The RatioMatic Version 3.00 is a nozzle-mix type burner
designed for direct air heating, indirect air heating, and oven
applications up to 1800° F. (1000° C.)
The burner package includes a combustion air blower and an
air:gas ratio regulator to fire over a wide gas turndown range at
a controlled ratio.
The burner is designed for:
•
efficient ratio controlled combustion
•
reliable burner operation
•
simple burner adjustment
•
direct spark ignition
•
multiple fuel capability
A wide variety of options and configurations are available due
to the modular design of the burner.
The RatioMatic Burner
