Summary of Contents for Scion 2012 xD
- Page 1 2012 Quick RefeRence GuiDe Get infoRmeD. Roll.
- Page 2 Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your new Scion xD. A word about safe vehicle operations This Quick Reference Guide is not a full description of Scion xD operations.
-
Page 3: Table Of Contents
INDEX Engine maintenance OVERVIEW Fuel tank door release and cap Hood release Indicator symbols Instrument cluster Instrument panel Keyless entry Light control-Instrument panel Air Conditioning/Heating FEATURES/OPERATIONS Automatic Transmission Bottle holders Clock Cruise control Cup holders Lights & turn signals Multi-information display Parking brake Power outlet Seat adjustments... - Page 4 OVERVIEW Instrument panel Steering wheel audio controls* Ignition switch Cruise control Headlight and turn signal controls Wiper and washer controls Emergency flasher button Clock Front passenger occupant classification indicator/Front passenger seat belt reminder light...
- Page 5 12V DC Power outlet USB port/AUX port* Tilt steering lock release Tire Pressure Monitoring (warning) System reset Instrument panel light control Power rearview mirror controls * For details, refer to the SCION Audio System, Owner’s Manual or SCION Navigation System Owner’s Manual.
-
Page 6: Instrument Cluster
OVERVIEW Instrument cluster Service indicator and reminder Speedometer MODE switch Multi-information display Tachometer Shift position indicator Fuel gauge Indicator symbols For details, refer to “Indicators and warning lights,” Section 2-2, 2012 Owner’s Manual. Brake system warning Driver seat belt reminder (alarm will sound if speed is over 12 mph) Front passenger seat belt reminder (alarm will sound if speed is over 12 mph) - Page 7 Low Tire Pressure Warning Low windshield washer fluid level warning Low engine coolant temperature indicator High engine coolant temperature warning Engine oil replacement reminder Front passenger occupant classification indicator Headlight low beam indicator Headlight high beam indicator Turn signal indicator Low fuel level warning Slip indicator Vehicle Stability Control OFF indicator...
-
Page 8: Keyless Entry 1
OVERVIEW Keyless entry Locking operation Unlocking operation Push ONCE: Driver door TWICE: ALL doors NOTE: If a door is not opened within 30 seconds of unlocking, all doors will Push relock for safety. Panic button Push and hold Fuel tank door release and cap Turn to open Pull up Store... -
Page 9: Light Control-Instrument Panel
Light control-Instrument panel Bright Dark Hood release Pull Pull up latch and raise hood Engine maintenance Windshield washer fluid tank Engine oil filler cap Engine coolant reservoir Engine oil level dipstick NOTE: Regularly scheduled maintenance, including oil changes, will help extend the life of your vehicle and maintain performance. -
Page 10: Parking Brake
FEATURES/OPERATIONS Automatic Transmission (if equipped) Park* Reverse Neutral Drive Third gear Second gear First gear * The ignition switch must be “ON” and the brake pedal depressed to shift from Park. Downshifting increases power going uphill, or provides engine braking downhill. For best fuel economy during normal driving conditions, always drive with the shift lever in the “D”... -
Page 11: Seat Adjustments
Seat adjustments Front Rear Pull up Seat position Seatback angle/ fold down Seatback angle Seat position (forward/backward) Seat-Folding down rear seat (2) Remove (3) Lower (1) Push (4) Pull up (5) Slide forward (6) Pull up (7) Fold down... - Page 12 FEATURES/OPERATIONS Lights & turn signals Headlights Type A Type B Headlights Headlights Parking lights Parking lights Low beam High beam flasher High beam Turn signals Right turn Lane change Lane change Left turn Windshield wipers & washers Front Type A Type B Single wipe Single wipe...
-
Page 13: Cruise Control
Windows Driver side Window lock switch Down Automatic down operation (driver side only) Push the switch completely down and release to fully open. To stop window midway, lightly pull the switch up. Window lock switch Deactivates all passenger windows. Driver’s window remains operable. -
Page 14: Tilt Steering Wheel
FEATURES/OPERATIONS Tilt steering wheel Angle Lock release lever Hold wheel, push lever down, set angle and return lever. NOTE: Do not attempt to adjust while the vehicle is in motion. Air Conditioning/Heating Air Conditioning ON/OFF Use fresh air to quickly cool interior, then change to recirculate for cooler air. Fan speed Rear window defogger Temperature selector... -
Page 15: Clock
By inserting a mini plug into the AUX port, you can listen to music from a portable audio device through the vehicle’s speaker system while in AUX mode. If you do not have a SCION genuine audio system, you will not be able to use the AUX port/USB port. -
Page 16: Multi-Information Display
Push to turn audio ON and select an audio mode. Push and hold to turn the audio system OFF. Refer to the SCION Audio or Navigation System Owner’s Manual for more details. Multi-information display Push button to change information in the following succession:... -
Page 17: Bottle Holders
Power outlet Designed for car accessories. Key must be in the “ACC” or “ON” position for use. Bottle holders Front Rear Cup holders Front Rear Center... -
Page 18: Seat Belts
SAFETY AND EMERGENCY FEATURES Door locks Unlock Lock Doors-Child safety locks Rear door Unlock Lock Moving the lever to “LOCK” will allow the door to be opened only from the outside. Seat belts-Shoulder belt anchor Push up, or pull lock release to lower Seat belts Take up slack... -
Page 19: Tire Pressure Monitoring (Warning) System
If the tire pressure indicator flashes for more than 60 seconds and then remains on, take the vehicle to your local Scion dealer. NOTE: The warning light may come on due to temperature changes or changes in tire pressure from natural air leakage. If the system has not been initialized recently, setting the tire pressures to factory specifications should turn off the light. - Page 20 SAFETY AND EMERGENCY FEATURES Star Safety System All new Toyota vehicles come standard with the Star Safety System , which combines Vehicle Stability Control (VSC), Traction Control (TRAC), Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA) and Smart Stop Technology (SST).
- Page 21 Smart Stop Technology (SST) Smart Stop Technology automatically reduces engine power when the accelerator and brake pedals are pressed simultaneously under certain conditions. SST engages when the accelerator is depressed first and the brakes are applied firmly for longer than one-half second at speeds greater than five miles per hour. SST doesn’t engage if the brake pedal is depressed before the accelerator pedal, allowing vehicles to start on a steep hill and safely accelerate without rolling backward.
- Page 22 NOTES...
- Page 24 Have a Question? Contact PhonE 1.866.70.sCion MAIl sCion 19001 s. Western Ave. D102, P .o. Box 2742 Torrance, CA 90509-2742 www.scion.com ©2011 Scion, a marque of Toyota Motor Sales, U.S.A., Inc. Printed in U.S.A. 9/11 11-TCS-05092 00505-QRG12-XD...
