User's Manual
G03-JC620EN-F
Manual revision: 1.0
Release Date：September, 2011
i

Advertisement

Table of Contents
loading

Related Manuals for OrionPC G03-JC620EN-F

Summary of Contents for OrionPC G03-JC620EN-F

  • Page 1 User’s Manual G03-JC620EN-F Manual revision: 1.0 Release Date：September, 2011...

  • Page 2: Package Contents

    User’s Notice Copyright of this manual belongs to the manufacturer. No part of this manual, including the products and software described in it may be reproduced, transmitted or translated into any language in any form or by any means without written permission of the manufacturer. This manual contains all information required for the utilization of this product to meet the user’s requirements.

  • Page 3: Safety Instruction

    Safety Instruction Operate the product according to the correct installation steps and with great care to make sure safety and comfort using experience. Please refer to the following safety instruction guide to avoid danger of electric shock or fire. Abide by the previous safety instruction guide to use and maintain the product and the hard disk to make sure of safe operating environment.

  • Page 4: Table Of Contents

    TABLE OF CONTENT USER’S NOTICE ........................ii PACKAGE CONTENTS ......................ii SAFETY INSTRUCTION ......................iii CHAPTER 1 BRIEF INTRODUCTION PRODUCT FEATURES....................1 SPECIFICATION ......................4 PRODUCT DIAGRAM....................5 CHAPTER 2 HARDWARE INSTALLATION TO OPEN THE CHASSIS ................... 6 TO INSTALL MEMORY MODULE(S)................. 7 TO INSTALL HARD DISK DRIVE ................

  • Page 5: Chapter 1 Brief Introduction

    Chapter 1 Brief Introduction 1.1 Product Features Thank you for purchasing the system, a new product developed, designed and manufactured under leading technical power and consistent dedication to fine workmanship. The system provides you HTPC enjoyment and stunning game-playing experience. It can also serves as home server for data gather with its expandable Wi-Fi function.
  • Page 6 The system has the following features besides other basic functions: HDMI: The system comes with an HDMI output connector to realize full HD1080P high-definition multimedia home theatre enjoyment. User can enjoy seamless playback of HD DVD and Blu-ray disk in the living room by connecting system to LCD TV set with an HDMI cable for non-compressed, full digital audio and video movie transmission.
  • Page 7 computers in the house can build wireless connections through the Mini TOP system and take necessary data from it, thus reducing the complexity in network establishment. Giga LAN: The system is integrated with Gigabit LAN network controller with ACPI management realizing efficient power management for the operating system.

  • Page 8: Specification

    1.2 Specification AMD Fusion E350 Dual core APU CPU Clock Speed: 1.6GHz Radeon™ Brand : HD 6310 ( 492MHz ) AMD Hudson M1 Chipset Chipset 2 * SO-DIMM DDRIII Memory slots support 2 * SO-DIMM DDRIII 800/1066 Memory Slots memory modules up to 8GB Integrated with Realtek Gigabit LAN chip Network Mini-PCIE slot support 802.11b/g/n Wi-Fi card...

  • Page 9: Product Diagram

    1-3 Product Diagram Remote Sensor Wi-Fi Antenna Connector Power Switch Button HDMI Port Line-out /Optical SPDIF-out DVI-I Port USB 2.0 Ports E-SATA /USB Port Card Reader Slot RJ-45 Port USB 3.0 Port 12V DC-in Jack TV Tuner Antenna Hole Front Panel I/O Rear Panel I/O...

  • Page 10: Chapter 2 Hardware Installation

    Chapter 2 Hardware Installation Please turn off the system and make sure that power cord is unplugged before WARNING! hardware installation to ensure safety. 2.1 To Open the Chassis Place the system on a flat surface and put the Push the removable panel in the direction side with removable cover upwards.

  • Page 11: To Install Memory Module(S)

    2.2 To Install Memory Module(s) 1. Locate the SO-DIMM memory slot(s) on the board. Insert the gold-figure side of the compatible Press down as the photo shows. The eject DDRIII SO-DIMM into the slot at a 30 tabs will lock it if installed correctly. degree.

  • Page 12: To Install Hard Disk Drive

    Notice: When installing, align the notch on the module matches the break on the slot. Memory module can only be installed in such a direction. If not, it will cause serious damage to module and the board. When you install memory module fully into the DIMM socket the eject tab should be locked into the module very firmly and fit into its indention on both sides.
  • Page 13 Lock the SATA hard disk to one of the racks Lock the SATA hard disk to the other rack by by tightening the screws in the marked tightening the screws in the marked position. position. Fit the hard disk into HDD connector on the Lock the racks to the board by tightening up motherboard in this direction.

  • Page 14: To Install Wifi Card

    2.4 To Install WIFI Card Remove the marked screws to unlock the Gently pick the board out of the chassis. board from the chassis. Turn the backside of the board upwards and Insert the gold figure side of the compatible locate Mini-PCIE WI-FI card slot Mini-PCIE WI-FI card into the Mini-PCI-E slot (MIMIPCIE1).
  • Page 15 Tighten up the screw to make sure that the Press the metal hat on the other end of the card locked to the board. antenna connector into the antenna slot (ANT1) on card as shown. *The above steps completed, please restore the board to chassis and close the chassis with the removable cover (refer to 2.6).

  • Page 16: To Install Tv Card

    2.5 To Install TV Card *The system also support TV card function. TV card slot is located near WIFI card slot. User also needs to open the chassis and find the TV card slot before installation (please refer to 2.4). Remove the TV antenna hole block net from Push the antenna connector into TV antenna the chassis.
  • Page 17 Insert the gold figure side of the compatible Tighten up the screw to make sure that the Mini-PCIE TV card into the MIMIPCIE2 slot card locked to the board. by a 45 angle. Press the metal hat on the other end of the Gently fit the board into its original place.

  • Page 18: To Restore Removable Chassis Cover

    2.6 To Restore Removable Chassis Cover Gently put the removable cover back to This edge with 3 plastic equidistant notches the chassis should be parallel to edge of the chassis’ back panel. Front Panel Back Panel Place the removable cover upon the chassis. See to it that the left and right edges of the cover should be parallel to those of the chassis and there should be a distance of about 1 cm left between the front edge and the front panel of the chassis as the photo shows.

  • Page 19: To Assemble The Stand

    Put the side of I/O back panel towards you and push the removable cover of the chassis in the direction forwards. 2.7 To Assemble the Stand See to it that the marked square space See to it that the marked tiny round space and fitted into the square notch on the chassis.

  • Page 20: To Vesa Mount The System

    Lock the stand to the chassis by tightening up a The photo of the system with stand screw to the marked place. installed. 2.8 To VESA Mount the System Attach the chassis rack to the back of monitor by See to it that the square notch on the tightening up the screws in the marked position.
  • Page 21 The square notch on the chassis and the Lock the chassis to the rack by tightening up square space on the stand. the screw in the marked position.

  • Page 22: Chapter 3 I/O Connection And Remote Control

    Chapter 3 I/O Connection and Remote Control After needed hardware installed inside the chassis, you can proceed on to connect cables to the rear panel and power on the system to enjoy the using the system. 3.1 Rear Panel Connection USB 3.0 port 3.1.1.
  • Page 23 3.1.2. RJ-45 Port RJ-45 LAN port RJ-45 LAN Cable Router Switch The connector is standard RJ-45 connector for network. Please connect to the network cable to this connector.
  • Page 24 3.1.3. ESATA/USB 2.0 Port ESATA/USB 2.0port ESATA Cable ESATA Hard Disk The function of this connector depends on different device connected to this connector through different cable. It could function as: E-SATA connector when a compatible ESATA hard disk is connected to it through SATA cable. USB 2.0 connector when a compatible USB device is connected to it through USB cable (for device connection please refer to 3.1.1).
  • Page 25 3.1.4. DIV Port DVI Port DVI Cable LCD Monitor (Should come with DVI port) This DVI (Digital Visual Interface) interface standard designed to maximize the visual quality of digital display devices such as flat panel LCD computer displays and digital projectors.
  • Page 26 3.1.5. HDMI Port HDMI Cable LCD Monitor (Should come with HDMI port for connection) This point-to-point HDMI (High-Definition Multimedia Interface) interface is for audio and video signals designed as a single-cable solution for home theater and consumer electronics equipment.
  • Page 27 3.1.6. DC-12V Power in Jack Power adapter Power cord Power socket Connect the DV power in end to the system, and plug the corresponding end of power cord to power adapter and the other end to power socket. Then Turn on the system either by power switch on front panel or remote control when all necessary configuration are made to power on the system.

  • Page 28: Front Panel Connection

    3.2 Front Panel Connection Remote Sensor Power on Switch W/ Power LED MIC Connector Line-out/SPDIF-out shared Connector USB 2.0 Port Card Reader Slot Card Reader Slot: to insert the MMC/SD/MS card to the front 3 in 1 card reader. USB 2.0 Connectors: to connect USB mouse, keyboard and other USB storage devices to the system. Line-Out /Optical SPDIF out shared Connector: this connector can function as ordinary audio line-out connector or optical SPDIF out connector depending on different device connected to it: Audio Line-out connector: by connecting stereo speakers or headphones.

  • Page 29: Remote Contrl Diagram

    3.3 Remote Control Diagram The accessories of the system include a remote control with which you could easily carry out a lot functions to bring you the friendly user-experience during HTPC watching, Karaoke, and other functions.

  • Page 30: Function Description Of The Remote Control

    3.4 Function Description of the Remote Control Icon Function Description Press this button to power on/shut down the computer. Power Press to set computer into sleep mode. STANDBY The ‘ESC’ key on the keyboard. Close the currently activated dialog box or task. CLOSE Opens the play DVD window in the Windows Media Center or opens the main menu or a DVD movie, if available.
  • Page 31 This is to be used with mouse control buttons for drag operation. Press and hold “Lock” to select the object and move cursor at the lock same time to desired position press again to un-lock. The ‘Enter’ key on the keyboard. The direction key that control the cursor movement.
  • Page 32 Windows common dialog forward function. Forward Opens internet explorer. Full screen function button. Full Screen To delete selected function. Delete To fast return desktop button. DeskTop Press the Mic OSD button on remote control to invoke the on-screen-display Karaoke microphone/audio options during Mic OSD...

  • Page 33: Chapter 4 New Vision User Interface

    Chapter 4 New Vision User Interface After necessary hardwares installed and needed connections made, please install the operating system and motherboard utility driver. There is also a ‘New Vision’ user interface disk attached in the package, please find and install it afterwards to enjoy more HTPC functions provided by the system! New Vision provide quick platform for user to play video, music and games or browse pictures easily.
  • Page 34 1. Click ‘Next’ on the welcom setup wizard 2. Select destination location, then click ‘Next’. menu. 3. Click ‘Next’ to select a start menu folder. If 4. Select the additional tasks you would like Setup to you would like to select a different folder, perform while installing New Vision, then click ‘Next’.
  • Page 35 5. Click ‘Install’ to continue the installation, or click 6. Click ‘Finish’ to complete the setup. The ‘Back’ if you want to review or change any application may be launched by selecting the previous settings. installed icons. Before you find the New Vision user interface program in the DVD that Notice! comes with the system and install it in default destination location, please install Windows operating system and motherboard driver.

  • Page 36: To Activate New Vision Program

    4-2．To Activate New Vision Program Double click New Vision shortcut or right-click on it, then click ‘Open’ to activate New Vision User Interface after installation completed. The following screen shall show up: Click on the New Vision square frame to continue executing (User can use [Enter] on keyboard or [OK] on remote control to enter as well).

  • Page 37: New Vision User Interface Basic Operations

    4-3． New Vision User Interface Basic Operations As shown in the photo below, you will see New Vision main menu. Before explaining the menu options, let’s learn the function keys first listed on the bottom part of the screen. • Press direction key Up/Down (↑/↓)on keyboard or remote control to select the options you wish to confirm or make changes.
  • Page 38 4-3-1. To Play Video Play Video: Select this option to play Video Use direction key Up/Down (↑/↓) on keyboard or remote control to select ‘Play Video’ on the main menu. Click [OK] on remote control (or the left button of the mouse, or press [Enter] on keyboard) to confirm.
  • Page 39 When playing the video, use the following remote control buttons to change settings: VOL+/-: Volume Up/Down; :Rewind ； : Forward; ： Play/Pause; :Replay; : Skip; : Stop. Media Player: use Windows Media Player to playback video. Video Libraries：playback video in Video Libraries of your system using user preset media player.
  • Page 40 drive in advance. Removable Device：Playback video from removable devices. Press Up/Down to select the desired removable device. Return： Press Left key “←” on remote control or keyboard) to return to previous page. Please make sure that the removable device is properly connected to Notice! the system before playing video.
  • Page 41 4-3-2. To Play Music Play Music: Select this option to play music. Use Up/Down (↑/↓) button on remote control or keyboard to select ‘Play Music’ on the main menu. Press [OK] on remote control (or click the left button of the mouse, or press [Enter] on keyboard or) to confirm.
  • Page 42 Music Libraries：play music from Video Libraries of your system using user preset media player DVD/CD：play music from DVD/VD. Insert DVD/CD into the optical disk drive in advance Removable Device：Playback music from removable devices. Press Up/Down to select the desired removable device. Return：...
  • Page 43 4-3-3. To Browse Pictures Browse Pictures: Select this option to browse pictures. Press Up/Down (↑/↓) on remote control or keyboard to select ‘Browse Pictures’ on the main menu. Click [OK] on remote control (or the left button of the mouse, or press [Enter] on keyboard or) to confirm.
  • Page 44 Picture Viewer: browse pictures stored in the computer by Microsoft Picture Viewer Media Player: use Windows Media Player to browse pictures. Picture Libraries：Browse pictures listed in Picture Libraries of Windows system. Removable Device：Browse pictures stored in desired removable device. Return： Press Left key “←” on remote control or keyboard) to return to previous page.
  • Page 45 4-3-4. KARAOKE KARAOKE: Enjoy the fun of Karaoke with interesting audio settings. Press Up/Down (↑/↓) key on remote control or keyboard to select ‘KARAOKE’ function. Press [OK] on remote control (or the left button of the mouse, or [Enter] on keyboard) to confirm.
  • Page 46 Video Libraries：Find and play music video in Videos Libraries. KARAOKE：Play music video/music in DVD/CD. Insert DVD/CD into the optical disk drive in advance. Removable Device：play music/music video in desired removable device. Return： Press Left key “←” on remote control or keyboard) to return to previous page. Delete: Press the DEL on keyboard to delete programs user added later to the menu (the default programs cannot be deleted).
  • Page 47 Mic Volume: increase or decrease the volume of MIC. Mic Echo: increase or decrease the echo effect of MIC. Mic Magic Voice: change MIC input voice into a desired magic voice. Change Key: change the key of the music upward or downward to meet singer’s desired key.
  • Page 48 4-3-5. Game Menu Game Menu: Select this option to play game listed on game menu. Press Up/Down (↑/↓) on remote control or keyboard or to select ‘Game Menu’ on the main menu. Press [OK] on remote control (or the left button of the mouse, or press [Enter] on keyboard) to confirm.
  • Page 49 The packaged New Vision software has no game program added to the list by default. User shall add game programs as desired to the list through ‘Add Program’ option on main menu. For more detail on how to add program please refer to 4-3-7.
  • Page 50 4-3-6. Other Program Other Program：User can add programs to this list Press Up/Down (↑/↓) on remote control or keyboard to select ‘Other Program’ on the main menu. Press [OK] on remote control (or the left button of the mouse, or press [Enter] on keyboard) to confirm.
  • Page 51 The default setting for New Vision has no program added to the list by default. User shall add other programs as desired to the list through ‘Add Program’ option on main menu. For more detail on how to add program please refer to 4-3-7.
  • Page 52 4-3-7. To Add Program Add Program: Add programs to New Version User Interface Press Up/Down (↑/↓) on remote control or keyboard to select ‘Add Program’ option. Press [OK] on remote control (or the left button of the mouse, or press [Enter] on keyboard) to confirm.
  • Page 53 The “Open” dialog window will automatically appear. Select the file you wish to add from the dialog window. Click ‘Open’ to confirm the operation. Only programs with .exe file extension can be added. You will see the following screen pop up for you to decide where the .exe program to be added to.
  • Page 54 Press Up/Down (↑/↓) on remote control or keyboard to select desired destination for the added program. For example, if you added ‘DVDMaker’ program to [Other Program], a newly added option ‘DVDMaker’ will appear in [Other Program] menu list. If you add it to ‘Game Menu’, it shall appear on the Game Menu list.
  • Page 55 4-3-8. To Exit Press Up/Down (↑/↓) on remote control or keyboard to select ‘Play Music’ on the main menu. Press [OK] on remote control (or the left button of the mouse, or press [Enter] on keyboard) to confirm. You can exit New Vision program now.

  • Page 56: Appendix

    Appendix General Notices European Union CE Marking and Compliance Notices Products intended for sale within the European Union are marked with the Conformity European (CE) Making, which indicates compliance with the applicable Directive and European standards and amendments identified. Shielded Cables Notice All connections to other computing devices must be made using shielded cables to maintain compliance with FCC regulations.

  • Page 57: Electronic Emissions Notices

    for use by consumers. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature. In some situation or environment, the use of Wireless LAN PCI Express Mini Card may be restricted by the proprietor of the building or responsible representatives of the organization.
  • Page 58 equipment. FCC Rules and Regulations-Part 15 This devices uses, generates and radiates radio frequency energy. The radio frequency energy produced by this device is well below the maximum exposure allowed by the Federal Communications Commission (FCC) This device complies with the limits for the Class B digital device pursuant to Part 15 subject to the following two conditions: This device may not cause harmful interference.
