- Page 1 DVD Module 04 E 2.00...
-
Page 3: Table Of Contents
DVD-Modul MK4 Re:source Contents DVD Module Perfect picture – DVS Module Installation SCART connection panel SCART assignment RCA plug connection panel RCA connections Video switch principle M300 connection options M301 connection options DVD-CD generally DVD menu DVD/CD operation Repeat function 13-15 Shuffle function DVD Setup menu... -
Page 4: Dvd Module
DVD module. device, e.g. the Re:ception 42 HD Plasma TV from Revox, with HDMI The DVD module from Revox is the interface. The DVS module is installed audio-visual interface between DVD parallel to the DVD module in Slot 4. -
Page 5: Installation
DVD-Modul MK4 Re:source Installation To be on the safe side, you should The DVD plug-in card has the most discharge any static from yourself by modern technology on it and should be touching an earthed metal object such handled with care. as a radiator. -
Page 6: Scart Connection Panel
SCART connector. If these devices don’t have a SCART input, you can obtain the corresponding cable or adapter directly from Revox or from you nearest specialist dealer. As well as the video and audio signals,... -
Page 7: Scart Assignment
DVD-Modul MK4 Re:source SCART –Assignment M51* Digital output The digital audio signal can be taken from the optical digital output DIGITAL OUT using a fibre optic cable. This connection is often referred as TOS- Link. This signal can be used for an Audio output (right) external decoder... -
Page 8: Rca Plug Connection Panel
DVD-Modul MK4 Re:source RCA plug connection panel RCA connections A RCA plug version is also available, The following video output signals can which outputs the audio and video be handled through the RCA sockets: components individually through RCA sockets. : CVBS-Video (FBAS) : S-Video (S-VHS) Y/Cb/Cr : Component signal As well as video signals, audio signals... -
Page 9: Video Switch Principle
DVD-Modul MK4 Re:source Video switch principle A separately available video switch Connecting a video switch adds an can be connected to both the SCART additional 6 video sources (Video 1...6) version and the RCA plug version of to the M51 Source menu. the DVD module. -
Page 10: M300 Connection Options
DVD-Modul MK4 Re:source M300 / DVD-SCART connection options... -
Page 11: M301 Connection Options
DVD-Modul MK4 Re:source M301 / DVD-RCA connection options... -
Page 12: Dvd-Cd Generally
DVD-Modul MK4 Re:source General Inserting the disc The CD drawer is opened by pressing The actual control of the different Disc button on the front of the M51. discs is done through the DVD menu. Insert the CD/DVD, with the reflective You can find details of the formats that side down taking care to center it in Technical Data... -
Page 13: Dvd Menu
DVD-Modul MK4 Re:source DVD Menu The Track number and the current If you have already opened the DVD playing time are displayed. The top line menu, the disc will start to play as also shows whether a CD or a DVD is soon as the CD drawer is closed. -
Page 14: Dvd/Cd Operation
DVD-Modul MK4 Re:source DVD/CD operation Change track Using the two "previous" and "next" Several commands are available to Track softkeys, you can jump to the give you quick and easy operation of start of the previous or next Track on a your CDs and/or DVDs. - Page 15 DVD-Modul MK4 Re:source Search Repeat If you want to search for a particular The Repeat function enables you to position within a Track or Chapter, you repeat and individual Track or the can use the Search function. This whole CD. function has two search speeds.
-
Page 16: Repeat Function
DVD-Modul MK4 Re:source Repeat CD The various CD Repeat functions can If you press Repeat again, the whole be selected by repeated pressing of CD will be repeated once. Then the CD the Repeat softkey. This takes you stops. This is shown in the display with through a loop which is ended when the text: Repeat Disc the Repeat function is deactivated. - Page 17 DVD-Modul MK4 Re:source Repeat DVD As with the CD, the three DVD Repeat If you want to repeat a whole DVD , functions can be selected by repeated press Repeat once more. This is pressing of the Repeat softkey. This shown in the display with the text takes you through a loop which is ended when the Repeat function is...
-
Page 18: Shuffle Function
DVD-Modul MK4 Re:source Shuffle Stop The Stop softkey stops all actions in With the Shuffle function, you can play the DVD menu and stops the disc your discs in a random order. The currently being played. Shuffle command is on the second page of the CD/DVD menu. -
Page 19: Dvd Setup Menu
DVD player Setup menu where basic and global settings can be made. The Setup menu is precon-figured by Revox and should only be changed if really necessary. Select the DVD source at the M51, switch the television on and press the OSD or Setup button on your remote control. - Page 20 DVD-Modul MK4 Re:source General Setup Page Disc Lock Using this option, you can block individual discs, even if the disc does not have any age level limits. Lock The Lock option activates the disc block. You have to enter the 6-digit password before starting the disc the next time.
- Page 21 DVD-Modul MK4 Re:source Program Using the TV screen, you can group Programme start certain CD/DVD titles within one disc The programming that you define is together. This type of programming is stored individually on each disc. The only visible if the TV or projector is M51 can store up to 100 CD/ DVDs.
- Page 22 DVD Module MK4 Re:source OSD language Sleep The OSD menus appear in the language Using the Sleep timer, the M51 can be you selected. This has no influence on the switched off automatically after a preset language that a DVD is played in. The time of 15, 30, 45 or 60 minutes, when a preferred language to be used when CD/ DVD is operating.
- Page 23 The Audio setup menu can be selected but the settings do not have any effect on TV DISPLAY the audio part of the M51. Revox generates all analogue and digital audio signals on a separate SDTV board that is ...
- Page 24 DVD Module MK4 Re:source TV Display Through this menu, you can adjust the M51 DVD player’s screen format to that of your television. The format you select must be available on the disc. Otherwise this setting will not have any effect on the play format.
- Page 25 DVD Module MK4 Re:source Preference Page Audio Through this menu item, you can define your preferred language choice when playing a DVD. If this language is not available on the DVD, the default language from the DVD will be used instead.
- Page 26 DVD Module MK4 Re:source Parental This setting allows you to define which Some DVDs have a child lock, which DVDs may be played back. If you allows you to restrict the playback in select a level from 1 to 8, discs and full or in part or to playback with scenes with the same or a lower level alternate scenes.
- Page 27 DVD Module MK4 Re:source PBC Password PBC is the Play Back Control, which You can define your own personal starts the interactive menus on the release code to replace the standard DVD that are prescribed by the 000 000 password using this menu manufacturer.
-
Page 28: Dvd Setup Menu
DVD Module MK4 Re:source Setup-DVD menu Selecting the video format The M51 DVD module can generate One of the following displays appears: different video formats for picture reproduction through different media. Through the Video Mode function, the DVD module makes four different formats available at the SCART and/or RCA plug connectors. -
Page 29: Rgb+Cvbs Video Mode
Blue (B). These three colour signals (yellow RCA socket), you can use this can either be transmitted using the video signal with the corresponding Revox-SCART cable or a special SCART adapter. SCART-RGB cable. RCA plug version... -
Page 30: Y/C/Cr/Cb Video Mode
SCART version SCART version These two signals are transmitted Many plasma televisions and monitors through the Revox- SCART cable, a use this signal. These three picture special SCART-S-VHS cable or a signals can either by transmitted using Hosiden SCART- connector. -
Page 31: Dvd Lock
DVD Module MK4 Re:source DVD Lock You can deactivate the DVD/CD control in an additional room with the DVD Lock function key. This ensures that no-one in another room interrupt reproduction, while you are watching a film in the main room. If, on the other hand, a CD is inserted in the M51, the function has no effect on the control. -
Page 32: Technical Data
DVD Module MK4 Re:source Technical data Usable formats DVD Video (Single and Dual-Layer) DVD+R, DVD+RW Video CD (VCD) Super Video CD (S-VCD) Audio CD ( incl. CD-R,CD-RW) MP3-CD ( incl. CD-R,CD-RW und DVD+RW) JPG-CD ( incl. CD-R,CD-RW und DVD+RW) TV Standards: Multi-standard PAL (Europe) 50Hz/625 lines... -
Page 33: Notes
DVD Module MK4 Re:source Notes Guarantee Manufactured under license from The guarantee period is 24 months Dolby Laboratories. “Dolby“, “Pro from the date of purchase. Logic” and the double D-Symbol are trade-marks of Dolby Laboratories. Your dealer should be your first contact if you need service. - Page 34 DVD Module MK4 Re:source DVD-Module MK4 Operating instructions / Part no.: 10.30.3078...
