Dometic Seitz GmbH
Operating Instruction HEKI 4plus
photo A
1
2
3
4
1 = open roof
2 = close roof
3 = light 1 on/off
4 = light 2 on/off
Crushing hazard
Warning. Danger of accidents!!!
do not operate the remote control when there are persons near the HEKI rooflight.
do not stop in the vicinity of the open acrylic dome
do not climb on the roof through the open acrylic dome
è The rooflight closes automatically through erroneous contact with the rain sensor, as well as contact with
humidity (fog,rain,condensation)
Before setting off close the acrylic dome and open the blinds.
Remote Control (coded)
The remote control is ready for use after inlaying the two
batteries. It functions until a distance of max. approx. 1.5 m
from the Heki rooflight (the remote control and control system
have a non-volatile memory). The red lamp is
starting current again after an interruption of the power
supply to the Heki rooflight. By pressing a button of the
remote control (e.g. lighting) in the direction of the red
lamp (picture A) this red lamp goes out. The control
lamp is switched off when the glazing panel is closed.
If the glazing panel is not closed completely the control
lamp is lighting. In
case of dysfunction see point 11 of the
installation instructions.
Lighting (optional):
Remote control buttons: Roof open, roof closed, lamp 1
switched on/off, lamp 2 switched on/off
Hold the remote control in the direction of the red control lamp
of the HEKI4 and press once both button 3 and button 4.
Now both lamps should be lit. By pressing once again button
3 and button 4, the lamps will be switched off.
Opening/closing the acrylic dome
Hold the remote control in the direction of the red control
lamp.(Photo A)
By short pressing the button 1
opened up to 70 degrees. Should an opening up to 70
degrees not be required,this could be interrupted by pressing
the button 1
once again.
Press the button 2
until the desired position is reached. The control lamp is
switching off when the glazing panel is completely locked.
Check the locking through lifting the glazing panel!
Rain sensor
The HEKI4 rooflight is equipped with an automatic rain
sensor which completely closes the rooflight By pressing the
button (open/closed), this procedure can be interrupted.
blinking when
, the glass dome will be
permanently for closing the roof
