802.11A+G Router Features; Setting Up The Device - Repotec RP WR0582 ML User Manual

To enable WPA (WiFi Protected Access) to assure authorized access as well as to implement
privacy of your data. WPA comes with two modes: 802.1x for enterprise users and PSK (Pre-
Shared Key) for SOHO users.

802.11a+g Router Features

Compliant with 802.11a, 802.11b, and 802.11g standards with roaming capability
Support of NAT for multiple users to share Internet access
IP routing (RIP1/RIP2) support
VPN (Virtual Private Network) support for PPTP pass-through
Support of PPPoE and PPTP client function for xDSL connections
Support of Internet Games (WarCraftIII, AOEII) pass-through.
Support of the Virtual Server function
Support of the standard Access Point mode for connection to wireless clients
Built-in DHCP server to assign IP addresses to DHCP client devices on both wired and
wireless LAN
Multiple security measures: to enable IP packet filtering, to disable SSID broadcast, to define
Access Control List, to enable WEP based encryption (up to 152 bits), to enable WPA, plus
enhanced Security with 802.1x using a primary and a backup RADIUS Server
Extensive monitoring capability such as event logging, traffic/error statistics monitoring
Easy configuration and monitoring through the use of a Web-browser based GUI (only
support IE6.0 or above) or SNMP commands from a remote SNMP management station
Setup Wizard for easy configuration/installation

Setting Up the device

A local PC on either the wired or wireless LAN network can manage the 802.11a+g Router. To do this,
the 802.11a+g Router must have an IP address, which can be statically configured, or is dynamically
obtained from a DHCP server on the LAN.
6
