- Page 1 SF-SA-180-D PIR HiLo 10A.qxd 16/05/2005 11:17 Page 1 PIR Motion Detector E-808 IQ Europe Limited Sandbeck Lane, Wetherby LS22 7TW. Visit us at www.iq-europe.co.uk Version 2 : 02/05 Installation helpline 0871 717 1100 IQ-SA-180-D-GR...
- Page 2 SF-SA-180-D PIR HiLo 10A.qxd 16/05/2005 11:17 Page 2 MANUFACTURER'S EXTENDED WARRANTY In addition to your statutory rights relating to this product it is also guaranteed by IQ (Europe) Limited ("IQ") for 12 months from the date of purchase against faulty materials or workmanship which affect its designed ability to detect or switch.
-
Page 3: General Information
SF-SA-180-D PIR HiLo 10A.qxd 16/05/2005 11:17 Page 3 SECTION ONE GENERAL INFORMATION The unit utilises passive infrared technology to detect heat radiation of moving human bodies. The dual output facility operates the attached lighting load at two light levels during the hours of darkness: high power security output when it senses movement within its detection field, dimmable courtesy output to provide an attractive low level of light when no movement is detected. -
Page 4: Installation
SF-SA-180-D PIR HiLo 10A.qxd 16/05/2005 11:17 Page 4 SECTION THREE INSTALLATION After choosing a suitable location (see previous section) install the unit as follows: The unit is suitable for connection to a 240 V ac 50Hz electricity supply. It is suggested that 3-core round flexible cable of 1mm²... -
Page 5: Connection Diagram
SF-SA-180-D PIR HiLo 10A.qxd 16/05/2005 11:17 Page 5 Ensure that all connections are secure. Ensure the terminal block is attached to its mounting posts in the sensor body. Un-hook the sensor unit from the wall plate and re-attach to the wall plate box as follows:- Ensure no wires are trapped. -
Page 6: Top View
SF-SA-180-D PIR HiLo 10A.qxd 16/05/2005 11:17 Page 6 TOP VIEW 180º Time Dusk SIDE VIEW 2.5m Lens Mask Less sensitive Restrict long detection Restrict short detection More Restrict RHS detection Restrict LHS detection sensitive... -
Page 7: Operation And Testing
SF-SA-180-D PIR HiLo 10A.qxd 16/05/2005 11:17 Page 7 SECTION FOUR OPERATION AND TESTING WALK TESTING PROCEDURE The sensor will rotate from left to right, and tilt forward or backward. Adjust the sensor to point in the desired direction. Set the adjustment controls on the underside of the unit (diagram C) to the following positions: DUSK - Fully clockwise DIMMER - Fully anti-clockwise TIME - Fully anti-clockwise... -
Page 8: Technical Specifications
If problems still exist, do not immediately return the unit to store. Telephone the IQ Customer Helpline 0871 71 71 100 Weekdays 9.00am - 5.00pm support@iq-group.com www.iq-europe.co.uk Qualified Customer Support Co-ordinators will be on-line to assist in resolving your query. -
Page 9: Troubleshooting Guide
SF-SA-180-D PIR HiLo 10A.qxd 16/05/2005 11:17 Page 9 SECTION SIX TROUBLESHOOTING GUIDE PROBLEM SOLUTION o Lamp stays ON all the time at Cover PIR lens with a thick cloth. If the light turns out, check night. detection area for heat or reflective source. If the light stays on, check wiring. - Page 10 SF-SA-180-D PIR HiLo 10A.qxd 16/05/2005 11:17 Page 10 180 degree rotation of sensor head ensures accurate detection control Ceiling or eave mount Wall Mount Wiring Box fixing screw.
- Page 11 SF-SA-180-D PIR HiLo 10A.qxd 16/05/2005 11:17 Page 11 Installation aid. Clip main body onto wall plate for easier wiring Extra view shows detail of clip arrangement 1. Align top edge and “click 2. Rotate sensor body down and “click” lower edge into place Fully tighten sensor fixing screw...
- Page 12 SF-SA-180-D PIR HiLo 10A.qxd 16/05/2005 11:17 Page 12 DID YOU KNOW... IQ products are designed and manufactured to give many years of trouble-free service. The materials used during manufacture have been selected to allow the product to be easily recycled when no longer functional.
