Names of all the parts

Remote control
sensor
Power lamp
ON: Lit (Green)
OFF: Unlit
LT-32DS6BJ/SJ, LT-26DS6BJ/SJ
Press to
remove.
If the cover cannot be closed due to the cables being in the way
Do not force the cover to close (leave it open).
Connecting terminals on the back of the TV
Change the direction of TV
6
Illumination lamp
Illumination lamp lights
while the TV is on.
"ILLUMINATION" (P.33)
Remove the terminal covers
Press to
remove.
Connecting External devices (P. 10)
Switch between
TV/AV
TV / AV devices
MENU
/OK
Display on-screen
menu / set
Change channel / page
P
Volume
Power On/Off
To headphones
LT-37DS6BJ
Press to
remove.
Check accessories
(P. 10)
Press to
remove.
Remote control
(RM-C1813H)
AA/R6 Batteries
For confi rming
the TV works
