEL 5518 4. To edit an existing event: A) Press the V button. VENT B) Select Next/Prev to sort by either the event times or event tasks. C) Turn the knob until you see the event you wish to edit.

  • Page 69: To Create A Passcode

    2-31 5518-FM DIGITAL INSTALLATION A single Level 1 (All Access) passcode, known only to the engineer responsible for the technical operation of the station, is usually appropriate for a 5518 installation. Starting with version 1.2.1 software, there is a default All-Access passcode: 1234. This allows PC Remote users to connect to the 5500 if they forgot to add a passcode from the 5500’s front panel.

  • Page 70: To Delete A Passcode

    2-32 INSTALLATION ORBAN MODEL 5518 If the front panel is already password protected, you can only access this screen by entering a passcode with A privileges. CCESS B) Turn the knob until you see the passcode you want to edit.

  • Page 71: To Unlock The Front Panel

    2-33 5518-FM DIGITAL INSTALLATION C) Press the Escape button to leave the Security menu. To Unlock the Front Panel: A) On the 5518 front panel, operate any button or the knob. The P screen will appear. ASSCODE B) Enter a passcode using the four soft buttons. The 5518 functionality that you can access depends on the security level of the passcode that you entered.

  • Page 72: Ethernet

    2-34 INSTALLATION ORBAN MODEL 5518 Administering the 5518 through its Serial Port or Ethernet Connecting to the 5518’s Ethernet Port or Serial Port via a Ter- minal Program on a PC You can connect a terminal emulation application to the 5518’s Ethernet or Serial ports via TCP/IP, port 23 (which is the standard Telnet port and the 5518 factory de- fault).

  • Page 73: Direct Control Using Putty

    2-35 5518-FM DIGITAL INSTALLATION screen. A serial connection uses a fixed IP address: 192.168.168.101. To control the 5518 directly through its Serial or Ethernet port, you can use the free- ware terminal emulation application PuTTY. If you wish to automate control, download Plink.

  • Page 74: Automated Control Using Putty/Plink

    2-36 INSTALLATION ORBAN MODEL 5518 ent or by placing them within batch files. Then process them with a scriptable Tel- net/SSH client that supports this operation, such as PuTTY, along with its companion command-line interpreter, Plink. You can also use netcat.exe. Below, we provide in- structions for both PuTTY/Plink and Netcat.

  • Page 75: Automated Control Using Netcat

    2-37 5518-FM DIGITAL INSTALLATION Automated Control Using Netcat Only one utility is required to use this method: netcat.exe. This is available as a free download. Google “netcat.” This method is scripted with a .cmd file and calls a .txt file. ...
  • Page 76 2-38 INSTALLATION ORBAN MODEL 5518 [no error message is issued] XXXXXXX = the preset name; In the above table: PASSCODE = any valid passcode.  If a non-existent control value and/or an invalid passcode is entered, the 5518 will ignore the command. If a non-existent preset name is entered, your Optimod will return an error message to indicate that the preset you entered does not ex- ist.
  • Page 77 2-39 5518-FM DIGITAL INSTALLATION PASSCODE = ANY VALID PASSCODE.  This command is useful when a station has two transmission chains (typically main and backup) that require different diversity delay settings. We recommend first using 5518 PC Remote to set the correct delays for the main and backup chains.

  • Page 78: Remote Control Interface Programming

    2-40 INSTALLATION ORBAN MODEL 5518 remote contact closure 2 [active][inactive] remote contact closure 3 [active][inactive] remote contact closure 4 [active][inactive] remote contact closure 5 [active][inactive] remote contact closure 6 [active][inactive] remote contact closure 7 [active][inactive] remote contact closure 8 [active][inactive]...
  • Page 79 2-41 5518-FM DIGITAL INSTALLATION 1. Navigate to Setup > Next > N & R > R ETWORK EMOTE EMOTE NTERFACE 2. Program one or more remote control interfaces. A) Navigate to the desired Remote Interface button (1 through 8) by repeatedly pressing the Next button.

  • Page 80: Networking And Remote Control

    2-42 INSTALLATION ORBAN MODEL 5518 Use this function to periodically re-sync the 5518’s internal clock to your station’s master clock.  Reset Clock to Midnight: Resets the clock to 0:00:00. You can use this function to periodically re-sync the 5518’s internal clock to your station’s master clock.
  • Page 81 2-43 5518-FM DIGITAL INSTALLATION b) Use the Next and Prev keys to move the cursor in turn to each digit in the subnet mask. Use the knob to set the digit to the desired value. Repeat until you have selected all the numbers in the subnet mask assigned by your network administrator c) Press the S soft button to confirm your setting.

  • Page 82: Synchronizing 5518 To A Network Time Server

    You will need two modems and two available phone lines, one of each for your PC and your 5518. Orban Customer Service supports only the 3Com/U.S. Robot- ics® 56kbps fax modem EXT on the 5518 side of your connection, although other 56kbps modems will often work OK.
  • Page 83 2-45 5518-FM DIGITAL INSTALLATION  Select T if the 5518 is behind a firewall that does not pass UPD packets. T selects the Time Protocol as described in the standard RFC868. This method uses TCP on port 37.  Select SNTP if your network timeserver supports the Simple Network Time Protocol as described in standard RFC1769.
  • Page 84 2-46 INSTALLATION ORBAN MODEL 5518 The timeserver IP Address Screen appears. a) Use the Next and Prev keys to move the cursor in turn to each digit in the IP address. Use the knob to set the digit to the desired value. Repeat until you have selected all the numbers in the desired IP address.

  • Page 85: Installing 5518 Pc Remote Control Software

    This section briefly summarizes the procedure for installing 5518 PC Remote soft- ware on existing 5518s. If required, you will find more detailed instructions in the .pdf file automatically installed on your computer by Orban’s installer program, Setup5518_x.x.x.x.exe, where “x.x.x.x” represents the software version you are installing.

  • Page 86: Installing The Necessary Windows Services

    5518’s serial port. (These services are also used to upgrade your 5518’s firmware when updates are available from Orban.) The exact process will vary, depending on how you wish to set up the communications. That is: ...

  • Page 87: Running The Orban Installer Program

     You might have obtained the automatic installer application from some other source than Orban’s CD, like Orban’s ftp site or another computer on your net- work. If so, just run the application and follow the on-screen instructions. ...

  • Page 88: Conclusion

    5518 questions, please contact Orban Customer Service: phone: +1 510 351-3500 email: custserv@orban.com For details on your new 5518 software, from new features to operational sugges- tions, refer to our FTP site (ftp.orban.com/5518).

  • Page 89: Appendix: Setting Up Serial Communications

    Windows Vista and 7, although we recommend using Ethernet connections with Vista or 7. Note that the screen shots were prepared us- ing Orban’s Optimod-FM 8300 but apply equally well to the 5518. Preparing for Communication through Null Modem Cable 1.
  • Page 90 2-52 INSTALLATION ORBAN MODEL 5518 If you cannot access the Internet after making a Direct or Modem connection, you will have to reconfigure certain networking parameters in Windows. Please see You Cannot Access the Internet After Making a Direct or Modem Connection of the 5518 on page 5-6.
  • Page 91 2-53 5518-FM DIGITAL INSTALLATION i) In the drop-down box, select the serial port you will be using to make the connection. j) Click “Next.” k) Select either “For all users” or “Only for myself.” The correct setting depends on how your network and security are configured.
  • Page 92 2-54 INSTALLATION ORBAN MODEL 5518 o) Click “Yes.” B) Edit your new Direct Connection properties: a) Click “Settings.” b) Click the “General” tab. c) Select the device you set up in step (i) on page 2-53. This will usually “Com-...
  • Page 93 2-55 5518-FM DIGITAL INSTALLATION e) Set “Maximum speed (bps)” “115200.” f) Check “Enable hardware flow con- trol.” g) Make sure that all other boxes are not checked. h) Click “OK.” i) Select the Networking tab. j) Make sure that “PPP: Windows 95/98/NT 4/2000, Internet”...

  • Page 94: Connecting Using Windows Xp Direct Serial Connection

    2-56 INSTALLATION ORBAN MODEL 5518 2. Launch an existing Windows 2000 Direct connection. Once you have set up a “connection” specifying Direct Connect in the 5518 PC Remote application (see To set up a new connection on page 3-9), choosing this connection from 5518 PC Remote automatically opens a Windows Direct Connec- tion to your 5518.
  • Page 95 2-57 5518-FM DIGITAL INSTALLATION c) Give your 5518 a name (e.g., “KABC”) by entering this name in the “5518 Alias” field. d) If you wish to have 5518 PC Remote remember password this Optimod, enter the password in the “Password“ field. e) Select “Serial Connection.”...
  • Page 96 2-58 INSTALLATION ORBAN MODEL 5518 k) Type in a name for your Connection such “Connection to 5518.” l) Click “Finish.” m)Click “Yes.” B) Edit your Direct Connection properties: a) Click “Settings.”...
  • Page 97 2-59 5518-FM DIGITAL INSTALLATION b) Click the “General” tab. c) Select the device you set up in step (i) on page 2-57. This will usually be “Communications cable between two computers (COM1).” d) Click “Configure.” e) Set the “Maximum Speed (bps)” to 115200.
  • Page 98 2-60 INSTALLATION ORBAN MODEL 5518 i) Select the Networking tab. j) Make sure that “PPP: Windows 95/98/NT 4/2000, Internet” appears in the “Type of dial-up server I am calling” field. k) Make sure that “Internet Protocol (TCP/IP) is checked. You may leave “File...

  • Page 99: Connecting Using Windows 7 Direct Serial Connection

    2-61 5518-FM DIGITAL INSTALLATION 3. To change the properties of an existing connection: Right-click the connection in the “connection List” window and choose “Proper- ties.” The “Connection properties” window opens (see page 2-52). Connecting Using Windows 7 Direct Serial Connection: You must install the Windows 7 direct serial connection as a modem device using the Modem setup procedures as shown in the steps below.
  • Page 100 2-62 INSTALLATION ORBAN MODEL 5518 B) In the Phone and Modem applet, click on the Mo- dems tab and click “Add.” You need ad- ministrator's rights to do this. If UAC comes up, provide the relevant creden- tials and pro- ceed.
  • Page 101 2-63 5518-FM DIGITAL INSTALLATION D) The Install New Modem window will appear. a) Select Communications cable between two computers. b) Proceed to next step by clicking on the NEXT button. E) Select the Serial com port to which the NULL cable is con- nected.
  • Page 102 2-64 INSTALLATION ORBAN MODEL 5518 F) At the Modem installation is finished window, click FINISH to complete the in- stallation. G) Once you are back at the Phone and Modem win- dow, you will see your newly installed communi- cation cable attached to the serial com port that you specified earlier.
  • Page 103 2-65 5518-FM DIGITAL INSTALLATION A) Go to the Network and Sharing Center and click on Set up a new connection or network link. B) In the Choose a connection op- tion window, select Set up a dial-up connection.
  • Page 104 2-66 INSTALLATION ORBAN MODEL 5518 C) If you are asked Which mo- dem do you want to use?, se- lect Communications cable between com- puters/modem. This only query will open appear if you have configured more than modem device. D) When prompted to “Type...
  • Page 105 2-67 5518-FM DIGITAL INSTALLATION Windows will emit a message stating The connection is ready for use. How- ever, you must to configure some of the PPP settings before you can make a connection to your Optimod Although you did not specifically install any-...
  • Page 106 2-68 INSTALLATION ORBAN MODEL 5518 B) In the Network adapter window, right-click the Direct Serial PPP icon and click on the properties. You need ad- ministrator rights to pro- ceed from here. If UAC comes up, pro- vide the rele-...
  • Page 107 2-69 5518-FM DIGITAL INSTALLATION c) If it is not correct, reset it to 115200 bps. d) Click OK to close the window. e) Click OK to dismiss the Properties window. f) Restart your computer. Restarting should ensure that the bps setting is saved. G) Select the Networking tab.
  • Page 108 2-70 INSTALLATION ORBAN MODEL 5518 H) In the Advance TCP/IP Set- tings window, click on the Advance button. a) Unselect default gateway remote network. b) Click OK to close this window. This prevents Win- dows 7 from rout- ing all networking...

  • Page 109: Preparing For Communication Through Modems

    You will need two modems and two available phone lines, one of each for your PC and your 5518. Reminder: Orban supports only the 3Com / U.S. Robotics® 56kbps fax modem EXT on the 5518 side (although other 56kbps modems will often work OK).
  • Page 110 2-72 INSTALLATION ORBAN MODEL 5518 b) On your PC, click “Start / Settings / Control Panel / Phone and Modem Op- tions.” c) Click the “Modems” tab. d) Verify that your modem appears in the list available under “The following Modems are installed.”...
  • Page 111 2-73 5518-FM DIGITAL INSTALLATION g) Select “Dial-up to private network.” h) Click “Next.” i) Enter the phone number of the modem connected to the 5518 that you are set- ting up. j) Click the “Next” button. k) Select either “For all users” or “Only for myself.”...
  • Page 112 2-74 INSTALLATION ORBAN MODEL 5518 m)Click the “Next” but– ton. n) Type in a name for your Connection such “Connection 5518 – Modem.” o) Click the “Finish” but– ton. p) Click “Yes.” D) Edit your new Direct Connection properties: a) Click “Settings.”...
  • Page 113 2-75 5518-FM DIGITAL INSTALLATION b) Click the “General” tab. c) In the “Connect using” field, select the modem you will be using to make the connection on the PC side. d) Click “Configure.” e) Set “Maximum speed (bps)” “115200.” f) Check “Enable hard-ware flow con- trol.”...
  • Page 114 2-76 INSTALLATION ORBAN MODEL 5518 k) Select the Networking tab. l) Make sure that “PPP: Windows 95 / 98 / NT 4 / 2000, Internet” ap- pears in the “Type of dial-up server I am calling” field. m)Make sure that “Inter- net Protocol (TCP/IP) is checked.

  • Page 115: Connecting Using Windows Xp Modem Connection

    2-77 5518-FM DIGITAL INSTALLATION 3. To change the properties of an existing connection: Right-click the connection in the “connection List” window and choose “Proper- ties.” The “Connection properties” window opens (see page 2-72). Connecting using Windows XP Modem Connection 1. Add and configure modem for Windows XP: Skip this step if your modem is already configured and working.
  • Page 116 2-78 INSTALLATION ORBAN MODEL 5518 If you are using an external modem, connect the modem to a serial port on your PC and make sure the modem is connected to a working phone line. b) On your PC, click “Start / Settings / Control Panel / Phone and Modem Op- tions.”...
  • Page 117 2-79 5518-FM DIGITAL INSTALLATION e) Click “Add.” The Windows New Connection Wizard starts up. f) Select “Serial Connection.” g) Click the “Add” button. h) Select “Dial-up to private network.” i) Click “Next.” j) Enter the phone number of the mo- dem connected to the 5518 you are setting up.
  • Page 118 2-80 INSTALLATION ORBAN MODEL 5518 n) Click “Yes.” D) Edit your new Direct Con- nection properties: a) Click “Settings.” b) Click the “General” tab. c) Select the modem you will be using to make the connection on the PC side.
  • Page 119 2-81 5518-FM DIGITAL INSTALLATION e) Set “Maximum speed (bps)” “115200.” f) Check “Enable hardware flow con- trol.” g) Check “Enable modem error control.” h) Check “Enable modem compression.” i) Make sure that no other box is checked. j) Click “OK.” k) Select the Networking tab.

  • Page 120: Updating Your 5518'S Software

    2-82 INSTALLATION ORBAN MODEL 5518 You can connect by selecting the desired con- nection from the drop-down list in the C ONNECT menu. You can also connect by double-clicking the connection in the “Connection List” window. If the connection is successful, a dialog bubble will appear on the bottom right hand corner of the screen verifying your connection.
  • Page 121 2-83 5518-FM DIGITAL INSTALLATION 4. Update your 5518. A) Attempt to initiate communication to your 5518 via your connection. See To initiate communication on page 3-10. 5518 PC Remote will automatically detect that the 5518 software version on your 5518 is not the same as the version of 5518 PC Remote. PC Re- mote will then offer to update your 5518 automatically.

  • Page 122: Snmp Support

    2-84 INSTALLATION ORBAN MODEL 5518 SNMP Support The SNMP (Simple Network Management Protocol) features allow you to monitor your Optimod’s status and to send Alarm notifications via your Optimod’s Ethernet connection to your network. It is beyond the scope of this manual to provide a gen- eral explanation of how SNMP works.

  • Page 123: Snmp Default Settings

    Secondary Manger (Alarm) Port: 162 SNMP Features Get/Query:  Station Name  System Diagnostics Orban (walks through all of the “get” commands and dis- plays their status.)  Primary and Secondary Manager IP  Primary and Secondary Manager Port ...
  • Page 124 2-86 INSTALLATION ORBAN MODEL 5518 Traps/Alert:  Analog Input Silent  Analog Input Active (selected as input source)  AES Input Silent  AES Error  Digital Input Active (The digital input is selected as the input source)

  • Page 125: Section 3 Operation

    5518-FM DIGITAL OPERATION Section 3 Operation 5518 Front Panel  Screen Display labels the four soft buttons and provides control-setting infor- mation.  Screen Contrast button adjusts the optimum viewing angle of the screen dis- play.  Four Soft buttons provide access to all 5518 functions and controls. The func- tions of the soft buttons change with each screen, according to the labels at the bottom of each screen.

  • Page 126: Signal Processing

    OPERATION ORBAN MODEL 5518  Input meters show the peak input level applied to the 5518’s analog or digital inputs with reference to 0 = digital full-scale. If the input meter’s red segment lights up, you are overdriving the 5518’s analog to digital converter, which is a very common cause of audible distortion.

  • Page 127: To Create Or Save A User Preset

    5518-FM DIGITAL OPERATION To Create or Save a User Preset Once you have edited a preset, you can save it as a user preset. The 5518 can store an indefinite number of user presets, limited only by available memory. However, most 5518 users will only require one user preset, which reflects the customization they did during initial setup.

  • Page 128: Itu-R Multiplex Power Controller

    OPERATION ORBAN MODEL 5518 pear. After you have saved the preset, reverse the edit and save the pre- set again. ITU-R Multiplex Power Controller The ITU-R recommends that the power in the composite baseband signal (including the pilot tone), integrated over any 60-second interval, not exceed the power in a sinewave that modulates the FM carrier to 19 kHz (25.3% modulation re ±75 kHz...

  • Page 129: Multiplex Power Threshold

    5518-FM DIGITAL OPERATION compensate for overshoots in the signal path upstream from the 5518, preventing excessive reduction of the multiplex power. The ITU412 control is found in the M > S ODIFY TEREO NCODER screen. Power control is applied to all outputs, not just the composite output. Multiplex Power Threshold The 5518 provides a means to limit the integrated multiplex power to the ITU stan- dard by a closed-loop technique.

  • Page 130: Ssb Stereo Encoder Operation

    OPERATION ORBAN MODEL 5518 SSB Stereo Encoder Operation Starting with version 1.2.1, the 5518 allows its stereo encoder’s stereo subchannel modulator to operate in an experimental compatible single sideband/vestigial side- band mode. Please note that to control modulation peaks successfully in SSB/VSB mode, you must activate the 5518’s composite limiter.

  • Page 131: Test Modes

    5518-FM DIGITAL OPERATION The group delay of the phase-linear filters needed to create the SSB/VSB waveform and the audio delay in the look-ahead limiter together add approximately 12 ms to the delay of the stereo encoder. When diversity delay is applied to the 5518’s com- posite output, the 5518 adjusts the delay automatically so that it is constant regard- less of mode.

  • Page 132: Using The 5518 Pc Remote Control Software

    Before running 5518 PC Remote, you must have installed the appropriate Windows communications services on your computer. By default, the installer installs a short- cut to 5518PC.exe on your desktop and in your Start Menu under Orban\5518.

  • Page 133: To Set Up A New Connection

    5518-FM DIGITAL OPERATION 5518 PC Remote can control only one 5518 at a time, but it can readily switch be- tween several 5518s. 5518 PC Remote has a built-in “address book” that allows it to select and connect to:  any 5518 on the same network as the PC, ...

  • Page 134: To Initiate Communication

    “Loading system files, please wait.” When run, the Orban PC Remote software installer makes copies of all 5518 fac- tory preset files on your local hard drive. The PC Remote software reads these files to speed up its initialization.

  • Page 135: To Recall A Preset

    3-11 5518-FM DIGITAL OPERATION To recall a preset: A) Choose Recall P from the F menu to bring up the O RESET RESET dialog box. B) Click the desired preset within the dialog box to select it. C) Double-click the desired preset or select it and click the Recall P RESET button to put it on-air.

  • Page 136: To Restore Archived Presets, System Files, And Automation Files

    The encryption options prevent archived presets, system files, and auto- mation files from being restored if the user does not have the password used for the encryption. There is no “back door”— Orban cannot help you to decrypt a preset whose password is unknown.

  • Page 137: To Modify Input /Output And System Setup

    3-13 5518-FM DIGITAL OPERATION C) To restore a single user preset: a) Set the field to a user preset file type (*.orb5518user). ILES b) Select the desired preset in the dialog box. c) Click the button. ESTORE D) To restore all the user presets from a specific location: a) Set the field to a user preset file type (*.orb5518user, *.orbu) ILES...

  • Page 138: To Group Multiple 5518S

    3-14 OPERATION ORBAN MODEL 5518 B) Click the N VENT to create a new event Controls to set the event type and time are available on the right hand side of the dialog box. C) Check the E NABLE UTOMATION check box at the top of the dialog box to en- able automation.

  • Page 139: Multiple Installations Of 5518 Pc Remote

    5518 PC Remote (usually \Program Files\Orban\5518). The folder has the same name as the Alias name. Once you establish the initial connection to the 5518, all presets for that 5518 are auto- matically copied to the Alias folder;...
  • Page 140 3-16 OPERATION ORBAN MODEL 5518 from an older version of 5518 PC Remote, it will refuse to connect and will emit an error message regarding incompatible versions. If you decide to install the new software to a different location on your PC, new Ali- ases created using the new software will not be located in the same place as the old Aliases.

  • Page 141: Section 4 Maintenance

    5518-FM DIGITAL MAINTENANCE Section 4 Maintenance Routine Maintenance The 5518 uses highly stable analog and digital circuitry throughout. Recommended routine maintenance is minimal. 1. Periodically check audio level and gain reduction meter readings. Become familiar with normal audio level meter readings, and with the normal performance of the G/R metering.

  • Page 142: Subassembly Removal And Replacement

    MAINTENANCE ORBAN MODEL 5518 Subassembly Removal and Replacement See page 6-27 for the Circuit Board Locator and Basic Interconnections diagram. 1. Removing the Top Cover: To access any internal board (including the display assembly), you must remove the top cover.
  • Page 143 5518-FM DIGITAL MAINTENANCE B) Using a deep hex nut driver (preferred), a small crescent wrench, or a pair of slip-joint pliers (in an emergency), remove the nuts and lockwashers holding the four BNC connectors to the chassis. The Composite/SCA daughterboard can now be removed. 4.
  • Page 144 EMI that violates FCC and/or CE regulations. If the power supply fails, please contact Orban Customer Service (custserv@orban.com) to obtain an exact replacement.
  • Page 145 5518-FM DIGITAL MAINTENANCE 9. Replacing the Composite/SCA Daughterboard Referring to step 3, follow the instructions in reverse. 10. Replacing the Front Panel Assembly: A) Set the front panel, face down, on a soft cloth to prevent scratches. B) Lightly reattach the bottom and top circuit boards by mating the four plugs and jacks.

  • Page 146: Field Audit Of Performance

    MAINTENANCE ORBAN MODEL 5518 Field Audit of Performance Required Equipment:  Ultra-low distortion sine-wave oscillator/THD analyzer/audio voltmeter With verified residual distortion below 0.01%. Audio Precision System One, or similar high-performance system. The NAB Broadcast and Audio System Test CD is an excellent source of test signals when used with a high-quality CD player.
  • Page 147 The power supply is a module. In case of any power supply failure, the entire supply must be replaced by an exact replacement (available from Orban Service). Attempts to repair the supply on a component level and/or to replace the supply with a non-approved supply may compromise your 5518’s compliance with the...
  • Page 148 MAINTENANCE ORBAN MODEL 5518 DI REF VU ................–15.0 dBFS R CH BAL ..................0.0 dB c) Navigate to Setup > I/O C > A . Set controls as follows: ALIB ALIB AO 100% ................. +10.0 dBu AO PRE-E ....................Flat AO SOURCE ..................FM d) Navigate to Setup >...
  • Page 149 5518-FM DIGITAL MAINTENANCE C) Connect the audio voltmeter to the Left Analog Output. D) Adjust output trim VR301 to make the meter read +10.0 dBu. (0 dBu = 0.775V rms.) Verify a frequency reading of 400 Hz. E) Verify THD+N reading of <0.03% (<0.01% typical) using a 22 kHz low pass fil- ter in the distortion analyzer.
  • Page 150 4-10 MAINTENANCE ORBAN MODEL 5518 H) Repeat steps (C) through (G) for the right channel. 5. Check distortion performance of Analog I/O. A) Verify 5518 software controls are set to their default settings. (Refer to page 4-7.) B) Be sure you are still in B mode [see step (3.F)] and set the B...
  • Page 151 4-11 5518-FM DIGITAL MAINTENANCE D) Set the I to D NPUT IGITAL E) Connect the digital source generator to the AES3 Digital Input XLR connector of the 5518. F) Set the frequency of the digital source generator to 400 Hz and its output level to 18 dB below full scale.
  • Page 152 4-12 MAINTENANCE ORBAN MODEL 5518 Connect the reference generator to one input and the 5518’s digital out- put to the other input. If correct synchronization is occurring, you should see an essentially stationary (although complex-looking) Lissajous pattern as opposed to one that precesses slowly either left or right. This should be true at any combination of input and output sample frequencies and a thorough test will test every permutation.
  • Page 153 4-13 5518-FM DIGITAL MAINTENANCE E) Navigate to Setup > S TEREO NCODER F) Set the C control to make the stereo monitor read 100% total modu- lation. G) Navigate to Setup > T to access the 5518’s tone oscillator parameters. H) Measure the L–R level on the stereo monitor at several frequencies, in units of dB below 100% modulation.
  • Page 154 4-14 MAINTENANCE ORBAN MODEL 5518 B) You can test the RS-232 port for functionality by verifying that you can con- nect to a PC through a null modem cable. See Networking and Remote Con- trol starting on page 2-42 (in particular, step 4 on page 2-44).

  • Page 155: Section 5 Troubleshooting

    5518 must have a competently designed preemphasis limiter, set to match the FM preemphasis standard in your country, must have a non-overshooting peak limiter, and must band-limit their output to 17 kHz or below. Orban OPTIMOD- FM processors fulfill these requirements.

  • Page 156: Poor Peak Modulation Control

    Many commercial monitors have this problem, but most of these problem units can be modified to indicate peak levels accurately. Orban uses the Belar “Wizard” series of DSP-based monitors internally for testing, because these units do not have this difficulty.

  • Page 157: Whistle On Air, Perhaps Only In Stereo Reception

    5518-FM DIGITAL TROUBLESHOOTING You may be overdriving the 5518’s left/right protection limiter and/or composite lim- iter. It is unwise to do more than 3 dB of gain reduction in the protection limiter or to set the C control higher than 1.0 .

  • Page 158: Shrill, Harsh Sound

    First, verify that a problem really exists by using a second frequency-measuring de- vice and/or verifying the problem with a monitoring service. If the problem is real, contact Orban Customer Service for a crystal replacement; there is no frequency trim available.

  • Page 159: Connection Issues Between The 5518 And A Pc, Modem, Or Network

    5518-FM DIGITAL TROUBLESHOOTING Connection Issues between the 5518 and a PC, Modem, or Net- work  User Interface Slowdown: The more user presets you make, the more slowly the 5518 will respond to front-panel commands. Delete any user presets you do not need.

  • Page 160: You Cannot Access The Internet After Making A Direct Or Modem Connection To The 5518

    TROUBLESHOOTING ORBAN MODEL 5518 A) Ensure that the modem cables and phone lines are connected properly. B) Check that you have entered the correct phone number for connection. C) Check that you have entered the passcode correctly on the 5518, and the pass- code has also been entered correctly on your PC.
  • Page 161 5518-FM DIGITAL TROUBLESHOOTING B) In the “Network Connections” window, right-click “5518 - Direct” and choose “Properties.” C) The “Properties” window opens for “5518 - Direct D) Click the “Networking” tab. E) Set “Type of dial-up server I am calling” to “PPP: Windows 95/98/NT4/2000, Internet.”...

  • Page 162: Troubleshooting Windows 2000 Modem Connect

    TROUBLESHOOTING ORBAN MODEL 5518 .” b) Right click the name of your connection and access “P ROPERTIES ” ” button. c) Go to the “G ENERALS and select the “C ONFIGURE d) Set the M ) to 115200. AXIMUM PEED e) Select OK and try your connection again.

  • Page 163: Troubleshooting Windows Xp Direct Connect

    5518-FM DIGITAL TROUBLESHOOTING O) Click the “Advanced…” button on the “Internet Protocol (TCP/IP)” Window. P) In the “Advanced TCP/IP Settings” select the “General” Tab; make sure that no check boxes are checked. Q) Click “OK” to dismiss the “Advanced TCP/IP Settings” window. R) Click “OK”...

  • Page 164: Troubleshooting Windows Xp Modem Connect

    5-10 TROUBLESHOOTING ORBAN MODEL 5518 N) Click “OK” to dismiss the window whose name is your new connection. O) Click “Cancel” to dismiss the “Connect [nnnn]” dialog box P) Restart your computer. This resets the serial port and reduces the likelihood that you will en- counter problems connecting to the 5518.

  • Page 165: Troubleshooting Ic Opamps

    Know the serial number of your 5518  this is printed on the rear panel of the unit. Please check Orban’s website, www.orban.com, for Frequently Asked Questions and other technical tips about 5518 that we may post from time to time. Manuals (in .pdf form) and 5518 software upgrades will be posted there too —...

  • Page 166: Shipping Instructions

    Returned units will be returned C.O.D. if the unit is not under warranty. Orban will pay return shipping if the unit is still under warranty. In all cases, the customer pays transportation charges to the factory (which are usually quite nominal).

  • Page 167: Section 6 Technical Data

    5518-FM DIGITAL TECHNICAL DATA Section 6 Technical Data Specifications It is impossible to characterize the listening quality of even the simplest limiter or compressor based on specifications, because such specifications cannot adequately describe the crucial dynamic processes that occur under program conditions. There- fore, the only way to evaluate the sound of an audio processor meaningfully is by subjective listening tests.

  • Page 168: Installation

    TECHNICAL DATA ORBAN MODEL 5518 Installation Analog Audio Input Configuration: Stereo. Impedance: >10k load impedance, electronically balanced Nominal Input Level: Software adjustable from –9.0 to +13.0 dBu (VU). Maximum Input Level: +27 dBu. Connectors: Two XLR-type, female, EMI-suppressed. Pin 1 chassis ground, Pins 2 (+) and 3 electronically balanced, floating and symmetrical.
  • Page 169 5518-FM DIGITAL TECHNICAL DATA Digital Audio Output Configuration: Stereo per AES3 standard. Output configured in software as flat or pre- emphasized to the chosen processing preemphasis (50µs or 75µs), with or without J.17 preemphasis. Sample Rate: Internal free running at 32, 44.1, 48, 88.2 or 96 kHz, selected in software. Can also be synced to the AES3 digital input at 32, 44.1, 48, 88.2 or 96 kHz, as config- ured in software.
  • Page 170 TECHNICAL DATA ORBAN MODEL 5518 Maximum Load Capacitance: 0.047 µF (0 source impedance). Maximum cable length of 100 feet/30 meters RG–58A/U. Filtering: RFI filtered. Subcarrier (SCA) Inputs Configuration: Two subcarrier inputs sum directly into composite baseband outputs; COMPx LVL control settings have no effect on the absolute subcarrier levels.

  • Page 171: Circuit Description

    RFI/EMI: Tested according to Cenelec procedures. FCC Part 15 Class A device. Shipping Weight: 10 lbs / 4.6 kg Warranty Two Years, Parts and Service: Subject to the limitations set forth in Orban's Standard Warranty Agreement. Because engineering improvements are ongoing, specifications are subject to change with- out notice.

  • Page 172: Control Circuits

    DSP code download has finished. If you hear a brief audio mute on air and you know that its input was not interrupted, you can assume that the 5518 has rebooted for some reason. Be prepared to convey this fact to Orban cus- tomer service if you call for technical assistance.

  • Page 173: User Control Interface And Lcd Display Circuits

    5518-FM DIGITAL TECHNICAL DATA User Control Interface and LCD Display Circuits The user control interface enables the user to control the 5518’s functionality. A rear panel GPI connector allows optically isolated remote control of certain functions, such as recalling presets, via contact closure. An RS-232 serial port and an Ethernet port allow you to connect a modem or computer to the 5518.

  • Page 174: Input Circuits

    TECHNICAL DATA ORBAN MODEL 5518 3. LED Meter Circuits Located on display board The meter LEDs are arranged in an 8x16 matrix, in rows and columns. Each row of LEDs in the matrix has a 1/8 duty cycle ON time. The rows are multi- plexed at a fast rate so that the meters appear continuously illuminated.
  • Page 175 5518-FM DIGITAL TECHNICAL DATA  solder pads available in the PC board to accept an optional 600 termination load [R201] on the input signal if the user wishes to install one.) A conven- tional three-opamp instrumentation amplifier (IC201 and associated circuitry) receives the input signal.

  • Page 176: Output Circuits

    6-10 TECHNICAL DATA ORBAN MODEL 5518 The input reference waveform is converted to a square wave via IC505 and asso- ciated circuitry, which implement a comparator with hysteresis. IC1103 is a CPLD (complex programmable logic device) that accepts the reference square wave.
  • Page 177 6-11 5518-FM DIGITAL TECHNICAL DATA differential output of the D/A converter into single-ended form. These com- ponents apply a 3 order lowpass filter to the differential signal from the D/A. This filter does not induce significant overshoot of the processed audio, which would otherwise waste modulation.

  • Page 178: Dsp Circuit

    During system initialization, the SC520 queries the DSP hardware about its opera- tional status and will display an error message on-screen if the DSP fails to initialize normally. Please note any such messages and be ready to report them to Orban Cus- tomer Service.

  • Page 179: Power Supply

    Because of safety and EMI suppression requirements in the power supply, there are no user-serviceable parts in it. In case of failure, replace the entire supply with an Orban-supplied replacement (Orban part number 29270.000.01.1), which ensures that your 5518 will continue to meet all regulatory requirements for safety and emissions.
  • Page 180 6-14 TECHNICAL DATA ORBAN MODEL 5518 decibel voltage measurement. 0 dBu = 0.775V RMS. For this application, the dBm-into- 600 scale on voltmeters can be read as if it were calibrated in dBu. digital input disk jockey, an announcer who plays records in a club or on the air...

  • Page 181: Parts List

    Consult the factory if the listing of a part includes the note “selected” or “realignment required.” Orban normally maintains an inventory of tested, exact replacement parts that can be supplied quickly at nominal cost. Standardized spare parts kits are also available.

  • Page 182: Control Board

    6-16 TECHNICAL DATA ORBAN MODEL 5518 Control Board Control Board PART # DESCRIPTION COMPONENT IDENTIFIER 20128.000.01 RESISTOR, 0 Ω, 0805 R21, R46 20128.010.01 RESISTOR, 10 Ω, 0805 R31, R34, R86, R89 20128.022.01 RESISTOR 22 Ω 1% 0805 R5, R6 20128.332.01 RESISTOR, 33.2 Ω, 0805...
  • Page 183 6-17 5518-FM DIGITAL TECHNICAL DATA Control Board PART # DESCRIPTION COMPONENT IDENTIFIER SOT223 24331.033.01 IC VOLTAGE REGULATOR LT1963-3.3 SOT223 24417.000.01 IC OCT D-TYPE FLIPFLOP W/ 24541.000.01 IC SDRAM MT48LC16 TSOP54P U2, U3 24638.000.01 IC, OCTAL BUS TRANS W/3 24654.000.01 IC, PWRST MIC8115 24656.475.01 IC, PWRST MCP120 SOT-23 24900.000.01...

  • Page 184: Combined Input/Output And Dsp (I/O+Dsp) Board

    6-18 TECHNICAL DATA ORBAN MODEL 5518 Combined Input/Output and DSP (I/O+DSP) Board I/O+DSP BOARD PART # DESCRIPTION COMPONENT IDENTIFIER 24421.000.01 IC SN74ALVCH16373DGGR IC802 21139.101.01 CAPACITOR CER 100PF 10% 50V0805 C1221, C1222, C1223, C1224, C1225, C1226 27058.000.01 CONNECTOR BNC RIGHT ANGLE 75Ω...
  • Page 185 6-19 5518-FM DIGITAL TECHNICAL DATA I/O+DSP BOARD PART # DESCRIPTION COMPONENT IDENTIFIER 28093.000.01 OSCILLATOR VCXO 3.3V 27MHz FVXO- IC1101 24337.000.01 IC LOW-DROPOUT VOLT REGULATOR IC1002 1.8V 200m 24772.000.01 IC PIC18LF4420 MICRO CONTROLLER IC1001 24769.000.01 IC 4CHANNEL ASYNCHRONOUS IC503, (IC504, NO, STUFF) CONVERTER 24768.000.01 IC 2CHANNEL ASYNCHRONOUS...
  • Page 186 6-20 TECHNICAL DATA ORBAN MODEL 5518 I/O+DSP BOARD PART # DESCRIPTION COMPONENT IDENTIFIER R1203, R1204 20129.301.01 RESISTOR 301Ω 0805 R510 20129.110.01 RESISTOR 0805 110Ω 1% 1/8W R260, R303, R304, R501, R503, R1217, R1218 (R502, R504 NO STUFF) 20129.475.01 RESISTOR 475Ω 1% 1/8W 0805...
  • Page 187 6-21 5518-FM DIGITAL TECHNICAL DATA I/O+DSP BOARD PART # DESCRIPTION COMPONENT IDENTIFIER 21146.310.01 CAPACITOR 0.01uf 0805 10% 0805 C430, C601, C602, C603, C604, C605, C606, C607, C608, C609, C610, C611, C612, C613, C614, C615, C616, C617, C618, C619, C620, C621, C622, C623, C624, C625, C626, C627, C628, C629, C630, C631, C632, C633, C634, C635, C636, C637, C638, C639,...

  • Page 188: Composite/Sca Daughterboard

    6-22 TECHNICAL DATA ORBAN MODEL 5518 I/O+DSP BOARD PART # DESCRIPTION COMPONENT IDENTIFIER 20129.768.01 RESISTOR 1/8W 1% 768Ω 0805 R225, R226 20129.249.01 RESISTOR 1/8W 1% 249Ω 0805 R255, R256, R257, R258, R259 20129.150.01 RESISTOR 1/8W 1% 150Ω 0805 R253, R254, R507, R508, R509, R1105 20128.499.01...

  • Page 189: Display Board (Back)

    6-23 5518-FM DIGITAL TECHNICAL DATA PART # DESCRIPTION COMPONENT IDENTIFIER 15057.010.01 SPACER, .100" HIGH CR1, CR2, CR3, CR4, CR5, CR6, CR7, CR8, CR9, CR16 15061.005.01 LED MNT, 1 POS'N, .240"HIGH MNTCR10 25106.001.01 LED, YELLOW, T-1, HIGH EFFICIENCY CR11, CR12, CR13, CR14, CR15 LAMP 25106.003.01 LED, RED, T-1, HIGH EFFICIENCY...
  • Page 190 6-24 TECHNICAL DATA ORBAN MODEL 5518 If you intend to replace parts, please read page 6-15. Please note that because sur- face-mount parts are used extensively in the 5518, few parts are field-replaceable. Servicing ordinarily occurs by swapping circuit board assemblies. However, many vulnerable parts connected to the outside world are socketed and can be readily re- placed in the field.
  • Page 191 6-25 5518-FM DIGITAL TECHNICAL DATA...
  • Page 193 6-27 5518-FM DIGITAL TECHNICAL DATA WARNING: INPUT/OUTPUT PARTS SECTION UNDER SHIELD ARE EXPOSED TO AC LINE CONTROL INPUT/OUTPUT+DSP BOARD BOARD POWER SUPPLY DSP SECTION DISPLAY ASSEMBLY...
  • Page 194 6-28 TECHNICAL DATA ORBAN MODEL 5518 CONTROL BOARD PARTS LOCATOR...
  • Page 195 6-29 5518-FM DIGITAL TECHNICAL DATA C44 10UF +3.3V 10.0K 0.1UF SYSTEM_RESET-N (SHT 5) U5 MIC8115TU +3.3V U1B SC520 MR-n PIO14/GPIRQ9 RESET-n PWRGOOD PIO14/GPIRQ9 AC22 GP_RESET GPRESET PRGRESET PRGRESET MCP120-475I/TT 10.0K (SHT 5) 7x 4.75K DACK1-N PIO11/GPDACK1 AF10 DREQ1 PIO7/GPDRQ1 PIO16/GPIRQ7 PIO16/GPIRQ7 PIO17/GPIRQ6 PIO17/GPIRQ6...
  • Page 196 6-30 TECHNICAL DATA ORBAN MODEL 5518 MD[0..31] MA[0..12] U2A MT48LC16 U3A MT48LC16 U1A SC520 MA12 MA12 MD15 MA12 MD31 MA12 DQ15 DQ15 MA11 MA11 MD14 MA11 MD30 MA11 DQ14 DQ14 MD31 MA10 +3.3V MA10 MD13 MA10 MD29 MD31 MA10 A10/AP...
  • Page 197 6-31 5518-FM DIGITAL TECHNICAL DATA +3.3V PCI_AD[0..31] RNET4.7K +3.3V U1C SC520 U10A DP83816AVNG +3.3V PCI_AD31 PCI_AD31 REQ4 AD31 AD31 PCI_AD30 PCI_AD30 REQ3 AD30 AD30 PCI_AD29 PCI_AD29 REQ2 AD29 AD29 PCI_AD28 PCI_AD28 REQ1 AD28 AD28 PCI_AD27 PCI_AD27 AD27 AD27 PCI_AD26 PCI_AD26 AD26 AD26 PCI_AD25...
  • Page 198 6-32 TECHNICAL DATA ORBAN MODEL 5518 PWRGOOD +3.3V (SHT2) +3.3V 100K 100K 100K 0 OHM U1D SC520 (NO-STUFF) 4.75K AF25 AC13 TRIG/TRACE TRIG/TRACE AF23 AD24 BR/TC BR/TC AE21 JTAG_TMS JTAG_TMS AE25 AF21 JTAG_TDI JTAG_TDI AE24 AD21 JTAG_TCK JTAG_TCK AD26 PIO31/RING2-N...
  • Page 199 6-33 5518-FM DIGITAL TECHNICAL DATA +3.3V U10B DP83816AVNG +3.3V +3.3V (NO-STUFF) +3.3V U2B MT48LC16 U3B MT48LC16 U4B E28F128 C201 RESERVED 1.0UF RESERVED RESERVED +3.3V VCCQ VSSQ VDDQ VSSQ VDDQ VSSQ VDDQ VSSQ VDDQ VSSQ VDDQ VSSQ VDDQ VSSQ VDDQ VSSQ VDDQ AUXVDD AUXVDD...
  • Page 200 6-34 TECHNICAL DATA ORBAN MODEL 5518 5500 I/O BOARD: Parts Locator Drawing 32370.000.02.1 (sheet 1 of 1)
  • Page 201 6-35 5518-FM DIGITAL TECHNICAL DATA IRQB- N DSP CONTROL INTERFACE I/O CONTROL INTERFACE 62370.000.02.1_Sheet07.SchDoc 62370.000.02.1_Sheet10.SchDoc IRQB- N DSP _RST- N EXTAL DSP _RST- N IRQB- N DSP _RST- N DSP _RST- N START START START SSI _DO MI SC_CS- N SSI _DO SSI _DO MI SC_CS- N...
  • Page 202 6-36 TECHNICAL DATA ORBAN MODEL 5518 R233 R245 J201 FEMALE L203 C201 3.65K 1.50K FILTER 47PF IC201A L201 R215 0.1% R203 L207 IND 1 K 5%,100V C205 E201 1200µH ????? 47PF 5%,100V 1000PF C207 OPA2134PA R241 C211 R207 R255 CR201...
  • Page 203 6-37 5518-FM DIGITAL TECHNICAL DATA L307 +5VA J301 C303 L303 L301 MALE IND 1K FILTER R331 L311 R335 1.0UF AGND 1200µH IC301 C302 C306 SHELL DRV134PA 1000PF R339 C323 C327 +15V 1.0UF 0.1UF C321 C305 R307 R311 R317 LEFT / 1 8.45K 8.45K 82.5K...
  • Page 204 6-38 TECHNICAL DATA ORBAN MODEL 5518 R407 R411 R415 COMPOSITE D/A CONVERTER 2.10K 2.10K 3.48K C423 R419 IC401 +5VA 82.5K 22PF MONO VCC2L C403 IC4 03A IC4 05A C408 10UF 0.1UF CHSL AGND3L AGND5 OP A2134UA OP A2134UA IOUTL- R425...
  • Page 205 6-39 5518-FM DIGITAL TECHNICAL DATA 5500 I/O BOARD: Composite/SCA Daughter Board 62310.000.02.1 (sheet 4b)
  • Page 206 6-40 TECHNICAL DATA ORBAN MODEL 5518 IC503B IC503A REF_M CLK REF_M CLK REF_M CLK (SHT11) REF_MCLK RCKIB RCKIA IN_FCLK IN_FCLK OUT_FCLK (SHT11) IN_FCLK LRCKIB LRCKOB LRCKIA LRCKOA IN_BCLK OUT_BCLK BCKIB BCKOB BCKIA BCKOA IN_BCLK DIN1_DATA (SHT11) DOUT1_DATA (SHT11) IN_BCLK SDINB...
  • Page 207 6-41 5518-FM DIGITAL TECHNICAL DATA (5500 NO-STUF F) (5500 NO-STUF F) IC601A IC602A IC603A IN_FCLK FSY NC FSY NC IN_FCLK FSR_0/PC1_0 FST_0/PC4_0 FSR_0/PC1_0 FST_0/PC4_0 FSR_0/PC1_0 FST_0/PC4_0 IN_BCLK BCLK BCLK IN_BCLK SCKR_0/PC0_0 SCKT_0/PC3_0 SCKR_0/PC0_0 SCKT_0/PC3_0 SCKR_0/PC0_0 SCKT_0/PC3_0 HCKR_0/PC2_0/SRCK HCKT_0/PC5_0/STCLK HCKR_0/PC2_0/SRCK HCKT_0/PC5_0/STCLK HCKR_0/PC2_0/SRCK HCKT_0/PC5_0/STCLK IC601_SDI0_0...
  • Page 208 6-42 TECHNICAL DATA ORBAN MODEL 5518 IC601B IC602B (5500 NO-STUFF) IC603B (5500 NO-STUFF) EXTAL EXTAL EXTAL EXTAL (SHT11) EXTAL EXTAL XTAL EXTAL XTAL EXTAL XTAL PINIT/NMI0 PINIT/NMI0 PINIT/NMI0 +3.3V +3.3V +3.3V DSP _RST- N DSP _RST- N DSP _RST- N...
  • Page 209 6-43 5518-FM DIGITAL TECHNICAL DATA IC601C IC602C (5500 NO-STUFF) IC603C (5500 NO-STUFF) LAD0/PA0 LALE LAD0/PA0 LALE LAD0/PA0 LALE LAD1/PA1 LAD1/PA1 LAD1/PA1 LAD2/PA2 LCS0 LAD2/PA2 LCS0 LAD2/PA2 LCS0 LAD3/PA3 LCS1 LAD3/PA3 LCS1 LAD3/PA3 LCS1 LAD4/PA4 LCS2 LAD4/PA4 LCS2 LAD4/PA4 LCS2 LAD5/PA5 LCS3 LAD5/PA5 LCS3...
  • Page 210 6-44 TECHNICAL DATA ORBAN MODEL 5518 IC601D IC602D (5500 NO-STUF F) IC603D (5500 NO-STUF F) +3.3V +3.3V +3.3V C607 C608 C609 IO_GND IO_VDD IO_GND IO_VDD IO_GND IO_VDD 0.01UF 0.01UF 0.01UF IO_GND IO_VDD IO_GND IO_VDD IO_GND IO_VDD C619 C620 C621 IO_GND...
  • Page 211 6-45 5518-FM DIGITAL TECHNICAL DATA +3.3V L1001 HZ0805G102R-10 +3.3V CR1001 C1019 IC501D IC SRC4382I PFB C1025 DI MRB0530 C1026 0.1UF +3.3V DGND IC1001 0.1UF 0.1UF IC501C R1001 2 OHM SCL/CCLK GPO1 R1007 A0/CS GPO2 0 OHM A1/CDIN GPO3 SDA/CDOUT GPO4 VDD33 SEL _L -N (SHT11)
  • Page 212 6-46 TECHNICAL DATA ORBAN MODEL 5518 IC1 103 RXCKO_1 IC606_SDO2_1 (SHT5) (SHT6) RXCKO_1 I0 (429) I0 (3) IC606_SDO2_1 RX_LRCK_1 IC606_SDO2_3 (SHT5) (SHT6) RX_LRCK_1 I0 (426) I0 (6) IC606_SDO2_3 RX_BCLK_1 IC605_SDO5_3 (SHT5) RX_BCLK_1 I0 (423) I0 (9) IC605_SDO5_3 (SHT6) DIN1_DATA IC605_SDO4_3...
  • Page 213 6-47 5518-FM DIGITAL TECHNICAL DATA FROM POWER SUPPLY TO CONTROL PCA C1227 R1201 TP1205 (NO-STUFF) IC1201 2 OHM 0.01UF J1203 J1201 C1209 C1219 SS/TRCK +3.3V 1.0UF 0.1UF L 1201 C1239 C1240 TP1203 (NO-STUFF) PVIN C1235 10UF 0.1UF +3.3V 1.5uH R1203 2 OHM C1231 C1201 HDR 2...
  • Page 214 6-48 TECHNICAL DATA ORBAN MODEL 5518 FRONT VIEW REAR VIEW FRONT PANEL PARTS LOCATOR DIAGRAM...
  • Page 215 6-49 5518-FM DIGITAL TECHNICAL DATA CR1A CR1B CR1C CR1D CR1E CR1F CR1G CR1H CR1I CR1J CR2A CR2B CR2C CR2D CR2E CR2F CR2G CR2H CR2I CR2J CR3A CR3B CR3C CR3D CR3E CR3F CR3G CR3H CR3I CR3J CR4A CR4B GNDF T O GND PLA NE ON LY GNDF GNDF RY10...
  • Page 216 6-50 TECHNICAL DATA ORBAN MODEL 5518 P4-1 and P4-2 provide GND to gnd plane on front bd. There is no other connection to GND on the front bd to the plane. IC7C IC7F 74HC14A 74HC14A IC7D RES_NET 74HC14A D[0..7] D[0..7]...
  • Page 217 6-51 5518-FM DIGITAL TECHNICAL DATA...
