Step 2
Select the desired camera channels to display on the multi
screen.
Select the [Setup] button of "Camera setup".
→ The setup page for camera channel allocation will be
displayed.
Note:
• The [Setup] button is displayed on "Camera setup" for
multi screen display patterns for which any camera
channels can be selected. The [Setup] button is not dis-
played for multi screen display patterns for which any
camera channels cannot be selected.
Step 3
Select the desired camera channels to display on each seg-
ment on the multi screen.
To return to the [Common] tab, select the [Back] button.
Note:
• It is impossible to select the same channel to display
images from it on multiple segments on the multi screen.
• When configuring from a PC (web browser), images from
cameras will not be displayed.
