ZoneVu 328 Series User Manual

Video matrix system
Hide thumbs Also See for ZoneVu 328 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
SERIES 328 VIDEO
MATRIX SYSTEM
USERS MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZoneVu 328 Series and is the answer not in the manual?

Questions and answers

Related Manuals for ZoneVu ZoneVu 328 Series

Summary of Contents for ZoneVu ZoneVu 328 Series

  • Page 1 SERIES 328 VIDEO MATRIX SYSTEM USERS MANUAL...

  • Page 2: Table Of Contents

    MEYERTECH DIVISION ISSUE 01 CONTENTS SERIES 328 WELCOME FEATURES INSTALLATION System Expansion CONNECTING THE ZVM-328 Setting up the system CONFIGURATION KEY TABLES OSD MENU SYSTEM SETUP MATRIX 4.3.1 CAMERA OPTIONS 4.3.2 MONITOR OPTIONS 4.3.3 ALARM OPTIONS 4.3.3.1 Alarm Reporting 4.3.3.2 Contract Alarms 4.3.3.3 Alarm Handling...
  • Page 3 ISSUE 01 MEYERTECH DIVISION ISSUE 01 ZVM-328 Factory preset conditions. SPECIFICATIONS Electrical Specification Mechanical Specification TROUBLE SHOOTING GUIDE DECLARATION OF CONFORMITY Product Warranty DOCUMENT HISTORY Whilst every effort has been made to confirm the information in this document is correct, MEYERTECH DIVISION cannot accept any liability for any errors, omissions and or incorrect information contained within this document.

  • Page 4: Series 328 Welcome

    The ZVM-328, ZVM-648 and ZVM-968 are powerful yet compact video matrices, which meet all small to medium size system requirements. In conjunction with other products within the ZoneVu range the ZVM-328, ZVM-648 and ZVM-968 provide complete and powerful CCTV solutions.

  • Page 5: Installation

    ISSUE 01 MEYERTECH DIVISION ISSUE 01 NSTALLATION INSTALLATION To obtain the optimum performance from your ZVM-328, please take time to read this manual before commencing installation. If you have any questions or problems our staff will be pleased to assist you on the technical help line listed on page 29.

  • Page 6: Connecting The Zvm-328

    MEYERTECH DIVISION ISSUE 01 3.2 CONNECTING THE ZVM-328 Connect up the ZVM-328 in accordance with diagram below and the Electrical Specification on page 22, paying special attention to the maximum ratings and the notes below. 1. The ZVM-328 MUST be earthed at the earthing tag provided on the housing. 2.

  • Page 7: Setting Up The System

    ISSUE 01 MEYERTECH DIVISION ISSUE 01 3.3 SETTING UP THE SYSTEM Each ZVM-328 matrix must be individually set-up in order to define its position within the overall system (see Section System Expansion on page 5). 1. Ensure ZVM-328 matrix is powered OFF. 2.

  • Page 8: Configuration

    MEYERTECH DIVISION ISSUE 01 CONFIGURATION The ZVM-328 should now be configured, by logging on from a ZVK series keyboard. 4.1 KEY TABLES • Using the ZVK-002 The following ZVK-002 keys are used to configure the matrix. Proceed to the selected option. Also used to accept parameters and to toggle through available options.

  • Page 9: Setup Matrix

    Miscellaneous Return To Main Menu 4.3.1 CAMERA OPTIONS CAMERA OPTIONS MENU Camera : 1 Video PRESENT Head Type : ZoneVu Set Caption Caption : ON Time/Date : BOTH Text Position : TOP Return To Matrix Menu The CAMERA OPTIONS MENU allows the user to configure all options on a camera by camera basis.
  • Page 10 ZVR-xxx over coaxial cable M.MERCER Mark Mercer Domes. D250MPT-AF JVC Domes. TK-C675E For further information regarding Meyertech ZoneVu protocols or any interfacing requirements please contact Meyertech Head Office. Contact details can be found at the end of this document. Caption Camera text on or off.

  • Page 11: Monitor Options

    ISSUE 01 MEYERTECH DIVISION ISSUE 01 4.3.2 MONITOR OPTIONS MONITOR OPTIONS MENU Monitor : 1 Set Caption Caption : ON Camera Text : ON Return To Matrix Menu The MONITOR OPTIONS MENU allows the user to configure all options available on a monitor by monitor basis.

  • Page 12: Alarm Reporting

    MEYERTECH DIVISION ISSUE 01 4.3.3.1 Alarm Reporting ALARM REPORTING Contact Alarms [ OFF ] Video Loss [ OFF ] Relay Output [ LATCH ] Return To Alarm Menu Editable Fields are: Contact Alarm [ ] ON or OFF. Master or Standalone Matrices only. Video Loss [ ] ON or OFF.

  • Page 13: Contract Alarms

    ISSUE 01 MEYERTECH DIVISION ISSUE 01 4.3.3.2 Contract Alarms CONTACT ALARMS MENU Alarm No [ 01] Alarm Text Alarm Status [N/O] Priority [ 1 ] Relay [ ENABLE ] Event #1 Event #2 Event #3 Return To Alarm Menu The CONTACT ALARMS MENU allows the user to configure all options relating to the contact alarm inputs located at the back of the ZVM-328.

  • Page 14: Alarm Handling

    Queue Type [CHRON] Return to Alarm Menu Auto Cancel This feature enables the ZoneVu system to handle alarms automatically. 1. A contact alarm occurs and activates user defined events. I.e. Cameras are sent to Presets, switched to monitors and keyboards reported to.

  • Page 15: Sequencing Options

    ISSUE 01 MEYERTECH DIVISION ISSUE 01 4.3.4 SEQUENCING OPTIONS SEQUENCING MENU Pattern [ 1 ] Position [ 1 ] Camera [ 1 ] Pattern size [ 32 ] Dwell in seconds [60] Return To Matrix Menu The SEQUENCING MENU allows the user to configure all monitor sequencing options. A sequence is a defined list of cameras.

  • Page 16: Miscellaneous Options

    MEYERTECH DIVISION ISSUE 01 4.3.5 MISCELLANEOUS OPTIONS The Miscellaneous Menu contains configuration options which do not directly relate to Cameras, Monitors, Alarms and Sequencing. MISCELLANEOUS MENU Setup Video Inputs Setup Contact Inputs Keyboards [ 4 ] Ctrl Time-out,mins [ 0 ]Mins Return to Matrix Menu 4.3.5.1 Setup of Video Inputs SETUP VIDEO INPUTS...

  • Page 17: Setup Of Contact Inputs

    ISSUE 01 MEYERTECH DIVISION ISSUE 01 4.3.5.2 Setup of Contact Inputs SETUP CONTACT INPUTS 1-O< 12-C 13-C 14-C Marks Moves 20-C 10-C 21-O 11-O EXIT This area of configuration is intended to be used as a tool for quickly setting up the Alarm Status field seen in the Contact Alarms menu.

  • Page 18: Setup Time/Date

    MEYERTECH DIVISION ISSUE 01 4.4 SETUP TIME/DATE TIME DATE MENU Set Hours [ 17 ] Set Minutes [ 00 ] Set Day [ 06 ] Set Month [ 11 ] Set Year [ 96 ] Initialise Clock Return To Main Menu The TIME DATE MENU allows the user to set and initialise the real time clock.

  • Page 19: Test Video Inputs

    ISSUE 01 MEYERTECH DIVISION ISSUE 01 4.5.1 T IDEO NPUTS This option gives quick diagnostic facilities for testing the matrix’s video inputs and for detecting which inputs have cameras present. The example below shows video detected on inputs 1-5. 1-ok Video 2-ok Inputs...

  • Page 20: Load Defaults

    MEYERTECH DIVISION ISSUE 01 4.6 LOAD DEFAULTS This option allows the user to reload all default programmable information such as camera captions, text options and sequences. See section 4.7 for default data. The user is given the option to abort loading default data if necessary. To re-boot the ZVM-328 and load default factory conditions: i) Remove power from the matrix.

  • Page 21: Zvm-328 Factory Preset Conditions

    ZVM-328 FACTORY PRESET CONDITIONS. By Camera Camera PRESENT Caption Camera nn Camera Text Time/Date BOTH Text Position Head Type ZoneVu Caption By Monitor Caption Mon n Caption Camera Text : ON By Sequence Pattern Position nn Camera nn Pattern Size...

  • Page 22: Specifications

    MEYERTECH DIVISION ISSUE 01 SPECIFICATIONS 5.1 ELECTRICAL SPECIFICATION POWER INPUT 12VDC Power Supply (included) from 230VAC CURRENT CONSUMPTION 650mA VIDEO Inputs 1V pk-pk 75Ω Outputs 1V pk-pk 75Ω CROSSTALK Better than 50dB SIGNAL TO NOISE Better than 50dB 5.2 MECHANICAL SPECIFICATION Video Inputs with bridged outputs.
  • Page 23 VICTA™ coax (Telemetry) RS-422 twisted pair (Telemetry / Network Communications) ZoneVu commands and data are transmitted in PACKETS. Each Packet has a unique HEADER to identify its destination and a common TERMINATOR to identify the end of the data Packet.

  • Page 24: Trouble Shooting Guide

    MEYERTECH DIVISION ISSUE 01 TROUBLE SHOOTING GUIDE This Trouble Shooting Guide should be used in the first instance of encountering any problems with the ZVM-328. If problems persist, contact MEYERTECH on the Technical Help line numbers given on page 29. Symptom Solution Telemetry not...

  • Page 25: Declaration Of Conformity

    ISSUE 01 MEYERTECH DIVISION ISSUE 01 DECLARATION OF CONFORMITY EC DECLARATION OF CONFORMITY ACCORDING TO ARTICLE 10 OF COUNCIL DIRECTIVE 89/336/EEC MEYERTECH DIVISION Manufacture’s Name: Manufacture’s Address: MEYERTECH Division Office Block One Southlink Business Park Oldham OL4 1DE declares, that the product(s): Product Name : ZVM-328 Video Matrix Model(s):...

  • Page 26: Product Warranty

    MEYERTECH DIVISION ISSUE 01 PRODUCT WARRANTY MEYERTECH DIVISION warrants that at the time of shipment the products manufactured by Meyertech will be free from defects in material and workmanship. Should any defects appear within twelve months from date of shipment, Meyertech Division shall at it’s sole discretion repair or replace the defective material.

  • Page 27: Document History

    ISSUE 01 MEYERTECH DIVISION ISSUE 01 DOCUMENT HISTORY ZVM-328 Video Matrix Users Manual: MAN-328. ISSUE DATE CHANGE RECORD 1st October 1997 First Issue MAN-328 http://www.meyertech.demon.co.uk Page 27...
  • Page 28 MEYERTECH DIVISION ISSUE 01 NOTES http://www.meyertech.demon.co.uk MAN-328 Page 28...
  • Page 29 ISSUE 01 MEYERTECH DIVISION ISSUE 01 Office Block One Southlink Business Park Oldham England OL4 1DE Sales Support Technical Support +44 (161) 628 8406 Oldham +44 (161) 628 8406 +44 (161) 628 9811 Email: technical@meyertech.co.uk Email: sales@meyertech.co.uk http://www.meyertech.demon.co.uk MAN-328 http://www.meyertech.demon.co.uk Page 29...

This manual is also suitable for:

Zonevu zvm-328Zonevu zvm-648Zonevu zvm-968
