Aiwa NSX-BL24 Service Manual

Compact disc stereo system
Hide thumbs Also See for NSX-BL24:

Advertisement

Quick Links

Download this manual
SERVICE MANUAL
COMPACT DISC STEREO SYSTEM
• Replace this Service Manual with "Revision Publishing" when it is issued.
NSX-BL24
NSX-BL26
NSX-BL28
BASIC TAPE MECHANISM : ZZM-3 YPR1NC
BASIC CD MECHANISM : AZG-1 ZD8RDC
S/M Code No. 09-003-426-1T2
EZ, K
EZ
EZ

Advertisement

loading
Need help?

Need help?

Do you have a question about the NSX-BL24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aiwa NSX-BL24

Summary of Contents for Aiwa NSX-BL24

  • Page 1 NSX-BL24 EZ, K NSX-BL26 NSX-BL28 SERVICE MANUAL BASIC TAPE MECHANISM : ZZM-3 YPR1NC COMPACT DISC STEREO SYSTEM BASIC CD MECHANISM : AZG-1 ZD8RDC • Replace this Service Manual with ”Revision Publishing” when it is issued. S/M Code No. 09-003-426-1T2...

  • Page 2: Electrical Main Parts List

    ELECTRICAL MAIN PARTS LIST - 1/7 NOTE: The characters in the suffix column indicate the part usage. 24K ....XX........C....24EZ ....XX........D....28EZ ....XX........F....26EZ ....XX........G..... KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 88-906-251-110 FF-CABLE,6P 1.25 ABCDEFG..... 88-911-101-110 FF-CABLE,11P 1.25 ABCDEFG..... 88-913-301-110 FF-CABLE,13P-1.25 ABCDEFG.....
  • Page 3 ELECTRICAL MAIN PARTS LIST - 2/7 87-A40-736-080 DIODE,1N4148M(SEM) ABCDEFG..... 87-A40-736-080 DIODE,1N4148M(SEM) ABCDEFG..... 87-A40-752-080 ZENER,UZ6.2BSC ABCDEFG..... 87-A40-269-080 C-DIODE,MC2836 ABCDEFG..... 87-A40-269-080 C-DIODE,MC2836 ABCDEFG..... 87-A40-269-080 C-DIODE,MC2836 ABCDEFG..... 87-A40-269-080 C-DIODE,MC2836 ABCDEFG..... 87-A40-269-080 C-DIODE,MC2836 ABCDEFG..... 87-A40-736-080 DIODE,1N4148M(SEM) ABCDEFG..... 87-A40-736-080 DIODE,1N4148M(SEM) ABCDEFG..... 87-A40-736-080 DIODE,1N4148M(SEM) ..G..... 87-A40-736-080 DIODE,1N4148M(SEM) ABCDEFG.....
  • Page 4 ELECTRICAL MAIN PARTS LIST - 3/7 87-010-187-080 CAP,CHIP S5600P ..E....87-010-188-080 CAP,CHIP 6800P ABCD.FG..... 87-010-188-080 CAP,CHIP 6800P ABCD.FG..... 87-010-263-080 CAP,ELECT 100-10V ABCDEFG..... 87-010-318-080 C-CAP,S 47P-50 CH ABCDEFG..... 87-010-546-080 CAP,ELECT 0.33-50V ABCDEFG..... 87-010-546-080 CAP,ELECT 0.33-50V ABCDEFG..... 87-010-598-080 C-CAP,S 0.068-16VRK ..E....87-010-598-080 C-CAP,S 0.068-16VRK ..E....
  • Page 5 ELECTRICAL MAIN PARTS LIST - 4/7 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309 ABCDEFG..... 87-010-197-080 CAP,CHIP 0.01 DM ABCDEFG..... 87-010-263-080 CAP,ELECT 100-10V ABCDEFG..... 87-010-971-080 C-CAP,S 4700P-50 B J ..CD.FG..... 87-010-149-080 C-CAP,S 5P-50 CH ABCDEFG..... 87-010-197-080 CAP,CHIP 0.01 DM ABCDEFG..... 87-010-197-080 CAP,CHIP 0.01 DM ABCDEFG.....
  • Page 6 ELECTRICAL MAIN PARTS LIST - 5/7 87-008-261-010 FILTER,SFE10.7MA5-A AB..E....87-008-423-010 CERAMIC FILTER,SFE10.7 ..CD.FG..... 87-A40-270-080 C-DIODE,MC2838 ..CD.FG..... 87-A40-736-080 DIODE,1N4148M(SEM) ..CD.FG..... FFE 831 A8-6ZA-19C-170 6ZA-1 YFEENC ..CD.FG..... FFE 831 A8-8ZA-193-070 8ZA-1 YFEUNC AB..E....87-A60-202-010 TERMINAL,ANT 4P MSP-154V-02 AB..E....87-A60-403-010 TERMINAL,ANT PAL 2P HSP-312V05 ..CD.FG.....
  • Page 7 ELECTRICAL MAIN PARTS LIST - 6/7 87-A40-736-080 DIODE,1N4148M(SEM) ABCDEFG..... 87-A40-736-080 DIODE,1N4148M(SEM) ABCDEFG..... 87-A40-854-080 ZENER,UZ15BSA ABCDEFG..... 87-A40-313-080 C-DIODE,MC 2840 ABCDEFG..... 87-A40-313-080 C-DIODE,MC 2840 ABCDEFG..... 87-A40-313-080 C-DIODE,MC 2840 ABCDEFG..... 87-026-609-080 TR,KTA1266GR ABCDEFG..... 87-026-609-080 TR,KTA1266GR ABCDEFG..... 87-026-609-080 TR,KTA1266GR ABCDEFG..... 87-026-610-080 TR,KTC3198GR ABCDEFG..... 87-A30-075-080 C-TR,2SA1235F ABCDEFG.....
  • Page 8 ELECTRICAL MAIN PARTS LIST - 7/7 87-010-405-080 CAP,ELECT 10-50V A.CD.FG..... 87-010-405-080 CAP,ELECT 10-50V A.CD.FG..... 87-010-866-080 CAP,ELECT 10-63 .B..E....87-010-866-080 CAP,ELECT 10-63 .B..E....87-012-369-080 C-CAP,S 0.047-50F .B....87-016-369-080 C-CAP,S 0.033-25 B K ..E....87-010-176-080 C-CAP,S 680P-50 SL ..CD.FG..... 87-010-176-080 C-CAP,S 680P-50 SL ..CD.FG.....

  • Page 9: Mechanical Parts List

    NOTE: The characters in the suffix column indicate the part usage. 24K ....XX........C....24EZ ....XX........D....28EZ ....XX........F....26EZ ....XX........G..... KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-B00-002-010 BADGE,AIWA 30 ABS SIL ABCDEFG..... 87-CE3-023-010 BADGE,AIWA 30N SILV ....8A-NF0-001-010 CABI,FR U .B....8A-NF0-003-010 BOX,CASS 1 ABCDEFG.....
  • Page 10 MECHANICAL PARTS LIST - 2/2 87-085-185-010 BUSHING, AC CORD (E) A.CDEFG..... 87-099-811-010 PLUG,ADPTR CONV(K) ..C....87-A91-422-010 BUSHING,AC CORD(U) .B....87-A80-092-010 AC CORD ASSY,E BLK SUN FAI A..DEFG..... 87-A80-105-010 AC CORD ASSY,AZ ....87-A80-110-010 AC CORD ASSY,U SPT-2W .B....87-A80-143-010 AC CORD ASSY,E BLK ..C....

  • Page 11: Accessories / Package List

    ACCESSORIES / PACKAGE LIST - 1/1 NOTE: The characters in the suffix column indicate the part usage. 24K ....XX........C....24EZ ....XX........D....28EZ ....XX........F....26EZ ....XX........G..... KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 8A-NF0-902-010 IB,LH(ESP)FM-BL24/BL34 A...E....8A-NF0-903-010 IB,U(ESF)FM-AJ24 .B....8A-NF0-905-010 IB,K(E)FM-BL24 ..C....8A-NF0-906-010 IB,EZ(9L)FM-BL24 ...D....
  • Page 12 SCHEMATIC DIAGRAM _ 1 (MAIN : 1/2) <AMP / DECK SECTION>...
  • Page 13 SCHEMATIC DIAGRAM _ 2 (MAIN : 2/2) <TUNER SECTION> [24EZ, 24K, 28EZ]...
  • Page 14 SCHEMATIC DIAGRAM _ 3 (MAIN : 2/2) <TUNER SECTION> [26EZ]...
  • Page 15 SCHEMATIC DIAGRAM _ 4 (FRONT) [24EZ, 24K, 28EZ]...
  • Page 16 SCHEMATIC DIAGRAM _ 5 (FRONT) [26EZ]...
  • Page 17 SCHEMATIC DIAGRAM _ 6 (PT)
  • Page 18 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9420025 Printed in Singapore...
  • Page 19 NSX-BL28 SERVICE MANUAL BASIC TAPE MECHANISM : ZZM-3 YPR1NC COMPACT DISC STEREO SYSTEM BASIC CD MECHANISM : AZG-1 ZD8RDC • Replace this Service Manual with ”Revision Publishing” when it is issued. S/M Code No. 09-004-426-1T3...
  • Page 20 ELECTRICAL MAIN PARTS LIST - 1/10 NOTE: The characters in the suffix column indicate the part usage. K ......XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 87-010-112-040 0E CAP,E 100-16 ....87-010-186-080 0E CAP,CHIP 4700P ....87-010-265-040 0E CAP,E 33-16 SME ....
  • Page 21 ELECTRICAL MAIN PARTS LIST - 2/10 87-010-196-080 0E CHIP CAPACITOR,0.1-25 A....87-010-378-040 0E CAP,E 10-16 A....87-012-157-080 0E C-CAP,S 330P-50 CH A....87-A60-057-010 0E CONN,11P V 9604S-11C A....87-099-720-010 1B CONN,30P TYK-B(P) A....87-099-015-010 0E CONN,13P 6216V A....87-020-465-080 0E DIODE,1SS133 (110MA) A....
  • Page 22 ELECTRICAL MAIN PARTS LIST - 3/10 87-010-178-080 0E CHIP CAP 1000P A....87-010-178-080 0E CHIP CAP 1000P A....87-010-178-080 0E CHIP CAP 1000P A....87-010-178-080 0E CHIP CAP 1000P A....87-010-198-080 0E CAP, CHIP 0.022 ....87-010-263-080 0E CAP, ELECT 100-10V A....
  • Page 23 ELECTRICAL MAIN PARTS LIST - 4/10 87-070-127-110 1C IC,LC72131 D A....87-A30-234-080 0E TR,CSC4115BC A....87-010-322-080 0E C-CAP,S 100P-50 CH A....87-010-322-080 0E C-CAP,S 100P-50 CH A....87-010-322-080 0E C-CAP,S 100P-50 CH A....87-A70-061-010 1A VIB,XTAL 4.500MHZ CSA-309 A....87-010-197-080 0E CAP, CHIP 0.01 DM A....
  • Page 24 ELECTRICAL MAIN PARTS LIST - 5/10 87-010-971-080 0E C-CAP,S 4700P-50 B J ....87-012-140-080 0E CAP 470P A....87-010-196-080 0E CHIP CAPACITOR,0.1-25 A....87-010-197-080 0E CAP, CHIP 0.01 DM A....87-010-197-080 0E CAP, CHIP 0.01 DM A....87-010-197-080 0E CAP, CHIP 0.01 DM ....
  • Page 25 ELECTRICAL MAIN PARTS LIST - 6/10 87-010-380-080 0E CAP, ELECT 47-16V A....87-010-381-080 0E CAP, ELECT 330-16V A....87-010-430-080 0E CAP, ELECT 100-63 A....87-010-260-080 0E CAP, ELECT 47-25V A....87-010-403-080 0E CAP, ELECT 3.3-50V A....87-010-196-080 0E CHIP CAPACITOR,0.1-25 A....
  • Page 26 ELECTRICAL MAIN PARTS LIST - 7/10 87-010-322-080 0E C-CAP,S 100P-50 CH A....87-010-182-080 0E C-CAP,S 2200P-50 B ....87-010-196-080 0E CHIP CAPACITOR,0.1-25 ....87-010-196-080 0E CHIP CAPACITOR,0.1-25 ....87-010-197-080 0E CAP, CHIP 0.01 DM A....87-010-322-080 0E C-CAP,S 100P-50 CH A....
  • Page 27 ELECTRICAL MAIN PARTS LIST - 8/10 87-010-179-080 0E CAP,CHIP S B1200P A....87-010-179-080 0E CAP,CHIP S B1200P A....87-010-197-080 0E CAP, CHIP 0.01 DM A....87-010-322-080 0E C-CAP,S 100P-50 CH A....87-010-391-080 0E CAP,E 10-35 SME A....87-010-391-080 0E CAP,E 10-35 SME A....
  • Page 28 ELECTRICAL MAIN PARTS LIST - 9/10 87-010-196-080 0E CHIP CAPACITOR,0.1-25 ....87-010-197-080 0E CAP, CHIP 0.01 DM ....87-010-197-080 0E CAP, CHIP 0.01 DM ....87-010-197-080 0E CAP, CHIP 0.01 DM ....87-010-197-080 0E CAP, CHIP 0.01 DM ....87-010-404-080 0E CAP, ELECT 4.7-50V ....
  • Page 29 ELECTRICAL MAIN PARTS LIST - 10/10 87-010-544-080 0E CAP, ELECT 0.1-50V ....87-010-544-080 0E CAP, ELECT 0.1-50V ....87-010-182-080 0E C-CAP,S 2200P-50 B ....87-010-405-080 0E CAP, ELECT 10-50V ....87-010-405-080 0E CAP, ELECT 10-50V ....87-010-183-080 0E C-CAP,S 2700P-50 B ....

  • Page 30: Mechanical Parts List

    MECHANICAL PARTS LIST - 1/2 NOTE: The characters in the suffix column indicate the part usage. K ......XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 8A-NF0-001-010 CABI,FR U ....8A-NF0-003-010 BOX,CASS 1 A....8A-NF0-004-010 BOX,CASS 2 A....8A-NF0-014-010 PANEL,TRAY A....8A-NF0-026-010 CABI,FR LH 24 A....
  • Page 31 MECHANICAL PARTS LIST - 2/2 87-099-811-010 1E PLUG,ADPTR CONV(K) A....87-A91-422-010 1D BUSHING,AC CORD(U) ....88-906-251-110 1A FF-CABLE,6P 1.25 A....88-911-101-110 0E FF-CABLE,11P 1.25 A....88-913-301-110 1B FF-CABLE,13P-1.25 A....87-018-131-080 0E CAP, CER 1000P-50V ....8A-NF9-612-010 2P PT,ANF-9 U ....8A-NF9-613-010 2B PT,ANF-9 HR ....
  • Page 32 ACCESSORIES / PACKAGE LIST - 1/1 NOTE: The characters in the suffix column indicate the part usage. K ......XX........A....KANRI REF.NO PARTS NO. DESCRIPTION SUFFIX 8A-NF0-901-010 IB,H(ECA)M -BL24 ....8A-NF0-902-010 IB,LH(ESP)FM -BL24/BL34 ....8A-NF0-903-010 IB,U(ESF)FM -AJ24 ....8A-NF0-905-010 IB,K(E)FM -BL24 A....
  • Page 33 SCHEMATIC DIAGRAM _ 1 (MAIN : 1/2) <AMP / DECK SECTION>...
  • Page 34 SCHEMATIC DIAGRAM _ 2 (MAIN : 2/2)
  • Page 35 SCHEMATIC DIAGRAM _ 3 (FRONT)
  • Page 36 SCHEMATIC DIAGRAM _ 4 (PT)
  • Page 37 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9420025 Printed in Singapore...
