PLASMA TV
SERVICE MANUAL
CHASSIS : RF-043B
MODEL : RT-60PY10
CAUTION
BEFORE SERVICING THE CHASSIS,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
POWER
TV GUIDE
TV/VIDEO
MENU
VOL
CH
website:http://biz.LGservice.com
e-mail:http://www.LGEservice.com/techsup.html

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RT-60PY10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG RT-60PY10

Summary of Contents for LG RT-60PY10

  • Page 1 PLASMA TV SERVICE MANUAL CHASSIS : RF-043B MODEL : RT-60PY10 CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. POWER TV GUIDE TV/VIDEO MENU...

  • Page 2: Table Of Contents

    CONTENTS SAFETY PRECAUTIONS ...................3 DESCRIPTION OF CONTROLS .................4 SPECIFICATIONS .....................14 ADJUSTMENT INSTRUCTIONS ..............16 TROUBLE SHOOTING GUIDE ................21 BLOCK DIAGRAM .....................32 EXPLODED VIEW ....................34 EXPLODED VIEW PARTS LIST ................35 REPLACEMENT PARTS LIST................36 SCHEMATIC DIAGRAM ..................PRINTED CIRCUIT BOARD .................. - 2 -...

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS IMPORT ANT SAFETY NOTICE Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by the Schematic Diagram and Replacement Parts List. It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent X-RADIATION, Shock, Fire, or other Hazards.

  • Page 4: Description Of Controls

    PAUSE STOP RECORD Moves the sub picture to Adjusts menu settings. direction. Selects menu item. SKIP DVD BUTTONS Controls a LG DVD player. REVEAL WIN.SIZE WIN.POSITION SLEEP SLEEP VCR BUTTONS Sets the sleep timer. Controls a LG video cassette I/II recorder.
  • Page 5 - Shown is a simplified representation of the set. - Here shown may be somewhat different from your set. <Front Panel Controls> Remote Control Sensor Power Standby Indicator Illuminates red in standby mode, Illuminates green when the set is turned on ON/OFF TV/AV MENU...
  • Page 6 <Back Panel> AC INPUT Antenna COMPONENT MONITOR OUTPUT INPUT 2 DVI INPUT AUDIO INPUT RGB INPUT RS-232C INPUT REMOTE COMPONENT (CONTROL/SERVICE) CONTROL INPUT1 INPUT 1 S-VIDEO L/MOND VIDEO AUDIO AUDIO VIDEO 1. CONTROL LOCK / REMOTE CONTROL 6. ANTENNA INPUT 2.
  • Page 7 External Equipment V iewing Setups External Equipment V iewing Setups Antenna Connection - Be careful for the bronze wire not to be bended in connecting to antenna input port. Apartments (connecting to wall antenna socket) wall antenna socket VIDEO AUDIO AUDIO VIDEO L/MOND...
  • Page 8 Watching Cable TV - After subscribing for a local cable TV station and installing a converter you can watch cable TV. - For further information of cable TV, contact the local cable TV station. To watch cable TV < Back panel of the set > 1.
  • Page 9 Watching DVD How to connect < Back panel of the set > Connect DVD video outputs to Y, P of COMPO- NENT INPUT and audio outputs to Audio sockets of AUDIO INPUT. How to use 1. Turn on the DVD player, and insert a DVD. 2.
  • Page 10 Connecting PC - To enjoy vivid picture and sound, connect a PC to the set. - Avoid keeping a fixed image on the setÕs screen for a long period of time. The fixed image may become permanently imprinted on the screen; use a screen saver when possible. - Connect PC to the RGB INPUT(PC INPUT) or DVI INPUT(DIGITAL RGB INPUT) port of the set;...
  • Page 11 Displayable Monitor Specification Displayable Monitor Specification RGB / DVI mode Horizontal Vertical Resolution Frequency(KHz) Frequency(Hz) 31.468 70.09 640x350 37.861 85.08 31.469 70.08 720x400 37.927 85.03 31.469 59.94 35.000 66.66 640x480 37.861 72.80 37.500 75.00 43.269 85.00 31.500 60.00 848x480 37.799 70.00 39.375 75.00...
  • Page 12 Remote Control handset OwnerÕs Manual Alkaline batteries 2-TV bracket bolts 6-RING SPACER 2-TV brackets (Only RT-60PY10/11 series Power Cord (Only RT-60PY10/11 series) 2-Wall brackets (optional) : 6-TV bracket bolts) Joinning the TV assembly to the wall to protect the set tumbling - Secure the TV assembly by joinning it to a wall by using the TV/Wall brackets.

  • Page 13: Installation Options

    10cm 10cm ¥ Install the RING SPACER with the bolts on the set as shown. (Only RT-60PY10/11 series) 1. Put the RING SPACER in the holes of the bolts before con- 2. When you connect the wall mounting bracket to the set, connect to it by using the bolts, (supplied with the product), necting to the wall mounting bracket.

  • Page 14: Specifications

    Aspect Ratio 16:9 PDP Module PDP60X5xxxx, RGB Closed Type Screen Filter 45% Total light transmittance (E- Mesh) Maker : LG Chemical Operating Environment 1) Temp : 0~40 deg 2) Humidity : 0~85% LGE SPEC Storage Environment 1) Temp : -20~60 deg...
  • Page 15 2. Model Specification Item Specification Remark Market Non-EU Broadcasting PAL B/G/I/D/K, NTSC Receiving system Upper Heterodyne Video Input (2EA) PAL, SECAM, NTSC 4 System : PAL, SECAM, NTSC,PAL60 Video Output(1EA) PAL, SECAM, NTSC 4 System : PAL, SECAM, NTSC,PAL60 PAL, SECAM, NTSC S-Video Input(2EA) 4 System : PAL, SECAM, NTSC,PAL60...

  • Page 16: Adjustment Instructions

    ADJUSTMENT INSTRUCTIONS 1. Application Object (2) select ÔCreate ShortcutÕ from the menu with the left mouse button and move the shortcut icon onto the desktop. These instructions apply to the RF-043A Chassis. (3) Double-click on the ÔLGIDSÕ icon on the desktop to execute the program.
  • Page 17 4-2. KEY Generation (Fig. 3) 4. HDCP Download (Fig. 5) 4-1. LGIDS Setting Method (1) Click on ÔsetupÕ to install in your directory. (1) Click on ÔKey Generation (G)Õ. (2) After installation is completed, check if the file shown on (2) Input the number of the key in Generation count.
  • Page 18 (6) It is possible to check how many Generations are created at this point. (Fig. 7) shows that you have created 130 Generations and you will start from 131 next time. (Fig. 7) (Fig. 10) Abnormal State 4-3. HDCP Download Method (4) If abnormal state (Fig.
  • Page 19 5-4. Adjustment Method for 6. DDC Data Input P/No. 3501V00182A B/D 6-1. Required Test Equipment (1) A jig for adjusting PC, DDC (PC serial to D-sub (1) Va Adjustment Connection equipment) 1) After receiving 100% Full White Pattern, HEAT RUN. (2) S/W for writing DDC (EDID Data Write &...
  • Page 20 7. Adjustment of White Balance 8-2. Method of Auto RGB Color Balance (1) Input RGB Source : Component 480p/576p 16 Gray Scale 7-1. Required Equipment Pattern At this time, except Pb and Pr signal, only Y signal insert. Color Analyzer (CA-100 or same product) (2) Press ADJ KEY on R/C for adjustment.

  • Page 21: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE 1. Power Board 1-1. The whole flowchart which it follows in voltage output state Start check Doesn't the It is identical Is the Interface screen whole come with Power Off signal operated? out? condition? 1. Check the Power Off 2.
  • Page 22 1-2. Sony Power Board Structure T502: Vs Trans T702: Va Trans T101: St-by Trans T103: Low Voltage Trans - 22 -...
  • Page 23 1-3. Sanken Power Board Structure T221: Vs Trans T271: Va Trans T121: St-by Trans T201: Low Voltage Trans - 23 -...
  • Page 24 2. No Power (1) Symptom DoesÕt minute discharge at module. ¯ Non does not come in into the front LED. ¯ (2) Check follow Is plug in power cord? Plug in power cord. Is connect the Line Filter and Power Connect Cable.
  • Page 25 3. Protect Mode (1) Symptom After once shining, it does not discharge minutely ¯ from module The Rely falls(The sound is audible ÒclickÓ) ¯ It is converted with the color where the front LED ¯ is red from green. (2) Check follow Is normal the Power Is output the normality Low/High Replace Power...
  • Page 26 4. No Raster (1) Symptom DoesÕt minute discharge at module. ¯ It maintains the condition where the front LED is green. ¯ (2) Check follow Is normal the Power Is output the normality Low/High Replace Power Board? voltage except Stand-by 5V? Board.
  • Page 27 5. In case of occur strange screen into specific mode 5-1. In case of doesÕt display the OSD (1) Symptom LED is green ¯ The minute discharge continuously becomes ¯ accomplished from module (2) Check follow Is normal the LVDS Is the LVDS cable Replace cable.
  • Page 28 5-2. In case of doesÕt display the screen into specific mode (1) Symptom The screen does not become the display from specific input mode ¯ (RF, AV, Component, RGB, DVI). (2) Check follow Check the all input mode should become normality display. ¯...
  • Page 29 (5) In the case of becomes unusual display from RF, AV, Component 480i mode Is normal the Input voltage, IIC Is normal the Replace IC Communication and HV sync? VPC3230? Is normal the Input voltage, IIC Is normal the S2300? Replace IC Communication and HV sync? Is normal the Input voltage, IIC...
  • Page 30 (7) In the case of becomes unusual display from RGB DTV mode Is normal the Input voltage, IIC Is normal the Replace IC Communication and HV sync? CXA2101? Is normal the Is normal the Input voltage, IIC Replace IC M52758? Communication and HV sync? Is normal the Input voltage, IIC Is normal the Scaler?
  • Page 31 6. In case of no sound (1) Symptom LED is green ¯ Screen display but sound is not output ¯ (2) Check follow Is normal the SPK Is the SPK cable Replace SPK cable cable? connected well? Cable inserts well. Is normal the Is the Flat cable Operates the IC800?

  • Page 32: Block Diagram

    BLOCK DIAGRAM BLOCK DIAGRAM - 32 -...
  • Page 33 - 33 -...

  • Page 34: Exploded View

    EXPLODED VIEW - 34 -...

  • Page 35: Exploded View Parts List

    SUPPORTER, FILTER AL PRESS 4980V00A97B SUPPORTER, FILTER AL PRESS 4980V00A95B SUPPORTER, FILTER AL PRESS 5230V00022C FILTER(MECH), DU-60PY10 LG-CHEMICAL FLATRON PLASMA DELETE LG FOR AMREICA 4980V00A96B SUPPORTER, FILTER AL PRESS 4811V00112A BRACKET ASSEMBLY, SPEAKER DU-60PY10 SPK GRILL ASSY R 4811V00113A BRACKET ASSEMBLY, SPEAKER DU-60PY10 SPK GRILLE ASSY L...

  • Page 36: Replacement Parts List

    0IMCRFA010A KA7809R, FAIRCHILD 2P D-PAK, R/TP IC IC1300 0IMCRRH001A BA033FP-E2 ROHM 3P-SOP,TO252-3 R/TP 3.3V IC500 0ICTMLG018A LGDP4410 LG IC 176P TQFP TRAY IEP IC1301 0IMCRSH001A PQ05DZ1U SHARP 5, SMD TYPE R/TP IC5006 0IDS162100B DS1621V 8P SOIC ST THERMOSTAT - IC1302...
  • Page 37 LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION Q110 0TR387500AA CHIP 2SC3875S(ALY) KEC Q806 0TR387500AA CHIP 2SC3875S(ALY) KEC Q111 Q808 0TR387500AA CHIP 2SC3875S(ALY) KEC 0TR387500AA CHIP 2SC3875S(ALY) KEC Q112 0TR387500AA CHIP 2SC3875S(ALY) KEC Q8105 0TR387500AA CHIP 2SC3875S(ALY) KEC Q113 0TR387500AA Q8108...
  • Page 38 LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION Q8212 0TR319809AA KTC3198(KTC1815) KEC TP TO92 50V 150MA D8407 0DD100009AP EG1ZV(1) TP TP SANKEN Q8403 D8414 0TR322709AA KTC3227-Y,TP(KTC1627A),KEC 0DR220000CA FMM-22S BK TO220 200V 10A 100A - 10UA Q8601 0TR150400BA CHIP 2SA1504S(ASY) KEC D8501 0DD100009AP EG1ZV(1) TP TP SANKEN...
  • Page 39 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
  • Page 40 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
  • Page 41 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
  • Page 42 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
  • Page 43 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
  • Page 44 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
  • Page 45 FBMH3216 HM501NT 3.2X1.6X1.6MM R/TP L1304 6210VC0006A FBMH3216 HM501NT 3.2X1.6X1.6MM R/TP SWITCH L1305 6210VC0006A FBMH3216 HM501NT 3.2X1.6X1.6MM R/TP SW201 140-315A TACT SKHV17910B LG C&D 12V L1307 6210VC0006A FBMH3216 HM501NT 3.2X1.6X1.6MM R/TP SW202 140-315A TACT SKHV17910B LG C&D 12V L1310 6210VC0006A FBMH3216 HM501NT 3.2X1.6X1.6MM R/TP...
  • Page 46 LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION L211 6200JB8010L MLB-201209-1000L-N2 R/TP 1000OHM 350MA R107 6200JB8010L MLB-201209-1000L-N2 R/TP 1000OHM 350MA L212 R108 6200JB8010L MLB-201209-1000L-N2 R/TP 1000OHM 350MA 6200JB8010L MLB-201209-1000L-N2 R/TP 1000OHM 350MA L213 6200JB8010L MLB-201209-1000L-N2 R/TP 1000OHM 350MA X500 6202VDT002K RESONATOR,CRYSTAL SX-1 6MHZ +/- 30 PPM...
  • Page 52 PRINTED CIRCUIT BOARD MAIN (TOP) MAIN (BOTTOM) SMPS (TOP) SMPS (BOTTOM) VA (TOP) VA (BOTTOM) VS (BOTTOM) VS (TOP) POWER CONTROL (TOP) POWER CONTROL (BOTTOM) PFC CONTROL (TOP) PFC CONTROL (BOTTOM) TUNER (BOTTOM) TUNER (TOP) CONTROL (TOP) SIDE A/V (TOP) PFC (TOP) CONTROL (BOTTOM) SIDE A/V (BOTTOM)
  • Page 53 Aug., 2004 P/NO : 3828VD0161L Printed in Korea...
