Summary of Contents for XTZ Sub Amp 1
- Page 1 XTZ SUB AMP1 Subwoofer Amplifier User manual © 2009 XTZ AB , www.xtz.se...
-
Page 2: Table Of Contents
Table of contents Page Contents About XTZ Technical presentation Preparations Practice of sound / Installation and placement tips Mounting and connection tips Functional reference Technical specifications Service & Support - 2-... -
Page 3: Contents
Contents XTZ SUB AMP1 offers some possibilities, so in Contents order to utilize your new loudspeaker in the best way; you should carefully read through this manual before using the loudspeaker for the first time. It may take some patience in order to make the loudspeaker sound optimal. -
Page 4: About Xtz
About XTZ Philosophy Our reference and starting point is to recreate a natural sound, but also in respect to the fact that acoustics always is a matter of taste. Our main goal is to provide the best value XTZ Goals for money. -
Page 5: Technical Presentation
Technical presentation SUB AMP 1 works just as good for those who want to power the passive subwoofers (XTZ 99 W10.17P) or any other subwoofers. SUB AMP1 can be perfect as a amplifier for bi-amping for full range speakers By using one or two subwoofers (with correct placement), it is often easier to get a better frequency response. -
Page 6: Practice Of Sound / Installation And Placement Tips
Practice of sound / Installation and placement tips This chapter contains common information on loudspeaker placement and installation. This is general rules, so there are exceptions of some rules In which room do No matter how good the equipment is, in the wrong listening environment it will inevitably sound bad. - Page 7 The placement of the subwoofer in the room Placement of the dramatically affects the overall frequency response subwoofer and sound level of the system. At low frequencies the effect of the room is strong. Even a slight change in the subwoofer's location can make a significant difference in the frequency balance.
-
Page 8: Mounting And Connection Tips
Mounting and connecting tips Mount the feet on the side you want to be Mounting SUM AMP1 is constructed to be placed lying down down. or standing up. Place the logotype in same direction alternatives as SUB AMP1 Always connect using the correct phase, from the If you by accident connect the other way, Connect using the there is no risk of damage. -
Page 9: Functional Reference
Functional reference XTZ SUB AMP1 Rear panel Main switch Power switch. Press down "I" to power on and the To obtain the optimal sound, you should let the subwoofer be in ON mode. The (ON, OFF) indicator will be lighted. Press "0" to power off. - Page 10 PHASE 0-180 phase adjustment The high pass crossover removes the HIGH PASS Switch ON and the high pass are available. Switch deepest part of the bass spectra. This is OFF and the high pass are unavailable. helpful in many rooms, since they heavily amplify the deep bass tones, which may lead to uncontrolled bass.
-
Page 11: Technical Specifications
Technical specifications Construction type Amplifier Class AB Dimensions 376 x 396 x 225 mm (HxBxD) Feet add 22mm Weight 16 kg/pcs 10-250 Hz Frequency response Connections Gold plated RCA XLR Balanced input Speaker input: Banana plug/Pole screw Speaker output: Banana plug/Pole screw 300 W RMS in 4 ohm Power amplifier 400 W RMS in 2 ohm... -
Page 12: Service & Support
Please contact our “free-of-charge” support if you need installation advice, or if any problems occur during the installation. Contact us by e-mail support@xtz.se and include your phone number if you require help, and we will ring you back. - 12-...
