ZoneVu 328 Series User Manual

Video matrix system
Hide thumbs Also See for ZoneVu 328 Series:
Table of Contents

Advertisement

Quick Links

SERIES 328 VIDEO
MATRIX SYSTEM
USERS MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZoneVu 328 Series and is the answer not in the manual?

Questions and answers

Related Manuals for ZoneVu ZoneVu 328 Series

Summary of Contents for ZoneVu ZoneVu 328 Series

  • Page 1 SERIES 328 VIDEO MATRIX SYSTEM USERS MANUAL...

  • Page 2: Table Of Contents

    SERIES 328 WELCOME ......................3 FEATURES ........................... 4 INSTALLATION ..........................5 CONFIGURATION ........................8 SPECIFICATIONS ........................21 TROUBLE SHOOTING GUIDE ....................23 DECLARATION OF CONFORMITY ..................24 MAINTENANCE .......................... 25 DISPOSAL ..........................25 SUPPORT ........................... 26 WARRANTY ..........................27 MEYERTECH LIMITED...

  • Page 3: Series 328 Welcome

    CCTV solutions. MEYERTECH are dedicated to customer service and support. If you have any questions or problems, our staff will be pleased to assist you on the technical help line listed on page Error! Bookmark not defined..

  • Page 4: Features

    ♦ Salvo Monitor Sequencing. ♦ Zonal Switching. ♦ Video Loss Detection. ♦ 32 Programmable Normally Open/Closed Alarm Contacts ♦ Event Driven Alarm Handling ♦ RS-422 or VICTA Coaxial Telemetry. ♦ Compatible with the full range of ZoneVu products. ♦ Diagnostics. MEYERTECH LIMITED...

  • Page 5: Installation

    The ZVM-328 Video Matrix is expandable in blocks of 32 inputs to a maximum size of 96 cameras and 8 monitors. Hence, the three matrix options are ZVM-328, ZVM-648 and ZVM-968. Minimum System Fully Expanded System Master Matrix SlaveMatrix #1 SlaveMatrix #2 32 Contact ZVM-328 ZVM-328 ZVM-328 Alarms Cameras 1-32 Camera 33-64 Cameras 65-96 Monitors 1-8 MEYERTECH LIMITED...
  • Page 6 Telemetry Receivers RS-422 and /or Video ZVM-328 ZVM-328 ZVM-328 32 Contact Master Slave 1 Slave 2 Alarms Rx Tx Monitors 1-8 Monitors 1-8 Monitors 1-8 4 Wire RS 422 Network ZVK-XXX Series Operator Keyboards. Expandable to 8 Keyboards MEYERTECH LIMITED...
  • Page 7 Step through options with link. Fit link. Power down to accept. Standalone Master Cameras 1-32 Slave Cameras 33-64 Slave Cameras 65-96 When each matrix has been configured in the above manner, power Slave matrices ON followed by the Master. MEYERTECH LIMITED...

  • Page 8: Configuration

    For further information regarding the ZVK-007 keyboard please refer to the ZVK-007 User Manual. Using the ZVK-77 • By using the ZVK-77s programming mode, navigation of the Series 328 menus can be done with the Softkeys. For further information regarding the ZVK-77 keyboard please refer to the ZVK-77 User Manual. MEYERTECH LIMITED...
  • Page 9 Sequencing Options Miscellaneous Return To Main Menu 4.3.1 CAMERA OPTIONS CAMERA OPTIONS MENU Camera : 1 Video PRESENT Head Type : ZoneVu Set Caption Caption : ON Time/Date : BOTH Text Position : TOP MEYERTECH LIMITED Return To Matrix Menu...
  • Page 10 The Series 328 will support a range of 3 party domes directly. See the supported driver documentation for more information For further information regarding Meyertech ZoneVu protocols or any interfacing requirements please contact Meyertech Head Office. Contact details can be found at the end of this document. Caption Camera text on or off.
  • Page 11 Toggle monitor caption text ON or OFF. Camera Text Toggle camera text ON or OFF – allows camera text to be turned off by monitor, not turned on. 4.3.3 ALARM OPTIONS ALARM OPTIONS MENU Alarm Reporting Contact Alarms Alarm Handling Return To Matrix Menu MEYERTECH LIMITED...
  • Page 12 ON or OFF. Master or Standalone Matrices only. Video Loss [ ] ON or OFF. Must be defined on Standalone / Master & Slave Matrices Relay Output [ Action is configurable as Off, Latched or Pulsed (for 1 second). Master or Standalone Matrices only. MEYERTECH LIMITED...
  • Page 13 Each Alarm triggers three events. Each event can be configured to switch a Camera to a Monitor, send a Camera to a Preset and Report the alarm to a Keyboard. Additionally, individual aspects of each event can be switched ON or OFF. MEYERTECH LIMITED...
  • Page 14 Queue Length Number of alarms allowed to be queued at any one time. Queue Type Determines whether alarms progress to the top of the alarm queue based on the order in which they occurred (CHRON) or their priority (PRIOR). MEYERTECH LIMITED...
  • Page 15 Up to 32 positions can be programmed into any pattern. The pattern size field sets the position after which the sequence restarts at position 1. Dwell Time [ The global time between updating monitors and stepping to the next pattern position. Range 1 to 99 seconds. MEYERTECH LIMITED...
  • Page 16 This area of configuration is intended to be used as a tool for quickly setting up the Video field seen in the Camera Options menu. (See section 4.3.1) Use the MONITOR key to manoeuvre through the menu and the ENTER key to place a marker next to each input where video is present. MEYERTECH LIMITED...
  • Page 17 If the Control Time-out feature is enabled, keyboards are forced to relinquish control after the specified period of time of inactivity. This option can be switched OFF by entering a value of 0 or ON by entering a value in the range 1 to 99 minutes. MEYERTECH LIMITED...
  • Page 18 CAMERA OPTIONS MENU. Each field must be set individually and the real time clock will only take on the new values when Initialise clock is selected. 4.5 DIAGNOSTICS DIAGNOSTICS MENU Test Video Inputs Test Contact Alarms Return To Main Menu MEYERTECH LIMITED...
  • Page 19 Closed Circuit. I.e. All Open. MATRIX ACTIVE CONTACTS 12-0 23-0 13-0 24-0 14-0 25-0 15-0 26-0 Test 16-0 27-0 17-0 28-0 18-0 29-0 19-0 30-0 20-0 31-0 10-0 21-0 32-0 11-0 22-0 4.5.3 LOAD DEFAULTS LOAD DEFAULTS Are You Sure? MEYERTECH LIMITED...
  • Page 20 Cam. to Pre. Report to Kbd. Global Time/Date 23:59:00 31/12/99 Dwell Time 5 seconds Video Loss Contact Alarms Auto Cancel Cancel Time 5 Seconds Alarm Queue Type CHRON (chronological) Alarm Queue Length Relay Output PULSED Report Monitor Keyboards Ctrl Timeout MEYERTECH LIMITED...

  • Page 21: Specifications

    19” by 3u (482mm x 132mm x 75mm) WEIGHT 3.2kg TEMPERATURE Operational 0 Degrees to 40 Degrees C Storage minus 20 Degrees to plus 60 Degrees C Humidity 10% to 95% (Non-condensing) VIDEO INPUTS BNC Terminal with link for 75Ω termination (remove if bridging input). MEYERTECH LIMITED...
  • Page 22 The Packet Headers and the Packet Terminator are formed from non- printable ASCII characters. Commands and data are formed from printable ASCII characters. ASCII NUL characters are used to separate data fields. Baud rate 9600 baud Parity none Stop bits Flow control none Data bits MEYERTECH LIMITED...

  • Page 23: Trouble Shooting Guide

    This Trouble Shooting Guide should be used in the first instance of encountering any problems with the ZVM-328. If problems persist, contact MEYERTECH on the Technical Help line numbers given on page Error! Reference source not found.Error! Reference source not found.Error! Reference source not found.Error! Bookmark not defined..

  • Page 24: Declaration Of Conformity

    Amendments 1, 2, & 3 1992 Supplementary Information: MEYERTECH declare under our sole responsibility that the product to which this declaration relates, is in conformity with the protection requirements of council directive 89/336/eec on the approximation of the laws of the member states relating to electromagnetic compatibility, when installed in accordance with the instructions given in this manual.

  • Page 25: Maintenance

    There are no additional requirements beyond safe working practice in the decommissioning of the Meyertech Series 328. However the Series 328 contains printed circuit boards populated with electronic components. The whole unit must be returned to Meyertech Service Centre for final disposal. Please follow the normal returns procedure. MEYERTECH LIMITED...

  • Page 26: Support

    Meyertech Limited is a member of the CCTV User Group. SUPPORT At Meyertech our staff understand quality support is important to you, vital in fact, which is why we place such a high precedence on providing it. For all matters relating to support go to our website to find the information your require visit http://www.meyertech.co.uk/support.html...

  • Page 27: Warranty

    Page 27 of 29 WARRANTY Please refer to Meyertech Limited ‘Terms & Conditions of Sale of Goods & Services’ for interpretation. 1. If the Buyer establishes to the Seller's reasonable satisfaction that there is a defect in the materials or workmanship of the Goods manufactured, then the Seller shall at its option, at its sole discretion and within a reasonable time, a.
  • Page 28 11. The Buyer is solely responsible for various scanning the software that it receives from the Seller pursuant to the Contract. 12. The Seller warrants that it will use reasonable skill and care in providing the Services to the buyer MEYERTECH LIMITED...
  • Page 29 ZVM-328 User Manual Issue 05 Page 29 of 29 NOTES MEYERTECH LIMITED...
