Cradlepoint 3G Quick Start Manual

3G Internet Kit Contents:
Carrying Case
Instructions:
Connect the Power Adapter to the power adapter port on the
1
CradlePoint router. Plug the other end into a standard 110V AC
wall outlet or power strip.
2
Insert the Verizon USB Modem into the USB slot on the router.
3
• After a few seconds, the router's modem LED will turn orange and eventually illuminate solid green
• Wait 2 minutes as the router initializes and connects to the Internet
For Hard-Wired Connections
4
Connect the Network Cable to 1 of the 4 yellow LAN ports on the router. Connect the other end of the cable to the
Ethernet port on your computer. You can connect up to 4 computers in this manner.
(Note: Do not use the blue WAN port.)
For Wireless (WiFi) Connections
• Make sure the wireless switch on the router is turned to the
ON position.
• Using your computer's wireless network connection
program, find and connect to the network name listed on
the label atop the router. (MBR-###)
• Open a new web browser window. The CradlePoint splash
page should load automatically (see screenshot to the
right). Enter the password shown on the router's label.
• If successful, you should now be able to surf the web.
Power CradlePoint
Adapter Mobile
Broadband
Router
• Place the Magnet Plate on a flat surface
such as a countertop.
• Place the Signal-Booster Antenna
upright on the Magnet Plate.
• Gently insert the Antenna Adapter
Cable into the small antenna port on
the side of the Verizon USB Modem.
3G Quick Start Guide
Signal- Verizon Network
Booster Wireless Cable
Antenna USB
Modem
CradlePoint Router
Magnet Antenna
Plate for Adapter
Antenna Cable
