Aria Child urbini Instructions For Use Manual

Petal infant car seat for touri travel system
Hide thumbs
Table of Contents

Advertisement

Quick Links

www.urbinibaby.com
Read all instructions before use.
If these instructions are not followed, the safety of a child
may be severely endangered. Keep instructions for future use.
1
©2013 IM0004A 11/2013

Advertisement

Table of Contents
loading

Related Manuals for Aria Child urbini

Summary of Contents for Aria Child urbini

  • Page 1 www.urbinibaby.com Read all instructions before use. If these instructions are not followed, the safety of a child may be severely endangered. Keep instructions for future use. ©2013 IM0004A 11/2013...

  • Page 2: Table Of Contents

    1. Registering Your Child Restraint .......4 For Recall Information ..........5 Certification ..............5 If You Need Assistance or Have Questions ..5 2. Warnings and Important Information ..6-10 3. Child Height and Weight Limits ...... 11 4. Base Features ............ 12-13 5. Carrier Features ..........14-17 6.
  • Page 3 9. Child Restraint Installation WITHOUT Base Using the Vehicle Belt Lap Belt ..............36-37 Lap/Shoulder Belt ..........38-39 Lap/Shoulder Belt (Alternate Method) ..40-41 10. Checking the Recline ........42-43 11. Adjusting the Recline ........44-45 12. Placing Your Child in the Carrier ..... 46-48 Changing the Buckle Strap Position ..

  • Page 4: Registering Your Child Restraint

    You must register this restraint to be reached in a recall. Send your name, address, e-mail address if available and the restraint’s model number and manufacturing date to: Aria Child Inc. P.O. Box 1415 New York, NY 10102-2195 or call 1-888-569-7288 or register online at: http://www.urbinibaby.com/carseatregistration...

  • Page 5: For Recall Information

    ATV’s or any other non-certified vehicle. If You Need Assistance or Have Questions If you have any questions regarding installation of your seat , please contact us at: Aria Child Inc. 530 Harrison Ave. Boston, MA 02118 1-888-569-7288 www.urbinibaby.com...

  • Page 6: Warnings And Important Information

    2. Warnings and Important Information WARNING DO NOT place rear-facing child seat ADVERTENCIA on front seat with air bag. DEATH OR SERIOUS INJURY can occur. The back seat is the safest place for children 12 and under. WHEN USED IN YOUR VEHICLE •...
  • Page 7 WARNING • USE ONLY WITH children who weigh between ADVERTENCIA 4 - 35 lbs (1.8 - 15.9 kg) and whose height is 32 inches (81cm) or less. Child’s head MUST be 1” (2.5 cm) or more below the top of the seat. •...
  • Page 8 WARNING ADVERTENCIA • NEVER place this child restraint on side-facing or rear facing vehicle seats. • SECURE THIS CHILD RESTRAINT with the vehicle’s child restraint anchorage system (LATCH) if available or with a vehicle belt, never both. • ALWAYS TIGHTLY INSTALL THE CHILD RESTRAINT AND BASE TO THE VEHICLE SEAT, since in a crash an unsecured child restraint system may injure other occupants.
  • Page 9 LATCH belt. • WHEN USING THIS CHILD RESTRAINT WITH A STROLLER, ONLY USE with the Urbini Touri Travel System. Refer to your stroller USER GUIDE for stroller attachment instructions. NEVER use this child restraint with other manufacturer’s strollers or with strollers for...

  • Page 10: Important Information

    IMPORTANT INFORMATION • DO NOT allow children to play with the child restraint. • ALWAYS MAKE SURE handle is locked in the upright carrying position before lifting. An unlocked handle could result in serious injury to your child from falling from the child restraint.

  • Page 11: Child Height And Weight Limits

    3. Child Height and Weight Limits The American Academy of Pediatrics recommends children should ride rear-facing for as long as possible up to 2 years in age, or until they reach maximum height and weight for their seat. Do not use this child restraint beyond the expiration date or if the child exceeds the limits of this seat.

  • Page 12: Base Features

    4. Base Features...
  • Page 13 Release Handle Level Indicator Belt Lock-Off LATCH Anchor Strap Guides LATCH Anchor Strap LATCH Storage Compartment Belt Path BASE Carrier to Base Indicators LATCH Adjustment Strap LATCH Release Button LATCH Belt Connector Recline Foot...

  • Page 14: Carrier Features

    5. Carrier Features THIS TEXT ESTA CARA FACES UP HACIA ARRIBA WARNING ADVERTENCIA To prevent suffocation, always Para prevenir la as xia, ponga siempre place preemie insert into the el accesorio para bebés prematuros en pocket located on the back of the el bolsillo de atrás del soporte body support exactly as shown.
  • Page 15 Preemie Insert Handle (in plastic bag with Canopy instruction sheet) Seat Pad Shoulder Belt Guide Stroller Release Button Harness Slots Lap Belt Guide Base Attachment Rods Harness Cover Chest Clip Harness Strap Body Support Buckle Splitter Plate Buckle Strap Cover Harness Waist Strap Adjustment...
  • Page 16 Handle WARNING ADVERTENCIA ALWAYS make sure the handle is securely locked in the upright carrying position (A) before carrying. ANY locked position can be used in vehicle. There are 4 positions: - Carrying position (A), - Middle positions (B - C), - Stationary position (D).
  • Page 17 Canopy To attach canopy, insert the canopy bow into the canopy mounts on both CLICK! sides of the seat until the button clicks into place. Fasten snap to canopy mount as shown. SNAP! To remove, press tab as shown, canopy can be removed for washing.

  • Page 18: Latch Location

    6. LATCH Location stands for Lower Anchors and Tethers LATCH for Children. It makes installation easier without using the vehicle’s seat belts. is a way to secure your LATCH child restraint to your vehicle by using the LATCH connectors on your child restraint base. These connectors attach to the lower anchor points in certain vehicle seating positions.

  • Page 19: Vehicle Installation Locations

    7. Vehicle Installation Locations WARNING ADVERTENCIA Failure to place the child restraint in the correct seating positions increases the risk of serious injury or death. DO NOT place rear-facing child seat on front seat with air bag. DEATH OR SERIOUS INJURY can occur.

  • Page 20: Unsafe Vehicle Seat Belt Types

    Vehicle Seat Belt Types UNSAFE If you have any of these types of vehicle belt systems listed, NEVER use any of these to install your child restraint in the vehicle. These vehicle belt systems are UNSAFE to use to install your child restraint in the vehicle.
  • Page 21 Non-Locking Lap Belts with Emergency Locking Retractor (ELR) The lap belt is always loose until it locks in a sudden stop or crash. Lap/Shoulder Belts with 2 Retractors (including inflatable seat belts) Belts are attached to retractors at the ends of the lap and shoulder belt and attached to one latch plate.

  • Page 22: Safe Vehicle Seat Belt Types

    Vehicle Seat Belt Types SAFE If you have any of these types of vehicle belt systems SAFE listed, these are to use to install your child restraint in the vehicle. Review vehicle owner’s manual for specific instructions on child restraint installation. LATCH can be used IN PLACE OF these vehicle belt types.
  • Page 23 Lap/Shoulder Belt with Locking Latch Plate The lap portion of this belt does not loosen once the belt is buckled. The vehicle belt is tightened by pulling up hard on shoulder belt and feeding the webbing into the retractor. Lap/Shoulder Belt with Sliding Latch Plate The latch plate slides freely along the lap/shoulder belt.

  • Page 24: With Latch

    8. Base Installation with LATCH Click! Click! Click!
  • Page 25 BEFORE installing base , make sure vehicle is on level ground. Place base on an approved LATCH vehicle seating location. Remove LATCH strap from LATCH storage compartment and extend the strap to its longest length (see image 8, pg 27 for extending LATCH length).
  • Page 26 Attach the carrier into the base until you hear a click. Lift up on the handle of the carrier to make sure that it is securely attached in the base. WARNING If the carrier does not latch securely into the base, ADVERTENCIA CHECK to make sure green is visible on the indicators...
  • Page 27 To remove the seat from the base, pull up the red release handle located on the base. Lift carrier away from the base. To remove LATCH, open lock-off, push button on adjuster to loosen LATCH then unhook from the anchor point. Repeat steps as shown on the other side of the base.

  • Page 28: With Lap/Shoulder Belt

    Base Installation with Lap / Shoulder Belt Pull! Click! Click!
  • Page 29 BEFORE installing base, make sure vehicle is on level ground. Place base on an approved vehicle seat location. Route the lap/shoulder belt through the belt path openings on both sides of base and under the belt lock-off. Make sure not to twist the belts and make sure they lie flat.
  • Page 30 Attach the carrier into the base until you hear a click. Lift up on the handle of the carrier to make sure that it is securely attached in the base. WARNING If the carrier does not latch securely into the base, ADVERTENCIA CHECK to make sure green is visible on the indicators...
  • Page 31 To remove the seat from the base, pull up the red release handle located on the base. Lift carrier away from the base. To remove child restraint from vehicle, open lock-off and unbuckle the belt.

  • Page 32: With Lap Belt

    Base Installation with Lap Belt Click! Pull! Click!
  • Page 33 BEFORE installing base, make sure vehicle is on level ground. Place base on an approved vehicle seat location. Route the lap belt through the belt path openings on both sides of base and under the belt lock-off. Make sure not to twist the belt and make sure it lies flat.
  • Page 34 Attach the carrier into the base until you hear a click. Lift up on the handle of the carrier to make sure that it is securely attached in the base. WARNING If the carrier does not latch securely into the base, ADVERTENCIA CHECK to make sure green is visible on the indicators...
  • Page 35 To remove the seat from the base, pull up the red release handle located on the base. Lift carrier away from the base. To remove child restraint from vehicle, open lock-off and unbuckle the belt.

  • Page 36: Child Restraint Installation Without Base Using The Vehicle Belt

    9. Child Restraint Installation WITHOUT the Base Using the Vehicle Belt Lap Belt Click! BEFORE installing carrier, make sure vehicle is on level ground. Place Click! carrier on an approved vehicle seat location in a rear-facing position. Route the lap belt through the lap belt guides on both sides of carrier.
  • Page 37 Push down in center of carrier and pull the free end of the lap belt to tighten carrier against the vehicle seat. CHECK to make sure carrier is secure by holding both sides near the lap belt guides and moving it from side to side and front and back. The lap belt should not loosen and the carrier should not move easily.

  • Page 38: Lap/Shoulder Belt

    Click! Lap/Shoulder Belt Click! BEFORE installing carrier, make sure vehicle is on level ground. Place carrier on an approved vehicle seat location in a rear-facing position. Route the lap portion of the lap/shoulder belt through the lap belt guides on both sides of carrier. Make sure not to twist the belt and make sure it lies flat.
  • Page 39 Route the shoulder portion of the belt around the rear of the seat and under the shoulder belt guide. If vehicle belt latch plate does not lock, then retractor must be switched. CHECK the vehicle owner’s manual and page 23 to see how to lock your seat belt.

  • Page 40: Lap/Shoulder Belt (Alternate Method)

    Lap/Shoulder Belt (Alternate Method) Click! BEFORE installing carrier , make sure vehicle is on level ground. Place carrier on an approved vehicle seat location in a rear-facing position. Route the lap portion of the lap/shoulder belt through the lap belt guides on both sides of carrier. Make sure not to twist the belt and make sure it lies flat.
  • Page 41 Pull on shoulder portion of vehicle belt while pushing down in the center of the seat to tighten carrier to vehicle seat. If vehicle belt latch plate does not lock, then retractor must be switched. CHECK the vehicle owner’s manual and page 23 to see how to lock your seat belt.

  • Page 42: Checking The Recline

    10. Checking the Recline WARNING ADVERTENCIA Improper recline of your child restraint or base could cause serious injury or death. If the child restraint is too upright, an infant’s head could drop forward and cause suffocation or breathing problems. If the child restraint is too reclined, a sudden stop or vehicle crash could cause injury to a child’s neck or shoulders.
  • Page 43 When using the child restraint and the base together: 1) Make sure vehicle is on level ground. 2) Only use the level indicator on the base to make sure the seat and base are level. 3) Recline base until 4-20lbs (2- 9.1 kg) ball rests in the zone 20-35lbs (9.1 -15.9 kg) of your child’s weight.

  • Page 44: Adjusting The Recline

    11. Adjusting the Recline The base has 2 recline adjustment positions for the foot. To raise the foot, pull the foot out from the bottom of the base then push it up until it snaps into place. To lower the foot, pull foot down, rotate under seat until it snaps into the bottom of the base.
  • Page 45 When using the carrier with the 4-20lbs (2- 9.1 kg) base, if the foot is in the raised position and the ball still falls in the 20-35lbs (9.1 -15.9 kg) red zone you may need to place a NOT LEVEL tightly rolled towel under the foot end of the base in order to get the seat to become level.

  • Page 46: Placing Your Child In The Carrier

    Head 1” (2.5cm) from top of seat 12. Placing Your Child in the Carrier Cabeza a 1 pulgada desde la parte de arriba del asiento WARNING 1” ADVERTENCIA Improper placement of the harness straps and buckle strap increases the risk of serious injury or death in a sudden stop or vehicle crash.
  • Page 47 From the front of seat, you will need to loosen the harness straps to be able to remove the harness from the splitter plate. Push the harness adjuster button and pull the harness straps toward you. Turn the seat over and remove the harness straps from the splitter plate as shown.
  • Page 48 For Larger Babies: Thread harness straps through either slots 3 or 4 depending on the size of your child and attach loops ( B ) to splitter plate. For Smaller Babies: Thread harness straps through either slots 1 or 2 depending on the size of your child and attach loops ( A ) to splitter plate.

  • Page 49: Changing The Buckle Strap Position

    Changing the Buckle Strap Position Turn the child restraint over and push the tab out of the way while pushing on the metal to unlock it from the carrier. Push the metal retainer through the slot and pull buckle strap out of the front of the seat.

  • Page 50: Changing The Waist Strap Position

    Changing the Waist Strap Position For Smaller Babies: In order to change waist strap position, you will need to remove the harness, the seat pad, the chest clip and the buckle tongues. 1) Insert the harness straps up through the bottom side of the shell through the inner waist slots with the folded portion of the strap facing in seating area as shown.
  • Page 51 3) Re-attach the buckle tongues then the chest clip as shown. 4) Re-insert the harness straps through the same set of slots in seat pad and shell of the seat that are appropriate for the size of your child. 5) Turn the seat over and pull harness straps through the back of the shell.
  • Page 52 Changing the Waist Strap Position For Larger Babies: In order to change waist strap position, you will need to remove the harness, the seat pad, the chest clip and the buckle tongues. 1) Insert the harness straps into the inner slots from the top side of the shell then pull them back up through the outer slots with the folded portion of the strap facing in.
  • Page 53 3) Re-attach the buckle tongues then the chest clip as shown. 4) Re-insert the harness straps through the same set of slots in seat pad and shell of the seat that are appropriate for the size of your child. 5) Turn the seat over and pull harness straps through the back of the shell.

  • Page 54: Using The Body Support

    Using the Body Support WARNING ADVERTENCIA To prevent ejection or serious injury, only use the body support when the harness is used in the bottom 2 sets of harness slots. If there is a gap between the buckle strap and the child, place a tightly rolled washcloth around the buckle strap.

  • Page 55: Using The Preemie Insert

    Using the Preemie Insert WARNING ADVERTENCIA To prevent ejection or serious injury: • For low birth-weight infant, you must always use the preemie insert in the body support. The preemie insert must be used for infants who weigh less than 6 lbs (2.7 kg). •...

  • Page 56: Securing Your Child In The Restraint

    13. Securing your Child in the Restraint WARNING ADVERTENCIA Improper placement of the harness straps and buckle strap increases the risk of serious injury or death in a sudden stop or vehicle crash. Rotate handle out of the way. Push the harness adjuster button then pull the harness straps toward you.
  • Page 57 Insert the buckle tongues into the buckle as shown. MAKE sure you hear them click into place. CLICK! DO NOT use child restraint if buckle tongues DO NOT click into the buckle. Try cleaning the buckle. If this does not remedy the problem, please call Customer Service before using the child restraint.

  • Page 58: Latch Storage

    14. LATCH Storage Fold LATCH Belt up as shown and place inside the storage compartment. 15. Instruction Manual Storage There is a small tag on the seat pad indicating the location for the instruction manual storage. Fold manual in half and store under the seat pad in the groove in the seat as shown.

  • Page 59: Care And Maintenance

    16. Care and Maintenance Cleaning the Seat Pad: Refer to the care tag on your seat pad for washing instructions. NEVER use carrier without the seat pad attached. Cleaning the Harness and Shell: Sponge clean using warm water and mild soap. Do not use any other cleaning agents or bleach.

  • Page 60: Warranty Information And Replacement Parts

    Do not use detergents or lubricants. 17. Warranty Information and Replacement Parts For information about warranty and replacement parts, please contact: Aria Child Inc. 530 Harrison Ave Boston, MA 02118 or call 1-888-569-7288 or visit www.urbinibaby.com...
