- Page 1 Covert Video Systems Clock/Radio Digital Video Recorder User’s Manual Clock/Radio Digital Video Recorder “See what you’ve been missing!!”...
- Page 2 Do not operate in wet and dusty conditions. Keep product surfaces • clean and dry. Avoid placing the Clock/Radio DVR in areas like a damp basement or a dusty hallway. Do not expose this product to rain or use near water. If the product gets •...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Overview Remote Controller Panel Setup Procedures SD Memory Installation and Connection to a Monitor OSD Menu and Main Menu Record Mode and Video Quality Event Mode Alarm Setup and Motion Setup Schedule Setup and Search Sub Menu Password Change and Time Set Brightness and Video Memory Sync and Reset Default Settings... -
Page 4: Overview
Clock/Radio DVR MENU section. VIDEO OUT Connect the Clock/Radio DVR to a TV or monitor using a BNC cable. If you connect one of the VIDEO OUT ports to the VCR, you can backup data with the VCR. -
Page 5: Remote Controller Panel
REMOTE CONTROL REC: The button to start recording. MENU: The button to display the on screen menu. UP/DOWN: The buttons to choose a menu field. FF: The button to playback recorded video faster. REW: The button to play recorded video backward. REW: The button to play recorded video backward. -
Page 6: Setup Procedures
The default recording setting for this system is set to 30 frames per second and normal video quality. If • you use 1GB SD Memory, the Clock/Radio DVR can record for 2 hours in a row approximately. There is an exception to entering the VIEW mode at start up. If the power is turned off while recording •... -
Page 7: Sd Memory Installation And Connection To A Monitor
2. Insert Micro SD Memory into SD slot on the Clock/Radio DVR. After formatting, take SD Memory from your PC and insert it into SD slot on the Clock/Radio DVR located in the battery compartment on the bottom of the clock/radio. -
Page 8: Osd Menu And Main Menu
In order to select cameras for recording, set recording quality, schedule recording times and to set other opera- tion parameters, you will need to access the Clock/Radio DVR’s menu. Numerals can be selected by pushing up/down button on the remote controller. -
Page 9: Record Mode And Video Quality
MICRO DVR MENUS 3. RECORD MODE 3. RECORD MODE 3.1 OVERWRITE (ON/OFF): If this option is ON, recording keeps going on by deleting old recorded files when SD memory storage capacity is full. If it is OFF, the recording session stops when all SD Memory is full. -
Page 10: Event Mode
MICRO DVR MENUS 4.2 POST RECORDING TIME: Post recording time means the time between one event and the next second to 30 minutes can be entered. 4.3 FRAME RATE NTSC: Selectable among 0.1 / 0.2 / 0.5 / 1 / 3 / 6 / 15 / 30 PAL: Selectable among 0.1 / 0.2 / 0.5 / 1 / 5 / 6 / 8 / 12.5 / 30 4.3.1 PRE RECORDING TIME High: up to 5 seconds for pre-recording available... -
Page 11: Alarm Setup And Motion Setup
MICRO DVR MENUS 5.1 ALARM SETUP 5.1.1 ALARM INPUT (ON / OFF): Select ‘ON’ if you want to use alarm input device. 5.1.2 TYPE: Select alarm input type between ‘NO’ and ‘NC’ NC: NORMAL CLOSE NO: NORMAL OPEN NOTE: In NORMAL-CLOSE mode, if an intruder cuts the cable line that connects the sensor to the de- vice, sensor recording starts automatically. -
Page 12: Schedule Setup And Search
5.2.2 SESITIVITY (LOW / NORMAL / HIGH): You can select the extent of sensitivity for motion detection. The higher the sensitivity is, the better the reaction the Clock/Radio DVR has to small motion. 5.2.3 MOTION MARK (ON / OFF): Select ‘ON’ if you want to display motion mark on the monitor. -
Page 13: Sub Menu
MICRO DVR MENUS 6.1 SEARCH METHOD: There are three ways to search recorded files; TIME, EVENT, BOTH (TIME & EVENT). 6.1.1 SEARCH MODE—TIME: Enter period of time when recorded files were generated. 6.1.2 SEARCH MODE—EVENT: When you select ‘EVENT (or BOTH) on SEARCH MODE’, additional search conditions open;... -
Page 14: Password Change And Time Set
MICRO DVR MENUS 7.1 PASSWORD CHANGE The Factory Default Password is 0000. To enter this number, press the UP/DOWN button on the remote con- troller. Once you input the current password, set a new six digit password using the numbered buttons UP, REW, DOWN, FF on the remote controller. -
Page 15: Brightness And Video
MICRO DVR MENUS 7.3 BRIGHTNESS Select brightness value among low, medium and high. 7.4 VIDEO Select video format between NTSC and PAL. -
Page 16: Memory Sync And Reset Default Settings
MICRO DVR MENUS 7.5 MEMORY SYNC The index file is automatically generated and stored in SD card inserted into the unit. If the index file does not match to the files actually stored in the SD card, users can synchronize the index file list and actual file list. -
Page 17: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING I pushed the menu button but it doesn’t show the menu directory. When the unit is in record mode no button on the front panel will work. The red light below the REC button is on when the system is recording. To end recording, press the STOP button. - Page 18 TROUBLESHOOTING What is the limitation of the SD Memory size that I can install in the system? A standard capacity SD Memory not a high capacity is required. Most 1-2GB cards are standard capacity. Some 4GB Memory cards are standard capacity but most are high capacity.
-
Page 19: Appendix
APPENDIX 23 19... -
Page 20: Warranty Information
The limited warranty stated herein is subject to all of the following terms and conditions. TERMS AND CONDITIONS 1. NOTIFICATION OF CLAIMS: WARRANTY SERVICE: If Purchaser believes that the product is defective in material or workmanship, then written notice with an explanation of the claim shall be given promptly by Purchaser to the Manufacturer but all claims for warranty service must be made within the warranty period.
