- Page 1 EN-8000 Series User Maunal User Manual Brighten Your Digital View! EN-8000 8-way H.264 HD/SD Encoder and Modulator Series EN-8000 Series Rev: A www.antiktech.com...
-
Page 2: Table Of Contents
EN-8000 Series User Maunal Contents 1. Features and Order Information ......2 2. ModelList............... 2 3 Specifications............3 4.Web Server ............. 6 4.1 Login..............6 4.2 Status..............6 4.3 TS/IP..............7 4.4 Remux ............... 17 4.5 System ............... 19 4.6 Configuration ............. 24 5 Installation ............ -
Page 3: Features And Order Information
EN-8000 Series User Maunal 1. Features and Order Information Complies with H.264/AVC HP@L4.0 & MPEG-2 MP@ML Built-in reMUX handles MPTS and SPTS Three TS/IP modes Single 128-way IPTV output @ 400Mb/s Dual 32-way IPTV output, one main and one redundant, 200Mb/s each ... -
Page 4: Specifications
EN-8000 Series User Maunal EN-8000-42HT DVB-T EN-8000-42HT2 DVB-T2 EN-8000-80SC DVB-C EN-8000-80ST DVB-T EN-8000-80ST2 DVB-T2 DVB-C EN-8000-82SC EN-8000-82ST DVB-T EN-8000-82ST2 DVB-T2 EN-8000-40SC DVB-C EN-8000-40ST DVB-T EN-8000-40ST2 DVB-T2 EN-8000-42SC DVB-C EN-8000-42ST DVB-T EN-8000-42ST2 DVB-T2 EN-8000-80CC DVB-C DVB-T CVBS&Audio EN-8000-80CT EN-8000-80CT2 DVB-T2 EN-8000-82CC... - Page 5 EN-8000 Series User Maunal Video Resolutions & their 1080i（1920×1080）@25Hz,29.97Hz:SMPTE274M: 1~13Mb/s Recommended Compression Bit 720p（1280×720）@50Hz,59.94Hz::SMPTE296M: 1~13Mb/s Rates 480i（720×480）@29.97Hz:SMPTE656M: 600K~8Mb/s H.264 576i（720×576）@25Hz: SMPTE656M:600K~8Mb/s Video Resolutions & their 480i（720×480）@29.97Hz:SMPTE656M: 3.5~8Mb/s Recommended Compression Bit Rates 576i（720×576）@25Hz: SMPTE656M: 3.5~8Mb/s MPEG-2 Video Scaler Manually adjustable, Aspect Ratio 4:3 or 16:9 Audio Inputs &...
- Page 6 EN-8000 Series User Maunal ≥12dB（typ.） Return Loss Interfaces on Rear Panel HDMI Inputs HDMI (see model list) x 8 HD-SDI Inputs BNC Female, 75Ω x 8 CVBS & Audio Inputs RCA Female, 75Ω (see model list) x 8 RF Output F-female, 75Ω...
-
Page 7: Web Server
EN-8000 Series User Maunal Web Server 4.1 Login Enter the IP address of the EN-8000 on to URL row on any web browser, there will be a pop- up showed and asking for login user and password. The default user name and password are “root”... -
Page 8: Ts/Ip
EN-8000 Series User Maunal Status 4.3 TS/IP All models provide three TS/IP operation modes. First, “Full Duplex mode”, which allows one MPTS or SPTS inputted, then make up a new MPTS with local encoders/IP input, then sends the new one over IP & ASI_out. The second mode is “IPTV mode” up to 128 TS are sent over IP, all null packets are removed to save bandwidth. - Page 9 EN-8000 Series User Maunal TS/IP Out TS/IP Out Switch: Enable or Disable the IP output Source: select the source for the IP output in the dropdown list TS Pkts Per UDP: select the number of TS packets that can be carried by each UDP packet...
- Page 10 EN-8000 Series User Maunal TS/IP In Under Full Duplex Mode, the device supports single uni/multicast reception. Set the uni/multicast target IP address and port number on the page below. TS/IP In Uni/Multicast: select the type of IP streamcast over IP, Unicast or multicast Source Identification: enable/disable the source identification of IP streamcast.
- Page 11 EN-8000 Series User Maunal TS/IP Local TS/IP Address: set the IP address of the IP port TS/IP Subnet Mask: set the net mask of the IP port TS/IP MAC Address: display the MAC address of the IP port, cannot be modified by user...
- Page 12 EN-8000 Series User Maunal TS/IP Out IPTV Channel Settings: assign an IPTV streamcast output channel that is going to be configured (refer as the current channel below) Source: set a source for the current IPTV channel, need to select program(s) in “IPTV channels Setup”...
- Page 13 EN-8000 Series User Maunal IPTV Channel Settings TS Input: display the TS source selected in previous step for the current channel (channel 110 for this example), and the total program/service number detected will be shown in the brackets. The program(s)/service(s) detected from the select TS source will be listed in the box beneath.
- Page 14 EN-8000 Series User Maunal button between TS Input window and IP Output window, then the program(s)/service(s) checked will appear in the IP Output window. 2. To remove program(s)/service(s), click the check box on the left of program(s)/service(s) name which is being removed from the current channel in the IP Output window. Click the left...
- Page 15 EN-8000 Series User Maunal TS/IP Address: set the IP address of the IP port TS/IP Subnet Mask: set the net mask of the IP port TS/IP MAC Address: display the MAC address of the IP port, cannot be modified by user...
- Page 16 EN-8000 Series User Maunal Protocol: select UDP or RTP protocol for the IP output. Default is UDP. TS Pkts Per UDP: select the number of TS packets that can be carried by each UDP packet. Default is 7. Time To Live: set TTL to the output IP packets. Default is 255.
- Page 17 EN-8000 Series User Maunal Target MAC Address-1: set the MAC address of the IP port of the destination device for the current channel in case of necessity. Default is ff:ff:ff:ff:ff:ff, this just imply to get the MAC address with Target IP Address and ARP protocol automatically, not really send stream to a device with MAC=ff:ff:ff:ff:ff:ff .
-
Page 18: Remux
EN-8000 Series User Maunal 216Mb/s. TS/IP In Under IPTV mode, the TS/IP In is not available. TS/IP Local Set the parameters for the TS/IP Local Settings on the page below. TS/IP Local TS/IP Address: set the IP address of the IP port... - Page 19 EN-8000 Series User Maunal Remux Packet Size: set the packet length of the TS re-multiplexed to 188 or 204 Byte. Bit Rate (Kb/s): set the bit rate for the new generated MPTS, valid range from 100~216000 Kb/s. The bit rate should be at least bigger than the total bit rate of selected programs, otherwise, packets may be dropped.
-
Page 20: System
EN-8000 Series User Maunal 4. A pop up will be displayed to confirm settings are accepted and applied. 5. The maximum output data bit rate of the build-in remux is 216Mb/s. 4.5 System The system page gives all information of this device including device name, serial number, software version, and so on. - Page 21 EN-8000 Series User Maunal IP Settings IP Address: set the address of the IP control port of this device. Network Mask: set the subnet mask for this device. Gateway: set the gateway IP address, to which this device is connected to, if any.
- Page 22 EN-8000 Series User Maunal Version Web Login Set the log-in user name and password for the web management server of this device. Default values are root and 12345, respectively. To retrieve these values in case of necessity, set it again on the front panel.
- Page 23 EN-8000 Series User Maunal Factory Default Click the Default button to restore the factory default settings to the device. Note: the IP address of the device and the operation mode of the Gigabit board will not be restored. Factory Default...
- Page 24 EN-8000 Series User Maunal System Reboot Upgrade User can upgrade the software of this device on web. Upgrade Firstly, verify a correct upgrade file with correct model and correct version. Consult your technical support person(s) if any ambiguity, this device might be totally out of order if a wrong file is upgraded.
-
Page 25: Configuration
EN-8000 Series User Maunal upgrade file”. Verify whether the correct file has been entered, again. Click the Upload button , progress of file upload will be shown and wait until the process is completed. Then Click the Upgrade button on the lower right corner of this page. Wait for few minutes for the upgrade, and this device will reboot automatically after upgrade success. - Page 26 EN-8000 Series User Maunal Encoder Video n Settings (n=1 in this example, same below) Video Bit Rate: set the video bit rate. The setting is valid only when the Video Rate Ctl is CBR. Aspect Ratio: set the aspect ratio for the encoded video, 4:3 or 16:9.
- Page 27 EN-8000 Series User Maunal Audio n Settings Audio Format: set the audio compression format MPEG-1 Layer II or MPEG2/4 AAC-LC HE- AAC. (NOTE:MPEG2/4 AAC-LC HE-AAC can be selected on EN-8000 models ) Audio Bit Rate: set the audio bit rate.
-
Page 28: Installation
EN-8000 Series User Maunal 5 Installation It is highly recommended to fix the EN-8000 be mounted in EIA standard 19” rack, any other mounting method may lead to damage of the device. Open the box and take out the device with care. Inspect if there is any damage to the appearance of the device. - Page 29 EN-8000 Series User Maunal ANTIK Technology http://www.antiktech.com Address: Čárskeho 10, SK-04001 Košice, Slovakia Tel: +421-55-3012345 Web: www.antiktech.com Email: info@antiktech.com...
