- Page 1 FLOODLIGHT RECEIVER Cat No’s. TLRX150B TLRX500B...
- Page 2 Introduction The TLRX150B/500B Floodlight Receiver is part of the Timeguard range of PIR products which communicate by radio frequency (r.f.) signals. This enables substantial amounts of wiring to be eliminated which is particulary useful in long wiring runs and coverage of outbuildings.
-
Page 3: Parts Included
We suggest that the Tx is placed in its optimum position to give the coverage and detection required, then the TLRX150B/500B is placed at a point where it can receive the Tx units signal. This will be less than 100m away if walls or chain link... -
Page 4: Installation
Installation IMPORTANT Switch off the electricity at the fuse box by removing the relevant fuse or switching off the circuit breaker before proceeding with the installation. Remove the wall plate from the floodlight by unscrewing the fixing screw (Fig A). This screw is captive. - Page 5 Connect the cable to the terminal block as follows (see connection diagram): NEUTRAL(Blue) EARTH (Green/Yellow) LIVE (Brown) Ensure the connectors are secure. Place terminal block onto its securing pillar on the wall bracket (Fig E) Remove the tether and retain for future use. Fit floodlight to wall bracket and secure by the fixing screw (Fig A) Connection Diagram...
- Page 6 *Any other Rx units required to learn the code of this new Tx unit should be left connected. ** If introducing the TLTXK2 hand held transmitter press TLRX150B/500B the “1” button on this unit to activate the ***If the button is pressed for 5 seconds or more then all...
-
Page 7: Manual Override
After Programming, set the ON TIME dial. To set how long the lamp will remain on after the TLRX150B/500B has received a signal, set the ON TIME dial on it to 1, 3 , 5 or 12 minutes. See fig D. -
Page 8: Troubleshooting Guide
2000W (e.g. 4 x 500W Tungsten Maximum Switchable Load: Halogen) TLRX500B:-230V Linear Tungsten Lamp Type: Halogen 500W (R7S cap) TLRX150B:-230V Linear Tungsten Halogen 150W (R7S cap) Time On Adjustment: 1, 3, 5 and 12 minutes Environmental Protection: IP44 (suitable for outdoor use) - Page 9 Incoming Wire Template 75mm 3” 25mm 1” Use this template to estimate incoming cable length...
-
Page 10: Year Guarantee
5 Year Guarantee In the unlikely event of this product becoming faulty due to defective material or manufacture within 5 years of the date of purchase, please return it to your supplier in the first year with proof of purchase and it will be replaced free of charge. For years 2 to 5 or any difficulty in the first year telephone the helpline on 020 8450 0515.
