- Page 1 5 0 0 W P I R H A L O G E N F L O O D L I G H T S L B 5 0 0 - B l a c k / S L W 5 0 0 - W h i t e 1 5 0 W P I R H A L O G E N F L O O D L I G H T S L B 1 5 0 - B l a c k / S L W 1 5 0 - W h i t e...
- Page 2 SLB500/SLW500 500W PIR HALOGEN FLOODLIGHT WEATHERPROOF LAMP TYPE 500w IP44 MAXIMUM PIR SWITCHING 2000w MAXIMUM MANUAL ON/OFF OVERRIDE TIME ON DETECTION ANGLE 5sec 5min ADJUSTABLE 140° ADJUSTABLE DUSK TO DAWN DETECTION RANGE ADJUSTABLE ADJUSTABLE 3 YEAR GUARANTEE In the unlikely event of this product becoming faulty due to defective material or manufacture, within 3 years of the date of purchase, please return it to your supplier with proof of purchase and it will be replaced free of charge.
- Page 3 SLB150/SLW150 150W PIR HALOGEN FLOODLIGHT WEATHERPROOF LAMP TYPE 150w MAXIMUM IP44 PIR SWITCHING 2000w MAXIMUM MANUAL ON/OFF OVERRIDE TIME ON DETECTION ANGLE 5sec 5min ADJUSTABLE 140° ADJUSTABLE DUSK TO DAWN DETECTION RANGE ADJUSTABLE ADJUSTABLE 3 YEAR GUARANTEE In the unlikely event of this product becoming faulty due to defective material or manufacture, within 3 years of the date of purchase, please return it to your supplier with proof of purchase and it will be replaced free of charge.
-
Page 4: General Information
SECTION ONE GENERAL INFORMATION The unit utilises passive infrared technology to detect heat radiation of moving human bodies. Upon detection, the lamp will illuminate for a user-determined time period. An integral daylight sensor ensures night-only operation. PARTS INCLUDED - Luminaire c/w PIR Sensor unit. - Instruction manual. -
Page 5: Installation
SECTION THREE Wiring Box Cover INSTALLATION Retaining Lugs Insert small screwdriver and gently push and lift After choosing a suitable location cover off. (see previous section) install the unit as follows: Remove the wiring box cover by gently pushing the side retaining lugs inwards and lift off. -
Page 6: Connection Diagram
CONNECTION DIAGRAM Mains Supply Isolation Switch The diagram below also shows the required connections for the addition of slave luminaires. When adding slaves, be sure not to exceed the maximum switchable load (see Technical Specifications). -
Page 7: Operation And Testing
SECTION FOUR OPERATION AND TESTING WALK TEST PROCEDURE The sensor will rotate from left to right, and tilt forward or backward. Adjust the sensor to point in the required direction. The unit can be set up in daylight or at night. Set the time adjustment to minimum (fully anti-clockwise). -
Page 8: Technical Specifications
MASKING THE SENSOR LENS To restrict the sensor coverage, preventing detection in unwanted areas, mask the sensor lens using the masking label provided (see diagram D). For your information, the top section of the lens covers long range detection, the bottom covers short range. Similarly the left and right lens sections cover the left and right detection areas respectively. -
Page 9: Troubleshooting Guide
SECTION SIX TROUBLESHOOTING GUIDE PROBLEM SOLUTION Lamp stays ON all the time The unit may be suffering from false activation. Cover the sensor lens completely with a thick cloth. This will prevent at night. the sensor from "seeing" anything. If the unit now switches off after the set time duration and does not re- activate, this indicates that the problem was caused by PIR keeps activating for no... - Page 10 TOP VIEW 140º SIDE VIEW 2.5m Lens Mask Less sensitive Restrict long detection Restrict short detection More sensitive Restrict RHS detection Restrict LHS detection...
-
Page 11: Product Range
CONSUMER SLW2000 PRODUCT RANGE 2000W PIR SLB500 Light 500W PIR Controller - Halogen White Floodlight - Black SLB88 SLW500 60W PIR 500W PIR Bulkhead Halogen Light - Floodlight - Black White SLB150 SLW89 150W PIR 60W PIR Halogen Bulkhead Floodlight - Light - Black White... - Page 12 Helpline 020-8450-0515 For a product brochure please contact: Timeguard Ltd. Victory Park, 400 Edgware Road, London NW2 6ND or email csc@timeguard.com...
