Carbon Monoxide Alarm
User Guide
Models: KN-COB-DP2
ATTENTION: Please take a few minutes to thoroughly read this
user guide which should be saved for future reference and passed
on to any subsequent owner.
KN-COB-DP2
• 120V AC Plug-In
• 2 AA battery
• Tamper Resist
• Event Memory
2546-7201-00

Advertisement

Table of Contents
loading

Related Manuals for Kidde KN-COB-DP2

Summary of Contents for Kidde KN-COB-DP2

  • Page 1 Carbon Monoxide Alarm User Guide Models: KN-COB-DP2 KN-COB-DP2 • 120V AC Plug-In • 2 AA battery • Tamper Resist • Event Memory ATTENTION: Please take a few minutes to thoroughly read this user guide which should be saved for future reference and passed on to any subsequent owner.

  • Page 2: What To Do When The Alarm Sounds

    What to do When the Alarm Sounds! Carbon Monoxide Alarm Procedure WARNING: Activation of the CO Alarm indicates the presence of Carbon Monoxide (CO) which can kill you. 1) Operate the Test/Reset button; 2) Call your emergency services (Fire Department or 911); PHONE NUMBER: 3) Immediately move to fresh air - outdoors or by an open door/window.

  • Page 3: Important Warning Statements

    Note: Many times throughout this User Guide, we will refer to Carbon Monoxide as “CO”. This Kidde carbon monoxide (CO) alarm is an important part of your family’s home safety plan. This alarm has been designed and tested to detect CO buildup in a residential environment. Your alarm is for use specifically in the home.
  • Page 4 Important Warning Statements WARNING: This product is intended for use in ordinary indoor locations of family living units. It is not designed to meas- ure compliance with Occupational Safety and Health Administration (OSHA), commercial or industrial standards. It is not suitable for installation in hazardous locations as defined in the National Electric Code.

  • Page 5: Information About Carbon Monoxide

    1. Information About Carbon Monoxide General Carbon Monoxide Information Carbon monoxide is a colorless, odorless and tasteless poison gas that can be fatal when inhaled. CO inhibits the blood’s capacity to carry oxy- gen. Periodically review this user guide and discuss your CO alarm emergency procedure with all the members of your family.
  • Page 6 1. Information About Carbon Monoxide Possible Sources of Carbon Monoxide Inside your home, appliances used for heating and cooking are the most likely sources of CO. Vehicles running in attached garages can also produce dangerous levels of CO. CO can be produced when burning any fossil fuel, such as gasoline, propane, natural gas, oil and wood.
  • Page 7 Because carbon monoxide is a cumulative poison, long-term exposures to low levels may cause symptoms, as well as short-term exposures to high levels. This Kidde unit has a time-weighted alarm – the higher the level of CO present, the sooner the alarm will be triggered.

  • Page 8: Product Features And Specifications

    1. Information About Carbon Monoxide • CO being present on one level of the home and not reach a CO alarm installed on a different level. (For example, CO in the basement may not reach an alarm on the second level, near the bedrooms). For these reasons, we recommend you provide complete coverage by placing a CO alarm on every level of the home.
  • Page 9 2. Product Features and Specifications Low Battery Warning If the battery is missing or battery power is low, the unit will chirp every 60 seconds to indicate the batteries must be replaced. THE BATTERIES MUST BE REPLACED IMMEDIATELY! Low Battery HUSH ®...
  • Page 10 2. Product Features and Specifications End of Life Notification IMPORTANT: Ten (10) years after unit is first powered, this alarm will chirp two times every 30 seconds to indicate it is time to replace the alarm. End of Life “Hush”: This model has an End of Life Hush feature which allows you to press the test/reset button on the alarm and disable the “chirps”...

  • Page 11: Installation Locations

    (4.4°C) or hotter than 100°F (37.8°C) such as crawl spaces, attics, porches and garages. • Do not install within 5 ft. of heating or cooking appliances. (Kidde recommends 15 ft. to prevent nuisance alarms). • Do not install near vents, flues, chimneys or any forced/unforced air ventilation openings.

  • Page 12: Installation Instructions

    4. Installation Instructions How to Install Your Alarm Direct Plug Alarm To install: 1. Choose a standard 120V unswitched outlet to plug the alarm into. 2. Write the date ten years from installation on the Replace by sticker 90º ROTATING DIRECT on the CO alarm.
  • Page 13 6.Operating Characteristics When the CO alarm loses AC power: If you have two good AA bat- teries installed, the alarm will automatically switch to the battery back- up mode and the green LED will flash approximately every 60 seconds. The unit will continue to operate normally and detect CO . When AC power is restored, the alarm will automatically switch back to normal operating mode and the green LED will come on continu- ously.

  • Page 14: Maintenance

    Operating and Alarm Characteristics Function LED Display Alarm Sound Unit Status Recommendation Replace batteries. Error/ serv- Red LED flashes every One quick beep Unit is in error condition If “Err” continues, unit ice alarm 30 seconds every 30 seconds has malfunctioned. Replace immediately.
  • Page 15 7. Maintenance Any of these batteries can be purchased where you bought the alarm or at your local hardware store. NOTE: Do not use Lithium batteries with this unit. IMPORTANT: Constant exposures to high or low humidity may reduce battery life. Use only the batteries specified. Use of different batteries may have a detrimental effect on alarm.
  • Page 16 7. Maintenance FCC COMPLIANCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 17 IMPORTANT: Do not remove unit back cover. Back cover removal will void warranty. Your Kidde Carbon Monoxide Alarm is not a substitute for property, disability, life or other insurance of any kind. Appropriate insurance coverage is your responsibility. Consult your insurance agent.
