  • Page 1 SIMPLY CLEVER ŠKODA Roomster The Owner's Manual...
  • Page 2 Preface You have opted for a ŠKODA – our sincere thanks for your confidence in us. Your new ŠKODA offers you a vehicle featuring the most modern engineering and a wide range of equipment. We recommend that you read this Owner's Manual carefully so that you can quickly familiarise yourself with your vehicle and all that it has to offer.
  • Page 3 The on-board literature The Help on the Road brochure The on-board literature for your vehicle consists of this “Owner's Manual” as well The Help on the Road brochure contains the most important telephone numbers as a “Service schedule” and the “Help on the road” brochure. in individual countries as well as the addresses and telephone numbers of ŠKODA importers.

  • Page 4: Table Of Contents

    Rear seats Safety Table of Contents Luggage compartment Variable loading floor in the luggage Passive Safety compartment Layout of this Owner's Manual (explanations) General information Bicycle carrier in the luggage compartment Correct seated position Abbreviations Roof rack system Seat belts Cup holders Seat belts Ashtray...
  • Page 5 Inspecting and replenishing Technical data Fuel Engine compartment Technical data Vehicle battery Introductory information Weights Wheels and Tyres Wheels Vehicle identification data Fuel consumption according to the ECE Accessories, changes and replacement of parts standards and EU guidelines Introductory information Dimensions Changes and impairments of the airbag Specifications and engine oil capacity...
  • Page 6 Table of Contents...

  • Page 7: Layout Of This Owner's Manual (Explanations)

    For the sake of the environment Layout of this Owner's Manual (explanations) An Environmental note draws your attention to environmental protection as- pects. This is where you will, for example, find tips aimed at reducing your fuel consumption. The Owner's Manual has been systematically designed in order to make it easy for you to search for and obtain the information you require.

  • Page 8: Abbreviations

    Abbreviations Abbreviation Definition Engine revolutions per minute Anti-lock brake system Automatic gearbox Traction control in g/km discharged quantity of carbon dioxide in grams per driven kilo- meter Diesel particle filter Automatic double clutch gearbox Stabilisation control Kilowatt, measuring unit for the engine output Manual gearbox Multi-functional indicator Vehicles of this class are designed and constructed for con-...
  • Page 9 Fig. 1 Cockpit Using the system...

  • Page 10: Using The System

    Fuse box in the dash panel Using the system Light switch and headlamp beam adjustment 40, 43 Bonnet release lever Lever for adjusting the steering wheel Cockpit Ignition lock Depending on equipment fitted: › Radio Overview › Navigation system Rocker switch for front left seat heating Power windows Central locking system Electric exterior mirror adjustment...

  • Page 11: Instruments And Warning Lights

    Overview of the Instrument cluster Instruments and warning lights Instrument cluster ä Introduction This chapter contains information on the following subjects: Overview of the Instrument cluster Engine revolutions counter Speedometer Coolant temperature gauge Fuel gauge Counter for distance driven Service Interval Display Fig.

  • Page 12: Engine Revolutions Counter

    › Set hours/minutes Coolant temperature gauge › Activate/deactivate display mode Fuel gauge » page 12 ä  First read and observe the introductory information and safety warn- ings on page 10. Engine revolutions counter The coolant temperature gauge » Fig. 2 operates only when the ignition is switched on.

  • Page 13: Fuel Gauge

    Odometer Fuel gauge The odometer indicates the total distance in kilometres or miles which the vehicle has been driven. ä First read and observe the introductory information and safety warn- ings on page 10. Fault display If there is a fault in the instrument cluster Error will appear continuously in the The fuel gauge »...

  • Page 14: Digital Clock

    As soon as the due date for the service is reached, a flashing key symbol  and Note the text Service appears in the display for 20 seconds after the ignition has been switched on. Never reset the display between service intervals, as this will result in the incor- ■...

  • Page 15: Multi-Functional Indicator (Onboard Computer)

    Driving time Recommended gear Current fuel consumption Average fuel consumption Fig. 4 Range Recommended gear Distance travelled Average speed Current speed Oil temperature Warning against excessive speeds The multi-functional indicator can only be operated when the ignition is switched on. After the ignition is switched on, the function displayed is the one which you last selected before switching off the ignition.

  • Page 16: Memory

    Note Memory All information in the memory 1 and 2 is erased if the battery of the vehicle is dis- Fig. 5 connected.  Multi-functional indicator Operation Fig. 6 Multi-functional indicator: Con- trol elements ä First read and observe the introductory information and safety warn- ings on page 14.

  • Page 17: Outside Temperature

    The current fuel consumption level is shown in the display in litres/100 km . With Outside temperature this information your style of driving can be adapted to the desired fuel consump- tion. ä First read and observe the introductory information and safety warn- ings on page 14.

  • Page 18: Distance Travelled

    The fuel consumption for the last 50 km is taken as a basis for calculating the The current speed which is identical to the display of the speedometer range. The range will be increase if you drive in a more economical manner. »...

  • Page 19: Maxi Dot (Information Display)

    › Pressing the button deletes the speed limit. WARNING › By pressing the button activates the ability to change the speed limit. Concentrate fully at all times on your driving! As the driver you are fully re- If the set speed limit is exceeded, an acoustic signal will sound as a warning. At sponsible for road safety.
  • Page 20 Time Note The time, time format (12 or 24 hour indicator) and the changeover between sum- mer/winter time can be set here. If warning messages are shown in the information display, these messages can ■ be confirmed with the button »...

  • Page 21: Auto Check Control

    Auto Check Control Yellow symbols A yellow symbol signals a warning. Car state Check the relevant function as soon as possible. The Auto Check Control checks the status of certain functions and vehicle compo- The meaning of the yellow symbols: nents.
  • Page 22   Electrohydraulic power steering » page 22 Speed regulating system » page 27   EPC fault light (petrol engine) » page 23 Airbag system » page 27   Glow plug system (diesel engine) » page 23 Diesel particle filter (diesel engine) »...

  • Page 23: Electrohydraulic Power Steering

    WARNING Main beam  If you have to stop for technical reasons, then park the vehicle at a safe dis- The indicator light comes on when the main beam or headlight flasher are se-  tance from the traffic, switch off the engine and activate the hazard warning lected »...
  • Page 24 In this case, switch off the engine, check the coolant level and top up the cool- fault light (petrol engine)  ant, if necessary. (Electronic Power Control) warning light comes on for a few seconds when Do not continue your journey if for some reason it is not possible to top up the ...

  • Page 25: Engine Oil

    The warning light flashes yellow (engine oil level sensor faulty)  Note A fault on the engine oil level sensor is indicated additionally by an audible signal and the warning light coming on several times after the ignition has been switch- The Text in the information display goes out only after refuelling and driving a ed on.
  • Page 26 Error: traction control (ASR) Exhaust inspection system  The fact that the TCS system operates together with the ABS means that the TCS The warning light comes on after the ignition has been switched on. warning light will also come on if the ABS system is not operating properly. ...
  • Page 27 If the indicator light comes on immediately after starting the engine, the ESC  WARNING can be switched off for technical reasons. In this case, the ESC can be switched on again by switching the ignition on and off. If the indicator light goes out, the If you have to stop for technical reasons, then park the vehicle at a safe dis- ■...
  • Page 28 The functionality of the airbag system is also monitored electronically when one WARNING airbag has been switched off. If you have to stop for technical reasons, then park the vehicle at a safe dis- ■ If a front, side or head airbag or belt tensioner has been switched off using the tance from the traffic, switch off the engine and activate the hazard warning vehicle system tester: light system...
  • Page 29 If the filter is not properly cleaned, the warning light does not go out and the If the seat belt is not fastened by the driver during the next 90 seconds, the  warning light begins to flash. The following appears in the information display warning signal is deactivated and the warning light lights up permanently.

  • Page 30: Unlocking And Locking

    CAUTION Unlocking and locking Each key contains electronic components; therefore it must be protected ■ against moisture and severe shocks. Vehicle key Keep the groove of the keys completely clean as impurities (textile fibres, dust, ■ etc.) have a negative effect on the functionality of the locking cylinder and igni- tion lock.

  • Page 31: Central Locking System

    CAUTION Locking/unlocking Pay attention to the correct polarity when changing the battery. ■ Valid for vehicles without a central locking system: The replacement battery must have the same specification as the original bat- ■ tery. Locking from the outside The securing knob will move upwards or downwards in the door when unlocking or locking.

  • Page 32: Individual Settings

    If the indicator light first of all flashes fast for about 2 seconds, afterwards lights Safe securing system up for about 30 seconds without interruption and then flashes slowly, there is a fault in the system of the central locking or in the interior monitor and in the tow- The central locking system is equipped with a safe securing system.
  • Page 33 › The safe securing system is immediately activated. Unlocking the vehicle using the key › The indicator light in the driver door begins flashing. Note Fig. 11 Turning the key for unlocking If the driver's door has been opened, the vehicle cannot be locked. ...

  • Page 34: Remote Control

    WARNING Remote control The central locking system also operates if the ignition is switched off. Chil- Introductory information dren should never be left unattended in the vehicle since it is difficult to pro- vide assistance from the outside when the doors are locked. Locked doors make it difficult for rescuers to get into the vehicle in an emergency - hazard! You can use the remote control key: ›...

  • Page 35: Anti-Theft Alarm System

    WARNING Unlocking and locking car If the car is locked from the outside and the safe securing system is activated, Fig. 14 there must not be any person in the car as it is then not possible to open ei- ther a door or a window from the inside.

  • Page 36: Interior Monitor And Towing Protection Monitoring

    How is the alarm system deactivated? Interior monitor and towing protection monitoring The anti-theft alarm system is deactivated if the vehicle is unlocked by only using the radio remote control. The anti-theft alarm system is reactivated if the vehicle is not opened within 30 seconds after transmitting the radio signal. Fig.

  • Page 37: Boot Lid

    Boot lid Boot lid ä Introduction This chapter contains information on the following subjects: Boot lid Emergency unlocking of the boot lid WARNING Ensure that the lock is properly engaged after closing the boot lid. Other- ■ wise, the boot lid might open suddenly when driving even if the boot lid lock Fig.

  • Page 38: Electric Power Windows

    WARNING Emergency unlocking of the boot lid If the vehicle is locked from the outside, do not leave anybody in the vehicle ■ Fig. 17 as it is not possible to open the windows from the inside in the event of an emergency.

  • Page 39: Buttons In The Driver's Door And The Rear Doors

    Safety pushbutton Buttons in the driver's door and the rear doors The buttons for power windows in the rear doors can be deactivated by pressing the safety pushbutton » Fig. 18. The buttons for the power windows in rear doors are activated again by pressing the safety pushbutton again.

  • Page 40: Panorama Roof

    Closing a window Panorama roof › by holding the key in the driver's lock in the lock position. › by holding the pressed locking button on the remote control key.  Fig. 19 You can interrupt the opening or closing process for the windows immediately by Panorama roof: Open sun screen releasing the key or the lock button.

  • Page 41: Lights And Visibility

    Note Lights and Visibility If the light switch is in the position , the ignition key is removed and the driv- ■ er's door is open, an acoustic warning signal will sound. The acoustic warning sig- Lights nal is switched off by means of the door contact when the driver's door is closed (ignition off), however, the side lights remain on to illuminate the parked vehicle if necessary.

  • Page 42: Day Light Function (Daylight Driving Light)

    DAY LIGHT function (Daylight driving light) Halogen projector headlights with cornering light function ä ä First read and observe the introductory information and safety warn- First read and observe the introductory information and safety warn- ings on page 40. ings on page 40.

  • Page 43: Tourist Light

    Note Tourist light When the “tourist light” mode is active, the warning light flashes for 10 sec-  ä First read and observe the introductory information and safety warn- onds each time the ignition is switched on.  ings on page 40. Halogen projector headlights with cornering light function Fog lights This mode makes it possible to drive in countries with opposing traffic system,...

  • Page 44: Rear Fog Light

    The fog lights with the function CORNER are adjusted according to the steering Headlamp beam adjustment  angle or after switching on the turn signal light in the following circumstances: › the vehicle is stationary and the engine is running or it moves with a speed of maximum 40 km/h;...

  • Page 45: Switches For The Hazard Warning Light System

    Switches for the hazard warning light system Turn signal and main beam lever Fig. 23 Fig. 24 Dash panel: Switch for hazard Turn signal and main beam lever warning lights ä ä First read and observe the introductory information and safety warn- First read and observe the introductory information and safety warn- ings on page 40.

  • Page 46: Interior Light

    A time delay switch causes the inner lighting on vehicles without a central locking Note system stays on for a few seconds after the doors have been closed. The inner light goes out out immediately after the ignition is switched on. The turn signal system only operates when the ignition is switched on.

  • Page 47: Visibility

    Visibility Sun visors Rear window heater Fig. 28 Sun visor: swivelling out Fig. 27 Switch for rear window heater The sun visor for the driver or front passenger can be pulled out of the fixture and swivelled towards the door in the direction of the arrow »...
  • Page 48 The rear window is wiped once if the windscreen wipers are on when reverse Activating the windscreen wipers and washers gear is selected. Top up with windscreen wiper fluid » page 146. Fig. 29 Windshield wiper lever WARNING Properly maintained windscreen wiper blades are essential for clear visibility ■...
  • Page 49 › ä Release the lever. The washer system stops and the wiper continues for anoth- First read and observe the introductory information and safety warn- er 1 to 3 wiper strokes (depending on the duration of the spraying process). The ings on page 46.

  • Page 50: Rear Window

    › With the other hand unlock the locking button in the direction of arrow and Adjusting the left-hand exterior mirror › remove the wiper blade. Place the rotary knob into the position . The movement of the mirror surface is identical to the movement of the rotary knob.

  • Page 51: Seats And Stowage

    WARNING (Continued) Seats and Stowage Always keep your feet in the footwell when the car is being driven - never ■ place your feet on the instrument panel, out of the window or on the surfaces Front seats of the seats. This is particularly important for the front seat passenger. You will be exposed to increased risk of injury if it becomes necessary to apply the brake or in the event of an accident.

  • Page 52: Head Restraints

    Adjusting height of seat CAUTION › To lift the seat, pull or pump the lever » Fig. 33 upwards. › To lower the seat, push or pump the lever downwards. Do not kneel on the seats or otherwise apply pressure at specific points to ■...

  • Page 53: Rear Seats

    › Press the locking button in direction of the arrow » Fig. 35 -  and pull the WARNING head restraint out. › To re-insert the head restraint, push it far enough down into the seat backrest The following guidelines must be observed »...
  • Page 54 Folding the seat backrest forwards Unlocking and removing seats › Put the belt tongue into the opening on the respective side of the vehicle - safety position. › Remove the head restraint from the rear middle seat » page 51, Head re- straints.

  • Page 55: Luggage Compartment

    WARNING Adjusting seats in crosswise direction The belt locks must be in their original position after folding back the seat ■ Fig. 40 cushions and backrests - they must be ready to use. The seat backrests must be securely interlocked in position so that no ob- Locking seats ■...

  • Page 56: Fastening Elements

    Example: In the event of a frontal collision at a speed of 50 km/h, an unsecured CAUTION object with a weight of 4.5 kg produces an energy, which corresponds to 20 times its own weight. This means that it results in a weight of approx. 90 kg “ ”. You can Please ensure that the heating elements for the rear window heater are not dam- imagine the injuries that can occur, if this “object”...

  • Page 57: Folding Hooks

    Fixing examples of the fixing net as a double horizontal pocket, floor fixing Folding hooks » Fig. 44 -  and double vertical pockets » Fig. 44 - . WARNING Fig. 43 Luggage compartment: folding The permissible load of the side nets is 1.5 kg. Heavy objects are not secured hooks sufficiently - risk of injury and net damage! CAUTION...

  • Page 58: Net Partition

    › Unhook the support straps » Fig. Net partition › Fold the luggage compartment cover forwards a little. › Remove the cover from the holders by pulling towards the rear, or by lightly knocking on the underside of the cover in the area between the holders. ›...

  • Page 59: Variable Loading Floor In The Luggage Compartment

    › Attach the bag with the aid of the plastic carabines to the eyes on the left and Dividing the luggage compartment with variable loading floor right luggage compartment trim panel. Installing and removing the net partition behind the rear seats is carried out anal- Fig.
  • Page 60 › Fold out the variable loading floor. WARNING › Lock the variable loading floor by turning the locking bolts » Fig. 48 to the right by around 180°. Ensure that the carrier rails and variable loading floor are correctly fastened ›...

  • Page 61: Bicycle Carrier In The Luggage Compartment

    › Place the cross member with the fixed part onto the right lashing eye and Bicycle carrier in the luggage compartment then place it on the left lashing eye with the removable part of the cross mem- › ä Press the holders until they latch.

  • Page 62: Roof Rack System

    Put bicycle into the bicycle carrier Secure the stability of the bicycles with a belt Fig. 53 Put in the bicycle/example fastening the front wheel Fig. 54 Securing bicycles ä ä First read and observe the introductory information and safety warn- First read and observe the introductory information and safety warn- ings on page 60.

  • Page 63: Cup Holders

    WARNING Cup holders The items which you transport on the roof bar system must be reliably at- ■ tached - risk of accident! Always secure the load with appropriate and undamaged lashing straps or ■ tensioning straps. Distribute the load evenly over the roof rack system. ■...

  • Page 64: Ashtray

    Ashtray Cigarette lighter, 12-volt power socket Cigarette lighter Fig. 57 Centre console: Cigarette lighter Fig. 56 Centre console: Ashtray at the front/rear Removing ashtray Operating the cigarette lighter › Pull out the ashtray » Fig. 56 upwards. › Press in the button of the cigarette lighter »...

  • Page 65: Storage Compartments

    Only use matching plugs to avoid damaging the 12-volt power socket. ■ 12-volt power socket Only use accessories that have been tested for electromagnetic compatibility in ■ accordance with the applicable directives. Before turning the ignition on or off, and before starting the car, switch off the Fig.
  • Page 66 Opening the air inlet when the air conditioning system is on causes fresh or inte- Storage compartments on the front passenger side rior air to flow into the storage compartment. We recommend closing the air supply if it is operated in heating mode or the cool- Fig.
  • Page 67 CAUTION CAUTION Do not put any heat-sensitive objects in the glasses storage box - they may be The storage compartment is designed for storing small objects of up to 1 kg. in damaged. weight in total.   Stowage compartment in centre console Front armrest with storage compartment Fig.
  • Page 68 Folding table on the medium seat rest Storage compartment in the front doors Fig. 66 Fig. 67 Rear seats: Armrest Stowage compartment in door panel A bottle holder is located in the area » Fig. 67 of the storage compartment for The medium seat rest can be used after folding the »...

  • Page 69: Clothes Hooks

    CAUTION Clothes hooks The storage compartments are designed for storing small objects of up to 1.5 kg. The clothes hooks are located on the handle of the headliner above each of the in weight in total.  rear doors. WARNING Flexible storage compartment Ensure that any clothes hanging from the hooks do not impair your vision to ■...

  • Page 70: Heating And Air Conditioning System

    Note Heating and air conditioning system The used air streams out through the air removal openings in the luggage com- ■ partment. Heating and air conditioning system We recommend that you do not smoke in the vehicle when the recirculating air ■...

  • Page 71: Air Outlet Vents

    If you cannot rectify the functional fault yourself, or the cooling capacity decrea- Heating ses, the cooling system must be switched off. Visit a specialist garage.  Using the system Air outlet vents Fig. 72 Heating: Control elements Fig. 71 Air outlet vents Setting temperature ›...
  • Page 72 Note If the air distribution is positioned towards the windows, the total amount of air is used to defrost the windows and thus no air will be fed to the footwell. This can lead to restriction of the heating comfort. ...

  • Page 73: Air Conditioning System (Manual Air Conditioning System)

    WARNING Using the system Do not leave recirculated air mode on over a longer period of time, as “stale” air can cause fatigue of the driver and passengers, reduce attention levels and also cause the windows to mist up. The risk of having an accident increases. Switch off recirculated air mode as soon as the windows start to mist up.
  • Page 74 Note The whole heat output will be needed to defrost the windshield and side win- ■ dows. No warm air will be fed to the footwell. This can lead to restriction of the heating comfort. The warning light in the button lights after activation, even if not all of the ■...
  • Page 75 Setting the air conditioning system Recommended basic settings of the control elements of the air conditioning sys- tem for the respective operating modes: Setting of the control dial Button Set-up Air outlet vents 4 Defrost windscreen and side Desired tempera- Automatically switched Open and align with the side ...

  • Page 76: Climatronic (Automatic Air Conditioning System)

    WARNING Overview of the control elements Do not leave recirculated air mode on over a longer period of time, as “stale” air can cause fatigue of the driver and passengers, reduce attention levels and also cause the windows to mist up. The risk of having an accident increases. Switch off recirculated air mode as soon as the windows start to mist up.

  • Page 77: Automatic Mode

    Recirculated air mode Recirculated air mode Air conditioning system switched on Recirculated air mode prevents polluted air outside the vehicle from getting into Note the vehicle, for example when driving through a tunnel or when standing in a traffic jam. The interior temperature sensor »...
  • Page 78 WARNING “Stale air” may result in fatigue in the driver and occupants, reduce attention ■ levels and also cause the windows to mist up. The risk of having an accident increases. Do not switch off the Climatronic system for longer than necessary. ■...

  • Page 79: Starting-Off And Driving

    WARNING (Continued) Starting-off and Driving Only pull the ignition key from the ignition lock when the vehicle has come ■ to a complete stop (by applying the handbrake). Otherwise the steering wheel Starting and stopping the engine could block - risk of accident! When leaving the vehicle, the ignition must always be removed.

  • Page 80: Electronic Immobiliser

    › Adjust the steering wheel to the desired position (with regard to the height and For the sake of the environment forward/back position). › Push the lever upwards to the stop. Do not warm up the engine while the vehicle is stationary. If possible, start your ...

  • Page 81: Brakes And Brake Assist Systems

    Vehicles with a diesel engine are equipped with a glow plug system. The pre- Ignition lock glow indicator light comes on after the ignition has been switched on. The en-  gine should be started immediately after the preglow indicator light goes out. Fig.
  • Page 82 WARNING Note The brake booster only operates when the engine is running. Greater physi- If the brakes are applied in full and the control unit for the braking system con- ■ ■ cal effort for braking is required when the engine is switched off - risk of acci- siders the situation to be dangerous for the following traffic, the brake light dent! flashes automatically.
  • Page 83 Faults in the brake surface Release parking brake! If it is found that the braking distance has suddenly become longer and that the The handbrake warning is activated if the vehicle is driven at a speed of more brake pedal can be depressed further, the brake system may be faulty. Visit a than 6 km/h for more than 3 seconds.
  • Page 84 ä The brake assist function is automatically switched off when the brake pedal is First read and observe the introductory information and safety warn- released. ings on page 80. Uphill start assist system The TCS is automatically activated after starting the engine. If the wheels are The uphill start assist makes it easier to start off on steep hills.

  • Page 85: Shifting (Manual Gearbox)

    Only use footmats from the range of ŠKODA Original Accessories, which are fitted Shifting (manual gearbox) to two attachment points. WARNING Fig. 79 Shift pattern of the 5-speed No objects are allowed in the driver's footwell – risk of obstruction or limita- manual gearbox tion in operating the pedal! ...

  • Page 86: Cruise Control System (Ccs)

    Activating/deactivating the parking aid The cruise control system (CCS) maintains a constant speed, more than 30 km/h The parking aid is activated automatically when reverse gear is engaged and the (20 mph), once it has been set, without you having to depress the accelerator ignition is turned on.
  • Page 87 Decreasing the speed Storing a speed › The stored speed can be reduced by pressing the rocker button » Fig. 81 into the position SET. › The speed will decrease continuously, if the rocker button is pressed and held Fig. 81 in the SET position.

  • Page 88: Start/Stop

    Conditions for the automatic engine shut down (stop phase) START/STOP › The gearshift lever is in Neutral. › The clutch pedal is not depressed. › The driver has fastened the seat belt. Fig. 82 › The driver's door is closed. Centre console: Button for the ›...
  • Page 89 Messages in the instrument cluster display (valid for vehicles without Information display) ERROR START STOP Error in the START-STOP system START STOP NOT POSSIBLE Automatic engine shut down is not possible. START STOP ACTIVE Automatic engine shut down (stop phase) SWITCH OFF IGNITION Switch off the ignition.

  • Page 90: Automatic Gearbox

    WARNING (Continued) Automatic gearbox If stopping on a hill (downhill gradient), never try to maintain the vehicle sta- ■ tionary with the gear engaged by means of the “accelerator pedal”, i.e. by let- Automatic gearbox ting the clutch slip. This can lead to overheating of the clutch. If there is a risk of overheating of the clutch due to overload, the clutch is opened automati- cally and the vehicle rolls backward - risk of accident! ä...

  • Page 91: Starting-Off And Driving

    When parking on a level road surface, it suffices to engage selector lever position Selector lever positions P. When parking on a slope, the handbrake should be applied firmly before the park position is selected. This ensures that there is no excessive pressure on the lock mechanism and that it is subsequently easier to move the selector lever out of position P.

  • Page 92: Manual Shifting Of Gears (Tiptronic)

    ä - Neutral First read and observe the introductory information and safety warn- The transmission is in Neutral in this position. ings on page 89. The brake pedal must be depressed to move the selector lever out of the position Tiptronic mode makes it possible to manually shift gears on the selector lever.

  • Page 93: Kickdown Function

    The selector lever lock is only active if the vehicle is stationary or moving at speed When adopting a sporty style of driving with rapid movements of the accelerator of less than 5 km/hour. The lock is switched off automatically into position N pedal combined with sharp acceleration, frequent changes in speed and exploit- when the car is travelling at a higher speed.

  • Page 94: Selector Lever-Emergency Unlocking

    Selector lever-emergency unlocking Fig. 85 Selector lever-emergency un- locking ä First read and observe the introductory information and safety warn- ings on page 89. In case of interruption of the power supply (e.g. flat vehicle battery, defective fuse) or defect of the selector lever lock, the selector lever can no longer be shif- ted from the position P in the normal way and the vehicle can no longer be moved.

  • Page 95: Communication

    Note Communication We recommend that the installation of mobile phones and two-way radio sys- ■ tems in a vehicle is only carried out by a ŠKODA Service Partner. Mobile phones and two-way radio systems ® Not all mobile phones that enable Bluetooth communication are compatible ■...
  • Page 96 The update is interrupted if a telephone event (e.g. incoming or outgoing call, Phone Phonebook voice control dialogue) occurs during the updating procedure. After the telephone event has ended, the updating starts anew. A phone phonebook is part of the hands-free system. This phone phonebook can be used depending on the type of mobile phone.
  • Page 97 Inserting the mobile phone and adapter Managing telephone calls with the help of the adapter Fig. 87 Universal telephone preinstalla- tion Only one telephone mount is factory-fitted. An adapter for the mobile phone can Fig. 88 Principle sketch: Adapter with one button/adapter with two but- be purchased from ŠKODA Original Accessories.
  • Page 98 › If the hands-free system announces (as standard SKODA_BT) on the display of Solving connection problems the mobile phone, enter the PIN within 30 seconds and wait, until the connec- If the system announces No paired phone found, check the operating state of the tion is established mobile phone.

  • Page 99: Voice Control

    Search ■ Phone book ■ Phone name - the possibility to change the name of the telephone unit (pre-set ■ ■ Dial number SKODA UHV) Call register ■ Settings Voice mailbox ■ ■ Bluetooth The following menu points can be selected in the menu Settings.
  • Page 100 The microphone for voice control is inserted in the moulded headliner and direc- Voice commands ted to the driver and front passenger. Therefore the driver and the front passen- ger can operate the equipment. Basic voice commands Entering the phone number Voice command Action The telephone number can be entered as a continuous series of individually spo-...

  • Page 101: Multimedia

    The music playback process is performed on the connected device. Multimedia The universal telephone preinstallation GSM II ensures that the music played back via the hands-free system can be controlled with the remote control » page ® Music playback via Bluetooth Voice commands.
  • Page 102 Button Action Radio, traffic information CD/MP3/Navigation Press button for a Interruption of the traffic report Fast forward long period of time Changing to the previously stored radio station Press briefly Changing to the previously stored traffic information Changing to the previous title Interrupting the traffic report Press button for a Interruption of the traffic report...

  • Page 103: Safety

    › belt tensioners for front seats; Safety › seat belt height adjusters for front seats; › Front airbag for the driver and the front seat passenger; › side airbags; › Passive Safety head airbags; › anchoring points for child seat using the ISOFIX system; ›...

  • Page 104: Correct Seated Position

    WARNING (Continued) What influences the driving safety? If the occupant adopts an incorrect seated position, he is exposed to life- ■ ä First read and observe the introductory information and safety warn- threatening injuries, in case he is hit by a deployed airbag. ings on page 102.
  • Page 105 For the safety of the front passenger and to reduce the risk of injury in the event Correct seated position for the driver of an accident, we recommend the following setting. › Position the front passenger seat back as far as possible. The front passenger must maintain a distance of at least 25 cm to the dash panel so that the airbag offers the greatest possible safety if it is deployed.
  • Page 106 The following list contains examples of which seated positions can cause serious injuries or death. This list is not complete, however we would like you to familiar- ise yourself with this subject. Therefore, while the car is moving never: › stand up in the vehicle;...

  • Page 107: Seat Belts

    Particular safety aspects must be observed when transporting children in the ve- Seat belts hicle » page 118, Transporting children safely. WARNING Seat belts Fasten your seat belt before each journey - even when driving in town! This ■ also applies to the people seated at the rear - risk of injury! ä...

  • Page 108: The Physical Principle Of A Frontal Collision

    As soon as the vehicle is moving, so-called kinetic energy (the energy of motion) WARNING (Continued) is produced both in terms of the car as well as in terms of the occupants. The The seat belts for the rear seats can only fulfil their function reliably when magnitude of this kinetic energy depends essentially on the speed at which the ■...

  • Page 109: Fastening And Unfastening Seat Belts

    It is important that the belt webbing is properly routed to ensure seat belts offer Fastening and unfastening seat belts the maximum protection. The shoulder part of the seat belt must never run across the neck but must roughly run over the middle of the shoulder and fit snugly against the chest.

  • Page 110: Seat Belt Height Adjuster On The Front Seats

    The belt tongues for the rear middle seat are shaped differently so that they only Seat belt height adjuster on the front seats fit into the correct belt buckle. If you are not able to insert a lock tongue into the wrong belt lock you probably tried to put it into the wrong buckle.
  • Page 111 Note Smoke is generated when the belt tensioners are deployed. This is not an indi- ■ cation of a fire in the vehicle. When disposing of the vehicle or parts of the belt tensioner system, it is impor- ■ tant to comply with national legal requirements. ŠKODA Service Partners are fa- miliar with these regulations and will be able to provide you with detailed infor- mation.

  • Page 112: Airbag System

    WARNING Airbag system The airbag is not a substitute for the seat belt, but instead forms part of the ■ complete passive vehicle safety concept. Please note that an airbag can only Description of the airbag system offer you optimal protection in combination with a seat belt which is fas- tened.

  • Page 113: Front Airbags

    Deployment factors Front airbags It is not possible to generally determine which deployment conditions apply to the airbag system in every situation. An important role is played by factors such as the type of object that the vehicle hits (hard, soft), the impact angle, vehicle ä...

  • Page 114: Side Airbags

    WARNING (Continued) Note is a risk of the child suffering severe or even fatal injuries if the front passen- The dash panel must be replaced after the front passenger airbag has been de- ger airbag is deployed. When transporting a child on the front passenger seat, ployed.
  • Page 115 WARNING WARNING (Continued) Any seat or protective covers which you fit to the driver or front passenger ■ Your head should never be positioned in the deployment area of the side ■ seats must only be of the type expressly authorized by ŠKODA. In view of the airbag.

  • Page 116: Head Airbags

    WARNING Function of the side airbags There must not be any objects in the deployment area of the head airbags ■ Fig. 100 which might prevent the airbags from inflating properly. Only hang light items of clothing on the hooks fitted in the vehicle. Never Inflated side airbag ■...

  • Page 117: Deactivating Airbags

    When deployed, the airbags cover the entire area of the side window and door Description of the head airbags pillar » Fig. 102. Any impact of the head against parts of the interior or objects outside of the car, Fig. 101 is cushioned by the inflated head airbag.
  • Page 118 Indicator light in the display    (front passenger airbag   Note switched off) In cases where the front passenger airbag is switched off the airbag indicator The national regulations for switching off airbags must be observed. ■ light comes on for a few seconds after switching on the ignition, goes out for A ŠKODA Service Partner will be able to inform you which airbags in your vehicle ■...

  • Page 119: Transporting Children Safely

    WARNING (Continued) Transporting children safely Under no circumstances allow children to be transported without the use of ■ a suitable restraint system. In the event of an accident the child will be Child seat thrown through the vehicle and may as a result suffer fatal injuries, and also injure other occupants.
  • Page 120 WARNING (Continued) Use of child safety seats on the front passenger seat This is also clearly stated on the sticker which is located on the B column on ■ the front passenger side » Fig. 104. The sticker is visible upon opening the Fig.
  • Page 121 Classification of child seats Child seats with the ISOFIX system ä First read and observe the introductory information and safety warn- Fig. 106 ings on page 118. Rear seat: ISOFIX Child safety seats are classified in 5 groups: Group Weight of the child Approximate age 0-10 kg up to 9 months...
  • Page 122 Child seat with the TOP TETHER system Fig. 107 Rear seat: TOP TETHER ä First read and observe the introductory information and safety warn- ings on page 118. There are fixing eyes on the rear side of the rear seat backrests for attaching the fixing belt for a child seat with the TOP TETHER system »...

  • Page 123: Driving Tips

    CAUTION Driving Tips All the speed and engine revolution figures apply only when the engine is at its normal operating temperature. Never rev up a cold engine when the vehicle is Driving and the Environment stationary or when driving in individual gears. For the sake of the environment The first 1 500 kilometres and then afterwards Not driving at unnecessarily high engine revolutions and shifting to a higher gear...

  • Page 124: Economical And Environmentally Friendly Driving

    The optimal engine speed should be obtained when accelerating, in order to WARNING avoid a high fuel consumption and resonance of the vehicle.  In view of the high temperatures which can be produced in the catalytic con- ■ verter, the vehicle should be parked in such a way that the catalytic converter Looking ahead when driving cannot come into contact with easily flammable materials under the vehicle - risk of fire!
  • Page 125 If an engine is only idling it takes much longer for it to reach its normal operating Note temperature. Wear-and-tear and pollutant emissions, though, are particularly high in the warming-up phase. Therefore, start driving as soon as the engine has Observe the recommended gear »...

  • Page 126: Environmental Compatibility

    It is particularly in town traffic, when one is accelerating quite often, that the ve- Avoid short distances hicle weight will have a significant effect upon the fuel consumption. A rule of thumb here is that an increase in weight of 100 kilograms will cause an increase in fuel consumption of about 1 litre/100 kilometres.

  • Page 127: Driving Abroad

    › The use of solvent-free adhesives. Headlights › No CFCs used in the production process. › Without use of mercury. The low beam of your headlights is set asymmetrically. It illuminates the side of › Use of water-soluble paints. the road on which the vehicle is being driven to a greater extent. Trade-in and recycling of old cars When driving in countries in which the traffic drives on the other side of the road ŠKODA meets the requirements of the brand and its products with regard to pro-...
  • Page 128 The following must be observed to avoid damage to the vehicle when driving through bodies of water (e.g. flooded roads): › Therefore determine the depth of the water before driving through bodies of water. The water level must fit around the strut on the side member as a maxi- »...

  • Page 129: Towing A Trailer

    Tyre pressure Towing a trailer Correct the tyre inflation pressure on your vehicle for a “full load” » page 152, Service life of tyres. Trailer load Towing a trailer The permissible trailer load must not be exceeded under any circumstan- »...
  • Page 130 Immediately reduce your speed as soon as even the slightest swaying of the trail- WARNING er is detected. Never attempt to stop the trailer from “swaying” by accelerating. Adapt your speed to the conditions of the road surface and to the traffic sit- Brakes uation.

  • Page 131: General Maintenance

    WARNING General Maintenance Care products may be harmful to your health if not used according to the in- ■ structions. Taking care of and cleaning the vehicle Always store care products in a safe place, out of the reach of children - risk ■...

  • Page 132: Washing The Vehicle

    If your vehicle is fitted with any particular attached parts, such as a spoiler, roof Note luggage rack, two-way radio aerial - it is best to consult the operator of the car wash system beforehand. Remove fresh stains such as those from ball-point pens, ink, lipstick, shoe pol- ■...

  • Page 133: Preserving And Polishing The Vehicle Paintwork

    First clean the chrome parts with a damp cloth and then polish them with a soft, CAUTION dry cloth. If this method does not completely clean chrome parts, use a specific chrome care product. The temperature of the water used for cleaning must not exceed 60 °C - risk of damaging the vehicle.

  • Page 134: De-Icing Windows And Exterior Mirrors

    CAUTION De-icing windows and exterior mirrors Never wipe the headlights dry and do not use any sharp objects to clean the ä ■ First read and observe the introductory information and safety warn- plastic lenses, this may damage the protective paintwork and consequently cause ings on page 130.

  • Page 135: Wheels

    As damage to the protective layer when driving cannot be ruled out completely, Wheels we recommend that you inspect and touch up any damaged areas of the protec- tive layer on the underside of your vehicle and on the chassis at certain intervals - ä...

  • Page 136: Artificial Leather And Materials

    Dry off the leather with a soft, dry cloth. Artificial leather and materials Removing stains ä First read and observe the introductory information and safety warn- Remove fresh stains which are water-based (e.g. coffee, tea, juices, blood, etc.) ings on page 130. with an absorbent cloth or household paper or use a suitable cleaner for a stain which has already dried in.

  • Page 137: Seat Belts

    Seat belts ä First read and observe the introductory information and safety warn- ings on page 130. Keep the seat belts clean! Clean dirty seat belts using a mild soapy solution and remove coarse dirt with a soft brush! Check the condition of all the seat belts on a regular basis. Belt webbing which has become severely soiled may prevent the inertia reel from reeling up the belt properly.

  • Page 138: Inspecting And Replenishing

    Refuelling Inspecting and replenishing Fuel ä Introduction This chapter contains information on the following subjects: Refuelling Unleaded petrol Diesel fuel Fig. 112 Right rear side of the vehicle: Fuel filler flap/fuel filler flap with cap The correct type of fuel for your vehicle and the tyre size and inflation pressure unscrewed are specified on the inside of the fuel filler flap »...
  • Page 139 On vehicles using prescribed unleaded petrol of min. 95 RON, the use of petrol Note with a higher octane number than 95 RON can increase the power and reduce fuel consumption. The fuel tank has a capacity of about 55 litres, containing a reserve of approx. 7 litres.

  • Page 140: Engine Compartment

    Engine compartment Diesel fuel ä First read and observe the introductory information and safety warn- ä Introduction ings on page 137. This chapter contains information on the following subjects: Your vehicle can only be operated with diesel fuel, which complies with the standard EN 590 (standard DIN 51628 in Germany, standard ÖNORM C 1590 in Opening and closing the bonnet Austria, GOST R 52368-2005/EN 590:2004 in Russia).
  • Page 141 WARNING (Continued) For the sake of the environment Firmly apply the handbrake. ■ In view of the environmentally friendly disposal of fluids, the specials tools and Allow the engine to cool. ■ knowledge required for such work, we recommend that fluids are changed by a Keep children clear of the engine compartment.

  • Page 142: Engine Compartment Overview

    Closing the bonnet Opening and closing the bonnet › Lift the bonnet slightly and unhook the bonnet support. Press the bonnet sup- port into the holder designed to hold it. › Let the bonnet drop into the lock carrier lock from a height of around 20 cm – do not push it in! ›...

  • Page 143: Checking The Engine Oil Level

    One should therefore check the oil level at regular intervals, preferably every time Checking the engine oil level after the fuel tank is filled or after driving for long stretches. We recommend maintaining the oil level within the range , but not above, if Fig.

  • Page 144: Changing Engine Oil

    Coolant capacity Changing engine oil Petrol engines Capacities (in litres) ä First read and observe the introductory information and safety warn- 1.2 l/51 kW ings on page 139. 1.2 ltr./63 kW TSI 1.2 ltr./77 kW TSI The engine oil must be changed at the intervals stated in the Service schedule or according to the service interval indicator »...

  • Page 145: Checking The Coolant Level

    Checking the coolant level Replenishing the coolant ä First read and observe the introductory information and safety warn- Fig. 117 ings on page 139. Engine compartment: Coolant › expansion reservoir Switch off the engine. › Allow the engine to cool. ›...

  • Page 146: Radiator Fan

    WARNING Radiator fan If the fluid level has dropped below the MIN marking, do not continue your ä First read and observe the introductory information and safety warn- journey - risk of accident! Get professional assistance.  ings on page 139. The radiator fan is driven by an electric motor and controlled according to the coolant temperature.

  • Page 147: Vehicle Battery

    Note Windshield washer system Do not remove the filter from the windshield washer fluid reservoir when replen- Fig. 119 ishing it with liquid otherwise the liquid transportation system can be contamina- ted, which can cause the windshield washer system to malfunction. Engine compartment: Wind- ...
  • Page 148 WARNING CAUTION The battery acid is strongly corrosive and must, therefore, be handled with The vehicle battery must only be disconnected if the ignition is switched off, ■ ■ the greatest of care. Always wear protective gloves, eye and skin protection otherwise the vehicle's electrical system (electronic components) can be dam- when handling the vehicle battery.

  • Page 149: Checking The Battery Electrolyte Level

    We recommend you have the electrolyte level checked by a specialist garage from Battery cover time to time, especially in the following cases. › High outside temperatures. › Long daily drives › After each charge » page 149, Charging a vehicle battery. On vehicles with a vehicle battery fitted with a colour indicator, the so-called magic eye »...

  • Page 150: Charging A Vehicle Battery

    Charging a vehicle battery Disconnecting and reconnecting the vehicle battery ä ä First read and observe the introductory information and safety warn- First read and observe the introductory information and safety warn- ings on page 146. ings on page 146. A properly charged vehicle battery is essential for reliably starting the engine.

  • Page 151: Automatic Load Deactivation

    Automatic load deactivation ä First read and observe the introductory information and safety warn- ings on page 146. An intelligent vehicle power management system automatically takes various measures at high loads on the vehicle battery to prevent discharging of the bat- tery: This manifests itself by the following.

  • Page 152: Wheels And Tyres

    WARNING (Continued) Wheels and Tyres Do not, where possible, replace individual tyres but at least replace them on ■ both wheels of a given axle at the same time. Always fit the tyres with the Wheels deeper tread depth to the front wheels. Never use tyres if you do not know anything about the condition and age.

  • Page 153: Service Life Of Tyres

    The tyres of the tyre size 185/55 R15, which are intended to be used with snow Service life of tyres chains and are fitted on models Roomster Scout, have the following inflation pressure values in kPa. Engine Half payload Full payload 1.2/63 kW TSI...

  • Page 154: Handling Wheels And Tyres

    Proper knowledge of the tyre data makes it easier for you to select the correct Handling wheels and tyres type of tyre. Tyres, for example, have the following inscription on their walls. 185/65 R 14 86 T Fig. 123 What this means is: Changing wheels around Tyre width in mm Height/width ratio in %...

  • Page 155: Unidirectional Tyres

    If the dimensions or design of the spare wheel differ from the tyres fitted to the Unidirectional tyres vehicle (e.g. winter tyres or low-profile tyres), it must only be used briefly in the event of a puncture and if an appropriately cautious style of driving is adop- ä...

  • Page 156: Full Wheel Trim

    ä First read and observe the introductory information and safety warn- Full wheel trim ings on page 151. ä First read and observe the introductory information and safety warn- Pulling off ings on page 151. › Push the plastic clip sufficiently far onto the cap until the inner catches of the clip are positioned at the collar of the cap and detach the cap »...

  • Page 157: Tyre Control Display

    › Press and hold the button » Fig. 127 for longer than 2 seconds. While   Tyre control display pressing the button, the indicator light illuminates. At the same time the sys-  tem memory is erased and the new calibration is started, which is confirmed with an audible signal and then the warning light goes out.

  • Page 158: Wheel Bolts

    Snow chains must only be mounted on the front wheels. Wheel bolts When driving on wintry roads, snow chains improve not only traction, but also the ä First read and observe the introductory information and safety warn- braking performance. ings on page 151.

  • Page 159: Accessories, Changes And Replacement Of Parts

    WARNING Accessories, changes and replacement of Work or modifications on your vehicle, which have been carried out unpro- ■ parts fessionally, can cause operational faults - risk of accident! We advise you, in your own interest, to only use ŠKODA Original Accessories ■...

  • Page 160: Do-It-Yourself

    The fire extinguisher must be checked by an authorised person on an annual ba- Do-it-yourself sis (the national legal provisions must be observed). WARNING Do-it-yourself The fire extinguisher must always be secured safely so that they do not come loose when making an emergency braking or in a vehicle collision which could cause injuries to occupants.

  • Page 161: Changing A Wheel

    › Replacement bulb set; WARNING › Screwdriver. If you are in flowing traffic, switch on the hazard warning light system and ■ Before placing the lifting jack back into its storage area, screw in the arm of the set up the warning triangle at the prescribed distance! The national legal re- lifting jack fully.
  • Page 162 Note Preliminary work All bolts must be clean and must turn easily. ■ ä First read and observe the introductory information and safety warn- Under no circumstances grease or oil the wheel bolts! ■ ings on page 160. When fitting unidirectional tyres, ensure that the direction of rotation is cor- ■...
  • Page 163 undoing and tightening wheel bolts Raising the vehicle Fig. 130 Fig. 131 Changing a wheel: Loosening Changing a wheel: Jacking points the wheel bolts for positioning lifting jack ä First read and observe the introductory information and safety warn- ings on page 160.

  • Page 164: Breakdown Kit

    › Continue turning up the jack until the wheel is just about lifted off the ground.  Breakdown kit Securing wheels against theft ä Introduction This chapter contains information on the following subjects: Fig. 133 Principle sketch: Anti-theft Components of the breakdown kit wheel bolt with adapter Preparing to use the breakdown kit Seal and inflate tyres...
  • Page 165 The breakdown kit contains the following parts: WARNING (Continued) Valve remover Do not drive faster than 80 km/h (50 mph). ■ Sticker with speed designation “max. 80 km/h”/“max. 50 mph” Avoid accelerating at full throttle, sharp braking and fast cornering. ■...
  • Page 166 › Use the valve remover to unscrew the valve core and place it on a clean sur- Check the tyre inflation pressure after driving for 10 minutes » page 165. face (rag, paper, etc.).  WARNING During inflation, the tyre inflation hose and air compressor may get hot- risk ■...

  • Page 167: Jump-Starting

    WARNING (Continued) Jump-starting Keep any sources of ignition (naked flame, smouldering cigarettes, etc.) ■ away from the battery - risk of an explosion! ä Introduction Never jump-start vehicle batteries with an electrolyte level that is too low - ■ risk of explosion and caustic burns. This chapter contains information on the following subjects: Jump-starting Note...

  • Page 168: Towing The Vehicle

    › Attach the other end to a solid metal part which is connected firmly to the Vehicles with automatic transmission can be towed in with a tow bar or a tow engine block, or to the engine block itself. rope or with the front wheels raised. If the vehicle is raised at rear, the automatic gearbox is damaged! Starting engine ›...
  • Page 169 › One should be constantly vigilant not to allow impermissibly high towing forces Screw in the towing eye by hand to the left up to the stop » Fig. 137 - . For ■ or jerky loadings. There is always a risk of excessive stresses and damage result- tightening purposes, we recommend, for example, using the wheel wrench, ing at the points to which you attach the tow rope or tow bar when you attempt towing eye from another vehicle or a similar object that can be pushed through...

  • Page 170: Fuses And Light Bulbs

    CAUTION Fuses and light bulbs Never “repair” fuses and also do not replace them with a fuse of a higher am- ■ perage - risk of fire! This may also cause damage at another part of the electrical Fuses system. Have the electrical system checked as quickly as possible by a specialist garage ■...
  • Page 171 Power consumer Fuses in the dash panel Control unit for ABS, button for START STOP Petrol engine: Speed regulating system Fig. 139 Reversing light (manual gearbox) Underside of the dash panel: Distribution board cover. Ignition, engine control unit, automatic gearbox Brake pedal switch, clutch pedal switch Operating controls for the heating, control unit for air conditioning sys- tem, parking aid, control unit for cornering lights, radiator fan, washing...
  • Page 172 Power consumer Fuses in the engine compartment High pressure fuel pump, pressure valve Engine control unit Engine control unit, vacuum pump Power supply of ignition lock Main beam Rear fog light, DC/DC converter START-STOP Fog lights Air blower for heating 40-41 Not assigned Rear window heater...

  • Page 173: Bulbs

    ■ Fog lights and daylight driving lights Replacement bulbs can be purchased from ŠKODA Original Accessories. Fog lights - Roomster Scout We recommend that the headlight settings are checked by a Škoda Service ■ Changing the bulb for the licence plate light Partner after replacing a bulb in the main or low beam.
  • Page 174 Headlights Replacing a bulb for low beam and main beam (halogen headlights) Fig. 144 Removing bulbs for low and main beam Fig. 143 Bulb arrangement: Halogen headlights/halogen projector head- lights ä First read and observe the introductory information and safety warn- ings on page 172.
  • Page 175 › Remove the rubber cover » Fig. 143. Replacing the bulb for the low beam (Halogen projector › Turn the connector with the bulb in an anti-clockwise direction up to the stop headlights) and remove » Fig. 146. › Replace the lamp, insert the connector with the new bulb and turn in a clock- wise direction to the the stop.
  • Page 176 Fog lights and daylight driving lights Fog lights - Roomster Scout Fig. 148 Front bumper: Roomster Scout Fig. 147 Front bumper: Protective grille/removing the fog light ä First read and observe the introductory information and safety warn- ings on page 172.
  • Page 177 › Replace the bulb, insert the socket with the new bulb and turn in a clockwise direction up to the stop. › Insert the plug into the socket › Retighten the screws and insert the cap. The cap must engage firmly. ...

  • Page 178: Praktik

    Lashing eyes Praktik Fig. 154 Praktik Loading area: Lashing eyes Rear interior light Fig. 153 Interior light - Praktik Eyes are located on the sides of the loading area for lashing the load to be loa- » Fig. 154. WARNING The load to be transported must always be secured safely so that it does not come loose when making an emergency braking or in a vehicle collision which Switching the interior light on...

  • Page 179: Fixing Of The Loading Floor

    › Move the safety partition into the required position. Ensure it is always move Fixing of the loading floor the same distance- the same number of holes on both sides both upwards and downwards. › On each side in the upper area of the body, undo and remove a bolt and undo and remove a bolt in the lower area.

  • Page 180: Technical Data

    › Roof load including roof rack system; Technical data › Trailer drawbar load when towing a trailer (max. 50 kg). The following specifications are listed on the type plate » Fig. 159: Technical data Maximum permissible gross weight Maximum permissible towed weight (towing vehicle and trailer) Permissible front axle load Introductory information Permitted rear axle load...

  • Page 181: Fuel Consumption According To The Ece Standards And Eu Guidelines

    Partial vehicle description 7GG, 7MB, 7MG - vehicles with DPF » page 27, Diesel particle filter (diesel engine) Vehicle identification number (VIN) The vehicle identification number - VIN (vehicle body number) is stamped into the engine compartment on the right hand suspension strut dome. This number is al- so located on a sign on the lower left hand edge below the windshield (together with a VIN bar code).

  • Page 182: Dimensions

    Dimensions Dimensions (mm) ROOMSTER PRAKTIK SCOUT Length 4214 4213 4240 Width 1684 1684 1695 Width including exterior mirror 1882 1882 1882 Height 1607 1607 1650 Clearance Wheel base 2620 2620 2620 1436/1500 1436/1500 Track gauge front/rear 1427/1494 (1420/1484) (1420/1484) ...

  • Page 183: Specifications And Engine Oil Capacity

    If the oils specified above are not available, oils according to ACEA A2 or ACEA A3 Specifications and engine oil capacity can be used once for refilling. The engine has been factory-filled with a high-grade oil that can be use through- Diesel engines Specification Filling level...

  • Page 184: Engine 1.2 L/51 Kw - Eu5, Eu2 Ddk

    Engine 1.2 l/51 kW - EU5, EU2 DDK Output (kW per rpm) Max. torque (Nm at rpm) Number of cylinders/Displacement (cm 51/5400 112/3000 3/1198 Performances ROOMSTER PRAKTIK Top speed (km/h) Acceleration 0 - 100 km/h (s) 15.9 Fuel consumption (in l/100 km) and CO (in g/km) Intra-urban...

  • Page 185: 1.2 L/63 Kw Tsi Engine - Eu5

    Output (kW per rpm) Max. torque (Nm at rpm) Number of cylinders/Displacement (cm 63/4800 160/1500 - 3500 4/1197 Performances ROOMSTER PRAKTIK Top speed (km/h) Acceleration 0 - 100 km/h (s) 12.6 Fuel consumption (in l/100 km) and CO (in g/km)

  • Page 186: 1.2 L/77 Kw Tsi Engine - Eu5

    Output (kW per rpm) Max. torque (Nm at rpm) Number of cylinders/Displacement (cm 77/5000 175/1500 - 4100 4/1197 Performances ROOMSTER MG5 ROOMSTER DSG7 Top speed (km/h) Acceleration 0 - 100 km/h (s) 10.9 11.0 Fuel consumption (in l/100 km) and CO...

  • Page 187: 1.4 L/63 Kw Engine - Eu5

    1.4 l/63 kW Engine - EU5 Output (kW per rpm) Max. torque (Nm at rpm) Number of cylinders/Displacement (cm 63/5000 132/3800 4/1390 Performances ROOMSTER PRAKTIK Top speed (km/h) Acceleration 0 - 100 km/h (s) 13.0 Fuel consumption (in l/100 km) and CO (in g/km) Intra-urban...

  • Page 188: 1.6 L/77 Kw Engine - Eu4, Eu2 Ddk

    Output (kW per rpm) Max. torque (Nm at rpm) Number of cylinders/Displacement (cm 77/5600 153/3800 4/1598 Performances ROOMSTER MG5 ROOMSTER AG6 Top speed (km/h) Acceleration 0 - 100 km/h (s) 11.3 12.5 Fuel consumption (in l/100 km) and CO (in g/km) Intra-urban 10.2...

  • Page 189: 1.2 L/55 Kw Tdi Cr Engine - Eu5

    1.2 l/55 kW TDI CR engine - EU5 Output (kW per rpm) Max. torque (Nm at rpm) Number of cylinders/Displacement (cm 55/4200 180/2000 3/1199 ROOMSTER Performances ROOMSTER PRAKTIK GreenLine Top speed (km/h) Acceleration 0 - 100 km/h (s) 15.5 15.4 15.5...

  • Page 190: 1.6 L/66 Kw Tdi Cr Engine - Eu5

    Output (kW per rpm) Max. torque (Nm at rpm) Number of cylinders/Displacement (cm 66/4200 230/1500 - 2500 4/1598 Performances ROOMSTER PRAKTIK Top speed (km/h) Acceleration 0 - 100 km/h (s) 13.3 Fuel consumption (in l/100 km) and CO (in g/km)

  • Page 191: 1.6 L/77 Kw Tdi Cr Engine - Eu5

    1.6 l/77 kW TDI CR engine - EU5 Output (kW per rpm) Max. torque (Nm at rpm) Number of cylinders/Displacement (cm 77/4400 250/1500 - 2500 4/1598 Performances Top speed (km/h) Acceleration 0 - 100 km/h (s) 11.5 Fuel consumption (in l/100 km) and CO (in g/km) Intra-urban Ex-urban...

  • Page 192: Index

    Auto-Computer Braking Index see Multifunctional indicator Brake fluid Auto Check Control Breakdown kit Automatic gearbox Bulbs - Replacing Dynamic shift programme Button in the driver's door Emergency programme Electric power windows Information for driving Warning light Kickdown Accessories Manual shifting of gears Adjusting Parking Car jack...
  • Page 193 Chrome parts Defrsoting rear window locking of the doors refer to Taking care of your vehicle Selector lever-unlocking Diesel Towing the vehicle Cigarette lighter refer to Fuel Tyre repair Cleaning Diesel fuel Unlocking the boot lid Artificial leather Operation in winter Emission values Headlight lenses Diesel particle filter...
  • Page 194 Refuelling Information display Lock Unleaded petrol see MAXI DOT Central locking system Fuel consumption Instrument cluster Locking Emergency locking Fuses Interior light Remote control Assignment Praktik without central locking Replacing Interior lighting Locking and unlocking from inside Praktik Luggage compartment Interior monitor Class N1 vehicles ISOFIX...
  • Page 195 Net partition Radiator fan Safe securing system Radio reception Safety Aerial Child safety Functional fault Child safety seats Head restraints Raise vehicle refer to Engine oil ISOFIX Rear mirror Onboard computer TOP TETHER Exterior mirror see Multifunctional indicator Save electrical energy Manual dimming interior mirror Operation in winter Seat...
  • Page 196 Snow chains Checking the electrolyte level Warning light Operation in winter Spare wheel Replacing Technical data Speedometer Safety instructions Telephone START/STOP Vehicle data sticker Function Tiptronic Vehicle dimensions see automatic gearbox Starting and stopping the engine Vehicle key Tool Starting engine Vehicle tool kit Jump-starting TOP TETHER...
  • Page 197 Windows De-icing See electric power windows Windscreen washer fluid Indicator light Windscreen washer system Windscreen wipers Windscreen wiper Replacing the rear window wiper blade Replacing the windscreen wiper blades Windscreen wipers Activating Cleaning the windscreen wiper blades Windshield Radio reception Windshield washer fluid Checking Replenishing...
  • Page 198 ŠKODA pursues a policy of constant product and model development. We trust Reprinting, reproduction or translation, either in whole or in part, is not permitted that you will understand that changes to models in terms of shape, equipment without the written consent of ŠKODA. and engineering, may be introduced at any time.
  • Page 200 Also please pay attention to those parts in the Owner's Manual that are marked  below. Work with us – for the sake of the environment. Návod k obsluze Roomster anglicky 05.2012 S80.5610.07.20 5J7 012 003 HT...

Table of Contents

Save PDF
