- Page 1 Owner’s Manual Digital Satellite Receiver Made in Germany Fu2_eng V.102...
-
Page 2: Table Of Contents
Contents Safety Instructions Important Instructions Warranty Connecting the receiver Front and rear panel Remote control The On Screen Display (OSD) Receiver Setup > Main Menu 10-11 Receiver Setup > Receiver Setup 11-12 Receiver Setup > LNB Configuration 12-13 Receiver Setup > OSD Parameters Controlling the Receiver 14-16 Selection of audio channels... -
Page 3: Safety Instructions
Safety Instructions Before installing your digital satellite receiver, all security and operating instructions should be read and understood. The User’s Manual should be retained for future reference. All warnings and hints on the product and in the operating instructions should be adhered to. -
Page 4: Important Instructions
Important Instructions You should unplug the receiver’s mains cable from the mains supply immediately and refer servicing to qualified service personnel, under following conditions: Power cord or plug or its electrical connection is damaged If liquid or other object got into the receiver If the product does not operate properly by following the operating instructions Product has been dropped or damaged in any other way... -
Page 5: Warranty
The receiver is marked with the CE-sign and corresponds to the essential requirements of the European Regulation 89/336 EWG, Electromagnetic Safety. After unpacking your receiver Please check, if the box for your digital satellite receiver contains following items: Receiver Remote control Power cord User’s manual... -
Page 6: Connecting The Receiver
If you additionally want to run a analogue satellite receiver, you can direct the sat-signal via the IF-OUTPUT to this device. For this purpose you’ve got OUTPUT to switch your digital satellite receiver to standby mode. For using same PC-based functions of this satellite receiver (e.g. software RS232 update), you can connect a PC to the receiver’s RS232-port. -
Page 7: Front And Rear Panel
Front and rear panel Front panel LED-Status-Display (Dual-colour-LED): LED shines red: Receiver is in Standby-Mode. LED shines green: Receiver is in normal operation mode (viewing mode). 4-digit display (Option): Shows channel number ON-/OFF Key (Standby) t Channel down s Channel up (Option) GERÄT DARF NUR VON EINEM IF INPUT... -
Page 8: Remote Control
Remote control ON-/OFF-Key: Switches receiver in “Standby” or “Power On” mode Mute: Turns sound on/off Activates TV channels of the receiver, if receiver is in Radio Mode. Otherwise: Displays programme information (short event information). LIST Displays channel list. RADIO Activates radio channels of receiver, if receiver is in TV mode. Otherwise: Displays programme information (short event information). -
Page 9: The On Screen Display (Osd)
They must be supplied to a facility, collecting and disposing exhausted batteries according to the EU environmental protection rules. The On Screen Display (OSD) The remote control is used for controlling your digital satellite receiver (set-top-box, STB). The following section describes which buttons enables you navigating in the On Screen Menu/Display. -
Page 10: Receiver Setup > Main Menu
Main menu - Hauptmenü The main menu is the entry point for all following sub menus. It is opened by using the MENU button of your remote control. Hauptmenü Main menu Grundeinstellungen Receiver Setup Sendersuche Channel Search Senderliste Channel List Sleep-Timer Sleep-Timer Information... -
Page 11: Receiver Setup > Receiver Setup
Receiver setup Use the OK button for entering the GRUNDEINSTELLUNGEN/RECEIVER SETUP menu: Grundeinstellungen Receiver Setup Gerä te-Setup Receiver Setup LNB-Konfiguration LNB Configuration OSD-Darstellung OSD Configuration Menu line „Geräte-Setup“/”Receiver Setup” is marked dark grey, now. Receiver Setup > Receiver Setup - Gerä te Setup Finally, press your remote control’s OK key again for entering the RECEIVER SETUP menu: Gerä... -
Page 12: Receiver Setup > Lnb Configuration
Receiver Setup > Receiver Setup – Gerä te Setup 4) Device Language Using buttons – or + enables you to select several languages. 5) Volume Using buttons – or + enables to set the volume level initialised when receiver is booting. -
Page 13: Receiver Setup > Osd Parameters
Receiver Setup > LNB-Configuration 1) LNB-ID ID of the corresponding satellite (at menu item LNB) for assigning the channels in the channel list to the satellite they are transmitted from. (This menu item can not be changed. The LNB ID changes automatically when modifying menu item LNB.) 2) LNB Select the satellite you want to receive. -
Page 14: Controlling The Receiver
Controlling the receiver Dual colour LED display (LED) on the front panel When you plug in AC power the dual colour LED on the receiver’s front shines red after ~ 5sec. The receiver is in standby mode now. 7-segment Display: After power on reset the standby mode is signalled at the receiver’s front (Optional) after 5sec..You can switch on your receiver now by using the button on... - Page 15 Controlling the receiver Channel change (TV channel) During channel changing, information on the current programme are displayed at the upper and lower area of your screen. These information is supplied by the corresponding channel/programme provider. Note: Duration and Transparency of these OSD graphics can be modified in menu „Receiver Setup >...
-
Page 16: Selection Of Audio Channels
Controlling the receiver Channel change (Radio channels) Press RADIO key for switching your receiver in radio mode. The TV-picture is switched off (=> screen black) and the channel/programme information is displayed only when changing channels. Now, you can select radio channels in the same way, as you did with TV channels in TV mode. -
Page 17: Epg - Electronic Programme Guide
EPG – Electronic Programme Guide Programme information will only be available if it is included in the transmission. Otherwise “There are no further information available” will be shown in the corresponding EPG OSD- graphics. Pressing button EPG (i) displays the EPG window. Pressing buttons + or –... -
Page 18: Modifying Channel List
Modifying channel list You can sort the TV (in TV mode) and Radio (in Radio mode) channels according to your personal demands/wishes. Also, you can delete channels you don’t want to use anymore. Press button MENU for displaying the main menu. There, move the cursor to menu item “Channel List”... -
Page 19: Channel Search
Channel Search Your receiver’s auto search function scans the transponders of the selected satellite for new channels. If new channels are found, they are attached at the end of the channel list automatically. The same happens to channels that are available already, if their parameters have changed (e.g. - Page 20 Channel Search 2. Experts Search The „Experts Search“ function enables you to scan a selected transponder for new channels. For this purpose you have got to enter the corresponding transponder parameters. How to do an Experts Search: For entering the “Experts Search” menu, please select menu item „Experts Search“ in menu “Channel Search”...
-
Page 21: Sleep Timer
Sleep-Timer This feature switches your digital satellite receiver into standby-mode automatically when a certain, user defined, period of time has passed. Step into main menu (see page 10), move cursor to menu item „Sleep-Timer“ and press OK for entering the “Sleep Timer” menu:... -
Page 22: Satellite Ids
Turksat 1C Connecting a analogue satellite receiver If you want to operate a analogue and a digital satellite receiver with the same antenna system, you have got to connect the IF-Input of your analogue receiver to the IF-OUTPUT of your digital receiver. -
Page 23: Problem Solving
Problem solving SYMPTOM Problem No Function, LED on front panel does not light - Power cord is not plugged in correctly - Power failure No picture - SCART cable not connected correctly - LNB Power switched off in LNB Configuration menu (see page 13) No sound - Muting active - SCART cable not plugged in correctly... -
Page 24: Technical Specifications
Technical Specifications 999 Channels 30 Satellites Videotext re-insertion Sleep-Timer Electronic Programme Guide Now/Next information Short and Extended event information Channel list editor Copy, moving, deleting etc.. blockwise modifications Channel search Auto search Expert search / Transponder scan Others Signal level monitor Spanish Radio Descriptors eva luation SWAP Function Volume control...
