- Page 1 Economy Reverse Osmosis Drinking Water System Installation, Operation and Service Manual Models E50TFC-3NSF and E75TFC-3NSF are tested and certified by WQA against NSF/ANSI 58 for the reduction of TDS. #90016 8/08...
- Page 2 IMPORTANT WARNING - PLEASE READ System Flushing: This reverse osmosis system contains a preservative solution to prevent microbiological growth and freezing which if ingested may cause irritation of the gastrointestinal tract, colic, diarrhea or other symptoms. Therefore, approximately 5 gallons of water must be drawn from the tap to flush out the preservative solution before using the system.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction ............................1 Models and System Configuration......................2 Parts List and Drawing ..........................3 Functional Description ...........................4 Your New Reverse Osmosis System (supplied items checklist) ............4 Installation Requirements ........................5 Installation of Feed Water Assembly ..................7 Installation of Drain Saddle Assembly ..................7 Installation of Ball Valve Assembly ...................8 Drilling Sink Hole ........................8 Installation of Non-Air Gap Faucet ...................8... -
Page 4: Introduction
INTRODUCTION Congratulations, on the purchase of your new Economy Reverse Osmosis Drinking Water System. Treated with care and regular maintenance, your new system will provide many years of service delivering purified water to the tap. By now, you have probably already opened the box to survey the contents. Please take a few moments to review this manual before proceeding with the installation and use of the system. -
Page 5: Models And System Configuration
Certified Contaminant Reduction Performance Models E50TFC-3NSF and E75TFC-3NSF are tested and certified by WQA against NSF/ANSI 58 for the reduction of TDS. The following Economy Reverse Osmosis Systems conform to NSF/ANSI 58 for the specific performance claims as verfied and substantiated by test data. -
Page 6: Parts List And Drawing
Parts List and Drawing - Models E(50 & 75) TFC-3NSF Note: There may be some parts listed, which are not included with this model. Component and Interconnection Locators* Drawing No. Description Item No. Drawing No. Description Item No. 1..Tubing, 1/4" OD, poly, natural 92600 Membranes and Filters 2A.. -
Page 7: Functional Description
Functional Description Feed water enters the 5-micron pre-filter, which filters out suspended particles such as dirt or sediment. The filtered water then enters the pre-carbon filter (3 sump models only), which contains granular activated carbon, which removes any chlorine from the water. The water then enters the reverse osmosis membrane. -
Page 8: Installation Requirements
These RO systems contain a replaceable treatment component critical to the efficiency of the system. Replacement of the reverse osmosis component should be with one of identical specification, as defined by WaterGroup to assure the same efficiency. Product water shall be tested periodically to verify the system is performing properly. - Page 9 To Prepare Tubing Cut tube ends square and straight. Do not deform tube (i.e., cause tube to compress its diameter so it is no longer round). Make sure outer surface of tube is clear of marks or scratches for a length equal to twice tube diameter. This allows "O"...
-
Page 10: Installation Of Feed Water Assembly
Installation of Feed Water Assembly The system comes supplied with a saddle-type valve with mounting hardware and is intended to be used on 3/8" to 1/2" copper tubing cold water supply line. NOTE: It is not to be used on flex lines. a. -
Page 11: Installation Of Ball Valve Assembly
Figure 5 - Recommended Drain Saddle Connections Vertical Placement Garbage Disposal Never Place Here Horizontal Placement Installation of Ball Valve Assembly The ball valve and quick connect adapter must be installed on the RO storage tank. a. Install the 1/4" x 3/8" male connector onto the ball valve. Tighten the fitting very gently until it is snug. Be very careful not to over-tighten or the threads may strip. -
Page 12: Installation Of Wall Mounted Airgap
Installation of Wall Mounted Airgap™ Specifications Location: Above RO system module and rinse water drain point. Air Gap: 1” of free flow. Water Flow: 0.5 gallons per minute maximum. Inlet Tubing: 1/4” O.D. polyethylene. Outlet Tubing: 3/8” O.D. polyethylene. Installation Instructions Important: The AIRGAP™... -
Page 13: Installation Of Filters
Installation of Filters A. Sump #1 - Sediment Pre-filter 5 micron Cartridge B. Sump #2 - Carbon Pre-filter Cartridge C. Sump #3 - Carbon Post-filter Cartridge Installation of Membrane Important: Keep the membrane and your hands clean in order to avoid bacterial contamination of the membrane. -
Page 14: Start-Up Procedure
Start-Up Procedure WARNING: To prevent microbiological growth and freezing, this reverse osmosis system contains a preservative solution which, if ingested, may cause irritation of the gastrointestinal tract, colic, diarrhea or other similar symptoms. Therefore, 5 gallons (approximately two full tanks) must be drawn from the spigot to flush out the preservative. This may represent two or three days of running, depending on conditions of the feed water. -
Page 15: Maintenance Schedule
Maintenance Schedule This schedule is designed for the average potable water supply and should be followed to ensure the proper functioning of your drinking water system. Pre-Filter - The pre-filter contains a 5 micron mechanical filter element. Its function is to remove suspended particles from the feed water, thus reducing the possibility of clogging the reverse osmosis membrane. -
Page 16: Sanitization Procedure For Your Reverse Osmosis System
Sanitization Procedures for your Reverse Osmosis System Sanitization is a simple but important part of a regular maintenance routine required to keep your Reverse Osmosis Drinking Water System operating properly. Recording the dates of all maintenance and sanitization done on the unit is a good idea as well as marking on your calendar future service interval dates. - Page 17 Sanitization Steps STEP 1: TURN OFF WATER SUPPLY - CLOSE INLET SUPPLY ALL THE STEP 2: DEPRESSURIZE SYSTEM - OPEN FAUCET SUPPLY UNTIL ALL WATER IS EMPTIED Use a clean drip pan or basin to continue to catch any spilled water remaining in the housings as you remove the membrane and cartridges.
- Page 18 STEP 8: POUR THE MIXED DISINFECTANT SOLUTION INTO THE 1ST PRE-FILTER SUMP AND RE-INSTALL. STEP 9: OPEN THE INLET VALVE AND OPEN THE FAUCET. WHEN WATER BEGINS RUNNING FROM THE FAUCET AGAIN, CLOSE THE FAUCET AND ALLOW THE PRESSURE TANK TO FILL FOR 5 - 10 MINUTES.
-
Page 19: Maintenance Record
Reverse Osmosis Drinking Water System Maintenance Record Installation Date: ___________ Use this chart to record the dates of any cartridge changes. It is meant to assist you on keeping track of this maintenance. #26091 #26081 #92035 and 92022 Sanitization WSW-05B WCB-10 TFC RO Membrane Procedure... -
Page 21: Reverse Osmosis Drinking Water System Flow Diagram (All Models)
Reverse Osmosis Drinking Water System Flow Diagram (all models) -
Page 22: Troubleshooting Guide
Trouble Shooting Guide Probable Cause Solutions No water or not enough water 1. Feed water shut off Turn on feed water 2. Storage tank valve shut off Open tank valve 3. Plugged or crimped lines Remove blockage or crimp in lines 4. - Page 24 WATERGROUP INC. WATERGROUP COMPANIES INC. 193 Osborne Road 580 Park Street...
