- Page 1 4Ch Real time / Triplex / Mux Stand Alone DVR User’s Manual VER 1.2 VSD-31 4 Channel Stand Alone DVR USB Backup available The most stable and reliable real stand alone Digital Video Multiplex Recorder...
- Page 2 4Ch Real time/Triplex/Mux - Stand Alone DVR Installation & Safeguards INSTALLATION & SAFEGUARDS All the safety and operating instructions should be read before the unit is operated. Environment Condition for Installation 1. To prevent electric shock or other hazard, do not expose units to rain, moisture, or dust. 2.
-
Page 3: Table Of Contents
4Ch Real time/Triplex/Mux - Stand Alone DVR Contents Contents CHAP. 1 Features & Package Contents ---------------------------------------------------------------- 1-1. Features ---------------------------------------------------------------- 1-2. Package Contents ---------------------------------------------------------------- CHAP. 2 Function of Each Button ---------------------------------------------------------------- 2-1. Front ---------------------------------------------------------------- 2-2. Rear ---------------------------------------------------------------- CHAP. 3 Installation ---------------------------------------------------------------- 3-1. - Page 4 4Ch Real time/Triplex/Mux - Stand Alone DVR Contents CHAP. 5 Set up ---------------------------------------------------------------- 5-1. General Operation ---------------------------------------------------------------- 5-2. Display Setup ---------------------------------------------------------------- VGA Setup ---------------------------------------------------------------- Screen Display Setup ---------------------------------------------------------------- OSD Setup ---------------------------------------------------------------- 5-3. Record ---------------------------------------------------------------- Record Setup ---------------------------------------------------------------- Schedule Setup ---------------------------------------------------------------- 5-3.
-
Page 5: Chap. 1 Features & Package Contents
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP 1. Features & Package Contents CHAP 1. Features & Package Contents 1-1. Features Live Display Real time display per camera Auto Sequence PIP (Picture in picture) Digital Zoom of display Simple playback mode Simple PTZ camera control Record Variable Record resolution (For higher picture quality or higher recording speed) -
Page 6: Package Contents
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP 1. Features & Package Contents 1-2. Package Contents 1. DVR Main Unit 2. Power Cable 5. Software CD 3. Power Adapter 4. User’s Manual 6. Rubber Pad 7. HDD absorber 8. Bolts 9. -
Page 7: Chap. 2 Function Of Each Button
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP 2. Function of Each Button CHAP 2. Function of Each Button 2-1. Front US B POWER HDD FUL L Name Function ① USB Device Used for updating Firmware ② USB HOST Used for Data Backup ③... -
Page 8: Rear
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP 2. Function of Each Button 2-2. Rear Name Function Connection with PTZ camera or other external device using RS 485 RS 485 interface Relay out terminal RELAY Output Sensor input terminal SENSOR Input RS-232C Connection to external device as PC using RS-232C to control the DVR ETHERNET... -
Page 9: Chap.3 Installation
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 3 Installation CHAP.3 Installation 3-1. Installation Configuration... -
Page 10: Detailed Installation
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 3 Installation 3-2. Detailed Installation 1) HDD 1. Connect Main Board and HDD1 using IDE cable and HDD power cable. 2. The jumper setting of HDD should be on Master when you install HDD. 3. -
Page 11: Monitor
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 3 Installation 3) Monitor Connect the video output marked MONITOR to Video-In of Main monitor. 4) Power DC over 12V adapter... -
Page 12: Other External Device
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 3 Installation 5) Other External Device RS-485 : Control external device like PTZ camera. (Pin No.8 & No.9 at D-SUB). RELAY Output : Relay Output (Pin No.6 & No.7 at D-SUB). SENSOR Input : Sensor Input – Alarm Input (Pin No.1 ~ No.4 at D-SUB). ETHERNET : Connection to LAN, WAN t. -
Page 13: Chap. 4 Operation
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 4 Operation 4-1. System Log-In 1) Move a cursor to lower right hand corner of DVR LOG-IN display by using a mouse, then you will see ‘Menu’ Icon. Click the ‘Menu’ Icon to log in. 2) Then, you will see ‘DVR Log-In’... -
Page 14: Display Configuration
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 4 Operation 4-3. Display Configuration ETHERNET Status HDD Status connected In Live Mode: Disconnected Amount of Recorded data Remote Search In Playback Mode: Amount of data displayed Current Date/ Time Camera Title PLAY SEARCH Alarm Record... -
Page 15: Live View Setup
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 4 Operation 4-4. Live View Setup 1) Full / Multiple View CHAP. 4 사용방법 Move a cursor to ‘split icon’ on the lower left corner of display and click it to view 4 channel division. To enlarge each channel, click 1,2,3,4 Icon. -
Page 16: Record
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 4 Operation 4-5. Record It records as a setting made by a user in Schedule Mode. - Schedule Record Go to MAIN MENU-SCHEDULE SETUP and setup schedule as you want. It records as a setting. - Record Icon in Red indicates Schedule Record, Motion record, and alarm record. -
Page 17: Search
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 4 Operation 4-7. SEARCH There are three search methods controlled by a mouse wheel button, left and right button of a mouse. When you click [SEARCH] icon, then you see a window shown as below. Select a target data by using a mouse. -
Page 18: Ptz Camera Operation
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 4 Operation 4-8. PAN/TILT/ZOOM Camera Operation Click [PTZ] icon to control a PTZ camera. PAN/TILT is controlled by Left & Right buttons and Zoom In & Out is controlled by a wheel of a mouse. You can control a PTZ camera in 8 different directions as shown below. -
Page 19: Chap. 5 Set Up
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 5 Set up CHAP. 5 Set up 5-1. General Operation Click [MENU] icon and input user password to log in. Mouse buttons Functions Up and down of setup value on the Menu mode Mouse Wheel Up and down of Playback speed Zoom in and out in PAN/TILT/ZOOM mode... -
Page 20: Display Setup
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 5 Set up 5-2. DISPLAY SETUP This is setup menu for display on the screen. If you click ‘DISPLAY SET UP’, then you change setting values for display as shown below. DISPLAY SETUP VGA SETUP SCREEN DISPLAY OSD SETUP... -
Page 21: Osd Setup
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 5 set up VERTICAL POSITION : 0 ~ 63 HORIZONTAL POSITION : 0 ~ 63 BORDER ENABLE : ON/OFF BORDER WIDTH : 1 ~ 10 BORDER COLOR : COLOR SELECT 3) OSD SETUP OSD SETUP TOP OSD OFFSET BOTTOM OSD OFFSET... -
Page 22: Record
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 5 Set up 5-3. RECORD This is the most important configuration of the DVR. When you select ‘RECORD SETUP’ in the main RECORD menu, you can see the window as shown on the left. RECORD SETUP SCHEDULE SETUP 1) RECORD SETUP... -
Page 23: Schedule Setup
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 5 Set up 2) SCHEDULE SETUP Unless you selected other recording mode, DVR system records in Schedule Recording mode. In Schedule Recording mode, you set type of recording by 1 hour time interval. Default frame rate for continuous recording speed is 30 FPS. -
Page 24: Configuration
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 5 Set up 5-4. CONFIGURATION When you click ‘CONFIGURATION’ on the CONFIGURATION main menu, you can go to ‘CONFIGURATION’ menu as shown on the right. HDD MANAGEMENT CAMERA SETUP MOTION SETUP ALARM SETUP INTERVAL SETUP TIME/DATE SETUP PASSWORD SETUP... -
Page 25: Time/Date Setup
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 5 Set up 2) TIME/DATE SETUP In this setup, you can select date/time of DVR TIME/DATE SETUP system and display format. You can adjust values by using a mouse wheel or DATE 2006/JUL/08 left/right button of a mouse. -
Page 26: Motion Setup
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 5 Set up 4) MOTION SETUP MOTION SETUP CHANNEL SENSITIYITY DURATION DETECT CELL NUM. DEFAULT ALL-DEFAULT MOTION SETUP : You can change values by mouse wheel and left/right button of a mouse. - SENSITIYITY : Adjusting sensitivity of a movement. -
Page 27: Interval Setup
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 5 Set up 5) INTERVAL SETUP See the switching time interval for SEQ or PIP function. INTERVAL SETUP (1 sec. ~99 sec. ） SEQUENCE SCREEN :Set the sequencing switch time SEQUENCE SCREEN 01 SEC interval in live full screen. -
Page 28: External Device Setup
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 5 Set up 5-5. EXTERNAL DEVICE EXTERNAL DEVICE Set parameters of external devices connected to DVR TCP/IP SETUP like Ethernet, PTZ camera, Spot monitor etc. PAN/TILT SETUP If you click ETERNAL DEVICE on the main menu, then SPOT SETUP you will see the window shown on the right. -
Page 29: Pan Tilt Zoom Setup
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 5 Set up 2) PAN/TILT SETUP COMMAND SETUP PAN/TILT SETUP CHANNEL PTZ Camera setup COMMAND SETUP MODEL PELCO-D SPEED SETUP PTZ Speed setup PTZ ID BAUDRATE 2400 BPS CMD DELAY 1 MSEC COMMAND PAN/TILT STOP LENGTH... -
Page 30: Back Up
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 5 Set up 5-6. BACK-UP 1) CDR SETUP You can back up the recorded data to CD using CD writer installed in DVR. Refer to [START] and [END] of data on HDD and set copy from time, [START], and size of data copied, [SIZE], and move to BURN and click it to start copy. -
Page 31: Firmware Upgrade
4Ch Real time/Triplex/Mux - Stand Alone DVR CHAP. 5 Set up System Status Messages (1) If MEMORY STICK is not inserted : - USB STORAGE IS CHECKING… - USB STORAGE IS NOT AVAILABLE - RE-CONNECT THE USB STORAGE - CONECT THE OTHER USB STORAGE (2) When MEMORY STICK or USB HDD is recognized - USB STORAGE IS CHECKING …...
