IMPORTANT for the U.K.
DO NOT cut off the mains plug from this equipment. If
the plug fitted is not suitable for the power points in your
home or the cable is too short to reach a power point,
then obtain an appropriate safety approved extension lead
or consult your dealer.
MICRO COMPONENT SYSTEM
BE SURE to replace the fuse only with an identical
approved type, as originally fitted.
UX-GN5
If nonetheless the mains plug is cut off ensure to remove
the fuse and dispose of the plug immediately, to avoid a
—Consists of CA-UXGN5 and SP-UXGN5
possible shock hazard by inadvertent connection to the
mains supply.
If this product is not supplied fitted with a mains plug then
follow the instructions given below:
IMPORTANT:
DO NOT make any connection to the terminal which is
marked with the letter E or by the safety earth symbol or
coloured green or green-and-yellow.
The wires in the mains lead on this product are coloured in
Thank you for purchasing a JVC product.
accordance with the following code:
Blue:
Neutral
INSTRUCTIONS
Brown:
Live
As these colours may not correspond with the coloured
markings identifying the terminals in your plug proceed
LVT1988-001A[B]
as follows:
0209RYMMDWDAT
The wire which is coloured blue must be connected to
the terminal which is marked with the letter N or coloured
©2009 Victor Company of Japan, Limited
black.
The wire which is coloured brown must be connected to
the terminal which is marked with the letter L or coloured
Warnings, Cautions and Others
red.
CAUTION
IF IN DOUBT - CONSULT A COMPETENT ELECTRICIAN.
The
button in any position does not disconnect the mains
line.
CAUTION: Proper Ventilation
Disconnect the mains plug to shut the power off completely
To avoid risk of electric shock and fire, and to prevent
(the STANDBY lamp goes off).
damage, locate the apparatus as follows:
1. Front: No obstructions and open spacing.
The MAINS plug or an appliance coupler is used as the
2. Sides/Top/Back: No obstructions should be placed in
disconnect device, the disconnect device shall remain readily
the areas shown by the dimensions below.
operable.
3. Bottom: Place on the level surface. Maintain an
• When the System is on standby, the STANDBY lamp lights
adequate air path for ventilation by placing on a stand
red.
with a height of 10 cm or more.
• When the System is turned on, the STANDBY lamp goes
off.
Front view
The power can be remote controlled.
CAUTION:
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
Dear Customer,
CA-UXGN5
SP-UXGN5
SP-UXGN5
This apparatus is in conformance with the valid European
directives and standards regarding electromagnetic
CAUTION:
compatibility and electrical safety.
Excessive sound pressure from earphones or headphones
European representative of Victor Company of Japan,
can cause hearing loss.
Limited is:
JVC Technical Services Europe GmbH
CAUTION:
Postfach 10 05 04
Battery shall not be exposed to excessive heat such as
61145 Friedberg
sunshine, fire, or the like.
Germany
Getting Started
Supplied Accessories
Connections
After unpacking, check to be sure that you have all the
following items.
Do not connect the AC power cord until all other connections have been made.
• Remote control, RM-SUXGN5R (× 1)
• Lithium coin battery (× 1: installed in the remote control)
• AM loop antenna (× 1)
Rear view
• FM antenna (× 1)
If anything is missing, consult your dealer immediately.
Prepare the Remote Control
When you use the remote control for the first time, pull out
the insulation sheet.
Insulation sheet
To Replace the Battery in the Remote Control
Lithium coin battery
(product number: CR2025)
NOTES:
To connect the FM antenna (supplied)
• Store the battery in a place where children cannot reach. If
Extend it so that you can obtain the best reception.
a child accidentally swallows the battery, consult a doctor
immediately.
• To prevent the battery from overheating, cracking, or starting
a fire:
FM antenna (supplied)
– Do not recharge, short, disassemble or heat the battery or
dispose of it in a fire.
– Do not leave the battery with other metallic materials.
– Wrap the battery with tape and insulate when throwing
away or saving it.
– Do not poke the battery with tweezers or similar tools.
• Dispose of battery in the proper manner, according to federal,
To assemble the AM loop antenna (supplied)
state, and local regulations.
AM loop antenna
CAUTION:
(supplied)
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
IMPORTANT FOR LASER PRODUCTS
Information for Users on Disposal of Old Equipment
1. CLASS 1 LASER PRODUCT
and Batteries
2. CAUTION: Do not open the top cover or cabinet. There
are no user serviceable parts inside the unit; leave all
servicing to qualified service personnel.
3. CAUTION: Visible and/or invisible class 1M laser radiation
when open. Do not view directly with optical instruments.
4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED
INSIDE THE UNIT.
Products
CAUTION:
• Do not block the ventilation openings or holes. (If the
Battery
ventilation openings or holes are blocked by a newspaper or
cloth, etc., the heat may not be able to get out.)
Notice:
• Do not place any naked flame sources, such as lighted
The sign Pb
candles, on the apparatus.
below the
• When discarding batteries, environmental problems
symbol for
must be considered and local rules or laws governing the
batteries
disposal of these batteries must be followed strictly.
• Do not expose this apparatus to rain, moisture, dripping
indicates that
or splashing and that no objects filled with liquids, such as
this battery
vases, shall be placed on the apparatus.
contains lead.
Precautions
Notes on the power cord
• When you are away on travel or otherwise for an extended
period of time, remove the plug from the wall outlet.
• When unplugging the System from the wall outlet, always
pull the plug, not the power cord.
• Do not handle the power cord with wet hands.
• Disconnect the power cord before cleaning the System or
moving the System.
• Do not alter, twist or pull the power cord, or put anything heavy
on it, which may cause fire, electric shock, or other accidents.
• If the cord is damaged, consult a dealer and have the power
cord replaced with a new one.
Avoid moisture, water, dust, and high temperatures
• Do not place the System in moist or dusty places.
• If water gets inside the System, turn off the power and remove
the plug from the wall outlet, then consult your dealer. Using
Side view
the System in this state may cause a fire or electrical shock.
• Do not expose the System to direct sunlight or place it near
a heating device.
Notes on installation
• Select a place which is level, dry and neither too hot nor too
cold—between 5˚C and 35˚C.
• Do not install the System in a place subject to vibrations.
CA-UXGN5
• Do not put heavy objects on the System.
To prevent malfunction or damage of the System
• Do not insert any metallic objects, such as wires, hairpins,
coins, etc. into the System.
• Do not block the vents.
There are no user-serviceable parts inside. If anything
goes wrong, unplug the power cord and consult your
dealer.
1
To a wall outlet
Plug the AC power cord only after all connections are complete.
To connect the speaker cords
For better FM reception
Disconnect the supplied FM antenna, and connect
to an outdoor FM antenna using a 75 Ω wire with
coaxial type connector (IEC or DIN45325).
From right
Outdoor FM antenna
speaker
(not supplied)
NOTES:
• Make sure the antenna conductors do not touch any other
terminals, connecting cords and power cord. Also, keep the
To connect the AM loop antenna
antennas away from metallic parts of the System, connecting
cords, and the AC power cord. This could cause poor reception.
• Keep the AM loop antenna cable wrapped around the AM loop
antenna frame, otherwise the effectiveness and sensitivity of the
AM loop antenna may be reduced.
Turn AM loop antenna until
• Make sure both the speakers are connected correctly and firmly.
the best reception is obtained.
• When connecting the speaker cords, match the polarity of the
speaker terminals: red color to (+) and black color to (–).
• DO NOT connect more than one speaker to each terminal.
• DO NOT allow the conductor of the speaker cords to be in touch
with the metallic parts of the System.
2
Basic and Common Operations
[European Union]
These symbols indicate that the electrical
and electronic equipment and the battery
Remote sensor
with this symbol should not be disposed
of as general household waste at its end-
of-life. Instead, the products should be
handed over to the applicable collection
points for the recycling of electrical and
electronic equipment as well as batteries
for proper treatment, recovery and
recycling in accordance with your national
legislation and the Directive 2002/96/EC
and 2006/66/EC.
By disposing of these products correctly,
you will help to conserve natural resources
and will help to prevent potential negative
effects on the environment and human
health which could otherwise be caused
by inappropriate waste handling of these
products.
For more information about collection
points and recycling of these products,
please contact your local municipal office,
your household waste disposal service
or the shop where you purchased the
product.
Penalties may be applicable for incorrect
disposal of this waste, in accordance with
national legislation.
[Business users]
If you wish to dispose of this product,
Display Demonstration
please visit our web page
When you plug in the System, the display demonstration
http://www.jvc.eu/ to obtain information
automatically starts.
To cancel the display demonstration, press and hold DEMO until
about the take-back of the product.
"DEMO CLR" is displayed while the System is on standby.
[Other Countries outside the European
• When the ECO Mode is activated, the display demonstration does
Union]
not work (and you cannot deactivate it).
These symbols are only valid in the
• When the display demonstration is activated, it also starts if no
European Union.
operation is done for about 2 minutes while the System is turned
If you wish to dispose of these items,
on.
please do so in accordance with applicable
national legislation or other rules in your
country for the treatment of old electrical
Laser Touch Operation
and electronic equipment and batteries.
You can use 4/¢ and VOL +/– on the front panel by sliding
your finger up or down on the illumination.
To use 4/¢
To use VOL +/–
Playing Back a Disc/USB Mass Storage Class Device
This System can play back...
– CD.
– CD-R/CD-RW recorded in audio CD format (CD-DA) or recorded MP3/WMA files
in ISO 9660 format.
– USB mass storage class device containing MP3/WMA files.
• When playing back an MP3 or WMA track, corresponding indicator lights up.
Loading a Disc
(on the System only)
1
Touch to open the disc tray.
2
• When using an 8 cm disc, place it on the inner
circle of the disc tray.
Press and hold
3
Touch to close the disc tray.
Release
Insert
Connecting a USB Mass Storage Class Device
You can connect a USB mass storage class device such as a USB flash memory
device, MP3 player, multimedia card reader, etc. to the System.
Front view
Red
Red
Black
Black
From left
speaker
NOTES:
• When connecting with a USB cable, use the USB 2.0 cable whose length is less than 1 m.
• USB mass storage class device is charged through the USB REC/PLAY terminal when
the System is turned on and the source is "USB."
• You cannot connect a computer to the USB REC/PLAY terminal of the System.
• Do not disconnect the USB mass storage class device when the System is turned on. It
may cause malfunction of both this System and the device.
• Noise and static electricity may stop the USB mass storage class device sound. In this
case, disconnect the USB mass storage class device and connect it again after turning
off the System.
• Depending on the shape of USB mass storage class device, the USB terminal may not
be fully inserted into the USB REC/PLAY terminal on the System. In such a case, use a
USB extension cable (not supplied) to connect.
Prohibiting Disc Ejection
(on the System only)
You can lock the disc tray so that no one can eject the loaded disc.
While the System is on standby...
To cancel the prohibition, repeat the same
procedure.
The operations on pages 4 to 6 are explained using the remote control, unless mentioned otherwise. However, if the System has the same or similar button names, they can also be
used for the operations.
STANDBY lamp
Point at the remote sensor on the front panel.
PHONES jack
Headphones
(not supplied)
Stereo mini plug cord
Using Headphones
Be sure to turn down the volume before connecting or putting on
the headphones.
• Connecting the headphones will deactivate the speakers.
• Sound adjustments also affect the sound through the headphones.
Motion Sensor on the Front Panel
When you move your hand close to the front panel while the System
is on standby, the controls on the front panel illuminate.
• When no operation is done for about 5 seconds, the illumination
turns off.
• When the ECO Mode is activated, the motion sensor does not work.
Touch to turn on the System.
3
Basic Disc/USB Mass Storage Class Device Operations
To
Press
Indication/Result
Play back the disc
• During playback, press again to pause.
Play back the USB
mass storage class
device
Stop playback
• While playback is stopped, total track number
and total playing time (for MP3/WMA files,
group number and track number) appear.
Select a track
Select the next tracks.
To go back to the beginning of the current or
previous tracks.
Select a group
Select the next groups.
(MP3/WMA only)
Select the previous groups.
Forward search/
Press and hold to fast-forward the track during
Reverse search
playback.
Press and hold to fast-reverse the track during
playback.
Change
(only for USB)
the display
Press repeatedly.
USB cable (not
USB memory
information
supplied)
(not supplied)
NOTES:
• If no disc is inserted or no USB mass storage class device is connected, "NO DISC" or
"NO USB" appears on the main display.
• If MP3/WMA files are not recorded on the disc or in the USB mass storage class device,
or
"NO PLAY" appears on the main display.
Playing Repeatedly—Repeat Play
Press repeatedly to specify the repeat mode as follows:
1
RPT TRK:
Repeats the current (or specified) track. [
RPT GRP:
Repeats all tracks in the current group (MP3/WMA
only). [
]
RPT ALL:
Repeats all tracks. [
ALL ]
RPT OFF:
Normal playback
2
or
4
Press
To
Indication/Result
Main
Remote
unit
Turn on or off
The STANDBY lamp on the System turns off/on.
(standby) the power
Select a source
See "Playing Back a Disc/USB Mass Storage Class Device"
on page 4.
Press repeatedly to select "FM" or "AM" as the source.
• See "Listening to FM and AM Broadcasts" on page 5.
See "Listening to Other Equipment" on page 5.
Adjust the volume
Drop the volume in
To restore the volume, press again, or adjust the
a moment
volume level.
Select the Sound
Press repeatedly to select the desired Sound Mode.
Mode
The SOUND indicator lights up.
(canceled)
Emphasize the
The S.TURBO indicator lights up.
sound (Sound
To cancel this function, press again.
Turbo)
Reinforce the bass
The HBS indicator lights up.
sound (Hyper Bass
• When Sound Turbo function is activated (see above),
Sound)
the HBS indicator goes off and HBS button does not
work.
To cancel this function, press again.
Change the display
Press repeatedly when the System is turned on.
brightness
(canceled)
Turn off the display
Press repeatedly while the System is on standby.
while on standby
Clock
DISP OFF:
Turns off the display with the motion sensor
on.
ECO ON:
Turns on the ECO (Ecology) Mode.
ECO Mode reduces power consumption
while the System is on standby by turning
off the display and motion sensor.
NOTE:
DO NOT turn off (standby) the System with the volume set to an extremely high level; otherwise, the sudden
blast of sound can damage your hearing, speakers and/or headphones when you turn on the System or start
playback.
Programming the Playing Order—Program Play
(only for Disc)
1
Select disc as the source.
2
Activate the Program Play.
3
Select tracks you want for Program Play.
• For MP3/WMA files only: You can also use UP or
DOWN.
or
4
Press to store the selected track.
5
Repeat steps 3 and 4 to program other tracks you want.
• If you try to program a 33rd track, "PGM FULL" appears.
6
The tracks are played back in the programmed
order.
Operations for Program Play (while not playing)
• To check the programmed contents, press 4 or ¢.
• To add tracks, repeat steps 3 and 4 above.
• To erase the entire program, press and hold CANCEL for about 2 seconds.
• To exit from Program Play, press PROGRAM or 7.
– The stored program is kept.
Playing at Random—Random Play
(only for Disc)
1
Select disc as the source.
2
Press repeatedly to select the desired Random Mode.
RANDOM:
Plays all tracks in random order. [ALL RND ]
RND GRP:
Plays tracks in the current group in random
order. (MP3/WMA only). [
RND ]
RND OFF:
Normal playback
1]
3
Playback starts in random order.
Operations for Random Play
• To skip a track, press ¢.
• To go back to the beginning of the current track, press 4.

Hide quick links:

Advertisement

loading

  Related Manuals for JVC 0209RYMMDWDAT

This manual is also suitable for:

Lvt1989-001aUx-gn6
