User Manual - SpitJack P150 Whole Hog Rotisserie
06/21/10 (Note: for updates or to get another copy of this manual:
http://www.spitjack.com/Merchant2/merchant.mvc?Store_Code=SJ&Screen=MANUAL
Thank you for purchasing the SpitJack P150 Whole Hog Rotisserie. All of our products are designed
and constructed to give you years of reliable service if used properly and kept adequately maintained.
Please read over the material below before assembling or using the product. There are some
notes, tips
important
and
effectively.
1. List of Parts
2. Assembly and usage
3. Operation
4. Prepping
5. Rigging
6. The pit
7. Maintenance
8. Safety precautions
9. Hardware and motor specs
10. Limited warranty
11. Rigging a hog (illustrated)
List of parts
The P150 is packed in 3 separate boxes.
all the parts listed below are accounted for.
Box 1: Spit parts and hardware
1. Hardware package
a. Spit assembly hardware (6 bolts and 6 wing nuts)
b. 2 hex wrenches
2. Spit plate (1)
3A. Spit - section A (with bearing ring attached)
3B. Spit - section B (with connector pipe and bearing ring attached)
3C. 2 bearing rings (attached to the spit) with set screws
Box 2: Tripod stand parts and hardware
4. Tripod stands (2) and base pins (2)
5. Spit support B
6. Spit support A
7. Spit support pipes
Box 3: Motor and motor mount with hardware
8. Motor (with housing and power cord attached), motor mount (attached to motor)
a. Two spit support screws
b. Spit coupler parts with setscrew (attached to drive shaft)
For hardware specifications,
safety cautions
mixed in that will help you in using the P150 safely and
Please check that you have received all 3 boxes and that
see
below.
1
Advertisement
Related Manuals for SpitJack P150
Summary of Contents for SpitJack P150
- Page 1 06/21/10 (Note: for updates or to get another copy of this manual: http://www.spitjack.com/Merchant2/merchant.mvc?Store_Code=SJ&Screen=MANUAL Thank you for purchasing the SpitJack P150 Whole Hog Rotisserie. All of our products are designed and constructed to give you years of reliable service if used properly and kept adequately maintained.
-
Page 2: Rotisserie Assembly
There are many accessories that you can order separately for your P150. If you have ordered them with the P150, they may be included in one of the boxes (but not pictured below) or come in a separate package. Rotisserie Assembly The P150 requires some minor assembly before its first use. - Page 3 Note: the spit plate has changed (shorter now) since this picture was taken and there are only 4 bolts needed for this assembly. 3. Push each of the 4 stainless bolts through the spit plate and the spit and fasten each securely with a stainless wing nut using the larger Allen wrench.
- Page 4 Tripods and spit supports assembly procedure: 1. Place the spit support pipe through the tripod bases. Adjust the height of each pipe and set it with the pins provided by putting it all the way through the holes in the tripod base and the Note: make sure both pipes are set at the same height.
- Page 5 4. When you need to rotate the spit, remove the setscrew, set a new position using the handle to turn the spit assembly and reset the screw. Completed P150 assembly (with Manual Operation Wheel)
- Page 6 Operating the Rotisserie Once the rotisserie has been fully assembled, all the screws and bolts are checked for tightness and proper adjustment, the loaded spit has been attached as instructed above, the drip pan is in place, the properly rated and fire pit has been constructed and the fire is underway, simply attach a (connected) sized extension cord to the power cord of the motor and the motor will automatically start.
-
Page 7: Maintenance
Using these guidelines, we have cooked a hog in 40 degree (F) ambient temperature on a windy day to 195 degrees in normal cooking time. Maintenance Care of the SpitJack P150 is simple and inexpensive but should be done regularly to insure maximizing the product life. Cleaning Before the first use and after extended storage: 1. - Page 8 BBQ grills). Motor The P150 motor is well-built, rugged component that will last years if properly used and maintained. 1. Try not to expose it to too much dust or dirt while in use and keep it as dry as possible.
-
Page 9: Safety Precautions
Fire, heat and burn hazard: Since you will need a large heat source to use the P150, special precautions must be taken to prevent harm to yourself, other people, the environment, property, and the equipment. 1. Make sure you have properly prepared your “pit” area where the fuel will be burned. There should be not be any easily combustible material either directly under the burning area or in nearby proximity. -
Page 10: Hardware Specifications
Hardware specifications: If you need to order hardware for your P150 either call us or ask for the following at your local parts dealer or online (key: diameter, length (mm), thread pitch): 1. Bearing ring setscrews (4) – M4 10 70 (stainless) 2. - Page 11 (365 days) from the date of receipt. Some jurisdictions do not allow such limitations on duration of an implied warranty, so the above limitation may not apply to you. . This warranty is valid only for Product (s) purchased directly from SpitJack or from one of its authorized dealers.
