Encore E9 Installation Manual

Professional 2-way lcd remote car starter & 6 channel alarm system
Hide thumbs Also See for E9:

Advertisement

Quick Links

Download this manual See also: Operating Manual
E9
PROFESSIONAL 2-WAY LCD REMOTE CAR STARTER & 6 CHANNEL
ALARM SYSTEM
With
Built-in Voltage & Temperature Sensor
And Two Way Serial Port Data Link
INSTALLATION MANUAL
This unit is designed for professional installation only and must be installed by an
Encore authorized dealer. Please register this product at
www.encoreautomotivesystems.com.
E9 IN REV. A
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the E9 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Encore E9

Summary of Contents for Encore E9

  • Page 1 Built-in Voltage & Temperature Sensor And Two Way Serial Port Data Link INSTALLATION MANUAL This unit is designed for professional installation only and must be installed by an Encore authorized dealer. Please register this product at www.encoreautomotivesystems.com. E9 IN REV. A...
  • Page 2 Install the wiring neatly under carpets or behind trim to prevent possible damage to wires. FOR AUTHORIZED DEALER TECHNICAL SUPPORT, PLEASE CALL Toll Free: (855) GO-ENCORE : 8:00 am TO 5:00 pm PST. WARNINGS: As with any product that performs automatic functions, there are certain safety precautions that you must practice and be aware of.
  • Page 3 6 PIN HEAVY GAUGE WIRE HARNESS E9 IN REV. A...
  • Page 4 Brown: Siren (+) Output Red: 12v + Battery Power 3 PIN, DOOR LOCK CONNECTOR ( - ) Unlock Pulse 1. Blue Wire (+) Lock Pulse ( - ) Lock Pulse 3. Green Wire ( + ) Unlock Pulse WIRING E9 IN REV. A...
  • Page 5 “12 volts” when the ignition key is in the “ON” or “RUN” and “START” or “CRANK” position. When the ignition is turned “OFF”, the ignition wire should receive “0” voltage. The YELLOW wire must be connected. PINK Wire – Ignition 2 Output E9 IN REV. A...
  • Page 6 RS232 Two way SERIAL DATA PORT CONNECTION: This connector is to be used for Serial Data communications with idatalink modules by Encore only! DO NOT CONNECT THIS TO ANY OTHER WIRING!
  • Page 7 This wire provides a 200mA (-) ground output. This output will energize when the remote start is activated, go away while the starter is cranking, and then come back on when the vehicle has started successfully. E9 IN REV. A...
  • Page 8 This line can be used if a second starter line is needed. Some vehicles require a two-starter line to remote start. This wire provides a negative output that will work the same way as the Violet starter line in connector H1. Black/White wire – (-) Neutral Safety Switch Input or (-) Enable Switch Input – E9 IN REV. A...
  • Page 9 This output is for a Key Sense wire by-pass that some Chrysler and Toyota vehicles need to activate remote start. This wire comes on when remote start is activated and stays on for 20 seconds. White / Black wire – Negative Safety Shut Down Input & Hood Trigger E9 IN REV. A...
  • Page 10 In most vehicles, in order to shift gear, the brake pedal must be depressed. The brake input will in turn cause the remote start unit to shut off. See diagram. Yellow wire – (-) 200mA Ignition 3 Output – E9 IN REV. A...
  • Page 11 +12V Or Ground Depending On System horn switch. When system Requirements triggered, the horn will sound. Factory Security Rearm Signal Output –(See Alarm Feature Programming) – E9 IN REV. A...
  • Page 12 Also on certain BMW, Mercedes Benz, Jaguar and Volkswagen cars, you can use this unique timed output to allow remote closure of all power window and sunroof without the need for an external module! E9 IN REV. A...
  • Page 13 Cut the Unlock Wire Red +12V Cut the Existing Lock Wire 3 Pin Plug OEM Slave Alarm Door Lock Switch Unlock Lock +12V Blue Wire OEM Driver’s Door Lock Motor To All Other Cut Existing Unlock Door Lock Motors E9 IN REV. A...

  • Page 14: Programming Transmitter

    LED four pulses Factory Default Button Setting Passive arming Passive arming without passive with passive door Active arming door locking locking. Automatic Automatic Rearm Rearm on 45 seconds Instant Door Ajar delay Door Ajar error chirp error chirp. E9 IN REV. A...
  • Page 15 & unlocks locks & unlocks 3.5 second door 0.8 second Lock, 0.8 sec. dbl 0.8 second door lock & Unlock 0.35 second Lock, lock & unlock Unlock 0.8 sec. dbl Unlock E9 IN REV. A...
  • Page 16 Eight Chirps = DBI Two step unlock ( DBI ONLY )** Nine chirps = DBI Unlock ALL doors ( DBI Only )** **Select either of these options when using Encore Two Way Data Bus Interface Only. Brown Wire = (+)
  • Page 17 You are now in the Alarm feature ‘C’ programming mode. Timer Program: buttons together 1. Press and release 4 times, [4] LED flash, [4] siren/horn chirps to indicate that you are in features “Channel 4 Timer Programming mode”. E9 IN REV. A...
  • Page 18 (92) has been accepted and stored in memory. Exit: Press any button (except button) of the transmitter to exit the password pin set up mode. REMOTE START FEATURE PROGRAM MODE. START FEATURE “D” PROGRAMMING: E9 IN REV. A...

  • Page 19: Safe Start (Child Safety Mode)

    1. Turn the Ignition 'switch ‘ON/OFF’ 3 TIMES and stay in OFF position. 2. Push the Valet switch 7 times (holding in on the 7 push) until one long chirp is heard then release the valet switch. You are now in the Start feature “E” programming mode. E9 IN REV. A...
  • Page 20 6. Press and hold the valet switch for 2 seconds until a long chirp and the LED light constant for two seconds. The RPM signal is learned. 7. Turns off the ignition switch to stop the engine running. Once you complete step 7, you can adjust and test “Check Level” as below: CHECK LEVEL PROGRAMMING: (TEST and ADJUST) E9 IN REV. A...
  • Page 21 1. Turn the Ignition 'switch ‘ON/OFF’ 3 TIMES and stay in OFF position. 2. Push the Valet switch 7 times and hold it on the 7 push until a long chirp is hearing then release the valet switch. E9 IN REV. A...

  • Page 22: Test Mode

    6 seconds, there will be a confirmation six chirps with three long chirps to confirm the system “Alarm Feature A, B, & C Programming” all returns to factory default setting. START FEATURE ALL RETURNS TO FACTORY DEFAULT SETTING: E9 IN REV. A...
  • Page 23 Caution!! The follow procedure must be performed after the installation of the Remote Start Device. It is the responsibility of the installing technician to complete these tests. Failure to test the unit in the following manner may result in personal injury, property damage, or both. E9 IN REV. A...

  • Page 24: Neutral Start Safety Test

    NOTE: When completing an installation using either of the following key in sensor circuits, if the operator inserts the ignition key while the vehicle is running under the control of the Remote Start, the vehicle will shut down. This must be E9 IN REV. A...
  • Page 25 AFTER THE CONNECTION OF THE NEUTRAL START SAFETY WIRE AS INDICATED IN ANY OF THE PREVIUOS ALTERNATE CONFIGURATINS, THIS CIRCUIT MUST BE TESTED FOR OPERATION. Retest by following the steps outlined in the NEUTRAL START SAFETY TEST shown in this manual. E9 IN REV. A...
  • Page 26 Encore Automotive Systems LLC. WARRANTS that this new unit has been thoroughly inspected and tested at the factory prior to delivery. Your Encore equipment is guaranteed for “life” to the original purchaser/user of the equipment and the original vehicle in which it was installed by an authorized installer under the following conditions: If the product proves defective (according to Encore’s testing) within the first year, the defective unit may be exchanged or repaired free of charge.
  • Page 27 **IMPORTANT NOTE: Any damages resulting from an installation performed by anyone other than a professional installation technician authorized by Encore will void the product’s Limited Lifetime Warranty It is the purchaser’s responsibility to register this product for any future warranty service.
