xB
2010
QUICK
REFERENCE
GUIDE
GET INFORMED.
ROLL.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the xB 2010 and is the answer not in the manual?

Questions and answers

Summary of Contents for Scion xB 2010

  • Page 1 2010 QUICK REFERENCE GUIDE GET INFORMED. ROLL.
  • Page 2 Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your new Scion xB. A word about safe vehicle operations This Quick Reference Guide is not a full description of Scion xB operations.
  • Page 3: Table Of Contents

    Doors-Child safety locks EMERGENCY FEATURES Seatbelts Seat belts-Shoulder belt anchor Spare tire & tools Tire Pressure Monitoring (warning) System Visit your Scion dealer for information on customizing this feature. Programmable by customer. Refer to the Owner’s Manual for instructions and more information.
  • Page 4: Instrument Panel

    OVERVIEW Instrument panel Headlight and turn signal controls Steering wheel audio controls* Wiper and washer controls Rear window defogger button Air Conditioning controls Front passenger occupant classification indicator/ Front passenger seatbelt reminder light Power outlet Emergency flasher button...
  • Page 5 Tire Pressure Monitoring (warning) System reset Tilt steering lock release “VSC OFF” (Vehicle Stability Control “OFF”) Instrument panel light control dial Power outside rearview mirror controls * For details, refer to the SCION Audio System Owner’s Manual or SCION Navigation System Owner’s Manual.
  • Page 6: Instrument Cluster

    OVERVIEW Instrument cluster Service indicator and reminder Speedometer Tachometer Fuel gauge Engine coolant temperature Odometer and two trip meters Trip meter reset knob Multi-information display Multi-information display control switch Automatic Transmission shift position indicator...
  • Page 7: Indicator Symbols

    Indicator symbols Brake system warning Driver seatbelt reminder (alarm will sound if speed is over 12 mph) Front passenger seatbelt reminder (alarm will sound if speed is over 12 mph) Charging system warning Malfunction/Check Engine indicator Low engine oil pressure warning Open door warning Airbag SRS warning Low Tire Pressure Warning...
  • Page 8: Keyless Entry

    OVERVIEW Keyless entry Locking operation Unlocking operation Push ONCE: Driver door TWICE: ALL doors NOTE: If a door is not opened within 60 seconds of unlocking, all Push doors will relock for safety. Panic button Push and hold Hood release Pull up latch Pull and raise hood...
  • Page 9: Fuel Tank Door Release And Cap

    Fuel tank door release and cap Store Driver seat Pull up Turn NOTE: Tighten until one click is heard. If the cap is not tightened enough, Check Engine “ ” indicator may illuminate. Engine maintenance Windshield washer fluid tank Engine coolant reservoir Engine oil filler cap Engine oil level dipstick Note: Regularly scheduled maintenance, including oil changes, will...
  • Page 10: Auto Lock Functions

    FEATURES/OPERATIONS Auto lock functions Automatic door locks can be programmed to operate in four different modes, or turned OFF. -Doors lock when shifting from Park.* -Doors lock when the vehicle speed goes above approximately 12 mph. -Doors unlock when ignition key is turned to “ACC” or “LOCK” position and driver’s door is opened.
  • Page 11: Seat Adjustments-Front

    Seats-Head restraints Front Rear Lock release button Lock release button Seat adjustments-Front Seat position (forward/backward) Height crank (driver side only) Seatback angle Seat-Folding down rear seat (3) Push (1) Push (2) Lower (4) Fold down...
  • Page 12: Lights & Turn Signals

    FEATURES/OPERATIONS Lights & turn signals Headlights High beam Headlights Low beam Parking lights High beam flasher Turn signals Right turn Lane change Lane change Left turn Window wipers & washers Front Single wipe Interval wipe Slow Pull to wash and wipe Fast Rear Wash and wipe...
  • Page 13: Cruise Control

    Windows Driver side Window lock switch Down Down Automatic operation (driver side only) Push the switch completely down and release to fully open. To stop window midway, lightly pull the switch Window lock switch Deactivates all passenger windows. Driver’s window remains operable.
  • Page 14: Tilt Steering Wheel

    FEATURES/OPERATIONS Tilt steering wheel Angle Lock release lever Hold wheel, push lever down, set angle and return lever. Note: Do not attempt to adjust while the vehicle is in motion. Air Conditioning/Heating Airflow vent In “ ” or “ ” mode, use fresh air (“ ”...
  • Page 15: Steering Wheel Switches

    By inserting a mini plug into the AUX jack, you can listen to music from a portable audio device through the vehicle’s speaker system. If you do not have a SCION genuine audio system, you will not be able to use the USB adapter or AUX jack.
  • Page 16: Power Outlet

    FEATURES/OPERATIONS Power outlet Instrument panel Designed for car accessories. Key must be in the “ACC” or “ON” position to use. Bottle holders Front door...
  • Page 17: Multi-Information Display

    Multi-information display Push “DISP” to change information in the following succession: (1) Clock (2) Outside temperature (3) Current gas mileage (MPG) (4) Average gas mileage (AVG/MPG) (5) Miles left on remaining fuel (RANGE/MI) (6) Average vehicle speed from engine start (AVG/MPH) (7) Running time from engine start (E/T)
  • Page 18: Safety And Emergency Features

    SAFETY AND EMERGENCY FEATURES Door locks Driver side Passenger side Lock Unlock Unlock Lock Doors-Child safety locks Rear door Moving the lever to “LOCK” will allow the door to be opened only from the outside. Seat belts-Shoulder belt anchor Push up to raise, or pull lock release to lower Seat belts Take up slack...
  • Page 19: Spare Tire & Tools

    Tire Pressure Monitoring (warning) System If tire pressure indicator is on, check/adjust each tire. After adjusting tire pressures, or after tires have been rotated or replaced, turn the ignition switch to “ON” and press and hold the “ SET” button until indicator blinks three times. Let the vehicle sit for a few minutes to allow initialization to complete.
  • Page 20  Have a Question?  Contact PHONE 1.866.70.SCION MAIL SCION 19001 S. Western Ave. D102, P .O. Box 2742 Torrance, CA 90509-2742 www.scion.com ©2009 Scion, a marque of Toyota Motor Sales, U.S.A., Inc. Printed in U.S.A. 03/09 08-TCS-03066 00505-QRG10-XB...
