- Page 1 All manuals and user guides at all-guides.com website:http://biz.LGservice.com e-mail:http://www.LGEservice.com/techsup.html PLASMA TV SERVICE MANUAL CHASSIS : RF-03OA MODEL : RT/RZ-42PZ60/70 MODEL : RT-42PZ60H CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com CONTENTS SAFETY PRECAUTIONS ...................3 DESCRIPTION OF CONTROLS ................ 4 SPECIFICATIONS ....................8 ADJUSTMENT INSTRUCTIONS ................9 PRINTED CIRCUIT BOARD ................12 BLOCK DIAGRAM .....................18 EXPLODED VIEW ..................20,22 EXPLODED VIEW PARTS LIST ..............21,23 REPLACEMENT PARTS LIST................24 SCHEMATIC DIAGRAM .................. -
Page 3: Safety Precautions
All manuals and user guides at all-guides.com SAFETY PRECAUTIONS IMPORT ANT SAFETY NOTICE Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by the Schematic Diagram and Replacement Parts List. It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent X-RADIATION, Shock, Fire, or other Hazards. -
Page 4: Description Of Controls
Moves the sub picture to Adjusts menu settings. Selects menu item. direction. PIP ARC SKIP DVD BUTTONS Changes the picture format for the Controls a LG DVD player. sub picture. PIP ARC WIN.SIZE WIN.POSITION SLEEP SLEEP VCR BUTTONS Sets the sleep timer. - Page 5 All manuals and user guides at all-guides.com - Shown is a simplified representation of the set. - Here shown may be somewhat different from your set. <Front Panel Controls> S-VIDEO VIDEO L/MONO AUDIO ON/OFF ON/OFF S-VIDEO VIDEO L/MONO AUDIO AUDIO/VIDEO IN SOCKETS (Volume Up/Down) Buttons S-VIDEO/AUDIO IN SOCKETS (Programme Up/Down) Buttons...
- Page 6 All manuals and user guides at all-guides.com Location and Function of Controls Location and Function of Controls <Back Panel> COMPONENT RS-232C INPUT REMOTE (CONTROL/SERVICE) CONTROL Antenna (MONO) RGB INPUT AUDIO INPUT DVI INPUT EXTERNAL SPEAKER AC INPUT VIDEO AUDIO S-VIDEO 1.
- Page 7 All manuals and user guides at all-guides.com Accessories CABLE AUDIO MODE FAVOURITE Q.VIEW PIP/DW TEXT MENU EXIT PIP PR- PIP INPUT 1.5V PIP PR+ SWAP PLAY PAUSE STOP RECORD SKIP PIP ARC WIN.SIZE WIN.POSITION SLEEP I/II LIST SPLIT ZOOM ZOOM- ZOOM+ Owner’s Manual Alkaline batteries...
-
Page 8: Specifications
4) Follow each drawing or spec for spec and performance of parts,based upon P/N of RPL 5) Warm up set for more than 20min before the measurement. Test and Inspection Method 1) Performance : Follow the Standard of LG TV test 2) Extra standards Safety: Follow the standard of CE, IEC... -
Page 9: Adjustment Instructions
All manuals and user guides at all-guides.com ADJUSTMENT INSTRUCTIONS 1. Application Object Each PCB Assy must be checked by the Check JIG Set before whole assembly. (Be careful the POWER PCB Assy not to These instructions are applied to all of the PDP monitor/ damage to PDP Module) Tuner , RF-03OA chassis. - Page 10 All manuals and user guides at all-guides.com (2) Vs Adjustment (4) Low Light, stick sensor to 70Gray Pattern and then press ADJ Key on R/C for adjustment and press D , E on R/C in ¤ Connect + terminal of D.M.M to Vs pin of P805 and adjustment mode to select R-H or G-H, press VOL +, - Key connect –...
- Page 11 All manuals and user guides at all-guides.com 8. Adjustment of Component Off-Set ¤Œ Operate EDID Read command and check whether Check Sum is OK. ¤ºIf Check Sum is NG, repeat c) ~ d). 8-1. Required Test Equipment ¤ If Check Sum is OK, DDC Data for Digital-RGB input is : HD-STB(SK-010T) or same product completed.
-
Page 12: Printed Circuit Board
All manuals and user guides at all-guides.com PRINTED CIRCUIT BOARD MAIN (TOP) - 12 -... - Page 13 All manuals and user guides at all-guides.com MAIN (BOTTOM) - 13 -...
- Page 14 All manuals and user guides at all-guides.com REAR AV (TOP) REAR AV (BOTTOM) AV BOARD (TOP) AV BOARD (BOTTOM) POWER SWITCH - 14 -...
- Page 15 All manuals and user guides at all-guides.com PREAMP (TOP) PREAMP (BOTTOM) SPEAKER (TOP) SPEAKER (BOTTOM) - 15 -...
- Page 16 All manuals and user guides at all-guides.com TUNER (TOP) - 16 -...
- Page 17 All manuals and user guides at all-guides.com TUNER (BOTTOM) - 17 -...
-
Page 18: Block Diagram
All manuals and user guides at all-guides.com BLOCK DIAGRAM - 18 -... - Page 19 All manuals and user guides at all-guides.com MEMO - 19 -...
-
Page 20: Exploded View
All manuals and user guides at all-guides.com EXPLODED VIEW(RT/RZ-42PZ70) - 20 -... -
Page 21: Exploded View Parts List
All manuals and user guides at all-guides.com EXPLODED VIEW PARTS LIST Part No. Description 6348Q-E038B PDP,42 16:9 852*480 PDP42V50330.ADLGA 6871QDH051A PWB(PCB) ASSEMBLY,DISPLAY YDRV ASSY HAND INSERT 42SD5_YDRV_TOP_TI_4LAYER 6871QDH052A PWB(PCB) ASSEMBLY,DISPLAY YDRV ASSY HAND INSERT 42SD5_YDRV_BTM_TI_4LAYER 6871QCH031C PWB(PCB) ASSEMBLY,DISPLAY CTRL ASSY HAND INSERT 42V5 TMDS LGPCMV1222H 6871QYH027B PWB(PCB) ASSEMBLY,DISPLAY YSUS ASSY HAND INSERT 42V5 SONY STANDRAD 6871QRH034A... - Page 22 All manuals and user guides at all-guides.com EXPLODED VIEW(RT/RZ-42PZ60) - 22 -...
- Page 23 PWB(PCB) ASSEMBLY,SUB TUNER RF03OA RT SDA6001 42 50 PDP 6871VSMX31B PWB(PCB) ASSEMBLY,SUB CONT RF03OA KK ANALOG BUILT IN 3501V00164B BOARD ASSEMBLY,POWER RT-42PZ60 RF03OA 42 XGA PDP P/NO: 3501V00164A 6V CHANGE 3720V00237B PANEL,ASSY RZ-50PZ60 VFD 16ML07HA1 SDI VFD 4814V00418A SHIELD,DN-4PZ70 AF03BB ET .
-
Page 24: Replacement Parts List
All manuals and user guides at all-guides.com REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION IC703 0IMMRHY033A HY57V643220C(L)T-6 HYNIX 86P TSOP IC704 0IMMRHY033A HY57V643220C(L)T-6 HYNIX 86P TSOP IC001 0IMCRMN023A SDA6001 QH B12 MICRONAS 128P MQFP IC801 0IPRPTI001A TFP401PZP TEXAS INSTRUMENT 100,TQFP... - Page 25 All manuals and user guides at all-guides.com LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION Q209 0TR387500AA CHIP 2SC3875S(ALY) KEC DIODE Q210 0TR387500AA CHIP 2SC3875S(ALY) KEC Q211 D001 0TR387500AA CHIP 2SC3875S(ALY) KEC 0DD226239AA CHIP KDS226 SOT-23 Q212 0TR387500AA CHIP 2SC3875S(ALY) KEC D002 0DD226239AA...
- Page 26 All manuals and user guides at all-guides.com For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
- Page 27 All manuals and user guides at all-guides.com For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
- Page 28 All manuals and user guides at all-guides.com For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
- Page 29 22 OHM 1 / 16 W 1608 5% R/TP 4P E24 SERIES AR428 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/TP 4P E24 SERIES SW001 140-315A TACT SKHV17910B LG C&D NON 12V AR429 0RRZVTA001D 22 OHM 1 / 16 W 1608 5% R/TP 4P E24 SERIES SW002 140-315A TACT SKHV17910B LG C&D NON 12V...
- Page 30 All manuals and user guides at all-guides.com LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION L017 6210VC0006A FBMH3216 HM501NT 3.2X1.6X1.6MM R/TP L909 6210VC0006A FBMH3216 HM501NT 3.2X1.6X1.6MM R/TP L018 6210VC0006A FBMH3216 HM501NT 3.2X1.6X1.6MM R/TP L910 6210VC0006A FBMH3216 HM501NT 3.2X1.6X1.6MM R/TP L019 L911 6210VC0006A...
- Page 31 All manuals and user guides at all-guides.com LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION X403 6202VDT002J RESONATOR,CRYSTAL SX-1 13.500000MHZ X501 6202VDT002J RESONATOR,CRYSTAL SX-1 13.500000MHZ X601 156-A02M RESONATOR,CRYSTAL HC49U 18.432MHZ 30PPM JACK JK101 6612M00001A UPJ-R1-023 UGCOM 21PIN JK102 6612M00001A UPJ-R1-023 UGCOM 21PIN JK103...
- Page 32 All manuals and user guides at all-guides.com ice.com up.html...
- Page 33 All manuals and user guides at all-guides.com...
- Page 34 All manuals and user guides at all-guides.com...
- Page 35 All manuals and user guides at all-guides.com...
- Page 36 All manuals and user guides at all-guides.com...
- Page 37 All manuals and user guides at all-guides.com...
- Page 38 All manuals and user guides at all-guides.com...
- Page 39 All manuals and user guides at all-guides.com...
- Page 40 All manuals and user guides at all-guides.com...
