Encore E 9 Operation Manual

Professional 2-way lcd remote car started & alarm system with built in temperature & voltage sensor and two-way serial port data link

Hide thumbs Also See for E 9:

Installation manual (27 pages)

Table Of Contents

Table of Contents

Quick Links

Need help?

Do you have a question about the E 9 and is the answer not in the manual?

Questions and answers

Summary of Contents for Encore E 9

Page 1 PROFESSIONAL 2-WAY LCD REMOTE CAR STARTER & ALARM SYSTEM With Built in Temperature & Voltage Sensor And Two-way Serial Port Data Link OPERATION MANUAL THIS PRODUCT IS DESIGNED FOR PROFESSIONAL INSTALLATION ONLY Please register your product at www.encoreautomotivesystems.com E9 OP REV. A1...
Page 2: Battery Changing
LCD REMOTE CONTROL TRANSCEIVER A. BATTERY CHANGING: Depending on the usage, the remote batteries should be changed at least once a year in the one way remote and once every 4-5 months for the two-way remote. The 1-way remote, (E-9s) is powered by a pair of 3V, CR2016 batteries. These batteries are available at most locations batteries are sold and can be replaced by the user.
Page 3 The lock icon will be displayed when The unlock icon will be displayed the door locked and the system is when the door unlock and the armed. system is Disarmed. Sensor Bypass Hidden Alarm Mode Sensor 1 bypass under Arm mode The security system arm with hidden alarm function (silent alarm)
Page 4: Remote Transmitter Operation
Melody Mode Low Battery Remote Control alert user through You have to charge the battery melody sound of remote control. Vibration Mode Valet Mode Remote Control vibrates when Remote start and alarm functions shall the system is triggered be temporarily on hold. Count Down Timer Reminder when time is up for parking...
Page 5: Sensor Bypass
Chirp Function Parking light Function 1 chirp 1 flash 2 chirps 2 flashes Disarm Disarm 3 chirps 3 flashes Defective Reminder Disarm / Triggered 4 chirps 12 flashes Disarm / Triggered Car Locator 6 chirps Constant On Car Locator Under Remote Start ALARM OPERATING CONDITION: Siren / Horn Parking Light...
Page 6: Active Disarming - Unlock & Disarm
3. After the 30-second time has elapsed, the security system will automatically “ARM”. The siren will chirp [1] time and the parking lights will flash [1] time. PASSIVE ARMING WITH PASSIVE DOOR LOCKING The vehicle doors will automatically lock after the passive arming cycle has been completed. PASSIVE ARMING BY-PASS: While the system is disarmed, Press the button twice, the system will respond with [1] chirp and LED will turn “ON”.
Page 7: Valet Mode
Note: You must override the alarm within 60 seconds. If not, the system will automatically re-arm. EXAMPLE: To Override the System with the Password Code 83, 1. Enter the vehicle and turn the ignition switch to the 'ON’ position. (Alarm will sound.) 2.
Page 8: Active Anti Car Jacking
Your system has a “Noise Abatement Circuit”. It prevents annoying NOISE ABATEMENT CIRCUIT: repetitive trigger sequences due to faulty door pin switches or environmental conditions such as thunder, jackhammers airport noise, etc. Here’s how “Noise Abatement Circuit” works: The alarm triggers five times. Each time, the same sensor or switch has triggered the alarm;...
Page 9 Note: If the system has no response then you are out of range. O. SYSTEM’S STATUS CHECK (For two-way transceiver operation only) Press button of LCD remote until 3 beeps sound , the LCD remote will show “STATUS “ icon flashing in the text area (see advanced users mode), then press button to activate system status check.
Page 10: Power On Memory
Press and hold button of LCD remote until 2 beeps sound , release and re-press button the LCD remote will show “CH 6” icon flash, then press to activate channel 6 function. button Channel 6 is user-programmable timer output. You may program the built-in timer to send a ground signal for any time duration from 1 second to 120 seconds.
Page 11: Remote Start Operation
1. Keep the transmitter out of children’s reach. 2. Do not leave anyone in the vehicle while running on remote control. 3. Alert servicing personnel that the vehicle can be started automatically. 4. Do not start the vehicle by remote while it’s in an enclosed area or garage. 5.
Page 12: Temporary Stop Feature
C. TEMPORARY STOP FEATURE: This feature allows the vehicle to remain running after the key has been removed from the ignition. This feature is useful for occasions when you wish to exit and lock the vehicle for short periods of time, but would like to leave the motor running and the climate control on.
Page 13: To Turn Off The Remote Start
” Press and hold the transmitter “ button first until 3 chirps are heard. Then press the Button three more times so that TEMP appears on the remote. Within 3 seconds press button; the in-door temperature will be shown on the LCD screen. This reading may be higher than actual ambient temperature due to the greenhouse effect and is relative only to the inside vehicle temperature.
Page 14: Hidden Alarm
Table 1: ONE beep to confirm (Press & hold “ F “ button until 1 Beep is heard) Button LCD Display Button Press once Backlight turns on for 5 seconds PASS Press twice within 5 Press button to arm the alarm seconds PASS icon flashing and bypass the sensor 1.
Page 15 Button LCD display Button DEMO Press and hold the mode Press button to activate Button for 4 second Backlight will be ON until until 4 beeps sounded DEMO operation end. Table 5: Do-Re-Mi sounds to confirm Button LCD display Button DEFLT Press and hold the flashing...
Page 16 12:00AM - Clock minutes - Adjusts clock minute from 0 to 59 00 is flashing Alarm Clock Default is Menu 12:00AM - Alarm hours - Adjusts alarm clock hour from 0 12 is flashing to 12 12:00AM - Alarm - Adjusts alarm clock minute from minutes 00 is flashing 0 to 59...
Page 17 Encore Automotive Systems LLC. WARRANTS that this new unit has been thoroughly inspected and tested at the factory prior to delivery. Your Encore equipment is guaranteed for “life” to the original purchaser/user of the equipment and the original vehicle in which it was installed by an authorized installer under the following conditions: If the product proves defective (according to Encore’s testing) within the first year, the defective unit may be exchanged or repaired free of charge.
Page 18 **IMPORTANT NOTE: Any damages resulting from an installation performed by anyone other than a professional installation technician authorized by Encore will void the product’s Limited Lifetime Warranty It is the purchaser’s responsibility to register this product for any future warranty service.
