Antik Juice Encoder EN 5008 User Manual

8-in-1 mpeg-4 avc/h.264 hd encoder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Juice Encoder EN 5008 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Antik Juice Encoder EN 5008

Summary of Contents for Antik Juice Encoder EN 5008

  • Page 2: Table Of Contents

    DIRECTORY Chapter 1 Product Introduction ......................1 1.1 Outline ..............................1 1.2 Main Features ........................... 1 1.3 Specifications ............................ 1 1.4 Principle Chart ........................... 3 1.5 Appearance and Illustration ......................3 Chapter 2 Installation Guide ........................5 2.1 Acquisition Check ..........................5 2.2 Installation Preparation ........................

  • Page 3: Chapter 1 Product Introduction

    Chapter 1 Product Introduction 1.1 Outline The ANTIK Juice Encoder EN 5008 8-in-1 MPEG-4 AVC/H.264 HD encoder is our newest professional HD audio & video encoding and multiplexing device with powerful functionality. It is equipped with 8 HDMI channels input supporting MPEG -4 AVC/H.264 High Profile code format &...
  • Page 4 (UDP unicast / multicast) LCD/keyboard operating, NMS supporting System function Chinese-English control interface Ethernet software & hardware upgrade Dimension (W× L× H) 440mm×410mm×44.5mm Approx weight Miscellaneous Temperature 0~45℃(work), -20~80℃（Storage） Power AC 100V-220V±10%, 50/60Hz Consumption 2 / 43 Antik Technology / www.antiktech.com...

  • Page 5: Principle Chart

    Indicate area: All indicators will light on when the device is on the current working state. LCD Screen Power Indicator TS In: Input Lock Indicator Indicators CH1-CH8: When the program has been multiplexed, the indicator will be on. UP/ DOWN, LEFT/RIGHT Keys Enter Key Menu Key Lock Key 3 / 43 Antik Technology / www.antiktech.com...
  • Page 6 EN 5008 8-in-1 MPEG-4 AVC/H.264 HD User’s Manual Rear Panel Illustration: 8 * HDMI Input Ports ASI Input Port 2 * ASI Output Ports Data Port (for IP Signal Output) NMS (Network Management Port) Power Switch and socket Grounding Pole 4 / 43 Antik Technology / www.antiktech.com...

  • Page 7: Chapter 2 Installation Guide

     Connecting communication port (if it is necessary) 2.2.1 Device’s Installation Flow Chart is Illustrated as following： Connecting Grouding Acquisition Fixing Connecting Setting Running Wire and Check Device Signal Wire Parameter Device Power Cord 2.2.2 Environment Requirement 5 / 43 Antik Technology / www.antiktech.com...
  • Page 8  It is prohibited to use any other device as part of grounding electric circuit  The area of the conduction between grounding wire and device’s frame should be no less than 25mm 6 / 43 Antik Technology / www.antiktech.com...

  • Page 9: Wire's Connection

    “OFF”. 2.4 Signal Cable Connection The signal connections include the connection of input signal cable and the connection of output signal cable. The details are as follows: 2.4.1 HDMI input cable illustration: 7 / 43 Antik Technology / www.antiktech.com...
  • Page 10 2.4.5 ASI output interface connection User can firstly find the ASI output interface on the device according to the connector mark described on the rear panel illustration, and then connect the ASI cable (in the accessories). One 8 / 43 Antik Technology / www.antiktech.com...
  • Page 11 (CAT5). One end of the network cable is connected to the encoder’s NMS connecter, while the other end to the computer or the PC. The encoder’s NMS connection is illustrated as follows: 9 / 43 Antik Technology / www.antiktech.com...
  • Page 12 EN 5008 8-in-1 MPEG-4 AVC/H.264 HD User’s Manual 10 / 43 Antik Technology / www.antiktech.com...

  • Page 13: Chapter 3 Operation

    8 in 1 Encoder 65.958 Mbps 1 480I 60 08.235M 2 480I 60 08.241M 3.2 General Setting By pressing LOCK key, users can enter in the main menu and set the input and output 11 / 43 Antik Technology / www.antiktech.com...

  • Page 14: Video Setting

    After users enter the submenu, the interface will turn into the following pages, and then users can enter the corresponding interface to modify the parameters. ►1.1.1 Video 1.1.2 Audio 1.1.3 System 1.1.4 PG Muxer 3.2.1.1 Video Setting ►1.1.1.1 Bitrate 1.1.1.2 BitrateMod 1.1.1.3 Profile 1.1.1.4 Level  Bitrate 12 / 43 Antik Technology / www.antiktech.com...
  • Page 15  Level User can select the H.264 level at this menu. The option with bracket is the current choice. 1.1.1.4 Level 01/03 [1.2] 1.1.1.4 Level 02/03 [2.2] 1.1.1.4 Level 03/03 [4.0] 3.2.1.2 Audio Setting 13 / 43 Antik Technology / www.antiktech.com...

  • Page 16: System Settings

    LC-AAC, and HE-AAC. When users enter the main editing menu, the LCD will display the following page: 1.1.2.2 Format 01/02 [MPEG1-Layer Ⅱ] LC-AAC 1.1.2.2 Format 02/02 [HE-AAC] 3.2.1.3 System Settings ►1.1.3.1 Prog Number 1.1.3.2 Video PID 1.1.3.3 Audio PID 1.1.3.4 PMT PID 14 / 43 Antik Technology / www.antiktech.com...
  • Page 17 PID number cannot exceed 0x1fff. 1.1.3.2 Video PID 0x0101 1.1.3.3 Audio PID 0x0102 1.1.3.4 PMT PID 0x0100 1.1.3.5 PCR PID 0x0101  IP Enable 1.1.3.6 IP Enable 01/01 [NO] 15 / 43 Antik Technology / www.antiktech.com...
  • Page 18 Users can check the ASI input program amount in this interface, and the LCD will display the following page. Prog: 006 represents the input program is 6 and Out:003 represents 3 of the 6 programs have been multiplexed. 16 / 43 Antik Technology / www.antiktech.com...
  • Page 19 If users enable the IP output function, then users can set the device IP output address in this interface. After users press the ENTER key, the operating interface will display the following page: ► 3.2 IP Out Address 224.002.002.002 17 / 43 Antik Technology / www.antiktech.com...

  • Page 20: Asi Output

    UTC refers to Universal Time Coordinated. User can enter this menu to set the time as needed and it will then generate the TDT table and show in the user’s STB. 3.7 UTC Time Configuration 2012-01-29 15:45:03 18 / 43 Antik Technology / www.antiktech.com...

  • Page 21: Network Setting

    4.4 Console Address 192.168.002.211 The MAC address is read-only in the keyboard operation interface, so users can just check the physical address under this interface, and the modification must be done in the network 19 / 43 Antik Technology / www.antiktech.com...
  • Page 22 Users can check the device software version and hardware version, and the LCD will display the following interface when users press the ENTER key. 8 in 1 Encoder SW 0.17F HW 08 3.2.8 Language User can select the needed language under this submenu: 8 Language 20 / 43 中文 Antik Technology / www.antiktech.com [ENGLISH]...

  • Page 23: Chapter 4 Snmp Operation

    User can login the NMS by pressing OK key after inputting user name. Upon the inputs, the software will verify them with database record automatically and the main interface will appear. 4.2.2 Main Interface 21 / 43 Antik Technology / www.antiktech.com...
  • Page 24 4.2.3 Adding Frequency Point The Add Freq Point dialog box popes up when the user clicks the Add Freq Point item in the 22 / 43 Antik Technology / www.antiktech.com...
  • Page 25 User should choose the frequency point in advance, and then the dialog box of Add Equipment will pop up when user clicks “Add Equipment” item in the Edit pull down menu on the menu row. 4.2.5 Edit Equipment Interface 23 / 43 Antik Technology / www.antiktech.com...
  • Page 26 Device IP is 192.168.2.136, sub mask is 255.255.255.0. So the PC IP address should be 192.168.2.X (1<X<255), sub mask is 255.255.255.0. User can use ping command to confirm these two are in same network or not. Click OK, it will appear as below: 24 / 43 Antik Technology / www.antiktech.com...

  • Page 27: Save Configuration

    4.2.7 Save Configuration After finishing all the parameters setting, user can click button on the toolbar to save the modifications to the device’s flash, while user can also reload the saved parameters 25 / 43 Antik Technology / www.antiktech.com...

  • Page 28: En 5008 8 In 1 Mpeg-4 Avc/ H.264 Hd Encoder Operation

    User can choose the encoder in the device tree; the procedure will display the encoder interface in operating area. The interface is mainly composed of encoding video parameters, audio parameters and the encoding system parameters, output parameters and etc. 4.3.1 Parameters Setting 26 / 43 Antik Technology / www.antiktech.com...
  • Page 29 IP output function or not.Users can modify the IP address here as well.  IP Out Address/Service IP Address/Service Mask/Service Gateway Users can set the address by modifying the value in these four fields.  ASI Output Channel 27 / 43 Antik Technology / www.antiktech.com...
  • Page 30 If this function is effected, then the null packets in IP output stream will be filtered.  PSI/SI Editor This button will trigger the PSI/SI Editor for some users’ advanced usage. For more detail, please refer to the manual of PSI/SI. 4.3.1.2 Video Parameters (Parameters->Channel->CH0X) 28 / 43 Antik Technology / www.antiktech.com...
  • Page 31 If any parameter is modified, it is supposed to click Set to make the modified to read and effect the current device’s activating parameters activate and click Get parameters. 4.3.2 Multiplexing 29 / 43 Antik Technology / www.antiktech.com...
  • Page 32 : To modify the output programs’ Program Name, PMT, PCR, video, or audio PID as needed. To modify program information, user can select the target program in output part first and click this button to pop up a dialog box as below: 30 / 43 Antik Technology / www.antiktech.com...
  • Page 33 EN 5008 8-in-1 MPEG-4 AVC/H.264 HD User’s Manual Select the target item and input the new value in the box below, then click to effect the modification. : The parsing overtime value 4.3.3 Tables 4.3.3.1 PID Filter Table 31 / 43 Antik Technology / www.antiktech.com...
  • Page 34 This is the main purpose of this function. The display will show as below when user clicks “Add” button. 32 / 43 Antik Technology / www.antiktech.com...
  • Page 35 User can also modify or delete the added PID through the corresponding buttons at right. 4.3.3.3 NIT Parameters NIT: Network Information Table. NIT table is a very important table for describing the network and TS. Users can set the parameters of the output NIT table. 33 / 43 Antik Technology / www.antiktech.com...
  • Page 36 ：The Descriptor Tag is an 8-bit field which identifies each descriptor. ：The Descriptor Data is the detailed information of the private description. ： Users can add the cable transmission descriptor in this Add button, and it will pop 34 / 43 Antik Technology / www.antiktech.com...
  • Page 37 ：The set “Button” will send the NIT to the chosen output Port. 4.3.4 Real-time Monitor There will be a real-time bit rate chart generating in the monitor for users to check the bit rate information. 35 / 43 Antik Technology / www.antiktech.com...

  • Page 38: Other Settings

    “Remote Save” on the toolbar explained in 4.2.7. This is the difference between “Set” and “Remote Save”. 4.4.2 IP Modification Users can click Operate and select Modify IP in the drop-down list, and a dialog box presents 36 / 43 Antik Technology / www.antiktech.com...
  • Page 39 Users then can refer to below prompts to edit the property by inputting the new IP to re-connect the equipment. Input the new IP Address in the box and click OK button, then the device will be connected again. 37 / 43 Antik Technology / www.antiktech.com...
  • Page 40 “√”, user can input the new username and new password as prompts below. It is required to click to add the new user and then click to save the new setting. 38 / 43 Antik Technology / www.antiktech.com...
  • Page 41 EN 5008 8-in-1 MPEG-4 AVC/H.264 HD User’s Manual 39 / 43 Antik Technology / www.antiktech.com...

  • Page 42: Chapter 5 Troubleshooting

    Chapter 5 Troubleshooting ANTIK’s ISO9001 quality assurance system has been approved by CQC organization. For guarantee the products’ quality, reliability and stability. All ANTIK products have been passed the testing and inspection before ship out factory. The testing and inspection scheme already covers all the Optical, Electronic and Mechanical criteria which have been published by ANTIK.

  • Page 43: Chapter 6 Packing List

    EN 5008 8-in-1 MPEG-4 AVC/H.264 HD User’s Manual Chapter 6 Packing list  EN 5008 8 in 1 MPEG-4 AVC/H.264 HD Encoder 1pcs  User’s manual 1pcs  HDMI cable 8pcs  ASI cable 1pcs  Power cord 1pcs 41 / 43 Antik Technology / www.antiktech.com...
