www.smartwitness.com
SWC101S
Wireless Outdoor CCTV Kit for Windows PCs
B EF O RE Y OU BE G IN
Please unpack the box carefully and identify that all the parts are present.
The Receiver is suitable for indoor use only.
Make sure you use the recommended power input. Damage caused to the Camera or
Receiver by incorrect voltage is not covered by the warranty.
Do not attempt to open the casing to access the Camera or Receiver. Damage caused
to the products by tampering with the casing is not covered by the warranty.
Ensure the camera and receiver are positioned in an area free from dust.
Do not aim the camera at the sun or similar intense light.
Avoid installing the camera where there are thick walls, or large obstructions between
the Camera(s) and the Receiver as this may reduce the wireless connection.
SWC101S v1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SWC101S and is the answer not in the manual?

Questions and answers

Related Manuals for SmartWitness SWC101S

Summary of Contents for SmartWitness SWC101S

  • Page 1 Ensure the camera and receiver are positioned in an area free from dust. Do not aim the camera at the sun or similar intense light. Avoid installing the camera where there are thick walls, or large obstructions between the Camera(s) and the Receiver as this may reduce the wireless connection. SWC101S v1.0...

  • Page 2: System Features

    PROD U C T D E S C R I P T IO N The SWC101S is a complete wireless system designed for home or business monitoring and recording. The system uses the latest interference-free wireless signal for excellent image quality.
  • Page 3 P AC K A G E C ON T E N T S Wireless Camera with Wireless USB Receiver mounting bracket Power Adaptor for Camera DVR Software Installation CD...
  • Page 4 PART S CAMERA FRONT CAMERA REAR IR LEDs Antenna IR Sensor Camera Lens Power cable Pair button CAMERA SIDES Camera bracket (Can be rotated for free Microphone standing or wall mounting)

  • Page 5: Wall Mounting Bracket

    RE C E IV E R P A RT S RECEIVER USB Connection Antenna Power LED Camera Antenna Receiver Antenna Antenna is permanently attached to the Receives signals from the camera(s). camera. It transmits wireless signals to the Adjust the antenna to vertical position for receiver.

  • Page 6: Camera Installation

    CA M E RA I N ST A LL AT ION Plan where the camera will be positioned. Ensure that the power adaptor cable is able to connect back to the camera. It is recommended that the performance of the wireless connection is verified at the selected location area before the camera is permanently installed.

  • Page 7: M A In A P Pl I C A Ti On Wi N D Ow

    M A IN A P PL I C A TI ON WI N D OW Display Area: This area shows the image from the camera or playback page. You can choose to view in either a single or a quad (4 camera) mode. Channel Status: This area shows the status of one specific camera.
  • Page 8 MA I N AP PL I C AT ION WI N D OW con ti n u ed Camera/Display control: This area contains the display controls for the camera. : Signal strength : Pair camera (Cruise) icon : Open a snapshot folder : Adjust the size of display area : Single channel display : Quad display...

  • Page 9: Viewing Mode

    VIE WIN G M O D E The camera image displays in a quad view after it is paired as shown below: Right click on the display image to view recording in full-screen which also enables camera’s ‘Audio’ feed.
  • Page 10 SY S T E M S E T T I N G S Click the ‘Setup’ button from the main Window to access the System Settings. Language: Current language in use. Mail server: The mail server details for setting up email alerts: •...
  • Page 11 SYST EM SE TT IN GS co ntinu ed Storage Location: The folder path to which both recordings and snapshots will be saved. Web Service: You can set the following parameters: • IP Address: : Local IP address (this is generated automatically) •...
  • Page 12 S YST E M SE T T I N GS c onti n u ed Basic Settings To view the camera’s settings window, click on the ‘Setting’ button. A new window opens up with three (3) tabs; ‘Basic Settings’, ‘Image Adjust’ and ‘Recording’. From here you can enter the following information as shown below: Name &...

  • Page 13: Image Adjustment

    S YST E M SE T T I N GS c onti n u ed Image Adjustment The user can adjust the image orientation in the following ways: • Flip Horizontal • Flip Vertical • Rotate The image quality can also be adjusted for: •...

  • Page 14: Image Quality

    S YST E M SE T T I N GS c onti n u ed Recording Settings Please Note: To activate the recording feature you must click the “Detect” button in live video mode. Users can configure the following parameters: Image Quality •...

  • Page 15: Motion Detection

    SYSTE M SE TTI NGS continued Please Note: When the Scheduled Based option is selected the user will see additional options to: • Add new schedule • Edit schedule • Delete schedule Dropdown Box 2: • Full-time: Records constantly once you click the ‘Detect’ button in live video, until you click again to stop the recording (Please note that selecting the full-time option the Motion Detect and Alert Settings tabs will disappear).
  • Page 16 S YST E M SE T T I N GS c onti n u ed Preview: Click ‘Refresh View’ to refresh the live camera image. Set Detection areas: Set detection areas on the preview image. • Full Area Detection: Detect all areas. •...

  • Page 17: Alert Settings

    S YST E M SE T T I N GS c onti n u ed Alert Settings When the recording option is set as ‘Triggered’ the user can set various alert settings, as detailed below: Vibration Alert: Enables the main viewer window to vibrate when motion is detected. Message Alert: The main window pops up with a preset text message when motion is detected.
  • Page 18 PLAY BA CK Recordings are stored in a folder of your preference from the ‘Path’ dialog box in the ‘Basic Settings’ window (refer to System Settings on page 10). To play recorded files: In Viewing mode, click the ‘Playback’ icon on the main screen. Select the Date, Time and Channel from the corresponding fields and click the ‘Query’...

  • Page 19: Rem Ot E V I E Wi N G

    REM OT E V I E WI N G This camera allows you to view recordings remotely using the Local Network or Internet. To view recordings remotely: Click on the ‘Setup’ button to open the System Settings window. Tick the ‘Start Web Server’ option under Startup Options. Make a note of the IP address and Port number under Web Service.

  • Page 20: Pair Camera(S)

    SUM M AR Y Channel Select menu If more than one camera is connected to the system, just select the camera you wish to view live from the main screen. Otherwise you can use the Multiple View tool to view Multiple Cameras simultaneously.

  • Page 21: Troubleshooting

    T ROUB L E S H OOT I N G Problem Solution 1. Check all connections to the camera. Make sure the Power Adaptor is plugged in. No picture from a 2. Make sure that the camera is within range of the Receiver. camera 3.
  • Page 22 SWC1 0 1 S S P E C I F I C AT I O N S Camera Image Sensor 1/5” Digital CMOS Lens 4.9mm Angle of View 60° Minimun Illumination 0 Lux (IR on), 2.5 Lux (IR off) Night Vision Up to 10 metres Audio Wall Mount...

  • Page 23: Warranty

    WA R RA N T Y TECHNICAL SUPPORT For Technical Support please contact your local distributor. LIMITED WARRANTY This product is supplied with a 1 Year warranty. The Warranty excludes products that have been misused (including accidental damage) and damage caused by normal wear and tear. In the unlikely event that you encounter a problem with this product, it should be returned to the place of purchase.
