- Page 1 Controlant Transceivers User‘s Guide Type Description CO 01.01 Wireless transceiver with GPRS Version 1.1 2/9/2011 Controlant ehf | Grensasvegur 7, 108 Reykjavik, Iceland |+354-517-0630 | www.controlant.com...
- Page 2 ©Controlant ehf. All Rights Reserved. Controlant provides this document “as is,” without warranty of any kind, either expressed or implied, including, but not limited to, the implied warranties of fitness or merchantability for a particular purpose. Controlant may make improvements and/or changes in this manual or in the product(s) and/or the program(s) described in this manual at any time.
-
Page 3: Table Of Contents
Scope ................................4 Warranty exception ............................4 Additional reference material ........................4 Questions and technical support........................4 Controlant Wireless GPRS Transceiver - CO 01.01 ..................... 5 Overview ................................. 5 Enclosure ................................ 5 Power options ..............................5 Power supply .............................. 5 Battery pack ............................... -
Page 4: General Information
Warranty exception Opening the enclosure of the CO 01.01, unless supervised or carried out by service personnel approved by Controlant, voids all warranty against equipment malfunction. Controlant’s CO 01.01 wireless transceiver products ships with batteries included. Lithium batteries must be replaced by Controlant or service personnel approved by Controlant. -
Page 5: Controlant Wireless Gprs Transceiver - Co 01.01
Battery pack Each CO 01.01 transceiver has a built in lithium Ion battery which will keep the system running in case of external power failure. The battery should only be replaced by Controlant employees or trained personnel approved by Controlant. In case of replacement, only batteries approved by Controlant should be used. -
Page 6: Leds, Buttons And Connectors
LEDs, Buttons and Connectors Figure 2: LED, On/Off switch and DC power connector for the CO 01.01 transceiver. Connection and power-on 1. Connect the DC plug of the external power supply to the DC power inlet. 2. Turn on the power switch. -
Page 7: Power Connector
The power connector dimensions are 2.5 x 5.5 x 14 mm as shown in Figure 3 and the polarity is shown in Figure 4Figure 3: Mechanical drawings of the DC power plug on the CO 01.01. Figure 3: Mechanical drawings of the DC power plug on the CO 01.01... -
Page 8: Specifications And Ratings
Specifications and ratings Environmental range The wireless transceiver’s working range is the following 1. Humidity a. 0-99% humidity for normal operation. b. Long term exposure to high levels of humidity may cause unexpected behavior in device. 2. Temperature a. Recommended operating range is 0-40°C b. -
Page 9: Antennas
Antenna connectors are RP-SMA and the GPRS antenna connector is SMA. Figure 6: Antenna connectors on the CO 01.01 Fuse replacement CO 01.01 wireless transceivers come with an internal fuse. The fuse should only be replaced by Controlant or service personnel approved by Controlant. -
Page 10: Wireless Connectivity
Wireless Connectivity Controlant wireless devices have up to 400m range in open air. The communication frequency channels are around 868MHz. The range in open air depends on various factors, including: 1. Mounting and antenna orientation. 2. Proper assembly and selection of antennas.
