- Page 1 GV-IR LED T2 User's Manual Before attempting to connect or operate this product, IRLEDT2-B please read these instructions carefully and save this manual for future use.
- Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
-
Page 3: Table Of Contents
Contents Contents ........................1 Preface ........................1 1. Introduction....................... 2 1.1 Features....................2 1.2 Packing List ..................... 3 2. Connecting GV-IR LED T2 to GV-IPCAM ............4 3. Installing GV-IR LED T2 ..................7 4. Specifications ....................8... -
Page 4: Contents
Preface Welcome to the GV-IR LED T2 User’s Manual. The GV-IR LED T2 is an indoor-use infrared illuminator, which is designed to work with the GV-IPCAM for a better night vision. The table below lists the compatible models of GV-IPCAM. -
Page 5: Introduction
Day mode or Night mode. If you set the GV-IR LED T2 to be triggered by D/N mode, the infrared light of GV-IR LED T2 will be turned on and the camera images will be switched to monochrome to produce better images in the Night mode. -
Page 6: Packing List
Introduction 1.2 Packing List The GV-IR LED package includes the following items: • GV-IR LED x 1 (with a power cable and unshielded wires) • Bracket x 1 • Camera Holder x 1 • Hexagon Head Phillips Screw x 1 •... -
Page 7: Connecting Gv-Ir Led T2 To Gv-Ipcam
2. Connecting GV-IR LED T2 to GV-IPCAM To connect the GV-IR LED T2 to a GV-IPCAM, follow the steps below: 1. Fasten the camera holder to the GV-IR LED T2 with the Round Head Phillips Screws with the washers. Round Head Phillips Screw... - Page 8 4. Unscrew the power cables of the GV-IPCAM from the supplied 2-pin Terminal Block. Twist the red wire from the GV-IR LED T2 to the power cable (DC 12 V), which has the gray stripes on it, and twist the black wire from the GV-IR LED T2 to the power cable (ground), which has the characters on it.
- Page 9 5. Connect the red wire twisted with the power cable (DC 12 V) to the right-side pin of the Terminal Block, and connect the black wire twisted with the power cable (ground) to the left-side pin of the Terminal Block. Connect the Terminal Block to the DV 12 V Port of the GV-IPCAM.
-
Page 10: Installing Gv-Ir Led T2
On: Select this option to leave the GV-IR LED T2 in the OFF status continuously. Trigger IR by D/N: Select this option to trigger the GV-IR LED T2 to turn on in the Night mode and turn off in the Day mode. -
Page 11: Specifications
4. Specifications Power 12V DC, 250 mA IR Wavelength 850 nm Environment Indoor use only IR LED Quantity 12 IR LEDs Illumination View Angle 35° Illumination Range 10 m / 32.81 ft Illumination Life 10,000 hrs Trigger Type Dry Contact Operating Temperature 0°C ~ 50°C Weight...
