Summary of Contents for McCulloch T22LCS

  • Page 1 GB Operator’s manual 2-22 SK Návod na obsluhu 346-366 SE Bruksanvisning 23-43 HR Priruãnik 367-387 DK Brugsanvisning 44-64 RS Priruãnik 388-408 Käyttöohje 65-86 Navodila za uporabo 409-429 NO Bruksanvisning 87-107 BA Uputstvo o upotrebi 430-450 FR Manuel d’utilisation 108-129 CZ Návod k pouÏití 451-471 NL Gebruiksaanwijzing 130-150 RO Instrucöiuni de utilizare 472-493 Istruzioni per l’uso 151-172...

  • Page 2: Key To Symbols

    KEY TO SYMBOLS Symbols Ignition; choke: Set the choke control in the choke WARNING! Clearing saws, position. brushcutters and trimmers can be dangerous! Careless or incorrect use can result in serious or fatal injury to Air purge. the operator or others. It is extremely important that you read and understand the contents of the operator’s manual.

  • Page 3: Table Of Contents

    CONTENTS Contents Note the following before starting: KEY TO SYMBOLS Symbols ..............2 Please read the operator’s manual carefully. Symbols on the machine and/or in the manual: ... 2 CONTENTS WARNING! Long-term exposure to noise can result in permanent hearing Contents ...............

  • Page 4: Introduction

    We certainly hope that you will be satisfied with your McCulloch product, as it is designed to be your companion for a long time. By following this operators manual’s advice on usage, service, and maintenance, its lifespan can be extended.

  • Page 5: What Is What

    WHAT IS WHAT? T22LS T22LCS What is what on the grass trimmer? Trimmer head 12 Starter Grease filler cap, bevel gear 13 Starter handle Bevel gear 14 Fuel tank Cutting attachment guard 15 Air filter cover Shaft 16 Air purge.

  • Page 6: General Safety Precautions

    GENERAL SAFETY PRECAUTIONS Important Personal protective equipment IMPORTANT! IMPORTANT! The machine is only designed for trimming grass. A clearing saw, brushcutter or trimmer can be dangerous if used incorrectly or carelessly, and can The only accessories you can operate with this engine cause serious or fatal injury to the operator or others.

  • Page 7: Machine's Safety Equipment

    GENERAL SAFETY PRECAUTIONS BOOTS Throttle lockout Wear sturdy, non-slip boots. The throttle lockout is designed to prevent accidental operation of the throttle control. When you press the lock (A) (i.e. when you grasp the handle) it releases the throttle control (B). When you release the handle the throttle control and the throttle lockout both move back to their original positions.
  • Page 8 GENERAL SAFETY PRECAUTIONS Stop switch Muffler Use the stop switch to switch off the engine. The muffler is designed to keep noise levels to a minimum and to direct exhaust fumes away from the user. A muffler fitted with a catalytic converter is also designed to reduce harmful exhaust gases.

  • Page 9: Cutting Equipment

    GENERAL SAFETY PRECAUTIONS Trimmer head WARNING! Mufflers fitted with catalytic converters get very hot during use and IMPORTANT! remain so for some time after stopping. This also applies at idle speed. Contact Always ensure the trimmer cord is wound tightly and can result in burns to the skin.

  • Page 10: Assembly

    ASSEMBLY Fitting the loop handle • Before using the unit, tighten the knob securely. • Clip the loop handle onto the shaft. Note that the loop handle must be fitted between the arrows on the shaft. Dismantling: • Loosen the coupling by turning the knob (at least 3 times).

  • Page 11: Fitting The Trimmer Guard And Trimmer Head

    Screw on the trimmer head/plastic blades (H) in the opposite direction to the direction of rotation. • To dismantle, follow the instructions in the reverse order. Fitting the trimmer guard and trimmer head (T22LCS) • Fit the guard as shown in the diagram. Tighten securely. – English...

  • Page 12: Fuel Handling

    For best results and performance use Universal, • The transport guard must always be fitted to the Universal powered by McCULLOCH two-stroke cutting attachment when the machine is being engine oil, which is specially formulated for our air- transported or in storage.

  • Page 13: Fueling

    FUEL HANDLING Mixing Fueling • Always mix the petrol and oil in a clean container intended for fuel. • Always start by filling half the amount of the petrol to be used. Then add the entire amount of oil. Mix WARNING! Taking the following (shake) the fuel mixture.

  • Page 14: Starting And Stopping

    STARTING AND STOPPING Check before starting Choke: Set the choke control in the choke position. • Check that the trimmer head and trimmer guard are not damaged or cracked. Replace the trimmer head or trimmer guard if they have been exposed to impact or are cracked.

  • Page 15: Working Techniques

    WORKING TECHNIQUES General working instructions Always hold the machine with both hands. Hold the machine on the right side of your body. Keep all parts of your body away from the hot surfaces. Keep all IMPORTANT! parts of your body away from the rotating cutting This section takes up the basic safety precautions for attachment.

  • Page 16: Basic Working Techniques

    WORKING TECHNIQUES Basic working techniques CAUTION! This technique increases the wear on the cord. Always slow the engine to idle speed after each working operation. Long periods at full throttle without any load on the engine can lead to serious engine damage. WARNING! Sometimes branches or grass get caught between the guard and cutting attachment.

  • Page 17: Maintenance

    MAINTENANCE Carburettor The muffler is designed to reduce the noise level and to direct the exhaust gases away from the operator. The exhaust gases are hot and can contain sparks, which may Adjustment of the idle speed cause fire if directed against dry and combustible Before any adjustments are made, make sure that the air material.

  • Page 18: Cooling System

    MAINTENANCE Cooling system spark plug should be replaced after about a month in operation or earlier if necessary. To keep the working temperature as low as possible the machine is equipped with a cooling system. CAUTION! Always use the recommended spark plug type! Use of the wrong spark plug can damage the piston/ cylinder.

  • Page 19: Air Filter

    MAINTENANCE Air filter Oiling the air filter Always use filter oil, art. no. 531 00 92-48. The filter oil The air filter must be regularly cleaned to remove dust contains a solvent to make it spread evenly through the and dirt in order to avoid: filter.

  • Page 20: Maintenance Schedule

    MAINTENANCE Maintenance schedule The following is a list of the maintenance that must be performed on the machine. Most of the items are described in the Maintenance section. The user must only carry out the maintenance and service work described in this Operator’s Manual.

  • Page 21: Technical Data

    TECHNICAL DATA Technical data T22LCS T22LS Engine Cylinder displacement, cm 21,7 21,7 Cylinder bore, mm 32,0 32,0 Stroke, mm Idle speed, rpm 2900 2900 Recommended max. speed, rpm 7200 9100 Speed of output shaft, rpm 7200 6232 Max. engine output, acc. to ISO 8893, kW/ rpm...

  • Page 22: Ec-Declaration Of Conformity

    We, Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel: +46-36-146500, declare that the grass trimmers McCULLOCH T22LS and T22LCS with serial numbers dating from 2012 onwards (the year is clearly stated on the rating plate, followed by the serial number), comply with the requirements of the COUNCIL’S DIRECTIVE: - of May 17, 2006 "relating to machinery"...

This manual is also suitable for:
