- Page 1 GV-G Series IP Camera Mount Installation Guide GV-Mount211-4 / 211-6 / 211-8 / 211-9 GV-Mount506 / 506-1 GV-Mount507 / 507-1 GV-Mount509 GV-Mount510 GV-Mount925 Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use.
- Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.
-
Page 3: Table Of Contents
Contents Preface ........................1 1. Wall Mount Bracket GV-Mount211-4 ..............2 2. Wall Mount Bracket GV-Mount211-6 / 211-8 ............6 3. Wall Mount Bracket GV-Mount211-9 ..............10 4. Junction Box GV-Mount506 / 506-1 ..............14 5. Junction Box GV-Mount507 ................18 6. -
Page 4: Preface
Preface Welcome to the GV-G Series IP Camera Mount Installation Guide. This Installation Guide is designed for the following models: Model Model Number GV-GBL12811 Bullet IP Camera GV-GBLF2802 GV-GBL4900 / GBL4911 Fixed Rugged IP Dome GV-GDR4900 Eyeball Dome GV-GEB4900 / GEBF4911... -
Page 5: Wall Mount Bracket Gv-Mount211-4
1. Wall Mount Bracket GV-Mount211-4 Packing List GV-Mount211-4 Short screw (4 x10 mm) x 4 Long screw (4 x 25 mm) x 4 Colloidal particle x 4 Hex Key Drill Template Paster Applicable Models GV-GDR4900 / GEBF4911 / GEB4900 Dimensions... - Page 6 Installation Before installation, make sure that the wall is strong enough to withstand 3 times the weight of the brackets and the camera. The steps below take straight cable outlet from the wall for example. Unscrew and remove the mounting base of GV-Mount211-4. Loosen the set screw and detach the mounting base of the camera.
- Page 7 Drill the screw holes on the wall according to the drill template. Secure the mounting base of GV-Mount211-4 to the wall. Route the cables through the cable hole and connect the cables.
- Page 8 Fix GV-Mount211-4 to its mounting base on the wall.
-
Page 9: Wall Mount Bracket Gv-Mount211-6 / 211-8
2. Wall Mount Bracket GV-Mount211-6 / 211-8 Packing List GV-Mount211-6 / 211-8 Screw (3 x 6 mm) x 2 Screw (6 x 12 mm) x 4 Screw (4 x 25 mm) x 3 Waterproof ring x 4 Plastic case (6 x 29) x 3 Drill Template Paster Applicable Models ... - Page 10 Dimensions Mount211-6 Mount211-8...
- Page 11 Installation Open the mounting base and the upper cover of GV-Mount506. Loosen the set screw and detach the mounting base of the camera. Secure the camera’s mounting base to the upper cover of GV-Mount506, and install the dome and enclosure to the camera’s mounting base.
- Page 12 Assemble GV-Mount211-6 / 211-8, and fix the mounting base of GV-Mount506 to GV-Mount211-6 / 211-8. Route the cables through the cable hole of Secure the camera mounted with the GV-Mount211-6 / 211-8 and connect the upper cover of GV-Mount506 to cables.
-
Page 13: Wall Mount Bracket Gv-Mount211-9
3. Wall Mount Bracket GV-Mount211-9 Packing List GV-Mount211-8 Screw (3 x 6 mm) x 2 Screw (4 x 12 mm) x 4 Screw (4 x 25 mm) x 3 Waterproof ring x 4 Plastic case (6 x 29) x 3 Drill Template Paster Applicable Models ... - Page 14 Dimensions Installation The following illustrations use GV-GDR4900 and GV-Mount509 as an example. Assemble GV-Mount211-9.
- Page 15 Secure GV-Mount509 with GV-Mount211-9. Use two fingers to remove the trim ring of the camera from the rim with marks. Then loosen the screws to open the lower dome. Attach the camera base to GV-Mount509.
- Page 16 Route the cables through the cable hole of GV-Mount211-9 and connect the cables. Put the trim ring back onto the lower dome and assemble the camera. Secure GV-Mount211-9 to the wall.
-
Page 17: Junction Box Gv-Mount506 / 506-1
4. Junction Box GV-Mount506 / 506-1 GV-Mount506 GV-Mount506-1 Packing List GV-Mount506 GV-Mount506 Plastic case (7 x 42 mm) x 4 Short screw (4 x 10 mm) x 4 Long screw (6.5 x 38 mm) x 4 Waterproof ring x 4 Drill Template Paster GV-Mount506-1 GV-Mount506-1... - Page 18 Dimensions GV-Mount506 GV-Mount506-1...
- Page 19 Installation Before installation, make sure that the wall is strong enough to withstand 3 times the weight of the junction box and camera. The steps below use GV-GBL4900 / GEBF4911 as an example. Drill the screw holes on the wall according to the drill template. Open the mounting base and the upper cover of GV-Mount506.
- Page 20 Loosen the set screw and detach the mounting base of the camera. Secure the camera’s mounting base to the Route the cables through the cable hole upper cover of GV-Mount506 first, and install (take side conduit cabling for example) the dome and enclosure to the camera’s and connect the cables.
-
Page 21: Junction Box Gv-Mount507
5. Junction Box GV-Mount507 Packing List GV-Mount507 Screw (4 x 10 mm) x 4 Screw (4 x 25 mm) x 3 Screw (3 x 6 mm) x 1 Plastic case x 3 Hex Key x 1 Waterproof ring x 5 Drill Template Paster Applicable Models ... - Page 22 Installation Before installation, make sure that the wall is strong enough to withstand 3 times the weight of the junction box and camera. The steps below use GV-GBL4900 as an example. Open the lower cover and the upper cover of the junction box by loosening the fixed screw.
- Page 23 Fix the camera to the upper cover of the junction box. Then route the cables through the cable hole (take side conduit cabling for example) and connect the cables. Install the camera with the upper cover of the junction box to the lower cover, with a clockwise rotation and then secure the junction box by tightening the fixed screw.
-
Page 24: Junction Box Gv-Mount507-1
6. Junction Box GV-Mount507-1 Packing List GV-Mount507-1 Screw (4 x 10 mm) x 4 Screw (4 x 25 mm) x 4 Plastic case x 4 Waterproof ring x 4 Drill Template Paster Applicable Models GV-GBL4900, GBLF2802 Dimensions... - Page 25 Installation Disassemble GV-Mount507-1. Secure the camera onto the cover of Assemble the camera and the bottom of GV-Mount507-1 using the supplied screws as GV-Mount507-1 using the supplied screws as indicated below. indicated below.
- Page 26 The installation is completed.
-
Page 27: Junction Box Gv-Mount510
7. Junction Box GV-Mount510 Packing List GV-Mount510 Screw (4 x 16 mm) x 4 Screw (6.5 x 38 mm) x 4 Plastic case (8 x 40 mm) x 4 Screw waterproof ring x 4 PG waterproof ring x 1 Drill Template Paster Applicable Models ... - Page 28 Installation Secure the junction box to the wall or ceiling with screws. Rotate the trim ring anticlockwise to remove it from the camera and then loosen the screws to open the lower dome. Route and connect these cables. Then fasten the camera to the junction box with screws.
-
Page 29: In-Ceiling Mounting Bracket Gv-Mount925
8. In-Ceiling Mounting Bracket GV-Mount925 Packing List GV-Mount925 Screw (4 x 10 mm) x 4 Drill Template Paster Applicable Models GV-GVD4910 Dimensions... - Page 30 Installation Attach the drill template to the ceiling where you want to install the dome camera. Then cut a hole according to the drill template. Note that +2 mm of the circle diameter is allowed. Rotate the trim ring anticlockwise to remove it. Then remove the lower dome of the camera by loosening the screws.
- Page 31 Route the cables through the ceiling and connect the cables. Then push the dome camera with the bracket into the mounting hole in the ceiling. Tighten the lock screws with the screwdriver and the locks will automatically rotate outwards to secure the dome camera to the ceiling. Then adjust the view angle of the camera.
- Page 32 Install the magnetic ring of the bracket.
