- Page 1 Reverse Osmosis Drinking Water System Installation, Operation and Service Manual #90012 Rev. 06/05 June - November 2005...
- Page 3 This volume of water represents approximately two days of production. The water flushed should be disposed of to the drain. Feed Water Quality: This reverse osmosis drinking water system is not intended to be used for the treatment of water that is microbiologically unsafe or of unknown quality. If...
-
Page 4: Table Of Contents
Maintenance ............................10 Sanitization Procedures ........................11 Maintenance Schedule ........................14 Parts List and Drawing for E75TFC-3SF / E50TFC-3SF ..............15 Parts List and Drawing for E35TFC-2SF.....................16 Reverse Osmosis Drinking Water System Flow Diagram (all models) ..........17 Troubleshooting Guide.........................18 Warranty Information & Addresses ......................20... -
Page 5: Introduction
Now you can relax and enjoy the benefits of great tasting water supplied by your reverse osmosis drinking water system. Remember that good quality water is important to maintaining a healthy lifestyle. You can also feel good about the money you have saved by installing your own drinking water system instead of dealing with the expense and hassle of bottled water delivery. -
Page 6: Product Specifications & Application Guidelines
Rejection percentages are dependent on the supply conditions and the substance being measured. Notes: The performance of a reverse osmosis membrane is highly dependent upon pressure, temperature and TDS. The actual volume of product water and rejection percentage will vary with differences from the test conditions that membrane ratings are based upon. -
Page 7: Your New Reverse Osmosis System (Supplied Items Checklist)
Out of the box, your new R.O. System should be supplied with the following items. If any items appear to be missing, please contact the distributor who sold the system. 1. Pressure Tank 2. Reverse Osmosis System, complete with tubing bundle 3. Reverse Osmosis membrane element (in sealed protective bag) 4. -
Page 8: Installation
Installation All State/Provincial and local government codes regarding installation of these devices must be observed. Verify Water Supply is Potable The water supply must meet provincial/state and/or national standards for potable drinking water. Water samples should be sent to a certified laboratory for analysis. Placement of Components Placement of the various components of the system will vary from installation to installation. - Page 9 Installation of Feed Water Assembly The system comes supplied with a saddle-type valve with mounting hardware and is intended to be used on 3/8" to 1/2" copper tubing cold water supply line. NOTE: It is not to be used on flex lines. a.
- Page 10 NOTE: Some state or local codes may require that the drain saddle be served by a trap other than the one serving the garbage disposal. Before making a connection as shown in Figure 5, please check with code authorities. Figure 5 - Drain Saddle Assembly Vertical Placement Garbage Disposal Never Place Here...
- Page 11 Installation of Ball Valve Assembly The ball valve and quick connect adapter must be installed on the RO storage tank. a. Put 2-3 wraps of Teflon tape on the storage tank threads, and on the 1/4" x 3/8" male connector. b.
- Page 12 Installation of Spigot See separate installation instructions for spigot Installation of Membrane Important: Keep the membrane and your hands clean in order to avoid bacterial contamination of the membrane. 1. Disconnect the hose on the end of the membrane housing end cap. 2.
-
Page 13: Startup And Operation
Start-Up Procedure WARNING: To prevent microbiological growth and freezing, this reverse osmosis system contains a preservative solution which, if ingested, may cause irritation of the gastrointestinal tract, colic, diarrhea or other similar symptoms. Therefore, 5 gallons (approximately two full tanks) must be drawn from the spigot to flush out the preservative. -
Page 14: Maintenance
- The pre-filter contains a 5 micron mechanical filter element. Its function is to remove suspended particles from the feed water, thus reducing the possibility of clogging the reverse osmosis membrane. The pre-filter element should be replaced every twelve months or earlier depending on the quality of the feed water. -
Page 15: Sanitization Procedures
• Whenever evidence of harmful bacteriological contamination of the system has been discovered. In this case contact your local water treatment specialist to disinfect your reverse osmosis system, and identify and eliminate the source of contamination. IMPORTANT: This Reverse Osmosis Drinking Water System should not be used on any water supply sources that are microbiologically unsafe or of unknown quality without adequate disinfection before and/or after the system. - Page 16 Sanitization Steps STEP 1: TURN OFF WATER SUPPLY - CLOSE INLET SUPPLY NEEDLE VALVE ALL THE WAY STEP 2: DEPRESSURIZE SYSTEM - OPEN FAUCET SUPPLY UNTIL ALL WATER IS EMPTIED Use a clean drip pan or basin to continue to catch any spilled water remaining in the housings as you remove the membrane and cartridges.
- Page 17 STEP 8: POUR THE MIXED DISINFECTANT SOLUTION INTO THE 1ST PRE-FILTER SUMP AND RE-INSTALL. STEP 9: OPEN THE INLET SADDLE VALVE AND OPEN THE FAUCET. WHEN WATER BEGINS RUNNING FROM THE FAUCET AGAIN, CLOSE THE FAUCET AND ALLOW THE PRESSURE TANK TO FILL FOR 5 - 10 MINUTES. WHEN THE PRESSURE TANK FEELS LIKE IT HAS FILLED, CLOSE THE INLET SUPPLY NEEDLE VALVE.
-
Page 18: Maintenance Schedule
Reverse Osmosis Drinking Water System Maintenance Record Installation Date: ___________ Use this chart to record the dates of any cartridge changes. It is meant to assist you on keeping track of this maintenance. #15500243 #26091 #26081 #92008,92035,92022 Sanitization WTB10 WSW-05B... -
Page 19: Parts List And Drawing For E75Tfc-3Sf / E50Tfc-3Sf
Parts List and Drawing - Models E(50 & 75) TFC-3SF Note: There may be some parts listed, which are not included with this model. An approved air gap is required by most plumbing codes to prevent waste water back flow. Drawing No. -
Page 20: Parts List And Drawing For E35Tfc-2Sf
Parts List and Drawing - Model E35TFC-2SF Note: There may be some parts listed, which are not included with this model. An approved air gap is required by most plumbing codes to prevent waste water back flow. Drawing No. Description Item No. -
Page 21: Reverse Osmosis Drinking Water System Flow Diagram (All Models)
Reverse Osmosis Drinking Water System Flow Diagram (all models) -
Page 22: Troubleshooting Guide
Trouble Shooting Guide Probable Cause Solutions No water or not enough water 1. Feed water shut off Turn on feed water 2. Storage tank valve shut off Open tank valve 3. Plugged or crimped lines Remove blockage or crimp in lines 4. -
Page 24: Warranty Information & Addresses
Two Year Pro-Rated Warranty The reverse osmosis membrane is warranted to be free from defects in material and workmanship for one year from date of purchase, when operated within the application guidelines. If found to be defective, we will replace said membrane free of charge.
