- Page 1 USER’S MANUAL CCTV Tester Pro...
- Page 2 Keep the S/N label for after-sale service within warranty period. Product without S/N label will be charged for repair service. If there is any question or problem while using the CCTV testerPRO, or damages occurred on the product, please contact our technical Department.
-
Page 3: Table Of Contents
CCTV tester PRO User’s Manual Table of Content 1 S a f e t y I n f o r m a t i o n -----------------------------------------------------------------------------------3 2 I n t r o d u c t i o n ----------------------------------------------------------------------------------------------4 2.1 Features --------------------------------------------------------------------------------------------------4... - Page 4 CCTV tester PRO User’s Manual S a f e t y I n f o r m a t i o n Notice The tester is intended to use in compliance with the local rules of the electrical usage and avoid to apply at the places which are inapplicable for the use of electrics such as hospital, gas station etc.
-
Page 5: Features
It can be used for displaying video, controlling PTZ, generating images, capturing data of RS485 and testing LAN cable etc. Its functions, easy operation, and portability makes it simple for the CCTV technician to install and maintain CCTV system, improving work efficiency and get the labor cost down. -
Page 6: Cctv Testerpro Kits
CCTV tester PRO User’s Manual PTZ address scanning, search up the ID of PTZ camera. Lithium Ion Polymer Battery (3.7V DC3000mAh). The device employs advanced power control and protection circuit. The device is high power-efficient, energy saving and environmental protection. It can last 12 hours for normal use after charging for 4 hours. -
Page 7: Front Panel
The charge indicator: it lights red while the battery is being charged. As the charging is complete, the indicator turns off automatically. The display Icon of battery electricity: it displays the electric quantity Main-menu: it shows main functions of CCTV testerPRO. Sub-menu: Shows and sets the values of functions Page.6... - Page 8 CCTV tester PRO User’s Manual Long-pressing it more than 2 seconds to turn on/off the tester; short-pressing to turn on/off the PTZ controller menu displaying. Menu key: it pops up the main-menu; constant-press it or press the key can shift between functions Setup key : press it or press left or right key to enter sub-menu to set the parameters of functions.
-
Page 9: Side View
CCTV tester PRO User’s Manual 2 . 4 S i d e v i e w Reset the default settings of parameters. External power supply (DC, 5V): It is highly recommended to use the equipped power adapter. UTP cable port: Please use together with UTP LAN cable tester. -
Page 10: Installing The Battery
CCTV tester PRO User’s Manual 2 . 5 I n s t a l l i n g t h e B a t t e r y The tester has built-in lithium ion polymer rechargeable battery. The battery cable inside battery... -
Page 11: Operation
Video settings, Colorbar generator, LAN cable tester, Data monitors, Device setting) and enter corresponding function setting sub-menu. Press SET key to set the parameters in function sub-menu. Note: When the CCTV testerPRO is powered on, it will return to the function which is being operated before it is turned off. - Page 12 5. Data Monitor Captures the protocol from the controlling system and display command data. It is helpful to debug and maintain RS485 communication. 6. Device setting Set the parameters of the CCTV testerPRO (Auto power off/ Keypad tone/Language/Brightness/Address search) Page.11...
-
Page 13: Ptz Controller
The Video In interface of the CCTV testerPRO and the output interface of camera b. Data A+ of the CCTV testerPRO and A+ of the PTZ camera or controlling device, data B- of the instrument and B- of the PTZ camera or controlling device Don’t connect communications interface with a circuit the voltage higher than 6V. - Page 14 CCTV tester PRO User’s Manual a. Press SET key to enter the sub-menu of PTZ controller. b. Press the key to select the parameter which we want to change the value. c. Press ENTER key to save the change or press RETURN key to give up the change d.
- Page 15 CCTV tester PRO User’s Manual Tips: Press key to accelerate the value changing. The way of calling the OSD menu and preset of the PTZ camera may vary with control systems from different manufacturers. Please read the operation manual of control system manufacturer for details.
-
Page 16: Video Setting
The Video Format and Video Level will be displayed in the lower portion of the screen. If there is no video signal at the Video IN port of the CCTV TesterPRO, the type of NTSC or PAL , and Video Level will not be displayed. -
Page 17: Colorbar Generator
CCTV tester PRO User’s Manual Depending on the type of camera connected to the CCTV testerPRO, the Video “Format: “ will automatically change between NTSC and PAL, and the Video Level will automatically change between IRE (Institute of Radio Engineers) and mV. NTSC signals measured in IRE units, PAL signals measured in mV. -
Page 18: Data Monitor
Set the parameters of the CCTV testerPRO Auto poweroff: Setting the time of auto shut-down.(Disable,5,10,…,60) Disable: Disable the “Auto poweroff” function. 5 means the CCTV will power off after 5 minutes when there is no any operation. Keypad tone: Open or close the beep of pressing keypad. -
Page 19: Address Search
CCTV tester PRO User’s Manual Brightness: Setting the brightness of OSD menu and background.(0~7) Address search: off / on Open or close the PTZ address search Menu. a. Press key to move the parameter we want to change. b. Press to change the value. -
Page 20: Digital Multimeter
CCTV tester PRO User’s Manual stop searching up. WIDE: The tester will search up the ID step by step (from 1 to 256). When the ID is searched, the PTZ camera will stop panning. FAR: The tester will search up the ID step by step (from 256 to 1). When the ID is searched, the PTZ camera will stop panning. - Page 21 CCTV tester PRO User’s Manual ⑵ SYMBOLS： ：AC Voltage Measuring U：DC Voltage Measuring ：AC Current Measuring A：DC Current Measuring Ω ：Resistance Measuring ： Continuity Testing ： ： Diode Testing Capacitance Measuring ⑶ OPERATING INSTRUCTION DC Voltage Measuring WARNING! You can’t input the voltage which more than 660V DC, it’s possible to show higher voltage, but it’s may destroy the inner circuit.
- Page 22 CCTV tester PRO User’s Manual AC Voltage Measuring WARNING! You can’t input the voltage which more than 660V AC, it’s possible to show higher voltage, but it’s may destroy the inner circuit. Pay attention not to get an electric shock when measuring high voltage.
- Page 23 CCTV tester PRO User’s Manual b. Press to select , enter the DC current measurement. Manual range by press , only manual range supply. 0.000mA Manual range： 6.6mA range 00.00mA 66mA range 000.0mA 660mA range 00.00A 10A range（use 10A socket）...
- Page 24 CCTV tester PRO User’s Manual 0.000mA Manual range： 6.6mA range 00.00mA 66mA range 000.0mA 660mA range 00.00A 10A range（use 10A socket） c. Connect test leads in series with the load under measurement. d. You can get reading from LCD.
- Page 25 CCTV tester PRO User’s Manual 000.0 KΩ 660KΩ range 0.000 MΩ 6MΩ range 00.00 MΩ 66MΩ range c. Connect test leads across the resistance under measurement. d. You can get reading from LCD. NOTE: When only the figure “OL” is displayed, it indicates overrange situation and the higher range has to be selected.
- Page 26 CCTV tester PRO User’s Manual d. You can get reading from LCD. NOTE: The meter will show approximate forward voltage drop of the diode. If the lead connection is reversed, only figure “OL” will be display. Capacitance Measuring...
-
Page 27: Dc12V Power Output
Don’t input any power into the “DC12/1A OUTPUT” port of the CCTV tester to avoid destroy. Don’t output this DC12V/1A power to the power input port of the CCTV tester to avoid destroy. When the requirement of the camera is higher than 1A, the CCTV tester will enter protection mode. -
Page 28: Specifications
CCTV tester PRO User’s Manual 6. Specifications 6.1 General Specifications MODEL CCTV Security TesterPRO Video Test Signal mode NTSC/PAL (Auto adapt) Display 3.5 inch digital TFT-LCD ,960 x 240 resolution LCD adjustment Brightness, Contrast, Saturation adjustable Video IN/OUT 1 channel BNC Input & 1 channel Output Video Output Mode 1.0 Vp-p... -
Page 29: Multimeter Specifications
CCTV tester PRO User’s Manual Rechargeable After charging 3-4 hour, working time lasts 12 hours Low Consumption Energy saving technology General Working -10℃---+50℃ Temperature Working Humidity 30%-90% Dimension/Weight 176mmx94mmx36mm/340g 6.2 Multimeter specifications Counts：-6600～+6600 Conversion rate : 3 times/s Current modes for clamp meter with ZERO function... - Page 30 CCTV tester PRO User’s Manual 660mA 100uA ±（1%+5） 10mA AC Current Range Accurac Resolution 6.6mA 66mA ±（0.5%+3） 10uA 660mA 100uA 10mA ±（1%+5） Resistance Range Accurac Resolution 660Ω 0.1Ω ±（0.8%+5） 6.6KΩ 1Ω 66KΩ 10Ω ±（0.8%+2） 660KΩ 100Ω 6.6MΩ 1KΩ 66MΩ 10KΩ...
