Dodge 2000 Durango Service Manual

Engine
Hide thumbs Also See for 2000 Durango:
Table of Contents

Advertisement

Quick Links

See also: Service Manual , Installation & Owner's Manual
DN
4.7L ENGINE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
5.2L ENGINE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
ENGINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
ENGINE LUBRICATION SYSTEM . . . . . . . . . . . . . . 3
CYLINDER BLOCK. . . . . . . . . . . . . . . . . . . . . . . . . 5
CRANKSHAFT . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
PISTON AND CONNECTING ROD . . . . . . . . . . . . . 5
CYLINDER HEAD. . . . . . . . . . . . . . . . . . . . . . . . . . 5
VALVE GUIDES . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
VALVES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
VALVE STEM SEAL . . . . . . . . . . . . . . . . . . . . . . . . 5
VALVE SPRING . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
HYDRAULIC LASH ADJUSTER . . . . . . . . . . . . . . . 6
TIMING DRIVE SYSTEM . . . . . . . . . . . . . . . . . . . . 6
CAMSHAFT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
ROCKER ARM . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
CYLINDER HEAD COVER . . . . . . . . . . . . . . . . . . . 6
OIL PAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
STRUCTURAL DUST COVER . . . . . . . . . . . . . . . . 7
INTAKE MANIFOLD . . . . . . . . . . . . . . . . . . . . . . . . 7
EXHAUST MANIFOLD . . . . . . . . . . . . . . . . . . . . . . 7
SERVICE DIAGNOSIS-MECHANICAL. . . . . . . . . 10
SERVICE DIAGNOSIS-LUBRICATION. . . . . . . . . 11
DIAGNOSIS . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
LEAKAGE TEST . . . . . . . . . . . . . . . . . . . . . . . . 12
ENGINE OIL LEAK INSPECTION . . . . . . . . . . . . . 13
DIAGNOSIS . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
CHECKING ENGINE OIL PRESSURE. . . . . . . . . . 15
ENGINE

TABLE OF CONTENTS

page
5.9L ENGINE. . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
4.7L ENGINE
TABLE OF CONTENTS
page
FORM-IN-PLACE GASKETS. . . . . . . . . . . . . . . . . 15
ENGINE OIL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
CYLINDER BORE-HONING . . . . . . . . . . . . . . . . 18
HYDROSTATIC LOCK . . . . . . . . . . . . . . . . . . . . . 18
VALVE SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . 19
ENGINE TIMING-VERIFICATION . . . . . . . . . . . . 19
TIMING CHAIN-MEASURING WEAR . . . . . . . . . 22
PISTONS-FITTING . . . . . . . . . . . . . . . . . . . . . . . 22
PISTON RINGS-FITTING . . . . . . . . . . . . . . . . . . 24
CRANKSHAFT MAIN BEARINGS . . . . . . . . . . . . . 27
ENGINE MOUNTS-LEFT AND RIGHT. . . . . . . . . 28
ENGINE MOUNT-REAR . . . . . . . . . . . . . . . . . . . 29
STRUCTURAL COVER. . . . . . . . . . . . . . . . . . . . . 30
ENGINE ASSEMBLY. . . . . . . . . . . . . . . . . . . . . . . 31
INTAKE MANIFOLD . . . . . . . . . . . . . . . . . . . . . . . 35
EXHAUST MANIFOLDS . . . . . . . . . . . . . . . . . . . . 36
CYLINDER HEAD COVER . . . . . . . . . . . . . . . . . . 38
ROCKER ARMS . . . . . . . . . . . . . . . . . . . . . . . . . . 40
CYLINDER HEADS. . . . . . . . . . . . . . . . . . . . . . . . 41
VALVE SPRINGS AND SEALS . . . . . . . . . . . . . . . 46
HYDRAULIC LASH ADJUSTER . . . . . . . . . . . . . . 46
CRANKSHAFT DAMPER . . . . . . . . . . . . . . . . . . . 47
TIMING CHAIN COVER . . . . . . . . . . . . . . . . . . . . 48
TIMING CHAIN AND SPROCKETS . . . . . . . . . . . . 49
IDLER SHAFT-TIMING DRIVE . . . . . . . . . . . . . . 55
CAMSHAFTS-IN VEHICLE . . . . . . . . . . . . . . . . . 56
CRANKSHAFT MAIN BEARINGS . . . . . . . . . . . . . 61
OIL PAN 4X2 VEHICLE. . . . . . . . . . . . . . . . . . . . . 61
OIL PAN 4X4 VEHICLE. . . . . . . . . . . . . . . . . . . . . 64
PISTON AND CONNECTING ROD . . . . . . . . . . . . 65
CRANKSHAFT . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
FLEXPLATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
ENGINE
