Introduction to the Product

Thank you for choosing our Indoor VoIP CPE, SWC-5x00W series. The VoIP CPE
allows you to share a superior data communication by Ethernet and WiFi network, and
to make Voice over Internet Protocol calls. The VoIP CPE comes with easy installation,
reliable network connection, advanced security & authentication and mores.
Please read this User Guide carefully to learn about SWC-5x00W series. It will help your
various communication needs properly served at home and offices.

Functional Features

Function
IEEE802.16e WiMAX Support
IEEE802.3u Ethernet Support
VoIP Support
LAN Port
Cable Auto Sense
NAT function
Firewall function

Front side of CPE

LED Indicator
PWR
LAN1 / LAN2
PHONE
RSSI
04
Features
Wave2 = DL : 30Mbps / UL : 6Mbps
10/100Mbps wired LAN connectable
1 x RJ-11 for Analog Telephone Service
2 x Ports 10/100Mbps Ethernet Switch built-in
Straight (Direct) or Cross Cable auto sensing
Supports up to 253 wired and wireless connections and
internet router*
Manages basic firewall and IP/Port/based access
Function
Power Supply status (On at Power ON)
ON when connected to PC, Flashing at communication
ON when connected to Telephone, Flashing at communication
Representation WiMAX received signal strength indication(RSSI), on
when the mode was selected router.
