Sony KDL-46S2000 Service Manual

Wax2 chassis lcd digital color television
Hide thumbs Also See for KDL-46S2000:
Table of Contents

Advertisement

Quick Links

HISTORY INFORMATION FOR THE FOLLOWING MANUAL:

SERVICE MANUAL

MODEL NAME
KDL-46S2000
KDL-46S2000
ORIGINAL MANUAL ISSUE DATE: 4/2006
:UPDATED ITEM
REVISION DATE
4/2006
6/2006
7/2006
8/2006
9-883-702-04
REMOTE COMMANDER
RM-YD005
RM-YD005
SUBJECT
No revisions or updates are applicable at this time.
Update entire manual to include new serial number ranges
(7,000,001 ~ models produced in INZ)
(8,000,001 ~ models produced in SBC-T)
Updated AU Board Schematic to include waveforms. Replaced Pg. 24,
Corrected Part Numbers for G2 Board and BU Board in Exp. View section. Replaced Pg.55
Corrected Part Number for G2 Board and added new component in Electrical PL. Replaced Pg.75 & 76
Added QS Board and QT Board Part Numbers to Electrical PL. Updated AC Power Supply Cord
as a critical component. Replaced Pgs. 81 & 82.
WAX2
DESTINATION
CANADA
US
LCD DIGITAL COLOR TELEVISION
CHASSIS

Advertisement

Table of Contents
loading

Related Manuals for Sony KDL-46S2000

Summary of Contents for Sony KDL-46S2000

  • Page 1: Service Manual

    HISTORY INFORMATION FOR THE FOLLOWING MANUAL: WAX2 SERVICE MANUAL CHASSIS MODEL NAME REMOTE COMMANDER DESTINATION KDL-46S2000 RM-YD005 CANADA KDL-46S2000 RM-YD005 ORIGINAL MANUAL ISSUE DATE: 4/2006 :UPDATED ITEM REVISION DATE SUBJECT 4/2006 No revisions or updates are applicable at this time.
  • Page 2 Self Diagnosis Supported model WAX2 SERVICE MANUAL CHASSIS MODEL NAME REMOTE COMMANDER DESTINATION KDL-46S2000 RM-YD005 CANADA KDL-46S2000 RM-YD005 KDL-46S2000 RM-YD005 LCD DIGITAL COLOR TELEVISION 9-883-702-04...

  • Page 3: Table Of Contents

    KDL-46S2000 TABLE OF CONTENTS SECTION TITLE PAGE SECTION TITLE PAGE Specifi cations ................. 4 3-4. Schematics and Supporting Information ......24 AU Board Schematic Diagram (1 of 2) ......... 24 Warnings and Cautions ..............6 AU Board Schematic Diagram (2 of 2) ......... 25 Safety-Related Component Warning ..........

  • Page 4: Specifi Cations

    5510752, 5736897. BBE and BBE symbol are registered trademarks of BBE Sound, Inc. Macintosh is a trademark licensed to Apple Computer, Inc., registered in the U.S.A and other countries. “BRAVIA” and are trademarks of Sony Corporation. ® As an ENERGY STAR Partner, Sony Corporation has ®...
  • Page 5 KDL-46S2000 .'/6 6SHDNHUV  [  PP  'LPHQVLRQV : [ + [ ' ZLWK VWDQG  [  [  PP  [  [  'LPHQVLRQV : [ + [ ' ZLWKRXW VWDQG  [  [  PP...

  • Page 6: Warnings And Cautions

    Ne les remplacer que par des composants Sony dont le numero de piece est indique dans le present manuel ou dans des supplements publies par Sony. Les reglages de circuit dont l’importance est critique pour la securite du fonctionnement sont identifi...

  • Page 7: Safety-Related Component Warning

    KDL-46S2000 SAFETY-RELATED COMPONENT WARNING There are critical components used in LCD color TVs that are important for safety. These components are identifi ed with shading and mark on the schematic diagrams and the electrical parts list. It is essential that these critical parts be replaced only with the part number specifi...
  • Page 8 Due to the higher melting point of Lead Free Solder the soldering iron tip temperature needs to be set to 370 degrees centigrade. This requires soldering equipment capable of accurate temperature control coupled with a good heat recovery characteristics. For more information on the use of Lead Free Solder, please refer to http://www.sony-training.com KDL-46S2000...

  • Page 9: Safety Check-Out

    KDL-46S2000 SAFETY CHECK-OUT The AC leakage from any exposed metal part to earth ground and After correcting the original service problem, perform the following from all exposed metal parts to any exposed metal part having a safety checks before releasing the set to the customer: return to chassis, must not exceed 0.5 mA (500 microamperes).

  • Page 10: Self-Diagnostic Function

    KDL-46S2000 Self Diagnosis SELF-DIAGNOSTIC FUNCTION Supported model Control Buttons MENU POWER TV/VIDEO VOLUME CHANNEL PIC OFF/TIMER STANDBY POWER Description of LED Indictors LED Type Description * Light is green when the TV set is on POWER LED Red/Green LED * Functions as failure indicator...
  • Page 11 KDL-46S2000 LED Control 7,0(5 /(' 67$786 32:(5 /(' 67$1'%< /(' 5(0$5.6 3,&785( 2)) /(' 3RZHU RII XVLQJ WKH SRZHU VZLWFK RU UHPRWH FRQWURO 127( 6WDQGE\ 3RZHU 2II VWDWH GRHV QRW H[LVW LQ WKLV PRGHO KRZHYHU WKH PLFURFRPSXWHU GRHV HQWHU LQWR VOHHS PRGH...

  • Page 12: Section 1: Disassembly

    KDL-46S2000 SECTION 1: DISASSEMBLY 1-1. REAR COVER REMOVAL 2 Screws, +PSW M6X16 2 Screws, +BVTP 3X12 Screws +BVTP2 4X16 Lift to remove Rear Cover 1-2. VESA BRACKET ASSEMBLY REMOVAL 4 Screws, +PSW M5X16 KDL-46S2000...

  • Page 13: H1 Board Removal

    KDL-46S2000 1-3. H1 BOARD REMOVAL Disconnect CN101 2 Screws +BVTP2 4X12 Multi Button Assy H1 board Pull tabs on bracket to release board 1-4. G2 BOARD AND H46 BOARD REMOVAL 2 Screws +BVTP 3X12 TYPE2 IT-3 H46 board 4 Screws +PSW 3X14...

  • Page 14: Au Board Removal

    KDL-46S2000 1-5. AU BOARD REMOVAL 2 Screws +BVTP 3X12 TYPE2 IT-3 4 Screws +PSW 3SG 7 Connectors CN9502, CN9501, CN7502, CN7501, CN9001, CN7503, CN7000 AU board 1-6. QT BOARD REMOVAL 1 Screws +PSW 3SG 3 Screws +BVTP 3X12 TYPE2 IT-3...

  • Page 15: Qs Board And Bu Board Removal

    KDL-46S2000 1-7. QS BOARD AND BU BOARD REMOVAL 2 Screws +PSW 3SG 1 Screw +PSW M3X5 3 Screws +PSW 3SG 2 Screws (HEX) 2 Screws +PSW 3SG 2 Screws +BVST 3X8 3 Screws, +PSW M3X5 4 Connectors CN7306, CN7314 CN7317, CN7802...

  • Page 16: Lcd Panel Removal

    KDL-46S2000 1-9. LCD PANEL REMOVAL 4 Screws, +BVTP2 4X12 2 Screws, +PSW M5X8 4 Screws, +BVTP2 4X16 2 Screws, +PSW M5X8 LCD bracket assy Harness with connector (LVDS) Connecter assy 14P LCD panel KDL-46S2000...

  • Page 17: Section 2: Service Adjustments

    KDL-46S2000 SECTION 2: SERVICE ADJUSTMENTS 2-1. REMOTE ADJUSTMENT BUTTONS AND 2-2. ACCESSING SERVICE ADJUSTMENTS INDICATORS To adjust various set features, use the Remote Commander to put the set into service mode to display the service menus. The Remote Commander displays the service menu associated with the Digital or Analog format POWER depending on which format is on the TV when you enter service mode.

  • Page 18: Viewing The Digital Module Box (Q-Box)

    KDL-46S2000 2-2-2. VIEWING THE DIGITAL MODULE BOX 2-2-3. ACCESSING THE ANALOG SERVICE (Q-BOX) SERVICE ITEMS ADJUSTMENT MENUS Use the following instructions to display the Digital menu items you want 1. Turn the TV on and view an Analog channel. to adjust.

  • Page 19: Resetting The User Menu - Factory Reset

    KDL-46S2000 2-3. RESETTING THE USER MENU - FACTORY 2-4. AGING MODE RESET Aging mode is designed to remove image retention from the screen. The TEST RESET option resets all the customer adjustable data back to the NOTE: Once you enter into Aging Mode the Remote Commander no factory defaults.

  • Page 20: White Balance Adjustment

    KDL-46S2000 2-5. WHITE BALANCE ADJUSTMENT 9. Access the Service Menu by pressing the following buttons on the Remote Commander within a second: The White Balance only needs to be adjusted when you replace the BU DISPLAY Volume + Channel 5 POWER Board.

  • Page 21: Section 3: Diagrams

    KDL-46S2000 SECTION 3: DIAGRAMS 3-1. CIRCUIT BOARDS LOCATION H1U Board QS Board BU Board H46 Board QT Board G2 Board AU Board H3U Board 3-2. PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS INFORMATION All capacitors are in µF unless otherwise noted. pF : µµF 50WV or All voltages are in V.
  • Page 22 KDL-46S2000 REFERENCE INFORMATION Terminal name of semiconductors in silk screen printed circuit ( RESISTOR CAPACITOR : RN METAL FILM : TA TANTALUM Circuit Device Printed symbol Terminal name : RC SOLID : PS STYROL Collector Transistor : FPRD NONFLAMMABLE CARBON...

  • Page 23: Block Diagram

    KDL-46S2000 3-3. BLOCK DIAGRAM Audio Audio HDMI for PC for DVI Digital F/E UART TMDS UART Main Micro 8bit Multiplex BUS MB91305 Flash DDRSDRAM 16bit 1MByte 4M x 32bit I2C-C D-Comp[15:0] MPEG DEC. MPEG DEC. RF/Cable Chroma Dec/IP x240H x240H...

  • Page 24: Schematics And Supporting Information

    KDL-46S2000 3-4. SCHEMATICS AND SUPPORTING INFORMATION AU BOARD SCHEMATIC DIAGRAM (1 OF 2) AU BOARD WAVEFORMS R6001 C6001 2 . 2 k R6004 0 . 1 2 . 2 k Q6009 1/10W 1/10W RN-CP 2 . 0 2SC3052EF-T1-LEF RN-CP R9057 1608 0.5%...

  • Page 25: Au Board Schematic Diagram (2 Of 2)

    KDL-46S2000 AU BOARD SCHEMATIC DIAGRAM (2 OF 2) L7012 — L7008 10uH PS7001 FB9100 C7061 C7062 22uH AU_15V 1000p 1000p C7044 L9606 C7113 AU_15V_M R7061 R7062 L7011 C7024 1/10W 1608 1608 1/10W 8 . 2 k RN-CP RN-CP TO DETECT...
  • Page 26 KDL-46S2000 [A/V SWITCH, INPUTS, AUDIO] AU BOARD COMPONENT SIDE LOCATOR LIST CONDUCTOR SIDE DIODE CN9502 CN9501 R9501 C9503 JL9509 CN9502 R6051 D7001 JL9509 CN9502 Q6011 Q6012 CN9523 D7004 JL9504 JL9505 C6018 JL9505 R6052 R6033 CN9501 Q6005 CN9522 C6009 C6009 R6034...

  • Page 27: Bu Board Schematic Diagram (1 Of 8)

    KDL-46S2000 BU BOARD SCHEMATIC DIAGRAM (1 OF 8) R1021 << STBY3.3V >> D1_IN_Y Y1/G1 1/10W RN-CP R1022 FROM A PWB D1_IN_CB M24256-BWMN6T CB1/B1 1/10W RESET R1167 *IC1005 RN-CP X1009 R1206 1/16W EEPROM 32.768kHz 1/16W R1023 1/10W CHIP R1193 — D1_IN_CR...

  • Page 28: Bu Board Schematic Diagram (2 Of 8)

    KDL-46S2000 BU BOARD SCHEMATIC DIAGRAM (2 OF 8) Mount Mecha A5000 409815701 IC5000 R5027 — R5026 CHIP CHIP — DCLK_AEP DCLK_AEP DY1_AEP DPA_0 TA1M DY2_AEP *RB5000 DPA_1 TA1P DY3_AEP — DPA_2 DY0_AEP DPA_3 TB1M DY4_AEP TO HDMI DPA_4 TB1P *RB5001...

  • Page 29: Bu Board Schematic Diagram (3 Of 8)

    KDL-46S2000 BU BOARD SCHEMATIC DIAGRAM (3 OF 8) — D3.3V VDDH VDDH VDDMQ D3.3V D3.3V FL5201 R5223 C5220 C5239 TC7SH86FU(T5RSOYJF) R5211 1000p 1/16W IC5203 CHIP 1608 CHIP L5201 1608 1608 C5281 VDDH VDDM FET BUS SWITCH C5278 SN74CBTLV3245APWR Exclusive —...

  • Page 30: Bu Board Schematic Diagram (4 Of 8)

    KDL-46S2000 BU BOARD SCHEMATIC DIAGRAM (4 OF 8) — MD[19] C5502 VDDMQO C5504 MD[16] 1608 1608 MD[18] FL5501 0.01 0.01 MD[17] R5500 RB5504 L5501 C5506 — 6.3V MD[20] MD[21] MD[22] MD[23] RB5505 — MVREF VDDMQ MD[0] MD[1] MD[3] FL5500 —...

  • Page 31: Bu Board Schematic Diagram (5 Of 8)

    KDL-46S2000 BU BOARD SCHEMATIC DIAGRAM (5 OF 8) — T O T r i d e n t CN6000 R6001 1/10W PC-R FB60010uH RN-CP PC_R R6021 FB6002 0uH PC-G 1/10W RN-CP — PC-B FB6000 0uH PC_G R6022 1/10W RN-CP PC_B...

  • Page 32: Bu Board Schematic Diagram (6 Of 8)

    KDL-46S2000 BU BOARD SCHEMATIC DIAGRAM (6 OF 8) — 10uH L9005 PC_AU_9V D3.3V HDMI3.3V 1608 R9062 150k 1/10W C9033 C9034 FL9000 RN-CP C9007 — R9047 *R9016 2012 Q9004 CHIP 2SC3052EF-T1-LEF C9011 *R9011 C9008 R9063 470k 150k DVI_L 1/10W R9065 C9035...

  • Page 33: Bu Board Schematic Diagram (7 Of 8)

    KDL-46S2000 BU BOARD SCHEMATIC DIAGRAM (7 OF 8) D7000 MMDL914T1 SI8008TM-TL — IC7001 D3.3V-2 R7031 — 2 . 2 k DIMMER 3.15A 1/10W FB7011 R7053 3 . 3 k RN-CP D3.3V R7051 1/10W 0.5% RN-CP 1/10W LFBK1608HS601 REG17.5V 0.5% TO G...

  • Page 34: Bu Board Schematic Diagram (8 Of 8)

    KDL-46S2000 BU BOARD SCHEMATIC DIAGRAM (8 OF 8) DC_ALERT — STBY3.3V TUNER_CONTROL R1710 CHIP 1/16W 1/16W CHIP R7542 — SDA_TUNER D7508 MMDL914T1 D3.3V SCL_TUNER TU_ISC_SCL CHIP R1707 R1709 SDA_TUNER 1/16W FB1720 1/16W Q7504 R7543 CHIP RT1N141M-TP-1 TU_I2C_SDA R7546 DC_ALERT1 FB1721...
  • Page 35 KDL-46S2000 [MICRO, VIDEO PROCESSOR, SVP-PX(2/2) DDR & CPU I/F, POWER & GND VIDEO PROCESSOR, DPR_SDRAM 128MBIT, PC IN, HDMI, PANEL5V & FE5V, POWER SUPPLY] [MICRO, VIDEO PROCESSOR, SVP-PX(2/2) DDR & CPU I/F, POWER & GND VIDEO PROCESSOR, DPR_SDRAM 128MBIT, PC IN, HDMI, PANEL5V & FE5V, POWER SUPPLY]...

  • Page 36: G2 Board Schematic Diagram

    KDL-46S2000 G2 BOARD SCHEMATIC DIAGRAM R6208 0.47 C6216 D6205 UNREG 33V 1/4W FPRD 100V 10ERB20-TB3 R6202 D6204 C6203 220k 10ERB20-TB3 1/10W Mount Mecha A6004 234990031 Q6100,Q6101 CHIP D6200 GND_1 GND_1 — D10SC6M-4012 L6500 L6502 175uH 100uH C6517 450V C6116 D6201...
  • Page 37 KDL-46S2000 [POWER SUPPLY] [POWER SUPPLY] COMPONENT SIDE CONDUCTOR SIDE 1-869-027-12 1-869-027-12 JL6401 IC6200 D6201 D6207 R6443 JR6009 R6417 R6555 R6554 EY6205 EY6202 R6441 R6529 EY6205 D6207 EY6202 D6201 C6217 D6207 D6201 PH6400 EY6206 EY6203 EY6201 R6552 R6527 A-1169- EY6204 EY6204...

  • Page 38: H1U Board Schematic Diagram

    KDL-46S2000 H1U BOARD SCHEMATIC DIAGRAM NOTE: THE SILK SCREEN ON THE BOARD MAY DISPLAYS “H1” NOT “H1U” POWER H1 USER CONTROL — S106 — TO BU BOARD CN1007 HOME MENU INPUT SEL VOL+ VOL- WEGAGATE POWER INT KEY1 — CN101...
  • Page 39 KDL-46S2000 [USER CONTROL] COMPONENT SIDE R104 R101 R102 R103 R105 A-1172-589-A 1-869-855-12 C101 (172722812) [USER CONTROL] CONDUCTOR SIDE CN101 1-869-855-12 (172722812) D101 D102 C103 C102 KDL-46S2000...

  • Page 40: H3U Board Schematic Diagram

    KDL-46S2000 H3U BOARD SCHEMATIC DIAGRAM NOTE: THE SILK SCREEN ON THE BOARD MAY DISPLAYS “H3” NOT “H3U” STBY3.3V — REC/RESERVE STBY_LED ON_TIMER PWR/RESERVE PICTURE_OFF — BL_IN R305 R303 R304 1 . 5 K VD3.3V R302 R301 1/10W 1/10W 1/10W RN-CP...

  • Page 41: H46 Board Schematic Diagram

    KDL-46S2000 H46 BOARD SCHEMATIC DIAGRAM J202 — *R212 *R220 VD201 CHIP CHIP C215 VD202 VD203 1000p 1608 — R225 R208 C206 R215 R211 2 . 2 D204 1/10W 1/10W 1/10W 1/10W HP_DET MM3Z10VT1 RN-CP RN-CP RN-CP RN-CP 2012 — HP_OUT_AU_L...
  • Page 42 KDL-46S2000 [HEAD PHONE/V2] COMPONENT SIDE A-1192- 085-A !d EP-GW !c 1-870-784-11 C201 (1-727-620-11) CN201 C210 D204 D201 C211 R211 A-1151- J202 Video IN 2 [HEAD PHONE/V2] CONDUCTOR SIDE R214 (000000003) R217 0-000-000-03 C205 KDL-46S2000...

  • Page 43: Qs Board Schematic Diagram (1 Of 5)

    KDL-46S2000 QS BOARD SCHEMATIC DIAGRAM (1 OF 5) *CN7307 TO BU BOARD *CN7317 CN4702 TO QT BOARD CN7800 CN7802 — *R7354 JL7395 JL7396 JL7916 1/16W CHIP JL7917 JL7914 HS-IN JL7897 JL7898 JL7899 JL7900 JL7901 JL7902 JL7903 JL7904 JL7905 JL7906 JL7907...

  • Page 44: Qs Board Schematic Diagram (2 Of 5)

    KDL-46S2000 QS BOARD SCHEMATIC DIAGRAM (2 OF 5) D2.6V ASIC CORE POWER JL7316 D1.2V CORE_1.2V C7720 I/O POWER VDDC_1.8 V C7320 C7719 C7721 IO POWER MEMORY (1.8V/2.5V) — VDDC VDDR1 C7452 C7458 C7405 C7410 C7968 C7459 VDDC VDDR1 AF16 VDDC18_BOTM...

  • Page 45: Qs Board Schematic Diagram (3 Of 5)

    KDL-46S2000 QS BOARD SCHEMATIC DIAGRAM (3 OF 5) — AG25 DQA31 AJ24 DQA30 AH25 DQA29 D2.6V D2.6V AG24 — DQA28 AJ26 QSA3 AK26 /DQMA3 C7731 C7732 C7728 C7727 C7733 C7734 C7726 C7725 AJ25 6.3V 6.3V 6.3V 6.3V DQA27 1005 1005...

  • Page 46: Qs Board Schematic Diagram (4 Of 5)

    KDL-46S2000 QS BOARD SCHEMATIC DIAGRAM (4 OF 5) — TERA TVLDA TSTRTA TDATA0 TDATA1 TDATA2 — TDATA3 TDATA4 *R7394 TDATA5 TDATA6 /AUD_DEMPH TDATA7 TCLKA D3.3V R7855 1/16W CHIP *IC7300 /SPI_DET — 215H47AGA21HG DVIDATA0 DVIDATA1 DVIDATA2 DVIDATA3 DVIDATA4 DVIDATA5 — DVIDATA6...

  • Page 47: Qs Board Schematic Diagram (5 Of 5)

    KDL-46S2000 QS BOARD SCHEMATIC DIAGRAM (5 OF 5) — A_VIDEO_OUT 1005 VI_IN0 VID_HS_OUT VI_IN1 C7974 C7493 VI_IN2 CVBS_IN VI_IN3 R7320 *C7309 HSYNC_OUT VI_IN4 1/16W VI_IN3 CHIP VSYNC_OUT VI_IN5 AG10 *C7310 HSYNC2_OUT VI_IN6 — VI_IN5 VSYNC2_OUT VI_IN7 R7323 C7977 *CN7318 C7490...
  • Page 48 KDL-46S2000 [DDR/FLASH/NVM, DIG IF, AVOUT/FE] COMPONENT SIDE 1-868-963-11 IC7324 R7769 R7769 C8010 C8010 C8000 C8000 R7939 R7939 C7726 C7726 R7773 R7773 - „EP-GW - ƒ C7734 C7734 R7774 R7774 IC7320 IC7320 C7451 C7451 3.15A FB7910 FB7910 FB7909 FB7909 R7770 R7770...
  • Page 49 KDL-46S2000 [DDR/FLASH/NVM, DIG IF, AVOUT/FE] CONDUCTOR SIDE 1-868-963-11 IC7324 C7426 C7426 ET7301 ET7301 JL7306 JL7306 R7769 C8010 R7939 C8000 C7726 C7728 C7728 R7773 - „EP-GW - ƒ R7430 R7430 C7734 CN7802 CN7802 CN7306 CN7306 R7774 R7775 R7775 R7385 R7385 IC7320...

  • Page 50: Qt Board Schematic Diagram

    KDL-46S2000 QT BOARD SCHEMATIC DIAGRAM SET_CTRL R7858 TO QS BOARD 1/10W Q7802 RN-CP CN7802 2SC3052EF-T1-LEF *CN7800 A_AGC_MUTE R7841 — 1/10W *R7839 RN-CP C7832 R7909 C7896 1000p *C7856 1000p JL7832 C7825 C7830 H_I2C_SDA 1/10W 1608 RN-CP H_I2C_SDA 1608 *FB7875 2012 C7838...
  • Page 51 KDL-46S2000 [TUNER] COMPONENT SIDE C7820 CN7800 C7822 C7801 C7821 C7800 C7836 C7844 C7851 ET7801 R7815 FB7807 R7816 CN7804 R7889 R7888 FB7806 C7803 FB7800 FB7801 C7833 R7820 Q7800 R7872 C7837 L7800 FB7870 C7892 C7807 C7808 L7801 C7881 C7876 L7877 C7875 C7877...
  • Page 52 KDL-46S2000 [TUNER] CONDUCTOR SIDE JL7820 JL7819 JL7818 JL7805 JL7831 R7867 JL7826 R7866 IC7802 R7865 R7892 JL7802 R7891 R7860 C7841 R7864 IC7871 R7881 FB7872 R7882 JL7803 R7879 R7903 R7880 R7890 JL7846 JL7801 JL7843 Q7805 R7824 R7822 R7826 JL7810 C7854 R7836 R7904...

  • Page 53: Semiconductors

    KDL-46S2000 3-5. SEMICONDUCTORS – KDL-46S2000...

  • Page 54: Section 4: Exploded Views

    KDL-46S2000 SECTION 4: EXPLODED VIEWS REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES] REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES] Components not identifi ed by a part number or The component parts of an assembly are indicated by the Items marked with an asterisk are not stocked since...

  • Page 55: Chassis

    KDL-46S2000 REF. NO. PART NO. DESCRIPTION [ASSEMBLY INCLUDES] NOTE: The components identifi ed by shading and mark are critical for safety. NOTE: Les composants identifi es per un trame et une marque sont critiques pour Replace only with part number specifi ed.

  • Page 56: Speakers

    KDL-46S2000 NOTE: The components identifi ed by shading and mark are critical for safety. NOTE: Les composants identifi es per un trame et une marque sont critiques pour Replace only with part number specifi ed. la securite. Ne les remplacer que par une piece portant le numero specifi e.

  • Page 57: Lcd Panel

    KDL-46S2000 NOTE: The components identifi ed by shading and mark are critical for safety. NOTE: Les composants identifi es per un trame et une marque sont critiques pour Replace only with part number specifi ed. la securite. Ne les remplacer que par une piece portant le numero specifi e.

  • Page 58: Section 5: Electrical Parts List

    KDL-46S2000 SECTION 5: ELECTRICAL PARTS LIST Items marked with an asterisk are not stocked since they NOTE: The components identifi ed by shading RESISTORS are seldom required for routine service. Expect some delay mark are critical for safety. Replace only •...
  • Page 59 KDL-46S2000 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C7047 1-162-966-11 CERAMIC CHIP 0.0022µF 10% C7105 1-164-004-11 CERAMIC CHIP 0.1µF C7048 1-162-966-11 CERAMIC CHIP 0.0022µF 10% C7106 1-164-004-11 CERAMIC CHIP 0.1µF C7051 1-127-573-11 CERAMIC CHIP 1µF...
  • Page 60 KDL-46S2000 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C7618 1-126-396-11 ELECT CHIP 47µF DIODE C7619 1-100-597-91 CERAMIC CHIP 0.1µF D6001 8-719-058-24 DIODE RB501V-40TE-17 C9005 1-127-573-11 CERAMIC CHIP 1µF D7001 6-500-551-01 DIODE MM3Z11VT1 C9006 1-127-573-11 CERAMIC CHIP 1µF...
  • Page 61 KDL-46S2000 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les remplacer mark are critical for safety. Replace only que par une piece portant le numero specifi e.
  • Page 62 KDL-46S2000 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R2019 1-216-809-11 METAL CHIP 1/10W R7011 1-216-845-11 METAL CHIP 100K 1/10W R2020 1-216-809-11 METAL CHIP 1/10W R7012 1-216-864-11 SHORT CHIP R2023 1-216-821-11 METAL CHIP 1/10W R7014 1-216-841-11...
  • Page 63 KDL-46S2000 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R7113 1-218-887-11 METAL CHIP 0.50% 1/10W R7503 1-216-864-11 SHORT CHIP R7114 1-218-855-11 METAL CHIP 2.2K 0.50% 1/10W R7504 1-216-864-11 SHORT CHIP R7115 1-218-887-11 METAL CHIP 0.50% 1/10W...
  • Page 64 KDL-46S2000 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R7657 1-216-837-11 METAL CHIP 1/10W R9034 1-216-801-11 METAL CHIP 1/10W R7658 1-216-857-11 METAL CHIP 1/10W R9035 1-218-831-11 METAL CHIP 0.50% 1/10W R7659 1-216-833-11 METAL CHIP 1/10W R9036...
  • Page 65 KDL-46S2000 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R9152 1-216-864-11 SHORT CHIP C1010 1-100-566-91 CERAMIC CHIP 0.1µF R9153 1-216-864-11 SHORT CHIP C1011 1-126-206-11 ELECT CHIP 100µF 6.3V R9154 1-216-864-11 SHORT CHIP C1012 1-100-591-91 CERAMIC CHIP 1µF...
  • Page 66 KDL-46S2000 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C1074 1-100-566-91 CERAMIC CHIP 0.1µF C5023 1-162-970-11 CERAMIC CHIP 0.01µF C1075 1-162-966-11 CERAMIC CHIP 0.0022µF 10% C5024 1-162-970-11 CERAMIC CHIP 0.01µF C1076 1-165-908-11 CERAMIC CHIP 1µF C5025...
  • Page 67 KDL-46S2000 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES C5256 1-100-566-91 CERAMIC CHIP 0.1µF C7004 1-164-315-11 CERAMIC CHIP 470pF C5257 1-100-566-91 CERAMIC CHIP 0.1µF C7005 1-162-966-11 CERAMIC CHIP 0.0022µF 10% C5258 1-100-566-91 CERAMIC CHIP 0.1µF C7006...
  • Page 68 KDL-46S2000 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les remplacer mark are critical for safety. Replace only que par une piece portant le numero specifi e.
  • Page 69 KDL-46S2000 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les remplacer mark are critical for safety. Replace only que par une piece portant le numero specifi e.
  • Page 70 KDL-46S2000 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les remplacer mark are critical for safety. Replace only que par une piece portant le numero specifi e.
  • Page 71 KDL-46S2000 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R1070 1-216-864-11 SHORT CHIP R1169 1-216-864-11 SHORT CHIP R1073 1-218-990-81 SHORT CHIP R1170 1-400-794-21 FERRITE 0µH R1075 1-218-965-11 RES-CHIP 1/16W R1180 1-218-965-11 RES-CHIP 1/16W R1076 1-218-965-11 RES-CHIP...
  • Page 72 KDL-46S2000 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R1261 1-400-591-22 FERRITE 0µH R5031 1-218-941-81 RES-CHIP 1/16W R1262 1-400-591-22 FERRITE 0µH R5039 1-218-990-81 SHORT CHIP R1263 1-400-591-22 FERRITE 0µH R5040 1-218-990-81 SHORT CHIP R1264 1-400-591-22 FERRITE 0µH...
  • Page 73 KDL-46S2000 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R6001 1-216-805-11 METAL CHIP 1/10W R7012 1-216-835-11 METAL CHIP 1/10W R6004 1-216-853-11 METAL CHIP 470K 1/10W R7013 1-218-882-11 METAL CHIP 0.50% 1/10W R6005 1-216-853-11 METAL CHIP 470K...
  • Page 74 KDL-46S2000 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R9033 1-218-929-11 RES-CHIP 1/16W R7080 1-400-591-22 FERRITE 0µH R9034 1-218-929-11 RES-CHIP 1/16W R7081 1-400-591-22 FERRITE 0µH R9035 1-218-929-11 RES-CHIP 1/16W R7082 1-400-591-22 FERRITE 0µH R9036 1-218-929-11 RES-CHIP...
  • Page 75 KDL-46S2000 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES RB5202 1-234-372-11 RES, NETWORK 100 (1005X4) RB5203 1-234-372-11 RES, NETWORK 100 (1005X4) RB5500 1-234-370-21 RES, NETWORK 22 (1005X4) RB5501 1-234-370-21 RES, NETWORK 22 (1005X4) A-1169-591-F G2 BOARD, COMPLETE...
  • Page 76 KDL-46S2000 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les remplacer mark are critical for safety. Replace only que par une piece portant le numero specifi e.
  • Page 77 KDL-46S2000 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les remplacer mark are critical for safety. Replace only que par une piece portant le numero specifi e.
  • Page 78 KDL-46S2000 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R6106 1-208-854-11 METAL CHIP 0.50% 1/10W R6408 1-218-879-11 METAL CHIP 0.50% 1/10W R6107 1-208-854-11 METAL CHIP 0.50% 1/10W R6409 1-216-833-11 METAL CHIP 1/10W R6108 1-208-854-11 METAL CHIP 0.50% 1/10W...
  • Page 79 KDL-46S2000 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES R6536 1-218-830-11 METAL CHIP 0.50% 1/10W R6537 1-249-389-11 CARBON 1/4W R6538 1-249-405-11 CARBON 1/4W R6539 1-218-830-11 METAL CHIP 0.50% 1/10W R6540 1-249-389-11 CARBON 1/4W A-1172-589-D H1U BOARD, MOUNTED...
  • Page 80 KDL-46S2000 H3U H46 REF. NO. PART NO. DESCRIPTION VALUES REF. NO. PART NO. DESCRIPTION VALUES CONNECTOR IC301 6-600-502-01 GP1UE26RK0VF CN201 1-820-192-11 HEADER ASSEMBLY (PRINT PWB) IC302 6-600-447-01 TPS853(SONY) DIODE TRANSISTOR D201 8-719-423-03 DIODE MA8100 Q301 8-729-028-96 TRANSISTOR DTC114EUA-T106 D202 8-719-423-03...
  • Page 81 KDL-46S2000 NOTE: Les composants identifi es per un trame et une NOTE: The components identifi ed by shading marque sont critiques pour la securite. Ne les remplacer mark are critical for safety. Replace only que par une piece portant le numero specifi e.
  • Page 82 FFC CONNECTOR ASSY 40P (For S/N’s 8,000,001 ~) 2-676-911-01 SHEET, C.F.B. (B) (For S/N’s 8,000,001 ~) REMOTE COMMANDER 1-479-686-21 REMOTE COMMANDER (RM-YD005) Sony Corporation English Sony Technology Center 2006DJ74WEB-1 Technical Services Printed in USA 9-883-702-04 Service Promotion Department © 2006.4 KDL-46S2000...
  • Page 83 In an effort to reduce the size of this pdf Þ le the tiled schematics are not attached to this Service Manual. To receive a complete set of the tiled schematics for this manual please submit a request to the Service Promotion Department at Service_Promotion@am.sony.com.
