Setup
4.3.2 UPnP™ (Network) Input
Parameter Options
Enabled:
Yes / No
Name:
User definable
Server History: Yes / No. If
is specified
NDS will remember the last used folder
if the UPnP™ server is still available. If
is specified NDS will display the full list of
available servers.
4.3.3 USB Input
Parameter Options
Enabled: Yes / No
Name: User definable
Folder History: Yes / No. If
is specified NDS
will automatically display the last used
folder on the USB device. If
the top level folder of the device will be
displayed.
4.3.4 Digital Inputs 1, 2 and 3
Parameter Options
Enabled:
Yes / No
Name: User definable
Unstable source: Yes / No
Select No
the NDS has problems locking to a digital
signal. Selecting
to lock to unstable digital signals, however
sound quality will be slightly degraded.
UPnP 1/3
Yes
4Enabled:
Name: UPnP
Server History Yes
Yes
No
USB 1/3
Yes
4Enabled:
Name: USB
Folder History: No
Yes
No is specified
Digital 1 1/3
Yes
4Enabled:
Name: Dig 1
Unstable source: No
unless
Yes will enable the NDS
4 . 4 Th e A n a lo g u e O u tp u t s M e n u

The Analogue Outputs menu

enables the main DIN or RCA
phono outputs to be disabled
or individually or simultaneously
selected.
Parameter Options
Main out: Disabled / DIN / Phono / DIN-Phono.
Select the appropriate option for your
installation. Only select the DIN-Phono
option if both outputs are simultaneously
required.
4 . 5 Th e N e tw o r k S e tt in g s M e n u

The Network Settings menu

enables NDS network parameters
to be customised to suit the
router and network. The options
are tabulated and described in
the following sections:
Parameter Options
Name: User definable (text entry)
Default: NDS-xxxx
Wireless: Not Used / Wireless Network Names
Status: Connected / Not Connected / No Signal
/ Login Failure / Busy / Etc.
DHCP:
Yes / No
MAC: Displays the NDS MAC address
The Name parameter enables the NDS's default network
name to be changed.
The Wireless parameter enables a wireless network to be
chosen and joined. See Section 4.5.1 below for detailed
wireless set up notes.
Network Status displays the current network connection
status.
The DHCP parameter enables the NDS network settings to
be modified. In most cases, specifying
NDS set to DHCP, will be the appropriate option. See
Section 4.5.2 for notes on static address (non-DHCP)
network connection.
Note: Devices installed on a network have an IP address
through which they are identified by all the other items
on the network. DHCP is a set of rules that enable the
automatic allocation of addresses as items are connected
(or switched on while connected) to the network. NDS is
set up by default to use DHCP.
Note: If NDS is connected to the network both wirelessly
and via Ethernet (wired), the Ethernet connection will take
priority.
Analogue Outputs 1/1
4Main Out: DIN
Network Settings 1/5
NDS-xxxx
4Name:
Wireless: Not Used
Status: Not Connected
DHCP Yes
Yes and leaving
13
